CTC-275 Construction Methods

1
CTC-275 Construction Methods

• Intro Earthwork

2
Get SUNYIT email account
3

• Many different ways to build same building
• How many ways can you build a ham and cheese
  sandwich?
• Types of ham, bread, cheese, toppings

4

• Construction methods change when
• Materials change
• Why thatch roofs?
• Why teepees and long houses?
• How important where nails to building
• Equipment changes
• Horses to steam engines to today
• Erie Canal was dug with shovels and rock sleds
• Steam engines were stationary with belts going
  from pulleys to the engine

5
House Construction

• What materials can be used to build a house and
  what equipment is required
• Wood hammers, saws, drills, squares
• Can also use engineered wood
• What has happened to lumber in last 100 years?
• Concrete either cast in place, precast, or
  shotcrete
• Can be above ground or below
• Steel
• Stone
• Brick
• Adobe only need forms
• Haybales

6
House Construction

• Wooden houses can be constructed using three
  methods
• 1. Balloon Framing
• 2. Platform Frame
• 3. Modular assembly line

7
Questions

• What made skyscrapers possible?
• How old is concrete and who first used it
• How old are nails?

8
Construction Order

• There is an order to all projects
• What activities get done first
• What activities need to be done in a specific
  order
• What activities can be done at any point in time

9
Construction Order

• Above ground Swimming pools
• Remove topsoil level area 3 larger that pool
  diameter
• Rake soil to remove rocks and roots
• Layout bottom track
• Dump sand inside pool area
• Level track
• Layout wall parts
• Roll wall and put on J channel and top rail
• Bolt wall, attach skimmer

10
Construction Order

• Swimming pools
• Spread sand inside pool wall rake tamp
• Attach wall uprights
• Attach liner to J channel
• Use vacuum to suck liner to wall
• Plumb sand filter pump together w/ skimmer
  return line
• Attach top coping
• Add water
• Cut out skimmer and return

11
Construction Order

• Buildings
• Clear site
• Foundation work
• Framing Siding
• Roofing
• Windows and Doors
• Siding
• Electrical - rough
• Plumbing - rough
• Insulation
• Wall finishes

12
Construction Order

• Buildings
• Foundation slab
• HVAC
• Ceilings
• Electrical finish
• Plumbing finish
• Paint/wall coverings
• Flooring
• Landscaping
• Pavement

13
Construction Order

• How far along do you need to be before starting
  next activity?
• On a house probably one at a time
• On a 1 floor bldg probably 1 activity at a
  time but depends on size
• Skyscraper 1 activity per floor

14
Construction Order

• Highways
• Centerline survey
• Clearing
• Bridge work
• Centerline survey
• Earthwork to get to bottom of subbase elevation
• Centerline survey
• Subbase placement
• Centerline survey
• Base placement

15
Construction Order

• Highways
• Centerline survey
• Drainage
• Utilities (lights etc)
• Pavement base course
• Pavement wearing course
• Side slope grading
• Guard rail
• Lights and signs
• Pavement Markings

16
Construction Order

• Move from one end of project to the other with
  each activity
• Have multiple activities happening at any time
• Surveying is a full time activity

17
Start at beginning

• Earthwork
• Moving rock or soil from one location to another
• Processing it to meet location, elevation,
  density moisture content, etc
• Efficient earthwork requires accurate estimating
  of work quantities and conditions, proper
  equipment, competent job mangement

18
Equip Selection

• Proper equipment has major impact on efficiency
  and profitablility
• Can equipment perform required work
• Also look at profitablility, other uses for
  equipment, return on investment, availability of
  parts and services, effect of downtime on other
  construction equip

19
Equipment planning

• Need to plan to effectively use equipment
• Production of equipment
• Production Volume per cycle/cycles per hour
• Cycles per hour is based on efficiency of equip
• Swing angle and elevation to truck bed
• Soil hardness and Soil type
• Room to manuever

20
Equipment planning

• Cost per production unit equip cost per working
  hour/equip production per hour
• Table 2-1 show efficiencies

21
Soil And Rock

• General Soil Characteristics
• Trafficability ability of soil to support
  weight of vehicles under repeated traffic
• Controls traffic on unimproved access roads
• Also gives measure of how earthmoving equip will
  operate
• Primarily function of moisture conditions and
  soil type
• Loadability how difficult to excavate and haul
  a soil
• Granular high
• Compact cohesive - low

22
Soil And Rock

• Unit Soil Weight
• Pounds /cy
• Depends on soil type, moisture content, degree of
  compaction
• Relation between soil weight and bearing capacity
• So soil weight is used as a measure of compaction
• Soil weight is also a factor in hauling

23
Soil And Rock

• Moisture Content() (moist wt dry wt)/dry wt
  X 100
• Soil sample 120
• Dry weight 100
• MC (120-100)/100X100 20

24
Soil ID

• Boulders
• Cobbles over 3 diameter
• Gravel 1/4 3 diameter
• Sand 0.7mm (200 sieve) ¼ diameter
• Silt 0.002 0.7 mm
• Clay less than 0.002mm
• Organic Matter decaying organic matter
• Soils classified using these types

25
Soil Classification Systems

• Unified System
• All material 3 removed
• Separates soils into two main groups- Fine
  grained and coarse grained
• Table 2-2, Figure 2-1
• AASHTO System
• 7 classes of soil
• Based on suitability of soil for subgrade
• Table 2-3
• Table 2-4

26
Soil Volume Change Characteristics

• Soil Conditions
• Bank material in natural state before
  disturbance Bank cubic yard
• Loose material that has been excavated or
  loaded loose cubic yard
• Compacted material after compaction compacted
  cubic yard

27
Soil Volume Change Characteristics

• Swell
• Soil increases in volume when it is excavated
• Soil grains are loosened and air fills voids
• So 1 unit of soil in bank is smaller than the
  soil once it is excavated
• Swell() ((weight/bank vol)/(weight/loose
  vol)-1)X100
• Soil wt 2800/cy in bank
• Soil wt 2000/cy loose
• Swell ((2800/2000)-1)X100 40

28
Soil Volume Change Characteristics

• Shrinkage
• Soil decreases in volume when it is compacted
• Air is forced out of soil
• So 1 unit of soil compacted is smaller than the
  soil in the bank or once it is excavated
• Shrinkage() (1-(weight/bank vol)/(weight/compac
  ted vol))X100
• Soil wt 2800/cy in bank
• Soil wt 3500/cy compacted
• Shrinkage (1-(2800/3500))X100 20

29
Soil Volume Change Characteristics

• Load and Shrinkage Factors
• Need a common unit of measure for earthwork (get
  rid of calculations )
• Can use any of the three measures
• Called pay measure in contract
• Load factor 1/(1swell)
• How many BCY can fit on a truck
• LCY Load Factor BCY
• Shrinkage factor 1- shrinkage
• How many BCY needed for CCY
• BCY Shrinkage factor CCY

30
Soil Volume Change Characteristics

• How many 10cy truck loads of soil 1000CCY ?
• Swell 30
• Shrinkage 25
• BCY CCY/(1-shrinkage)
• LCY BCY(1Swell)
• LCY CCY/(1-shrinkage)(1swell)
• LCY 1000/(0.75)1.30 1735 LCY
• Truck loads LCY/10 174 truck loads

31
Spoil Banks

• Material removed from excavation
• Longer than wide spoil bank triangular x
  section
• Conical spoil pile
• To determine the size of the bank or pile need
  swell and angle of repose for soil
• Angle of repose angle that soil on side of bank
  naturally form
• Varies with moisture content and type
• Table 2-6

32
Spoil Banks

• Spoil bank
• Vol X sect area x length
• B (4V/(lx tan R))1.2
• H (B x tan R)/2
• B base width
• H height
• L length
• R angle of repose
• V volume

33
Spoil Banks

• Spoil pile
• Vol 1/3 p(D/2)2 X H
• D (7.64V/tan R)1/3
• H D/2 x tan R
• D diameter of base
• H height
• R angle of repose
• V volume

34

• How long would a spoil bank for 40000 cy be if it
  was 100 wide? Angle of repose 30 deg
• How high can a spoil pile 50 in diameter be if
  the angle of repose 35 deg?
• How many cy can it hold?

35
Estimating earthwork

• 3 types of excavations
• Small pit
• Trench
• Large areas
• Roadways
• Find cut and fill using cross sections
• Mass diagram

36
Roadways
37
Estimating earthwork

• Pit Excavations
• Area X average depth
• Depending on size and ground may break into
  several geometric shapes to get volume
• Give bank volume

38
Estimating earthwork

• Trench Excavations
• V x sectional area X length
• Take x sections every 50 feet and compute volumes
  between x sections
• When estimating dont forget the angle of repose
  and OSHA

39
Estimating earthwork

• Large Areas
• Use a grid to find volume
• V A(average depth)
• For a rectangle
• V (LxW)(h1h2h3h4)/4(1/27) cy

40
Estimating earthwork
