Title: Electrical Inspection and Testing C&G 2391 Module 2 Initial


1
Electrical Inspection and Testing CG 2391
  • Module 2
  • Initial Verification

2
Initial Verification 711-01-01
  • Every installation shall, during erection and on
    completion before being put into service be
    inspected and tested to verify , so far as is
    reasonably practicable that the requirements of
    the Regulations have been met.
  • Precautions shall be taken to avoid danger to
    persons and damage to property and installed
    equipment during the inspection and testing

3
Avoid Danger to Persons
  • Have you checked to see if any essential services
    are supplied from the board e.g emergency
    lighting,
  • fire alarms, life-support equipment, UPS
    systems,
  • gas monitoring systems, etc.
  • Have you isolated the circuit correctly
  • Have you discharged any capacitors
  • Is the test equipment appropriate for the
    environment e.g intrinsically safe
  • Are you using long test leads that could cause
    people to trip over
  • Have you informed people of the dangers

4
Avoid Damage to Property
  • Is there an RCD in the circuit
  • Are there computers on line
  • Is there electronic equipment in the circuit
  • Could gaskets be damaged when removing covers
  • Are all the loads disconnected
  • Is there any equipment or processes which may be
    damaged if disconnected for long periods of time
  • Is there any essential equipment which cannot be
    turned off

5
HSE Guidance Note GS38Approved Voltage Tester
  • Adequate insulation
  • Have coloured leads to distinguish one lead from
    the other
  • Have finger barriers
  • Maximum of 2mm exposed probe
  • Flexible and Robust
  • Sheathed leads to prevent damage
  • Long enough for their purpose
  • No accessible parts even if the lead is loose
  • Have fused leads

6
HSE Guidance Note GS38
Approved Voltage Tester
Sheathed
Fused leads
Finger guards
Note If the instrument does not have a built in
test facility a proving unit will be required
Colour identified
Max 2mm tip
7
International Protection Code
  • First Column
    Indicated by number protection against
    ingress of solid foreign bodies
  • Second Column
    Indicated by number protection against
    ingress of water
  • Third Column
    Indicated by letter protection offered
    to a person against contact with a dangerous part
    within an enclosure

8
Third Column
  • A The back of the hand is protected against
    touching dangerous parts within an enclosure
  • B A finger (12mm x 80mm) is protected against
    touching dangerous parts
  • C A tool (2.5mm x 10mm) is protected against
    touching dangerous parts
  • D A piece of wire (1.00mm2 x 100mm) is protected
    against touching live parts

9
Examples
  • IP2X Full penetration of 12.5mm dia sphere
    not allowed and protection against finger
    (12mm x 80mm)
  • IPXXB Protection against finger contact only
    i.e (12mm x 80mm)
  • IP4X Protection against solid objects (tools,
    wires 1.00mm dia)
  • IPX8 Indefinite immersion shall not allow
    water to enter the enclosure
  • i.e submersion

10
Information Required for Initial Verification
711-01-02
  • Maximum Demand of the installation
  • Number and type of live conductors
  • Type of Earthing arrangements
  • Nominal Voltage
  • The nature of the current and the frequency
  • Prospective fault current at the origin
  • External phase to earth loop impedance Ze
  • Suitability of the supply for the installation
  • Type and nominal rating of the overcurrent device
    at the origin

11
  • Diagrams, charts or tables providing adequate
    information relating to the type and composition
    of each circuit including points served, type of
    wiring and the number and size of the circuit
    conductors
  • Information regarding the identification and
    location of isolation and switching devices
  • Identification of any circuit and/or equipment
    liable to damage by a typical test
  • Identification of the method used for and means
    of compliance with Reg 413-02-04

12
Inspection 712-01-01
  • Inspection shall precede testing and shall
    normally be done with that part of the
    installation under inspection disconnected from
    the supply

13
Inspection 712-01-02
  • The inspection shall be made to verify that the
    installed electrical equipment is
  • In compliance with Section 511 (this may be
    ascertained by mark or by certification furnished
    by the installer or by the manufacturer), and
  • Correctly selected and erected in accordance with
    the Regulations, and
  • Not visibly damaged or defective so as to impair
    safety

14
Inspection Checklist 712-01-03
  • Connection of conductors
  • Identification of conductors
  • Routing of cables in safe zones or protection
    against mechanical damage, in compliance with
    Section 522
  • Selection of conductors for current-carrying
    capacity and voltage drop, in accordance with the
    design
  • Connection of single pole devices for protection
    or switching in phase conductors only

15
  • Correct connection of accessories and equipment
  • Presence of fire barriers, suitable seals and
    protection against thermal effects
  • Methods of protection against electric shock
    (a)protection against both direct and indirect
    contact, i.e SELV or limitation of energy
  • (b)protection against direct contact
    protection by insulation of live parts
    protection by a barrier or an enclosure
    protection by obstacles
    protection by placing out of reach
    protection by PELV

16
  • (c) protection against indirect contact
    Earthed Equipotential Bonding and Automatic
    Disconnection of Supply
  • presence of earthing conductors
  • presence of protective conductors
  • presence of main equipotential bonding
    conductors
  • presence of supplementary equipotential bonding
    conductors
  • presence of earthing arrangements for combined
    protective and functional purposes

17
  • Use of Class II equipment or equivalent
    insulation
  • Non-conducting locations
    absence of protective conductors
  • Earth free-local equipotential bonding
    presence of earth-free equipotential bonding
    conductors
  • Electrical separation

18
  • Prevention of mutual detrimental influences
  • Presence of appropriate devices for isolation and
    switching correctly located
  • Presence of undervoltage protective devices
  • Choice and setting of protective and monitoring
    devices (indirect contact and/or overcurrent)
  • Labelling of protective devices, switches and
    terminals
  • Selection of equipment and protective measures
    appropriate to external influences

19
  • Adequacy of access to switchgear and equipment
  • Presence of danger notices and other warning
    signs
  • Presence of diagrams, instructions and similar
    information
  • Erection methods

20
Conduit
  • Fixings (correct number and type of saddle)
  • Ends of tube reamed
  • Couplings tightened
  • Running couplings locknuts tightened
  • Box lids fitted complete with screws
  • Vice marks removed
  • Damaged finishes restored
  • External protective conductors installed

21
(1)Regarding the Initial verification of a NEW
installationState the documentation that(a)
Should be available(b) Will need to be completed
  • (a) Charts / diagrams or similar information
    regarding the type of circuit, the number of
    points served, type of wiring and conductor size
    etc.
  • b) i)Inspection schedule
  • ii)Test results schedule
  • iii)Electrical installation certificate

22
(2) State(a) TWO statutory documents that have
a direct influence upon inspection and
testing(b) The legal status of HSE GS38 document
on electrical test equipment for electricians
  • (a) Health and Safety at Work Act and the
    Electricity at Work Regulations
  • (b) This is a Guidance note and therefore cannot
    be statutory i.e
    Non-Statutory

23
(3) State THREE methods of protection against
direct contact
  • There are FOUR methods of protection against
    direct contact stated in BS7671
  • Insulation of LIVE parts
  • Barriers or Enclosures
  • Use of Obstacles
  • Placing out of reach
  • Any three of these would be acceptable

24
(4) State three human senses that could be used
during an inspection of an installation
  • All of the senses could be used-
  • Sight,
  • Smell,
  • Hearing,
  • Touch (give examples) Some smells taste

25
(5) State THREE methods of protection against
indirect contact
  • There are FIVE methods of protection against
    indirect contact listed in BS7671
  • EEBADS (Earthed Equipotential Bonding and
    Automatic Disconnection of Supply)
  • Protection by Class II Equipment
  • Protection by non-conducting location
  • Protection by earth-free local equipotential
    bonding
  • Protection by electrical separation
  • Any three will be acceptable

26
(6) With reference to the Electricity at Work
Regulations State-(a) Title of the person who
has control of an electrical installation(b)
Status of the person identified above(c)
Responsibilities of this person when carrying out
the inspection and testing
  • Duty Holder
  • Competent
  • Carry out the work safely, no danger or injury to
    persons or livestock and no damage to equipment

27
(7) State three requirements of the Electricity
at Work Regulations regarding test instruments
Equipment must be Constructed, Maintained and
Used in a way to prevent danger
28
(8) State the three general requirements to which
the installed equipment must conform when
carrying out an initial inspection
  • The equipment is in compliance with standards
    i.e. To the correct BS or BSEN
  • Correctly selected and erected in accordance
    with BS7671
  • It is not visibly damaged

29
  • (9) State the legal status of each of the
    following-
  • BS7671
  • The On Site Guide
  • The Electricity at Work Regulations
  • Non-Statutory
  • Non-Statutory
  • Statutory

30
(10) List three requirements of GS38 regarding
the construction of an approved test lamp
  • Fused leads
  • Maximum of 2mm exposed tip
  • Finger guards

31
(11) a) Within the code IP2X what is represented
by i) 2 ii) X b) State the level of
protection offered by IP4X
  • i) standard finger 80mm long x 12mm diameter and
  • no penetration by 12.5mm diameter sphere
  • ii) unspecified regarding the protection
    provided
  • b) Protection against small items 1.0mm diameter

32
  • (12) State the form of protection provided by-
  • Insulation of live parts
  • SELV
  • Protection against DIRECT contact
  • Protection against both Direct and Indirect
    contact

33
  • (13) State-
  • The meaning of
  • i) EEBADS
  • ii) Indirect contact
  • b) One other method of protection against
    indirect contact

a) i) Earthed Equipotential Bonding and
Automatic Disconnection of supply ii)
Contact with parts made live by a fault, b) Any
of the other four e.g. Class II Equipment
34
(14) BS7671 gives a list of items to be checked,
where relevant, during an initial inspection.
List three of these.
There are 18 items listed in the inspection check
list of 712-01-02, any three of these would
do e.g.- Connection of conductors Identification
of conductors Routing of cables in safe
zones Selection of conductors for current
carrying capacity Connection of single pole
devices in phase conductor only Correct
connection of accessories. etc
35
  • (15) State
  • When an initial inspection and test should be
    carried out
  • The precautions to be taken during an inspection
    and test
  • During and on completion, before being put into
    service
  • Avoid danger to persons, livestock and damage to
    property
Write a Comment
User Comments (0)
About PowerShow.com
