Title: Forensics Toolbox


1
Forensics Toolbox
  • Paul A. Henry
  • MCPI, MCSE, CCSA, CCSE, CISSP-ISSAP, CISM, CISA,
    CIFI, CCE
  • Florida PI License C2800597
  • Forensics Recovery LLC
  • Florida PI Agency License A2900048

2
Latest Additions To My Tool Kit
  • Cellebrite UFED
  • SafeBlockXP
  • SAFE Boot CD
  • VOOM III
  • F-Response
  • Tableau TD1
  • HBGary RAM FastDump
  • FTK 2.x

3
Cellebrite UFED
  • Cell phones were becoming a part of larger
    forensic jobs
  • Recognized that I am not going to make a living
    imaging cell phones but had lost a couple of
    larger jobs because I could not include the cell
    phones along with the laptops and PCs
  • Tried several software solutions
  • Limited to small range of phones
  • Driver support is really really bad
  • No write block protection
  • I do not like the idea of jail-breaking

4
Cellebrite UFED
  • Supports CDMA, GSM, IDEN and TDMA
  • Covers 1700 phones / PDAs
  • What does it capture?
  • Phonebook
  • Pictures
  • Videos
  • Text Messages
  • Call Logs
  • ESN and IMEI information
  • Complete MD5 verified evidence reports
  • Writes NOTHING to the phone

5
Cellebrite UFED
  • Interfaces
  • USB
  • Serial
  • Bluetooth
  • Infrared
  • RJ45
  • SIM / USIM Reader
  • SD Card Reader
  • Ethernet
  • Mini DIN to PC Com Port

6
Cellebrite UFED
  • Yes it supports 2G / 3G iPhones also new Google
    G1
  • Can unlock the iPhone using plist files from host
    without jail-breaking
  • Memory dump extracts 382 files including 180
    property list files (Plist files)
  • SQLite databases
  • SMS
  • Notes
  • Call History
  • Calendar
  • Address Book
  • Appstore program data

7
Cellebrite UFED
8
Cellebrite UFED
  • New version of MobileSync Browser with direct
    support for UFED Memory Dump is coming from
    Vaughn Cordero

9
Cellebrite UFED
10
Cellebrite UFED
11
Cellebrite UFED
12
Cellebrite UFED
13
Cellebrite UFED
14
Cellebrite UFED
  • 1700 Phone and PDA support is huge
  • 63 adapter cables included
  • Also available as a ruggedized kit
  • Integrated write block no jail breaking
  • Great reporting with MD5 validation

15
SAFE Block XP
  • Point Click write blocking in Windows
  • Simultaneously block multiple devices
  • Nearly anything that plugs in to Windows can be
    write blocked
  • Application independent
  • Transparent to your other applications
  • FAST no USB or FireWire bottleneck
  • HPA and DCO support
  • Remove, store replace

16
SAFE Block XP
  • Using the 5 step NIST like methodology outlined
    in the Helix documentation validated that it did
    not alter the hard drive under test
  • 1. Prepare the media
  • a. Insert the drive into the removable drive tray
  • b. Wipe drive and validate
  • c. Format the drive
  • d. Copy data to the drive
  • e. Delete a portion of the data on the drive

17
SAFE Block XP
f. Since all of my drives are configured to use
write caching for performance, I added the extra
step of flush the drive write cache using the MS
SysInternals Sync program g. Image and MD5 Hash
the drive to a folder called Step-1 2. Test
the media a. Copy additional data to the drive b.
Delete a portion of the data that was written to
the drive c. Flush the drive cache
18
SAFE Block XP
d. Image and MD5 Hash the drive to a folder
called Step-2 e. Compare the MD5 Hash for the
drive in folder Step-1 with the MD5 Hash for
the image in folder Step 2. The media had in
fact been changed so the MD5 Hash values should
be different 3. Activate the write blocking
device a. Activate the software write block for
the drive under test
19
SAFE Block XP
4. Test the write blocking device a. Attempt to
copy data to the drive b. Attempt to delete data
from the drive c. Attempt to format the drive d.
Flush the drive cache e. Image and MD5 Hash the
drive to a folder called Step-5 5. Check for
any changes in the media a. Compare the MD5 Hash
for the image in folder Step-2 and the MD5
Hash for the image contained in folder Step-5
20
SAFE Block XP
If the write block is forensically sound the
MD5 Hashes will match validating that the write
block prevented any changes to the drive
21
SAFE Block XP
22
SAFE Boot CD
  • Windows based alternative to Linux
  • Built on top of SAFE Block XP
  • Compatible with numerous tools
  • FTK Imager
  • EnCase6
  • X-Ways
  • WinRAR
  • Win Hex
  • Irfanview image viewer
  • VLC video viewer
  • Open Office 1.5

23
SAFE Boot CD
  • Includes utility to create bootable USB
  • Includes utility to create tools media

24
SAFE Boot CD
  • Built in file explorer

25
SAFE Boot CD
  • Integrated search utility

26
SAFE Boot CD
  • Command line

27
VOOM Hardcopy III
  • Full test data available here
  • http//www.forensicsandrecovery.com/Public/Blog/En
    tries/2009/4/29_Real_World_Testing_-_Voom_Hardcopy
    _III.html
  • Claims 7.5 GB Min
  • Maximum I found with off the shelf drives was 5.6
    GB Min
  • Provides two SATA target ports
  • Wipe two drives simultaneously
  • Copy one source to two targets
  • Image one source to two targets
  • Current version only supports SHA1
  • Provides CRC for file chunks

28
VOOM Hardcopy III
29
VOOM Hardcopy III
  • Notable findings
  • No performance degradation when SHA1 enabled
  • No performance degradation when wiping 2 drives
    simultaneously
  • No performance degradation when copying one
    source to two targets
  • No performance degradation when imaging one
    source to two targets

30
F-Response
  • Vendor agnostic solution for remote forensics
  • Provides read only access to the full physical
    disk of any remote computer on the wire
  • Provides read only access to RAM in Windows
    computers on the wire
  • Except Vista x64
  • Remote physical drive or RAM simply look like a
    local resource to your forensic tools

31
F-Response
  • I have used it for remote access to image Windows
    XP and Windows Vista as well as a MacBook Pro and
    an iMac while running my tools on a local Vista
    x64 machine with no issues
  • Great alternative to digging out your watch
    repair tools to take apart that laptop -)
  • Great way to handle a RAID array
  • Small defendable footprint on the host
  • USB insertion and USB app execution

32
F-Response
  • I purchased the Field Edition
  • Allows for one to one connection
  • Also available as a Consultant Edition
  • Allows for access to multiple source machines
    using a single USB key
  • Also available as a Enterprise Edition
  • Distribute to many targets across the entire
    enterprise with an unlimited license
  • Indispensable tool I dont leave home without it

33
Tableau TD1
  • Fastest imager I have used to date
  • When imaging 1 source to 1 target
  • Claims 6.0 GB Min
  • Maximum I saw was 5.9 GB Min
  • When imaging a 500 GB source to a 1 TB target it
    completed 26 minutes faster then its nearest
    competitor
  • Features
  • Multiple wipe modes
  • SHA1 and MD5 Hashes
  • Keyboard port available but no keyboard required
    to enter data (keypad)

34
Tableau TD1
  • Log data written to USB key or USB printer
  • Retains user data and configuration in memory and
    allows 1 button imaging
  • Integrated SATA and IDE source / target ports
  • No need for external IDE adapters
  • Also includes laptop and ZIF connectors

35
Tableau TD1
36
Final Imager Considerations
  • The Voom Hardcopy III and Tableau TD1 are both
    formidable imagers
  • If you need to regularly image to two targets or
    wipe two drive simultaneously then the Voom
    Hardcopy III is a good choice
  • If you want the fastest imager, do not need to
    image or wipe multiple drives but need SHA and
    MD5 hashing or multiple wipe modes then the TD1
    is a good choice
  • Tough choice - I bought them both -)

37
HBGary RAM Capture
  • Live forensics playing a much more important role
    in forensics
  • So much volatile info available in RAM
  • Keys to the kingdom smoking gun
  • http//volatility.tumblr.com/
  • I have tested many tools that claimed to be able
    to capture a complete image of RAM in a Vista
    environment
  • Only 1 tool can handle capturing more then 8Gb of
    RAM in Vista x64
  • HBGary FastDump ROCKS

38
FTK 2.x
  • I have done a lot of work with FTK 2.x
  • I do not work for them but am a member of the
    beta team
  • In the simplest of terms FTK 2.x works well but
    you need the horse power to properly run it
  • I moved to FTK years ago because I like the
    automation they bring to the table not found in
    other products
  • Not making excuses for them but the move to Vista
    has been difficult for EVERYONE

39
FTK 2.x
  • What do I run FTK on?

40
FTK 2.x
  • Intel Quad-core Q9450 over clocked to 3.2 Ghz
  • FSB at 1600 DDR2 1066 RAM (cooled)
  • 8 SATA ports using 5 slot removable rack with
    hot swap SATA backplane

41
FTK 2.x
  • Best investment for FTK 2.x
  • I run mine with 8 300 GB 10k velociraptors in
    RAID 0

42
FTK 2.x
  • Performance
  • Processing images lt 1,000,000 objects
  • Speeds of up to 70 objects per second
  • Processing images gt 1,500,000 objects
  • Speeds of up to 50 objects per second
  • I have a stand alone configuration
  • So what does that mean?
  • 500 GB HD with 1.8 million objects
  • lt10 hrs start to finish in RAID 0
  • Carve everything
  • Process PSTs
  • Separate compound files / metadata

43
FTK 2.x
  • I found best performance under Vista x64
  • Kill ReadyBoost
  • Kill SuperFetch
  • Turn off visual enhancements
  • Disable UAC / AV / Update / backup
  • 1 huge RAID 0 array partitioned as separate
    drives
  • Let the adaptec buffer manager sort it out
  • I store my images and back up everything over a
    dedicated 1GB LAN to a RAID 5 NAS

44
  • Forensics
  • Recovery LLC
  • Florida PI License A 29004
  • www.forensicsandrecovery.com
  • Paul A. Henry
  • MCPI, MCSE, CCSA, CCSE, CISSP-ISSAP, CISM, CISA,
    CIFI, CCE
  • Florida PI License C2800597
  • 25 SE 69th Place Ocala, Fl 34480 Telephone
    (954) 854 9143 phenry_at_forensicsandrecover
    y.com
