Title: Load Cell


1
fgvbdf
Load Cell
  • WEL COME TO

http//www.epochloadcell.com/load_cells.html
2
Load Cell
  • Load cells are transducer which transforms force
    into a considerable electrical outcome signals.
  • Types of load cells
  • S Beam Load Cell
  • Cantilever Load Cell
  • Double Ended Beam Load Cell
  • Compression Load Cell
  • Tension Load Cell
  • Shear Web Load Cell
  • Pedal Force Load Cell
  • Web Tension Load Cell

http//www.epochloadcell.com/load_cells.html
3
S Beam Load Cell
  • S beam Load Cell is versatile, compact and
    Rugged.
  • It is used for tension measurement, weighing,
    industrial automation, and research application.

http//www.epochloadcell.com/load_cells.html
4
Cantilever Load Cell
  • Cantilever load cell is a strain gauge based low
    profile bending beam load cell and is for
    precision
  • single point load applications.
  • These load cells can be used in Tank Weighing,
    Hopper Weighing, Truck weighing etc.

http//www.epochloadcell.com/load_cells.html
5
Double Ended Beam Load Cell
  • The Double Ended Shear Beam load cell, is readily
    capable for tough surroundings associated with
    Vehicle machines.

http//www.epochloadcell.com/load_cells.html
6
Compression Load Cell
  • Compression Load Cell is a high perfection force
    indicator for strict load statistic.
  • These load cells are used in the application
    of hopper weighing, tank weighing, tension
    measurements, crane weighing, platform scales,
    weigh bridges, silo weighing.

http//www.epochloadcell.com/load_cells.html
7
Tension Load Cell
  • Tension Load Cell is a high precision force
    sensor for load measurement.
  • These load cells is used for Tower Testing, Rope
    Testing etc.

http//www.epochloadcell.com/load_cells.html
8
Shear Web Load Cell
  • Shear Web Load Cell is universal type.
  • It is used for measurement, weighing,
    industrial automation, Universal Testing
    Machines.

http//www.epochloadcell.com/load_cells.html
9
Pedal Force Load Cell
  • pedal force load cell, which is applied during a
    roller brake or plate brake test, can be measured
    with the pedal force meter.
  • pedal force is visible on the LCD display.

http//www.epochloadcell.com/load_cells.html
10
Web Tension Load Cell
  • Web Tension Load Cell measures and monitors
    precise tension on web process or wire machinery
    that utilizes either rotating shafts or dead
    shaft rollers.

http//www.epochloadcell.com/load_cells.html
11
Contact Us
  • Address
  • MIG 132, Ist Floor, 2nd Stage, 80 Feet Road,
  • K.H.B. Colony, Bangalore - 560079,
  • Karnataka, India.
  • Phone
  • 91-80-2348 1364
  • 91-80-2328 3728
  • 91-80-6576 1259
  • 91-80- 2559 8268
  • Mobile
  • 91 93412 30785
  • Email
  • epochic_at_dataone.in
  • Website
  • http//www.epochloadcell.com

12
For More Details Login to Our Website
  • http//www.epochloadcell.com/
