Title: Safety for Frontline Supervisors

Safety for Frontline Supervisors
  • August 9, 2011

Table of Contents
  • OSHA
  • Required Written and Training Programs
  • Personal Protective Equipment
  • Walking/Working Surfaces
  • Machine Guarding
  • Lockout/Tagout
  • Electrical
  • Hazard Communication
  • Emergency Egress
  • Powered Industrial Trucks
  • Industrial Hygiene
  • Ergonomics

  • Occupational Safety and Health Act of 1970.
  • To assure so far as possible every working man
    and woman in the nation safe and healthful
    working conditions
  • Everyone must comply with OSHA Standards.
  • OSHA can be enforced by either the Federal or
    State Government depending on the state
    Arkansas is a Federal State for OSHA.
  • The Federal OSHA website is
  • OSHA Inspection Priorities are as follows
  • Imminent danger
  • Catastrophes and fatal accidents
  • Employee complaints
  • High hazard industries

Reason for OSHA
  • Annual Statistics
  • About 6,000 deaths from workplace injuries
  • An estimated 50,000 deaths from illnesses cause
    by workplace exposures
  • 6 million non-fatal workplace injuries
  • Injuries alone cost U.S. businesses more than
    125 billion

Impact of OSHA Since 1970
  • Cut the work-related fatality rate in half
  • Reduced overall injury and illness rates in
    industries where OSHA concentrated its attention
  • Virtually eliminated brown lung disease in the
    textile industry, and
  • Reduced trenching and excavation fatalities by 35

Functions of OSHA
  • Encourages employers and employees to reduce
    workplace hazards and implement new or improve
    existing safety and health programs
  • Develops and enforces mandatory job safety and
    health standards
  • Maintains a reporting and recordkeeping system to
    monitor job-related injuries and illnesses
  • Provides assistance, training and other support
    programs to help employers and workers

OSHA Standards
  • OSHA is responsible for writing and enforcing
    standards that employers must follow
  • Where OSHA has not issued specific standards,
    employers are responsible for following the OSH
    Act's General Duty Clause
  • States with OSHA-approved programs must set
    standards at least as effective as federal

OSHA Workers Page
OSHA Inspection Process
  • CSHO displays official credentials
  • Opening conference
  • Walk around inspection
  • Closing conference

OSHA Emergency Hot-Line 1-800-321-OSHA
  • Hot-line for reporting workplace safety or health
  • Provides a 24-hour point of contact to report
    imminent dangers on the job

Sources of Assistance for Small Businesses
  • OSHA Office of Small Business Assistance
  • http//
  • OSHA Compliance Assistance Quick Start
  • http//
  • OSHA Small Business Handbook
  • http//
  • Safety Health Achievement Recognition Program
  • Arkansas Department of Labor OSHA Consultation
  • http//
  • Workers Compensation Carrier

Required Written and Training Programs
  • All Workplaces
  • General Safety
  • Hazard Abatement
  • Hazard Communication
  • Emergency Action Plans
  • Fire Protection
  • Recordkeeping
  • Hospital/Clinical
  • Bloodborne Pathogens
  • Industrial Environments
  • Powered Industrial Trucks
  • Cranes
  • Hot Works
  • Lockout/Tagout
  • Electrical
  • Confined Space
  • Bloodborne Pathogens
  • Personal Protective Equipment

Personal Protective Equipment (PPE)
  • PPE is the last line of defense
  • Engineering controls are preferable
  • Initial design specifications
  • Substitute less harmful material
  • Change process
  • Enclose process
  • Isolate process
  • Ventilation
  • Work practice controls are also preferable
  • Use of wet methods to suppress dust
  • Personal hygiene
  • Housekeeping and maintenance
  • Job rotation of workers

Personal Protective Equipment (PPE)
  • Establish a PPE Program by
  • Sets out procedures for selecting, providing and
    using PPE as part of an employers routine
  • Assess the workplace to determine if hazards are
  • Once the proper PPE has been selected, the
    employer must provide training
  • Training must include
  • When PPE is necessary
  • What type of PPE is necessary
  • How to properly put on, take off, adjust, and
  • Limitations of the PPE
  • Proper care, maintenance, useful life and

Walking/Working Surfaces
  • Housekeeping
  • Workroom floors must be maintained as clean and
    dry as possible
  • Workplaces must be kept clean, orderly, and
  • Aisles
  • Keep clear and move obstructions that could
    create a hazard
  • Mark permanent aisles and passageways
  • Aisles must be sufficiently wide where mechanical
    handling equipment is used

Walking/Working Surfaces
  • Open-sided floors or platforms 4 feet or more
    above adjacent floor or ground level must be
    guarded by a standard railing on all open sides
  • A toeboard is required when, beneath the open
  • persons can pass,
  • there is moving machinery, or
  • there is equipment with which falling materials
    could create a hazard
  • Standard railing. Consists of top rail, mid
    rail, and posts. Height from the upper surface
    of top rail to floor level is 42 inches. Mid
    rail height is 21 inches.
  • Standard toeboard. 4 inches high, with not more
    than ¼-inch clearance above the floor.

Machine Guarding
  • Any machine part, function, or process which may
    cause injury must be safeguarded
  • Point of operation
  • All parts of the machine which move, such as
  • flywheels, pulleys, belts, couplings, chains,
    cranks, gears, etc.
  • feed mechanisms and auxiliary parts of the
  • In-running nip points
  • Point-of-Operation is defined as where the work
    is performed on the material, such as cutting,
    shaping, boring, or forming of stock

Machine Guarding
  • Requirements for Machine Guards
  • Prevent contact - prevent workers body or
    clothing from contacting hazardous moving parts
  • Secure - firmly secured to machine and not easily
  • Protect from falling objects - ensure that no
    objects can fall into moving parts
  • Create no new hazards - must not have shear
    points, jagged edges or unfinished surfaces
  • Create no interference - must not prevent worker
    from performing the job quickly and comfortably
  • Allow safe lubrication - if possible, be able to
    lubricate the machine without removing the

Types of Machine Guards
  • Guards
  • fixed
  • interlocked
  • adjustable
  • self-adjusting
  • Devices
  • presence sensing
  • pullback
  • restraint
  • safety controls (tripwire cable, two-hand
    control, etc.)
  • gates
  • Location/distance
  • Feeding and ejection methods
  • automatic and/or semi-automatic feed and ejection
  • robots
  • Miscellaneous aids
  • awareness barriers
  • protective shields
  • hand-feeding tools

Machine Guarding
  • Holding Tools
  • Used to place and remove stock in the danger area
  • Not to be used instead of other machine
    safeguards, but as a supplement

  • Lockout/Tagout is a technique used to prevent the
    release of hazardous energy, or to prevent the
    hazardous energy from escaping while machinery or
    equipment is being maintained
  • Five main causes of injuries with Lockout/Tagout
  • Failure to stop equipment
  • Failure to disconnect from power source
  • Failure to dissipate (bleed, neutralize) residual
  • Accidental restarting of equipment
  • Failure to clear work areas before restarting

  • Sources of Energy to Control
  • Electrical
  • Generated
  • Static
  • Mechanical
  • Transitional
  • Rotational
  • Thermal
  • Machines or Equipment
  • Chemical Reactions
  • Potential
  • Pressure
  • Hydraulic
  • Pneumatic
  • Vacuum
  • Springs
  • Gravity
  • Energy Control Devices
  • Plug Locks
  • Ball Valve Lockout
  • Gate Valve Lockout
  • Group Lockout Hasp
  • Electrical
  • Hydraulic, pneumatic, and other pressurized

  • There are four main types of electrical injuries
  • Electrocution (death due to electrical shock)
  • Electrical shock
  • Burns
  • Falls
  • Severity of the shock depends on
  • Path of current through the body
  • Amount of current flowing through the body
  • Length of time the body is in the circuit

Electrical Hazards
  • Hazards
  • Inadequate wiring
  • Exposed electrical parts
  • Wires with bad insulation
  • Ungrounded electrical systems and tools
  • Overloaded circuits
  • Damaged power tools and equipment
  • Using the wrong PPE and tools
  • Overhead powerlines
  • All hazards are made worse in wet conditions

Countermeasures to Electrical Hazards
  • Proper grounding
  • Using GFCIs
  • Using fuses and circuit breakers
  • Guarding live parts
  • Proper use of flexible cords
  • Training

Hazard Communication
  • Written Program Requirements
  • Describes container labeling, MSDSs, and employee
    training for each workplace
  • List of the hazardous chemicals
  • Make information regarding hazards and protective
    measures available to other employers onsite
  • Chemical Labels Must Include
  • Identity of the chemical
  • Appropriate hazard warnings
  • Name and address of the responsible party

Emergency Egress
  • A continuous and unobstructed way of exit travel
    from any point in a building or structure to a
    public way (a street, yard, court or other open
    space leading to the street)
  • Three parts to an escape route
  • the way of exit access
  • the exit and
  • the way of exit discharge.

Powered Industrial Trucks
  • Written certification program
  • Classroom training
  • Hands-on training
  • Written evaluation
  • Operations evaluation
  • Inspection of equipment
  • Refueling/recharging
  • Proper storage
  • Ventilation
  • PPE

Industrial Hygiene
  • Ventilation
  • Direct
  • General
  • Air sampling
  • Dusts
  • Fumes
  • Vapors
  • Gases

  • Workstation Design
  • Neutral position
  • Lighting
  • Adjustable heights
  • Seats versus standing
  • Anti-fatigue mats
  • Tools/Equipment
  • In-line tools
  • Padding
  • Pallet lift tables
  • Job rotation
  • Stretching exercises
