Title: MATERIALS RESEARCH PRESENTATION: 04.02.09


1
MATERIALS RESEARCH PRESENTATION
04.02.09 PREPARED FOR THE DUPAGE HABITAT FOR
HUMANITY
2
GROUP 1
  • TEAM MEMBERS
  • Jack Bowen
  • Rizwan Moin
  • Jeff Nemcher
  • Jairo Ortega
  • Afia Syeda
  • RESEARCH TOPICS
  • 1.0 - General Data
  • 2.0 - Sitework
  • 3.0 - Concrete
  • 6.0 - Carpentry

3
RESEARCH TOPIC CONSTRUCTION WASTE MANAGEMENT
  • SUMMARY
  • Hoving Recycling Disposal, Inc provides full
    recycling and waste removal service. They also
    offer a variety of comprehensive recycling that
    is customized to fit our needs.
  • Services Pit Stop - Portable Restroom
    Service Dispose of Waste Street
    Sweeping Recycle Transfer Waste
  • Location West Chicago, Illinois.

4
RESEARCH TOPIC CONSTRUCTION WASTE MANAGEMENT
SUMMARY RSI that stands for Recycling
systems,Inc. is the largest recycling facility in
the chicagoland area owned by a family. For
almost 40 years, this company has been serving
Chicago area and many other people including
contractors, businesses and etc. RSI also provide
tracking and documentation of the city of Chicago
mandates and also for LEED building projects.
Its services are very convenient. They drop off
a dumpster and pick up waste material. They
accept mixed construction and demolition debris,
straight loads of recyclable material and
municipal solid waste. Their main objective is to
recycle material as much as possible and turning
it into useful resources. They handle Waste
Recycling Junk Metal Concrete Dirt
Roofing Vegetation Construction Demolition
Landscaping waste Storm damage Flooding
damage Drywall carpet Furniture Roll off
boxes Plastic Wood Cardboard Scrap
Tiles Asphalt
5
RESEARCH TOPIC CONSTRUCTION WASTE MANAGEMENT
  • Services
  • Products
  • Asbestos Hauler, Asphalt, Cars, Construction
    Waste, Electrical Conduit, Piping, Electronics,
    Gypsum Board, Metal, Office Paper, Old Cardboard,
    Railroad Ties, Soil, Landscape Waste, Wood, Wood
    Sheet Materials, Wood Trim, Carpet and Ceiling
    Tiles, Drywall, Furniture, Plastic, Roofing.
  • Location 3152 California Av, Chicago, IL
    60608.
  • Construction and Demolition Debris
  • Container Services
  • Customizing
  • Demolition
  • Free Unloading
  • Hauling
  • Open to the Public
  • Permits
  • Recycling
  • Sorting
  • LEED
  • Roll-Off Service Container Rental

6
RESEARCH TOPIC Construction Activity Pollution
Prevention
  • There are many simple, inexpensive ways to reduce
    the amount of pollution produced at a
    construction site
  • Use of water or non-toxic chemicals to control
    dust
  • Limit the driving speed of construction vehicles.
  • Cover air conditioning units, vents and registers
    with plastic, to prevent particles from getting
    inside.
  • Wash vehicles off at construction site.

7
RESEARCH TOPIC Storm Water Management
WHAT? When it rains, storm water runoff that
isn't properly managed can flow over impervious
surfaces picking up pollutants along the way and
washing them into rivers and streams. Storm water
runoff can also cause flooding and erosion,
destroy habitat and contribute to combined sewer
overflows. WHY? Only 1 of Chicagos rainwater
is re-used. The other 99 is channeled back into
lakes, rivers and streams, full of contaminants.
27,200 gallons of water fall on a one-acre yard
during a one-inch rainfall. All of which can be
re-used.
8
RESEARCH TOPIC Storm Water Management
Rain Barrels Rain barrels are attached to
downspouts which collect storm water running off
of the roof.  An overflow system allows excess
water to be directed elsewhere.  The rainwater
collected in the barrel can be used for watering
your plants or garden during dry times of the
year and even to wash your car. Lawn and garden
watering can make up 40 percent of your household
water use during the summer months.
Pricing Aquascape (St. Charles, IL) 250 City of
Chicago Rain Barrel Program (Residency Required)
40 Installation Easy. Just a matter of
shortening the downspout from the gutters to flow
directly into the barrel through a downspout
adapter (15/Each).
INCLUDE IMAGES ON LEFT SIDE AS NECESSARY TO
SUPPORT RESEARCH, TYPICAL
9
RESEARCH TOPIC Storm Water Management
Rain Gardens A rain garden is a natural or dug
shallow depression designed to capture and soak
up storm water runoff from your roof or other
impervious areas around your home like driveways
and walkways. Rain gardens can reduce storm
water pollution by 30. Most effective with
native planting. Installation/Pricing Rain
gardens can be very easy to install. Set-up can
be as simple as pointing a downspout towards a
garden. If the lawn is sloped away from the
house, the rain garden can be up to 30 feet away
from the house. Pricing for a 210 square foot
Rain garden Mulch 2 cu. yd. 26/cu. yd. 52 Sand
6 cu. yd. 16/cu. yd. 96 Compost 6 cu. yd.
32/cu. yd. 192 Topsoil 12 cu. yd. 26/cu. yd.
312 Native Plants Approx. 30 2-15/plant
60 Excavator 1 160-200/day Cost
Varies Approximate Cost 712-1,102
10
RESEARCH TOPIC Sustainable Landscaping
  • WHAT?
  • Sustainable landscaping is a low-impact,
    low-maintenance and low-resource-use way to
    landscape.
  • WHY?
  • Benefits of sustainable landscaping are
  • Enhance and protect ecosystems and biodiversity
  • Improve air and water quality
  • Reduce solid waste
  • Conserve natural resources
  • -Reduce maintenance costs

11
RESEARCH TOPIC Sustainable Landscaping
Native Planting Native planting is a low cost
alternative to traditional landscaping. That uses
plants and grasses that are native or adaptable
to the location they are going to be used. They
typically have longer root structures, which work
better at absorbing materials in the soil. The
reduced maintenance benefits the environment, by
not using fertilizers or excess amounts of water.
Cost -Similar to traditional landscaping -Long
term savings as much as 1/5 Application -Absorb
area that usually goes to lawns -Which cuts down
maintenance and pollution
12
RESEARCH TOPIC Sustainable Landscaping
Trellis and Vines Having a trellis and vines on a
portion of the house that receives direct
sunlight will block the sunlight from heating up
the outside (and inside) of the house. In the
winter, when you need the sunlight for added
heat, the leaves are off which allows the light
to get through. These will be particularly
useful in the new development, since freshly
planted trees will need some time to produce
shade. Cost Minimal due to the fact that these
can be built onsite by volunteers. Maintenance
The homeowner will have to trim the vines from
time to time.
13
RESEARCH TOPIC Pervious Pavement
WHAT? Pervious pavement allows water to run
though the material to the soil, rather than
being fed through the storm drainage systems
which then runs into natural waterways. WHY?
-Reduces storm water runoff -Replenishes
groundwater -Requires less land to be set aside
for drainage -Reduces pollutants in
runoff -Reduces irrigation of area plantings
based on the seepage of rain into the sub soil
surfaces
14
RESEARCH TOPIC Pervious Pavement
Pervious Asphalt Recommended for streets due to
its high durability, reduced roadway noise,
non-slippery when wet, extended pavement life.
Disadvantages are that it needs to be vacuumed
to avoid clogging, and it only works when it is
installed correctly. Cost 20 More than
traditional asphalt. Cost can be offset by
reducing the amount of storm water
infrastructure, and not having to use as much
land for water run-offs. (Meyer Materials,
McHenry IL) Installation Uses the same technique
of application as traditional asphalt, but a
experienced contractor is a requirement for it to
work properly.
15
RESEARCH TOPIC Pervious Pavement
Walkways and Patios Instead of paying the extra
cost for pervious asphalt on short walkways or
patios, traditional materials can be used using
the right technique. Cost Comparable to
traditional methods, although it will require
more labor. -By using gravel and spacing the
tiles correctly, it will allow rainwater to run
down to the soil. -Using traditional materials
with a catch basin. By pitching the sidewalk or
driveway, and letting the water run off into
designated area (or garden) for drainage into the
soil.
16
RESEARCH TOPIC Concrete
  • Making Concrete Construction Green
  • Modify the concrete mix
  • Pouring concrete more responsibly
  • Low or Non-VOC sealants, releases, curing agents
  • Green concrete systems
  • Insulated concrete forms (ICFs)
  • Pervious Concrete

17
RESEARCH TOPIC Concrete - Green Construction
  • Modifying the Concrete Mix
  • Add Fly Ash to the Mix
  • Minimize use of portland cement
  • Reduces Carbon emission
  • Pouring Concrete More Responsibly
  • Add a designated washout zone
  • Helps control waste management
  • Low or Non-VOC sealants, releases, curing agents,
    stains, etc.
  • Volatile Organic Compounds (VOCs) are know for
    causing health problems.
  • Consider using Low or Non-VOC products

18
RESEARCH TOPIC Concrete - Insulated Concrete
Forms
  • Insulated Concrete Forms (ICFs)
  • ICFs are permanent modular concrete forms that
    provide high levels of insulation
  • ICFs can reduce energy costs up to 40
  • Types of ICF construction
  • Foundation only
  • Entire house
  • ICF flooring systems
  • Installation
  • Easy to install, other Habitat chapters have had
    volunteers install the system with minimal
    training.

19
RESEARCH TOPIC Concrete - Pervious Concrete
  • Pervious Concrete
  • Allows water to circulate through concrete
  • Allows for snow to melt faster
  • Safer sidewalks, driveways, and roads
  • Reduces heat island effect
  • Installation
  • Requires specialized training/certification
    needed
  • Special roller screed is needed to place concrete

20
RESEARCH TOPIC Alternative Framing Methods
  • 6.0 - CARPENTRY
  • Advanced Framing Methods Material Reduction
  • INCREASE EXTERIOR WALLS TO 2x6 STUDS
  • Allows for easy installation of thicker
    insulation.
  • Allows for 24 O.C. stud spacing.
  • Reduces the number of studs required for framing.
  • Places structural elements efficiently.

SIMPLIFIED ADVANCED FRAMING DIAGRAM
21
RESEARCH TOPIC Alternative Framing Methods
  • SUMMARY
  • According to the US Department of Energy's Office
    of Building Technology, advanced framing
    techniques can save 500 in material costs per
    1200 square feet of house, shave 3 to 5 percent
    off of labor costs, and reduce annual heating and
    cooling costs by 5 percent .

22
RESEARCH TOPIC Alternative Framing Materials
  • 6.0 - CARPENTRY
  • Finger Jointed Studs
  • BENEFITS OF FINGER JOINTED STUDS
  • Finger Jointed Studs are approved by the IBC and
    IRC and are considered interchangeable with
    solid-sawn lumber in vertical applications.
  • Finger Jointed Studs can be made from shorter
    sections of wood including scrap and waste from
    other production activities.

23
RESEARCH TOPIC Alternative Framing Materials
  • SUMMARY
  • Finger Jointed Studs are a sustainable product
    that exceeds the vertical compression
    requirements of standard dimensional lumber.
  • Finger Jointed Studs that contain 3 or more
    joints per stud is increased stability.
  • The cost for Finger Jointed Studs can be slightly
    higher than conventional sawn dimensional lumber.
    Current price differences are approximately 3 to
    8 percent. This relates to an average increase
    of 75 to 150 dollars per 1,000 board feet of
    lumber.
  • Most finger jointed lumber is only approved for
    vertical applications making it necessary to
    order standard dimensional lumber for any cross
    bracing, rafters, joists, blocking and other
    horizontal and angular applications.

24
RESEARCH TOPIC Locally Sourced Materials
  • 6.0 - CARPENTRY
  • Locally Produced OSB
  • LOCAL MATERIALS PROVIDE MULTIPLE BENEFITS
  • Locally produced materials help maintain a
    healthy local economy.
  • Transportation costs are reduced.
  • Emissions and pollution related to long distance
    shipping are eliminated.

25
RESEARCH TOPIC Certified Green Building Products
  • 6.0 - CARPENTRY
  • FSC Certified Lumber
  • BENEFITS OF FSC CERTIFIED LUMBER
  • The FORESTRY STEWARDSHIP COUNCIL (FSC) inspects
    and certifies the harvesting and management
    practices of participating companies.
  • FSC lumber is a proven sustainable resource that
    ensures our forests will be able to produce
    products for future generations.

26
RESEARCH TOPIC Certified Green Building Products
  • SUMMARY
  • FSC Certification provides the opportunity to
    support the sustainable management of our nations
    forests. These benefits add a 10 to 30 cost
    premium compared to traditional lumber prices.
  • FSC lumber is locally available and may be in
    stock or may require lead times of 2 to 4 weeks
    on some orders.
  • Additionally, careful documentation of FSC
    products is required in order to achieve LEED
    points.

27
RESEARCH TOPIC General Data
  • 1.0 - GENERAL DATA
  • Recycling
  • SEPARATION OF SCRAP LUMBER
  • On site storage of scrap lumber can reduce waste
    by more than 50 percent.
  • Create an are on site to separate scrap lumber by
    dimensions and length.
  • Bins or areas for 2 and shorter, 2 to 4, 4 to
    8 and longer lengths are most common.
  • 2 sections can be used for blocking, 2 to 4 may
    be useful in door and window framing.

28
GROUP 2
  • TEAM MEMBERS
  • David Chell
  • Juan Perez
  • Guillermo Lara
  • RESEARCH TOPICS
  • 7.0 Roofing
  • 7.0 Sealants and Caulks
  • 7.0 Siding
  • 7.0 Insulation
  • 8.0 Doors and Windows

29
RESEARCH TOPIC ROOFING (SHINGLES)
  • WHAT
  • DOMAIN WINSLOW COOL COLOR SERIES (asphalt
    shingles by Elk Premium Building Products)
  • WHY?
  • SLOW HEAT BUILD-UP AND MAKE THE HOME MORE
    ENERGY-EFFICIENT

ELK PREMIUM BUILDING PRODUCTS
30
RESEARCH TOPIC ROOFING (SHINGLES)
  • SUMMARY
  • COMPOSED OF HIGHLY REFLECTIVE GRANULES
  • A GREAT ALTERNATIVE TO THE STANDARD ASPHALT
    SHINGLE AND ENERGY-STAR RATED
  • EASILY INSTALLED AND POSSIBLE LEED PTS. FOR AIR
    INFILTRATION
  • COST APPROX. 140 PER SQ.

DOMAIN WINSLOW COOL COLOR SERIES
31
RESEARCH TOPIC ROOFING (UNDERLAYMENT)
  • WHAT
  • VersaShield NON-ASPHALTIC FIBERGLASS-BASED
    UNDERLAYMENT
  • WHY?
  • PROVIDES INCREASED MOISTURE PROTECTION

VersaShield
32
RESEARCH TOPIC ROOFING (UNDERLAYMENT)
  • SUMMARY
  • INSENSITIVE TO EXTREME WEATHER CONDITIONS
  • PROVIDES INCREASED FIRE RATED PROTECTION AND
    INCREASED MOISTURE PROTECTION
  • EASILY INSTALLED AND POSSIBLE LEED PTS. FOR AIR
    INFILTRATION
  • COST APPROX. 100 PER ROLL

VOLUNTEER-INSTALLED
33
RESEARCH TOPIC ROOFING (UNDERLAYMENT)
  • WHAT?
  • WinterGuard BY CERTAINTEED (UNDERLAYMENT)
  • WHY?
  • WinterGuard PROVIDES BETTER PROTECTION AGAINST
    ICE DAMS OVER THE AVERAGE UNDERLAYMENT

WinterGuard
34
RESEARCH TOPIC ROOFING (UNDERLAYMENT)
  • SUMMARY
  • CONTAINS POLYMERS WHICH PROVIDE FOR ADDITIONAL
    PROTECTION
  • COMES IN THREE EFFECTIVE SURFACE FINISHES SAND,
    GRANULAR, AND HIGH TACK/TEMPERATURE
  • CAN BE EASILY INSTALLED BY HABITAT VOLUNTEERS
  • COST ANYWHERE FROM 200 - 300 PER ROOF FT.

WinterGuard
35
RESEARCH TOPIC ROOFING/INSULATION
  • WHAT
  • Rboard INSULATION SHEATHING (by Atlas Roofing
    Corporation)
  • WHY?
  • CAN HELP MEET, OR EXCEED THE MODEL ENERGY CODE
    STANDARDS

Atlas Rboard
36
RESEARCH TOPIC ROOFING/INSULATION
  • SUMMARY
  • REDUCES THE POTENTIAL FOR CONDENSATIONS PROBLEMS
  • ACUltra TECHNOLOGY MEANS ZERO HCFCS
  • COST-EFFECTIVE GREEN SOLUTION
  • COST APPROX. 10 PER SHEET (1/2 x 4 x 8)

Atlas Rboard
37
RESEARCH TOPIC ROOFING CHART
38
RESEARCH TOPIC DOORS and WINDOWS
  • There are many factors to consider when buying a
    window.
  • Most importantly the U-Factor a ratio of heat
    transfer
  • measured by CONDUCTION, CONVECTION, and
    RADIATION. The lower the number the more
    insulated a component is.
  • SUNLIGHT half VISIBLE LIGHT, and the rest is
    mostly NEAR-INFRARED with a small
    amount of ULTRAVIOLET
  • Four basic properties of glazing that affect
    radiant energy transfer TRANSMITTANCE,
    REFLECTANCE, ABSORPTANCE, EMITTANCE

39
RESEARCH TOPIC DOORS and WINDOWS
  • IGUs
  • Reflective coatings and films
  • Double Glazing
  • Low-Emittance coatings
  • High-Solar-Gain
  • Moderate-Solar-Gain
  • Low-Solar-Gain
  • Gas fills and gap width
  • Triple Glazing

DOORS and WINDOWS
40
RESEARCH TOPIC DOORS and WINDOWS
  • Weatherstripping
  • Compression-seal awning, hopper, and casement
  • Frames
  • Aluminum
  • Wood
  • Vinyl
  • Insulated Vinyl
  • Fiberglass
  • Window Installation
  • Architectural and Interior Design decisions

DOORS and WINDOWS
41
RESEARCH TOPIC DOORS and WINDOWS
  • WHAT?
  • Pella ThermaStar Windows
  • WHY?
  • These windows have a U-Value of .3 because of its
    doubled glazing and insulated vinyl framethe
    lower the U-Value, the high the window performs

DOORS and WINDOWS
42
RESEARCH TOPIC DOORS and WINDOWS
  • SUMMARY
  • These windows are very durable, glazing
    guaranteed for 20 years and frame guaranteed for
    10 years
  • Require no special maintenance and are easily
    installed by Habitat volunteer
  • U-Value .3
  • Price varies greatly on the type of window, but
    are more expensive than your single glazed window
  • May contribute to LEED points (depending on
    proper installation)

DOORS and WINDOWS
43
RESEARCH TOPIC DOORS and WINDOWS
  • WHAT?
  • Andersen Doors and Windows
  • WHY?
  • Low E4 glass, with Perma-Shield
  • Lifespan of 20 years on glazing and 10 years on
    all non-glass parts.
  • Easily installed by Habitat volunteer

DOORS and WINDOWS
44
RESEARCH TOPIC DOORS and WINDOWS
  • SUMMARY
  • Available from Home Depot
  • Cost-effective
  • Doors and windows are energy

DOORS and WINDOWS
45
RESEARCH TOPIC DOORS and WINDOWS
  • WHAT
  • Alside Window System
  • WHY?
  • Window systems are ENERGY-STAR rated
  • Easily installed by a volunteer
  • Require no special maintenance
  • Locally available at Home Depot.

DOORS and WINDOWS
46
RESEARCH TOPIC DOORS and WINDOWS
  • SUMMARY
  • Energy-efficient, reduced air infiltration, high
    performance warm edge spacer system
  • Guaranteed for up to 20 years

DOORS and WINDOWS
47
RESEARCH TOPIC SUSTAINABLE SIDING (OVERVIEW)
  • WHAT?
  • VINYL SIDING
  • WHY?
  • USES LOW AMOUNTS OF ENERGY DURING MANUFACTURING
  • LESS AIR POLLUTION DURING PRODUCTION
  • REQUIRES LESS ENERGY TO TRANSPORT
  • MINIMAL WASTE DURING INSTALLATION
  • RECYCLED CONTENT
  • MINIMAL AIR POLLUTION DURING INSTALLATION
  • MAINTENANCE FREE
  • LIFE EXPECTANCY LIFETIME

SUSTAINABLE SIDING
48
RESEARCH TOPIC SUSTAINABLE SIDING (BRANDS)
  • MITTEN - Cambridge (TYPICAL VINYL SIDING)
  • MITTEN - Sentry (PREMIUM)
  • CERTAINTEED - Monogram
  • (DBL 4 PREMIUM SIDING)
  • CERTAINTEED - Cedarboards (INSULATED)
  • JAMES HARDIE - Hardieplank (FIBER CEMENT)

SUSTAINABLE SIDING
SUSTAINABLE SIDING
49
RESEARCH TOPIC SUSTAINABLE SIDING
WHAT? Mitten Cambridge
(TRADITIONAL VINYL SIDING)
  • WHY?
  • AVAILABLE IN 16 COLORS
  • LOCALLY AVAILABLE
  • EASY TO INSTALL
  • LOW MAINTENANCE
  • LOW COST
  • LEED QUALIFIED
  • LIFETIME WARRANTY

SUSTAINABLE SIDING
50
RESEARCH TOPIC SUSTAINABLE SIDING
WHAT? Mitten - Sentry (PREMIUM VINYL SIDING)
  • WHY?
  • AVAILABLE IN 11 COLORS
  • THICKER THAN AVERAGE VINYL SIDING
  • LESS SUSCEPTIBLE TO BOWING/BUCKLING
  • LOCALLY AVAILABLE
  • EASY TO INSTALL
  • LOW MAINTENANCE
  • LOW COST
  • QUALIFIES AS AN ENVIRONMENTALL FRIENDLY PRODUCT

SUSTAINABLE SIDING
51
RESEARCH TOPIC SUSTAINABLE SIDING
WHAT? Certainteed - Monogram (DBL 4 PREMIUM
SIDING)
  • WHY?
  • AVAILABLE IN 28 LOW-GLOSS COLORS LOW-GLOSS
    WOOD-TONE BLENDS
  • LOCALLY AVAILABLE
  • EASY TO INSTALL
  • LOW MAINTENANCE
  • LOW COST
  • THICKER THAN TYPICAL VINYL
  • ENVIRONMENTALLY PREFERABLE PRODUCT (1-2 LEED
    PTS.)
  • LIFETIME WARRANTY

SUSTAINABLE SIDING
SUSTAINABLE SIDING
52
RESEARCH TOPIC SUSTAINABLE SIDING
WHAT? Certainteed - CedarBoards (DBL 6
INSULATED VINYL SIDING)
  • WHY?
  • AVAILABLE IN 15 COLORS
  • LOCALLY AVAILABLE
  • PROVIDES ADDED STRENGTH
  • THERMAL BENEFIT OF RIGID FOAM INSULATION
  • ABSORBS SOUND FOR REDUCED EXTERIOR NOISE
  • 300 MORE R-VALUE THAN TRADITIONAL SIDING
  • REDUCES ENERGY LOSS BY AS MUCH AS 25
  • LIFETIME WARRANTY
  • QUALIFIES FOR LEED PTS. (1-10 PTS.)

SUSTAINABLE SIDING
53
RESEARCH TOPIC SIDING CHART
54
RESEARCH TOPIC INSULATION
  • WHAT?
  • JOHNS MANVILLE Climate Pro LOOSE-FILL FIBERGLASS
    BLOW-IN INSULATION
  • WHY?
  • JOHNS MANVILLE Climate Pro IS FORMALDEHYDE-FREE
    AND IS ELIGIBLE FOR LEED POINTS

JOHNS MANVILLE Climate Pro
55
RESEARCH TOPIC INSULATION
  • SUMMARY
  • Climate Pro INSULATION IS MADE OF AT LEAST 20
    POST-CONSUMER GLASS AND IS SCS (SCIENTIFIC
    CERTIFICATION SYSTEMS) CERTIFIED
  • Climate Pro INSULATION GAINS LEED POINTS FOR
    BEING COMPOSED OF AT LEAST 20 POST-CONSUMER
    RECYCLED MATERIAL AND AT LEAST 10
    POST-INDUSTRIAL RECYCLED MATERIAL
  • FIRE RESISTANT
  • COST APPROX. 25 - 30 PER BAG

JOHNS MANVILLE Climate Pro
56
RESEARCH TOPIC INSULATION
  • WHAT?
  • COCOON BLOW-IN CELLULOSE INSULATION (BY
    GreenFiber)
  • WHY?
  • COCOON IS MADE FROM 85 RECYCLED PAPER FIBER AND
    SUPPORTS ENERGY CONSERVATION PROGRAMS FOCUSED ON
    ENVIRONMENTAL RESPONSIBILITY

COCOON BY GreenFiber
57
RESEARCH TOPIC INSULATION
  • SUMMARY
  • TWO TO THREE TIMES AS DENSE AS RIGID INSULATION
  • THIS PRODUCT OFFERS PERMANENT FIRE RESISTANCE FOR
    THE LIFE OF THE STRUCTURE AND REDUCES NOISE.
  • THE R-VALUE OF GreenFiber INSULATION, OR ITS
    ABILITY TO STOP HEAT TRANSFER, REMAINS CONSISTENT
    THROUGH A GREATER TEMPERATURE AND APPLICATION
    RANGE THAN THAT OF LOOSE-FILL FIBERGLASS
    PRODUCTSKEEPING HEAT IN DURING THE WINTER, AND
    OUT DURING THE SUMMER
  • COST 9.31 (40 sq. ft.)

COCOON BY GreenFiber
58
RESEARCH TOPIC INSULATION
  • WHAT?
  • CertaSpray SPRAY FOAM (CLOSED CELL) INSULATION
  • WHY?
  • CertaSpray GREATLY REDUCES COST AND AIR
    INFILTRATION THROUGH THE BUILDING ENVELOPE

CertaSpray BY CERTAINTEED
59
RESEARCH TOPIC INSULATION
  • SUMMARY
  • GREENGUARD CERTIFIED (ALSO GREENGUARD CHILDREN
    AND SCHOOL CERTIFIED)
  • STOPS FIBERGLASS LEAKAGE
  • ACTS AS A SECOND VAPOR BARRIER

CertaSpray BY CERTAINTEED
60
RESEARCH TOPIC INSULATION
  • WHAT
  • BioBased SPRAY FOAM INSULATION
  • WHY?
  • SOY-BASED INSULATION THAT PRODUCES MINIMAL WASTE

BioBased Insulation
61
RESEARCH TOPIC INSULATION
  • SUMMARY
  • BioBased IS WATER-BLOWN AND SOY-BASED, MAKING IT
    MORE ENVIRONMENTALLY RESPONSIBLE
  • IS GRANTED MULTIPLE LEED POINTS (POINTS FOR
    OPTIMAL ENERGY PERFORMANCE, MINIMUM ENERGY
    PERFORMANCE, CONSTRUCTION WASTE MANAGEMENT,
    REGIONAL MATERIALS, RAPIDLY RENEWABLE MATERIALS,
    ETC)
  • INCORPORATES NATURAL, RENEWABLE OIL-BASED POLYOLS
    AS A REPLACEMENT FOR A PORTION OF THE TRADITIONAL
    PETROLEUM-BASED POLYOLS
  • COST 1.35 - 1.55 (per sq. ft.)

BioBased SOY-BASED
62
RESEARCH TOPIC INSULATION CHART
63
RESEARCH TOPIC SEALANTS AND CAULKS
  • WHAT
  • GREENchoice SEALANTS AND CAULKS
  • WHY?
  • GREENchoice SEALANTS AND CAULKS ALL CONTAIN VERY
    LOW AMOUNTS OF VOCs (VOLATILE ORGANIC COMPOUNDS)

SEALANTS and CAULKS
64
RESEARCH TOPIC SEALANTS AND CAULKS
  • SUMMARY
  • PASSES THE VOC LIMITS OF CALIFORNIAS SOUTH
    COAST AIR QUALITY MANAGEMENT DISTRICT RULE AND IS
    GRANTED 1 LEED POINT
  • HAS AT LEAST 20 OF ITS BUILDING MATERIALS AND
    PRODUCTS MANUFACTURED WITHIN 500 MILES OF
    BUILDING OR COMPONENT ASSEMBLY AND IS GRANTED 1
    LEED POINT
  • ON THE AVERAGE, GREENchoice PRODUCTS HAVE BELOW
    50g/L OF VOCS, A QUARTER OF THE AMOUNT AS SET
    FORTH BY THE CALIFORNIA AIR RESOURCES BOARD
  • COST ANYWHERE BETWEEN 2 AND 10 PER TUBE

GREENchoice
65
GROUP 3
  • TEAM MEMBERS
  • Steve Jaroch
  • Sarah Valker
  • Ryan Wakat
  • Bogdan Zamkotowicz
  • Maggie Zuzia
  • RESEARCH TOPICS
  • INTERIOR FINISHES
  • Low-VOC Paints
  • Low-VOC Construction Adhesive
  • Linoleum Flooring
  • Carpet
  • Bamboo Flooring
  • Cork Flooring

66
RESEARCH TOPIC PAINT
  • WHAT?
  • PAINT
  • WHY?
  • COMMONLY USED
  • INDOOR AIR QUALITY
  • CONTACTS OCCUPANTS

BABY TOUCHES PAINTED WALL
67
RESEARCH TOPIC PRIMER
VALPSAR INTERIOR LATEX MULTI PURPOSE PRIMER
  • SUMMARY
  • COST APX. 18.00 PER GALLON OR 0.05 A SQUARE
    FOOT.
  • TINTABLE PRIMER
  • L.E.E.D.
  • BENEFITS INCLUDE
  • VALSPAR PRODUCT
  • LOW COST
  • LOW V.O.C. CONTENT (50 GRAMS PER LITER)
  • DISADVANTAGES INCLUDE
  • 1. STAIN COVERAGE

68
RESEARCH TOPIC PAINT
VALPSAR ELAN SERIES INTERIOR PAINT
  • SUMMARY
  • COST 40 PER GALLON OR 0.10 A SQUARE FOOT.
  • TWO FINISHES
  • BENEFITS INCLUDE
  • LOW V.O.C. CONTENT
  • COMPARABLE DURABILITY
  • VALSPAR PRODUCT
  • DISADVANTAGES INCLUDE
  • 1. HIGH COST
  • 2. LEED TIME

69
V.O.C.s COLOR
HIGH V.O.C.
HIGH V.O.C.
LOW V.O.C.
70
V.O.C.s FINISHES
HIGH V.O.C.
MID V.O.C.
LOW V.O.C.
71
(No Transcript)
72
RESEARCH TOPIC LIQUID NAILS CONSTRUCTION ADHESIVE
  • WHAT?
  • Liquid Nails Low-VOC Heavy Duty Construction
    Adhesive is a less pollutant adhesive formulated
    to provide professionals and do-it-yourselfers
    with excellent adhesion and longer working time.
  • WHY?
  • Many finishes and construction products release
    Volatile Organic Compounds, polluting the clean
    air. The lower the VOC content, the more
    eco-friendly the product is. Many companies are
    working to make their VOC-emitting products have
    less VOC content in them.

73
RESEARCH TOPIC LIQUID NAILS CONSTRUCTION ADHESIVE
  • SUMMARY
  • Same price as regular LIQUID NAILS
  • Can be used for fiberwood, drywall, trim,
    particle board, plywood, ceiling tiles, and most
    common interior finishes
  • Locally available
  • Quickly and easily purchased
  • Meets the National Green Building Standard

74
RESEARCH TOPIC ArmStrong Migrations
  • WHAT?
  • A HIGHLY RECYCLABLE, REUSABLE FLOORING MATERIAL
    THAT IS VERY ECO FRIENDLY
  • WHY?
  • THIS PRODUCT HAS BEEN CONSIDERED BECAUSE OF ITS
    SUSTAINABLE MATERIAL INTAKE
  • IT USES A BINDING AGENT THAT IS DERIVED FROM CORN
    INSTEAD OF PETROLEUM
  • CONTRIBUTES TO LEED POINTS
  • INEXPENSIVE COMPARED TO OTHER GREEN FLOORING
    SOLUTIONS
  • AVAILABLE LOCALLY

ARCHITECTURE 2840 SUSTAINABLE DESIGN INITIATIVES
COLLEGE OF DUPAGE
75
RESEARCH TOPIC Johnsonite Square
  • WHAT?
  • A LOW MAINTENANCE, HIGH-PERFORMANCE ACOUSTIC,
    MODULAR TILE
  • WHY?
  • EXTREMELY DURABLE PUR-REINFORECE WEAR LAYER AND
    SQUARE CONSTRUCTION CONTRIBUTE TO LONG LIFE AND
    WEARABILITY
  • COMFORTABLE UNDERFOOT REDUCES NOISE SOUND
    IMPACT
  • OTHER SOLUTIONS AVAILABLE FROM JOHNSONITE
  • AVAILABLE LOCALLY

ARCHITECTURE 2840 SUSTAINABLE DESIGN INITIATIVES
COLLEGE OF DUPAGE
76
RESEARCH TOPICSHAW CARPET
  • SUMMARY
  • Only residential carpet fiber capable of being
    recycled back into carpet fiber repeatedly.
  • Locally available
  • Low VOC green label plus for indoor air quality
  • No Formaldehyde
  • Willing to lower price if habitat continues to do
    business
  • Lasts longer than regular carpeting due to
    natural additives
  • No special maintenance after installation.

77
RESEARCH TOPICGREENFLOORS CARPET
  • SUMMARY
  • Recycled and recyclable
  • Certified by CRI Green Label indoor air quality
    carpet testing program for VOCs
  • Guarantee that the carpet will not be land
    filled.
  • No special maintenance
  • Last longer than regular carpet due to natural
    additives
  • No formaldehyde

78
WICANDERS CORK FLOORING
  • ORIGIN
  • Bark of the cork oak tree.
  • Grows back and may be harvested every 10 years.
  • Can be harvested 15-20 times during its average
    300 years life cycle.

79
WICANDERS CORK FLOORING
  • PROPERTIES
  • Compressible and elastic,
  • Low conductivity of heat, sound and vibration,
  • Fire retardant,
  • Resistance to wear.
  • SUSTAINABILITY
  • Renewable source. Compostable.
  • Low waste.
  • Long lifespan. High durability.
  • Easy to maintain.

80
WICANDERS CORK FLOORING
  • WICANDERS CORK TILES AND PANELS
  • COST 6 (glue down tiles) or 10 (floating
    panels)
  • LIFESPAN 50 Years
  • AVAILABILITY Limited availability
  • MAINTENANCE Vacuum and sweep
  • LEED POINTS MR 4.1, MR 4.2, MR 6, IEQ 4.1, ID
    1-1.4

81
TERAGREN BAMBOO FLOORING
  • ORIGIN
  • Classified as grass
  • Grows and mature fast.
  • Does not require replanting.
  • PROPERTIES
  • High strength (harder than red oak or rock
    maple),
  • More resistant to dents and dings,
  • Very stable- less likely to expand or contract.
  • SUSTAINABILITY
  • Renewable source.
  • Long lifespan. High durability.

82
TERAGREN BAMBOO FLOORING
  • TERAGREN BAMBO FLOORING
  • COST 6-9
  • LIFESPAN 30 Years
  • AVAILABILITY Broadly available
  • MAINTENANCE Vacuum and sweep, light mopping
  • LEED POINTS EQ 4.4

83
FLOORING SUMMARY
84
GROUP 4
  • TEAM MEMBERS
  • JAMES BOYD
  • PHIL SVETICH
  • SARAH NEVILLE
  • NATALIE BIAGIOLI
  • RESEARCH TOPICS
  • ELECTRICAL
  • PLUMBING
  • HVAC
  • APPLIANCES

85
RESEARCH TOPIC ELECTRICAL
  • WHAT?
  • Green electrical materials can include . . .
  • Light bulbs (lamps)
  • Lighting fixtures
  • Solar powered exhaust fans (aids in ventilation)
  • Programmable thermostats (aids in heating and
    AC)
  • WHY?
  • The electrical components of a home can be a
    major factor in saving money, energy, and
    ultimately the environment.

86
RESEARCH TOPIC ELECTRICAL
  • LIGHT BULBS (LAMPS)
  • Compact Fluorescent Lamps (CFL) reduce emission
    of
  • Carbon Dioxide
  • Sulfur Dioxide
  • Nitrous Oxide
  • Light Emitting Diode (LED)
  • Very low homeowner maintenance
  • Reduce the need for large / bulky fixtures
  • Recycling
  • Free used bulb recycling programs are already in
    place at
  • Home Depot
  • Ace Hardware

87
RESEARCH TOPIC ELECTRICAL
  • LIGHT BULBS (LAMPS)

88
RESEARCH TOPIC ELECTRICAL
  • LIGHT FIXTURE ARRANGEMENT
  • Function
  • Current average home lighting fixture layout
  • 3 outdoor
  • 9 overhead main room light
  • 4 closet (one house)
  • Recommendations for new fixture layout
  • Task Lighting (LED)
  • under kitchen cabinets
  • small areas (closets)
  • Large Area Lighting (CFL)
  • entire rooms
  • stairwells
  • hallways

89
RESEARCH TOPIC ELECTRICAL
  • LIGHT FIXTURES
  • Benefits by using Energy Star Qualified Fixtures
  • Use ¼ the energy of traditional lighting
  • Distribute light more efficiently and evenly
    than standard fixtures
  • Many convenient features
  • Cost
  • Comparable to the cost of regular light fixtures
  • LEED vs. Energy Star
  • Energy Star 5 high use fixtures
  • LEED 3 additional fixtures obtains 1.5 points
  • OR
  • Advanced Lighting Package (use only Energy Star
    Fixtures) obtains 3 points

90
RESEARCH TOPIC ELECTRICAL
  • EXHAUST FANS
  • When it is hot
  • Significantly reduces attic temperatures
  • Lowers attic temperature, thus reducing
    temperature in living space and cooling costs
  • Prevents floors from warping and premature
    deterioration of shingles
  • When it is cold
  • Prevents ice dams and condensation which can
    damage rafters, floors, and insulation
  • SOLAR POWERED EXHAUST FANS
  • Do not require hard wire to electrical circuit
  • Self operated when needed
  • Cost Difference
  • Electrical are about 100 for gable or roof
    mounted
  • Solar are at least 300 for roof mounted

91
RESEARCH TOPIC ELECTRICAL
  • PROGRAMMABLE THERMOSTATS
  • AUTOMATICALLY REGULATE HOME TEMPERATURE
  • In summer
  • In winter
  • When occupants are asleep
  • When occupants are away for a period of time
  • Energy Star Quotes / Facts
  • Can save roughly 180 per year with programmable
    thermostat
  • Choose a product that can be set for your daily
    schedule
  • Cost
  • Non-Programmable range from about 18 - 40
  • Programmable range from about 25 - 100

92
RESEARCH TOPIC PLUMBING
  • WHAT?
  • Green plumbing fixtures include . . .
  • Toilets
  • Shower heads/ Bathroom Faucets
  • Washing Machines/Dish Washers
  • Tank less Water Heaters
  • WHY?
  • Simple plumbing upgrades and techniques can
    reduce utility bills and conserve water
    consumption. Not only is it does it benefit costs
    but the environment as well.

93
RESEARCH TOPIC PLUMBING
  • Toilets
  • Types of Flushing Systems
  • Dual Flush
  • Cadet Flush
  • Class 5 Flush
  • Class 6 Flush
  • Energy Star Quotes / Facts
  • Average Flush Rates approx. 3.5gpf
  • Flush rates for newer toilets .08gpf-1.6gpf
    (Saves 4,189g/yr)
  • Saves about 35 of water bill
  • Cost
  • Between 300-400

94
RESEARCH TOPIC PLUMBING
  • Toilets

95
RESEARCH TOPIC PLUMBING
  • Shower Heads
  • Types
  • Low Flow
  • High Powered
  • Multifunction
  • Energy Star Quotes / Facts
  • 1/2gpm can save up to 35,000gals/yr (5people)
  • Lady Bug Adaptor
  • Adjustable valve to conserve water
  • Saves up to 75/2,700gals yearly
  • Cost
  • About 35 can be purchased online

96
RESEARCH TOPIC PLUMBING
  • Bathroom Faucets
  • Main Usages
  • Rinse tooth brush
  • Wash hands
  • Other personal hygiene
  • Energy Star Quotes / Facts
  • Average Flow Rates approx 2.5gpm
  • Newer Faucet Flow Rates can be as low as .5gpm
  • install 1.5gpm
  • Cost
  • Between 150-200

97
RESEARCH TOPIC PLUMBING
  • Washing Machines
  • Types of Washing Systems
  • Steam wash
  • Standard wash
  • Energy Star Quotes / Facts
  • Steam increases temp
  • Accelerated spin to lessen time in dryer
  • Software technology (6th sense)
  • Cost
  • Between 1000-1500

98
RESEARCH TOPIC PLUMBING
  • Dishwashers
  • Energy Star VS Hand Wash
  • saves 5,000 gals of water yearly
  • 40 on utilities
  • 230 hrs of your time
  • Energy Star rated VS Standard Dishwasher
  • use 33 less water
  • can save up to 30yr on utilities
  • Cost
  • Between 700-1000

99
RESEARCH TOPIC PLUMBING
  • Tank less Water heaters
  • Types of Water Heaters
  • Standard
  • Tank Less
  • Energy Star Quotes / Facts
  • More efficient by 20
  • can save up to 120 yearly
  • 2-5gals of hot water per min
  • Less space
  • Cost
  • Standard 600-700
  • Tank less 1200

100
Heating
Research Topic Heating Options
  • Types Heating Options
  • Fossil Fuel
  • Electricity
  • Radiant Heating
  • Boilers
  • Ground Heat Pumps
  • Hybrids (combine heating and cooling with an
    air-source heat pump)
  • Can be Energy Star rated
  • SEER- seasonal energy efficiency
  • Economical Choices
  • Electric
  • Gas
  • Hybrids

101
Hybrids (AC/Heating)
Research Topic Heating Options
  • Hybrids combine heating and air conditioning
  • Uses a heat pump
  • Performance issues in extreme temperatures
  • Relatively inexpensive way of heating and cooling
    a home Carriers Comfort
  • Series is SEER rated 15
  • Are Energy Star rated
  • Heating Seasonal Performance Factor (HSPF)-
    rating system specific to heat pumps these rate
    at 8.5
  • Runs on electricity

102
Gas Furnaces
Research Topic Heating Options
  • Most common method of heating a home
  • Should have a high-percentage efficiency rating
  • 80 and above
  • Most manufacturers produce high-efficiency
    furnaces,
  • Many of the high- efficiency furnaces are also
    Energy Star rated
  • Readily available- competitively priced
  • Costs
  • .74-1.45 cents/dollar per therm

103
Electric Furnaces
Research Topic Heating Options
  • Expensive- up to 50 more
  • Much harder to find available products
  • Can be high-efficiency/Energy Star Rated
  • Fuel isnt as expensive as gas right now but
    that may change in the future
  • Costs
  • 14 cents per kilo-watt hour
Write a Comment
User Comments (0)
About PowerShow.com
