Grammatical Machine Translation

1
Grammatical Machine Translation

• Stefan Riezler John Maxwell

2
Overview

• Introduction
• Extracting F-Structure Snippets
• Parsing-Transfer-Generation
• Statistical Models and Training
• Experimental Evaluation
• Discussion

3
Section 1Introduction
4
Introduction

• Recent approaches to SMT use
• Phrase-based SMT
• Syntactic knowledge
• Phrase-base SMT is great for
• Local ordering
• Short idiomatic expressions
• But not so good for
• Learning LDDs
• Generalising to unseen phrases that share
  non-overt linguistic info

5
Statistical Parsers

• Statistical Parsers can provide information to
• Resolve LDDs
• Generalise to unseen phrases that share non-overt
  linguistic info
• Examples
• Xia McCord 2004
• Collins et al. 2005
• Lin 2004
• Ding Palmer 2005
• Quirk et al. 2005

6
Grammar-based Generation

• Could grammar-based generation be useful for MT?
• Quirk et al. 2005
• Simple statistical model outperforms grammar-base
  generator of Menezes Richardson 2001 on BLEU
  score
• Charniak et al. 2003
• Parsing-based language modelling can improve
  grammaticality of translations while not
  improving BLEU score
• Perhaps BLEU score is not sufficient way to test
  for grammaticality.
• Further investigation needed

7
Grammatical Machine Translation

• Aim
• Investigate incorporating a grammar-based
  generator into a dependency-based SMT system
• The authors present
• A dependency-based SMT model
• Statistical components that are modelled on
  phrase-based system of Koehn et al. 2003
• Also used
• Component weights adjusted using MER training
  (Och 2003)
• Grammar-based generator
• N-gram and distortion models

8
Section 2Extracting F-Structure Snippets
9
Extracting F-Structure Snippets

• SL and TL sentences of bilingual corpus parsed
  using
• LFG grammars
• For each English and German f-structure pair
• The two f-structures that most preserve
  dependencies are selected
• Many-to-many word alignments used to create
  many-to-many correspondences between the
  substructures
• Correspondences are the basis for deciding what
  goes into the basic transfer rule

10
Extracting F-Structure SnippetsExample

• Dafur bin ich zutiefst dankbar ? I have a
  deep appreciation for that
• ltfor thatgt ltamgt ltIgt ltdeepestgt ltthankfulgt
• Many-to-many bidirectional word alignment

11
Transfer Rule Extraction Example

• From the aligned words we get the following
  substructure correspondences

12
Transfer Rule Extraction Example

• From the correspondences two kinds of transfer
  rules are extracted
• Primitive Transfer Rules
• Complex Transfer Rules

• Transfer Contiguity Constraint
• Source and target f-structures are each
  connected.
• F-structures in the transfer source can only be
  aligned with f-structures in the transfer target
  and vice versa.

13
Transfer Rule Extraction Example

• Primitive Rule 1
• pred( X1, sein) pred( X1, have)
• subj( X1, X2) ? subj( X1, X2)
• xcomp( X1, X3) obj( X1, X3)

14
Transfer Rule Extraction Example

• Primitive Rule 2
• pred( X1, ich) ? pred( X1, I)

15
Transfer Rule Extraction Example

• Primitive Rule 3
• pred( X1, dafur) pred( X1, for)
• ? obj( X1, X2)
• pred( X2, that)

16
Transfer Rule Extraction Example

• Primitive Rule 4
• pred( X1, dankbar) pred( X1, appreciation)
• adj( X1, X2) ? spec( X1, X2)
• in_set( X3, X2) pred( X2, a)
• pred(X3, zutiefst) adj( X1, X3)
• in_set( X4, X3)
• pred( X4, deep)

17
Transfer Rule Extraction Example

• Complex Transfer Rules
• primitive transfer rules that are adjacent in
  f-structure combined to form more complex rules
• Example (rules 1 2 above)

pred( X1, sein) pred( X1, have) subj( X1,
X2) ? subj( X1, X2) pred( X2, ich)
pred( X2, I) xcomp( X1, X3) obj( X1, X3)
In the worst case, there can be an exponential
number of combinations of primitive transfer
rules, the number of primitive rules used to form
a complex rule is restricted to 3 causing the
no. of transfer rules taken to be O(n2) in the
worst case.
18
Section 3Parsing-Transfer-Generation

19
Parsing

• LFG grammars used to parse source and target text
• FRAGMENT grammar is used to augment standard
  grammar increasing robustness
• Correct parse determined by fewest chunk method

20
Transfer

• Rules applied to source f-structure
  non-deterministically and in parallel
• Each fact of German f-structure translated by
  exactly one transfer rule
• Default rule included that allows any fact to be
  translated as itself
• Chart used to encode translations
• Beam search decoding used to select the most
  probable translations

21
Generation

• Method of generation has to be fault tolerant
• Transfer system can be given a fragmentary parse
  as input
• Transfer system can output an non-valid
  f-structure
• Unknown predicates
• Default morphology used to inflect source stem
  for English
• Unknown structures
• Default grammar used that allows any attribute to
  be generated in any order with any category

22
Section 4Statistical Models Training

23
Statistical Components

• Modelled on statistical components of Pharaoh
• Paraoh integrates 8 statistical models
• Relative frequency of phrase translations in
  source-to-target
• Relative frequency of phrase translations in
  target-to-source
• Lexical weighting in source-to-target
• Lexical weighting in target-to-source
• Phrase count
• Language model probability
• Word count
• Distortion probability

24
Statistical Components

• Following statistics for each translation
• Log-probability of source-to-target transfer
  rules, where the probability r(ef) of a rule
  that transfers source snippet f into target
  snippet e is estimated by the relative frequency

2. Log-probability of target-to-source rules
25
Statistical Components

• 3. Log-probability of lexical translations from
• source to target snippets, estimated from
  Viterbi alignments â between source word
  positions i 1, , n and target word positions j
  1, , m for stems fi and ej in snippets f and e
  with relative word translation frequencies
  t(ejfi)

4. Log-probability of lexical translations from
target-to-source snippets
26
Statistical Components

• 5. Number of transfer rule
• 6. Number of transfer rules with frequency 1
• 7. Number of default transfer rules
• 8. Log-probability of strings of predicates from
  root to frontier of target f-structure, estimated
  from predicate trigrams of English
• 9. Number of predicates in target language
• 10. Number of constituent movements during
  generation based on the original order of the
  head predicates of the constituents (for example,
  AP2 BP3 CP1 counts as two movements since
  the head predicate of CP moved from first to
  third position)

27
Statistical Components

• 11. Number of generation repairs
• 12. Log-probability of target string as computed
  by trigram language model
• 13. Number of words in target string
• 1 10 are used to choose the most probable parse
  from the transfer chart
• 1 7 are are tests on source and target
  f-structure snippets related via transfer rules
• 8 -10 are language model and distortion features
  on the target c- and f-structures
• 11 13 are computed on the strings that are
  generated from the target f-structure
• The statistics are combined into a log-linear
  model whose parameters are adjusted by minimum
  error rate training.

28
Section 5ExperimentalEvaluation

29
Experimental Evaluation

• Europarl German to English
• Sents of length 5 15 words
• Training set 163,141 sents
• Development set 1,967 sents
• Test set 1,755 sents (same as Koehn et al
  2003)
• Bidirectional word alignment created from word
  alignment of IBM model 4 as implemented by Giza
  (Och et al. 1999)
• Grammars achieve 100 coverage on unseen data
• 80 as full parses
• 20 as fragment parses
• 700,000 transfer rules extracted
• For language modelling trigram model of Stolcke
  2002 is used

30
Experimental Evaluation

• For translating the test set
• 1 parse for each German sentence was used
• 10 transferred f-structures
• 1,000 generated strings for each transferred
  f-structure
• Most probable target f-structure is gotten by a
  beam search on the transfer chart using features
  1-10 above, with a beam size of 20.
• Features 11-13 are computed on the strings that
  are generated

31
Experimental Evaluation

• For automatic evaluation they used NIST combined
  with the approximate randomization test (Noreen,
  1999)

32
Experimental Evaluation

• Manual Evaluation
• To separate the factors of grammaticality and
  translation adequacy
• 500 sentences randomly extracted from in-coverage
  examples
• 2 independent human judges
• Presented with the output from the phrase-based
  SMT system and LFG-based system in a blind test
  and asked them to choose a preference for one of
  the translations based on
• Grammaticality / fluency
• Translational / semantic adequacy

33
Experimental Evaluation

• Promising results for examples that are
  in-coverage of LFG grammars ?
• However, back-off to robustness techniques for
  parsing and generation results in loss of
  translation quality ?
• Rule Extraction Problems
• 20 of the parses are fragmental
• Errors occur in rule extraction process resulting
  in ill-formed transfer rules
• Parsing-Transfer-Generation Problems
• Parsing errors ? errors in transfer ? generation
  errors
• In-coverage ? disambiguation errors in parsing
  and transfer ? suboptimal translation

34
Experimental Evaluation

• Despite use of minimum error rate training and
  n-gram language models, the system cannot be used
  to maximize n-gram scores on reference
  translations in the same way as phrase-based
  systems since statistical ordering models are
  employed in the framework after generation
• This gives preference to grammaticality over
  similarity to reference translations

35
Conclusion

• SMT model that marries phrase-based SMT with
  traditional grammar-based MT
• NIST measure showed that results achieved are
  comparable with phrase-based SMT system of Koehn
  et al 2003 for in-coverage examples
• Manual evaluation showed significant improvements
  in both grammaticality and translational adequacy
  for in-coverage examples

36
Conclusion

• Determinable with this system whether or not a
  source sentence is in-coverage
• Possibility for hybrid system that achieves
  improved grammaticality at state-of-the-art
  translation quality
• Future Work
• Improvement of translation of in-coverage source
  sentences e.g. stochastic generation
• Apply system to other language pairs and data sets

37
References

• Miriam Butt, Dyvik Helge, Tracy King, Hiroshi
  Masuichi and Christian Rohrer. 2002 The Parallel
  Grammar Project.
• Eugene Charniak, Kevin Knight and Kenji Yamada.
  2003 Syntax-based Language Models for Statistical
  Machine Translation.
• Michael Collins, PhilippKoehn and Ivona
  Kucerova. 2005 Clause Restructuring for
  Statistical Machine Translation.
• Philipp Koehn, Franz Och and Daniel Marcu. 2003
  Statistical Phrase-based Translation.
• Philipp Koehn. 2004 Pharaoh a beam search
  decoder for phrase-based statistical machine
  translation
• Arul Menezes and Stephen Richardson. 2001 A
  best-first alignment for automatic extraction of
  transfer mappings from bilingual corpora.
• Franz Och, Christoph Tillmann and Ney Hermann.
  1999 Improved Alignment Models for Statistical
  Machine Translation.
• Franz Och. 2003 Minimum error rate training in
  statistical machine translation.
• Kishore Papineni, Salim Roukos, Todd Ward and
  Wei-Jing Zhu. 2002 BLEU a method for automatic
  evaluation of machine translation.
• Stefan Riezler, Tracy King, Ronald Kaplan,
  Richard Crouch, John Maxwell and Mark Johnson.
  2002 Parsing the Wall Street Journal using LFG
  and Discriminative Estimation Techniques
• Stefan Riezler and John Maxwell. 2006
  Grammatical Machine Translation.
• Fei Xia and Michael McCord. 2004 Improving a
  statistical MT system with automatically learned
  rewrite patterns
