Title: Company and Product Line Overview


1
Company and Product Line Overview
2
Contents
  • IMC Company Overview
  • Management, History and Strategy
  • Product Line Overview
  • Core Products
  • Managed Optical Ethernet (FTTx) Devices for
    Service Providers
  • Media Converters for LAN/WAN Applications
  • Includes fiber mode converters
  • Element Management Software (iView2)
  • Additional Product Categories
  • Ongoing Product Innovations/New Product Line
    Extensions

3
Company Overview
  • Founded 1988, privately held
  • Offices in Southern California (HQ), Clearwater,
    FL, Washington DC Metro, and Aarschot (Brussels),
    Belgium
  • 70 employees
  • US-designed and made products

4
IMC Management
  • Jerry Roby Chairman/CEO
  • Michael Dailey President/COO
  • Jeff Murray VP Operations
  • Tom Craft VP of Engineering

5
Ethernet Innovation
  • 1st Ethernet Media Converters
  • 1st SNMP-Managed Media Converters
  • 1st Compact Media Converters
  • 1st Remotely End-to-End Managed Media Converters
  • 1st 10/100 Mbps Media Converter
  • 1st Gigabit Ethernet Copper-to-Fiber Media
    Converter
  • 1st USB-Powered Media Converter
  • 1st Modular Ethernet Repeaters

6
Market Focus
  • Wholesale Distribution (not End-Users)
  • Channel Marketing Program
  • Strong OEM / Private Label
  • Dependable partner
  • Government / Education / Military
  • Carriers Telcos / Internet Access Providers /
    ISPs / Managed Service Providers

7
Product Strategy
  • Innovative LAN/WAN connectivity products
  • Develop easy to use, cost-effective solutions for
    real-world networking problems
  • Solutions provider, not box mover
  • Not commodity hubs, NICs, switches
  • Not competing with Cisco or Nortel

8
Company Expertise
  • Extensive Fiber Optic and Copper Ethernet
    experience
  • Fiber Consulting Services
  • Fiber to the x (FTTx) Optical Demarcation
  • SNMP Management
  • Flexible towards customer requirements
  • ISO 9001 Manufacturing

9
Fiber Consulting Services (FCS)
  • Free Engineering consulting service offered by
    IMC Networks
  • Assists customers with
  • questions about products that will enable network
    expansion
  • designing network applications
  • addressing security concerns
  • determining the best solution to meet network
    needs
  • Email fcs_at_imcnetworks.com

10
Target Markets Carrier Versus Enterprise
  • Two Main Project Types
  • FTTx/ISP Optical Demarcation - 40
  • Premise-Based Media Conversion - 60

IMC Networks 2006
11
Target Market Comparison
  • FTTx/ISP Optical Demarcation
  • Project-based Longer Sales Cycle
  • Typically Rack-Mounted, SNMP- Managed hardware
  • Intelligent CO and Customer side hardware
  • SNMP, 802.1p, q (QoS), VLAN Tagging
  • Growing Market
  • i.e. Triple-Play Voice, Video and Data Services
  • Low-Cost Competitors Omit Required Features
  • Premise-based/Enterprise Media Conversion
  • Steady, Ongoing Business
  • Unmanaged Hardware
  • Mix of Standalone and Rack Mount
  • Sales Primarily Through Distribution
  • Commoditized Market with Low Cost Asian
    Competitors

12
What is Media Conversion?
  • Media converters are devices that convert one
    cable type (media) to another - e.g.
  • Twisted pair (Cat 5, 5e, 6) to fiber
  • Fiber to fiber mode converter (single- to
    multi-mode)
  • Coax (10Base-2) to twisted pair
  • Converters can be
  • Ethernet based
  • Layer 1 (media) e.g. copper/fiber
  • Layer 2 (media and speed) e.g. copper/fiber
  • 10 Mbps HDX to 100 Mbps FDX
  • Protocol Independent Mode converters, T1/E1,
    DS3/E3
  • Majority of converters sold are copper to fiber

13
Four Main Types of Conversion
Cable Type Conversion
100BaseTX
100BaseSX
100BaseFX
10Base2
10BaseT
1000BaseT
1000BaseSX
10BaseFX
1000BaseLX
Fiber Mode Conversion
Speed Conversion
100Mbps
1300nm
10Mbps
1000Mbps
850nm
1310nm
Duplex Mode Conversion
1550nm
- Multi-Mode Fiber
Full Duplex
Half Duplex
- Single-Mode Fiber
14
Where is Fiber Used?
  • Point-to-point high speed networking, e.g. FTTB
    (Building) or FTTH (Home)
  • Inter-office, e.g. short haul FTTD (Desktop)
  • Switch-to-switch links, e.g. collapsed backbone
    or star networks
  • Inter-building links, e.g. office/factory
  • Leased fiber for long distance transmission, e.g.
    FTTC (Curb)
  • Where the protocol only works with fiber, e.g.
    Fibre Channel

15
Types of Fiber
  • Multi-mode Fiber (MM)
  • Typically 50 or 62.5 micron core
  • Will work with low cost optics (LED)
  • High loss, low bandwidth, short distance
  • Relatively easy installation
  • Single-mode Fiber (SM)
  • Typically 9 micron core
  • Single strand of silica core
  • Works with LASER based optics
  • Low loss, high-bandwidth
  • Higher skilled installers needed

16
Types of Fiber (cont.)Single-Strand Fiber
  • Normally, IT equipment uses two strands one to
    receive light, the other to send
  • Now, advances in optics allow users to
    send/receive using only one strand
  • Why do this?
  • Double the data capacity of cable
  • Mix protocols over the existing fiber plant e.g.
    Ethernet over one strand, DS3/E3 over the other
  • Single-Strand versions are now available for most
    of IMC Networks products

17
Single-Strand Fiber (cont.)
  • How does it work?
  • Light is transmitted at TWO different wavelengths
    (think Wave Division Multiplexing, or think TWO
    different colors)
  • In one direction light _at_ 1310nm is used, in the
    return direction light _at_ 1550nm is used

18
Coarse Wave Division Multiplexing (CWDM)
  • Increase the capacity of existing fiber by
    multiplexing multiple optical carriers having
    different wavelengths, over the same fiber strand
  • CWDM is typically eight or fewer wavelengths per
    strand
  • Wider 20 nm channel spacing allows use of
    uncooled lasers, lowering manufacturing cost
  • CWDM versions are now available for a variety of
    IMC Networks products, including SFPs. Call for
    info.

19
Why Use Media Converters?Benefit 1 - Price
  • Optical ports on network hardware are normally
    more expensive than media converters.
  • Instead of an expensive switch with a fiber port,
    buy a fiber to copper media converter and pair it
    with a less expensive copper switch.
  • Preserve investments in expensive fiber hardware
    such as server blades, by using media converters

20
Why Use Media Converters?Benefit 2 - Flexibility
  • Easily integrate new fiber types and technologies
    with existing network hardware
  • Combine hardware designed for different fiber
    protocols onto the same network
  • Combine multiple network segments running
    different rates onto the same switch
  • Extend copper LAN segments over higher
    performance fiber links
  • e.g. Exceed the 100m range limitation of Ethernet
  • Enjoy the higher security of fiber

21
Why Use Media Converters?Benefit 3 - Simplicity
  • Simplify network cabling and protocol upgrades
  • Incremental upgrades rather than full scale
    replacement
  • Media conversion provides the perfect demarcation
    point between optical and electrical
  • Installer terminates the fiber
  • Support engineer configures the switch
  • Both installer and support engineer
  • only deal with what they understand

22
Core Product Focus FTTx Fiber To The x
  • Fastest growing subset of the Media Conversion
    market
  • Two types
  • Fiber to the neighborhood, curb or building
    (FTTN/FTTC/FTTB)
  • Fiber to the premises or home (FTTP/FTTH)

23
FTTx/ISP Market
  • Sales into operators/ISPs/FTTx outfits are
    getting stronger
  • Current product line is a pretty good fit as to
    what operators want to achieve (FTTB)
  • IMC is less expensive than using a fully
    functional switch from a major vendor
  • Far Eastern solutions do exist, but have proved
    unpopular
  • Risk, support, difficult to work with, pricing is
    not a critical issue
  • In most cases, its not the incumbent were
    selling to, but the newer operators

24
FTTx/ISP Market (cont.)
  • FTTx/ISP market is priority 1
  • Sales Are Driven by
  • Launching Applicable Product Lines
  • Educating the Distribution Base
  • Developing Reseller Program
  • Enhancing the IMC Web Site

25
FTTx Market Segments by Operator
  • Incumbent local exchange carriers
  • Competitive or emerging carriers
  • Municipalities, utilities, real estate developers
    and other operators
  • CATV operators

26
FTTH Worldwide
  • Europe From under 400,000 in 2003, the number
    of Western European homes subscribing to FTTH
    services will grow by 60 a year until at least
    2008
  • US Verizon passed 2.5 million homes in 2006 with
    FTTH, and expects that number to reach 3 million
    homes in 2007
  • US ATT (SBC) pledged to rapidly expand its
    Project Lightspeed initiative to 18 million homes
    within three years

Chris Lewis, Senior Vice President of Research,
EMEA, Yankee Group
27
FTTx in Asia Pacific
  • In China, FTTC/N LAN is proving to be a
    cost-effective way to introduce broadband to
    homes.
  • Japan has built up high-speed network
    infrastructures extending fiber all the way to
    the home to deliver a wide array of voice, data
    and multimedia applications including
    increasingly popular VoIP service.
  • In South Korea, service providers have found that
    online gaming, Video-On-Demand, and e-commerce
    are moneymaking applications that are well suited
    to the increased bandwidth of FTTx.

28
FTTx in Asia Pacific (cont.)
  • Five major countries in Asia -- Japan, South
    Korea, China, Hong Kong, and Australia -- are the
    fastest growing regional market for residential
    fiber broadband.
  • Asia as a whole, particularly the Australian and
    China markets, has tremendous growth potential
    for service and equipment providers to collect a
    portion of the flourishing FTTX market.

Asia/Pacific Embraces Residential FTTx
Services In-Stat Report January 10, 2006
29
FTTx Access Products Intelligent Solutions for
the Networks Edge
  • FiberLinX-II Family
  • Point to Point Managed Optical Ethernet
    Connection
  • For high-speed Internet, Ethernet Private Line
    and Transparent LAN services
  • SNMP-Managed, MEF Certified
  • AccessEtherLinX
  • Layer-2, VLAN-based secure Multi-user Optical
    Access Edge Device
  • Performs a conversion from fiber to twisted pair
    LAN
  • Rate limiting/bandwidth feature on all ports
    enables service providers to offer Ethernet
    Private Line and Transparent LAN services
  • 3 or 4 customer ports (AE/3 or AE/4)

FiberLinX-II
AccessEtherLinX/4
30
iMcV-FiberLinX-II
iMcV-FiberLinX-II Module
  • An Optical Demarcation Device offering advanced
    media conversion and management features
  • Allows copper and fiber networks to be seamlessly
    integrated
  • Full SNMP management control of remote devices
  • Next generation of FiberLinX family first
    deployed in 1999

31
iMcV-FiberLinX-II
iMcV-FiberLinX-II Module
  • Advanced VLAN extra-tagging (Q-in-Q) support
    keeps management and customer traffic segregated
  • User selectable Ethertypes
  • Cost-effectively and transparently extend LAN
    traffic over fiber
  • Efficiently monitor and maintain service level
    agreements (SLAs)
  • Currently available in 1x9 versions (SC, ST
    connectors)
  • All copper and SFP versions coming in Q2 2007

32
Unified Management Agent (UMA)
  • The Unified Management Agent (UMA) allows
    operators to use a single IP address to centrally
    manage FiberLinX-II modules installed in an
    iMediaChassis chassis.
  • Leverages FiberLinX-IIs on-board intelligence
  • Also allows management of remote FiberLinX-II
    modules connected to the modules in the chassis
  • Allows central management and firmware upgrades
    over multiple devices.

33
iMcV-FiberLinX-II Application
34
IMC Networks Successes iMcV-FiberLinX-II
  • Major US Cable MSO with national fiber network,
    deploying FiberLinX as a managed demarcation
    unit.
  • Major US Optical Ethernet Provider for Metro
    Carriers has deployed a complete FTTx solution
  • FiberLinX provides the managed CPE end point
  • Belgian-based fiber optic network operator using
    FiberLinX in conjunction with Cisco core to
    provide a fully managed MAN

Common themes Remote management, CPE monitoring
35
IMC Networks Successes iMcV-FiberLinX-II (cont.)
  • Chilean ISO 90012000 certified company
    delivering voice, leased line data, Internet
    access
  • Chilean Reseller/Integrator providing hardware
    and integration services to Latin Americas
    leading voice and data carrier
  • Products used include iMcV-T1/E1, McBasic and
    iMcV-LIM
  • Benefits of working with IMC Networks
  • Product performance and stability versus
    competition
  • Reduction of operating costs
  • Fiber Consulting Services (FCS)

36
iMcV-Giga-FiberLinX-II
  • Gigabit speed version of iMcV-FiberLinX-II
  • Requires two slots
  • Provides single conversion from 10/100/1000
    Copper to 1Gbps fiber
  • Offers choice of fiber or SFP (1 or 2) uplink
    ports
  • DB-9 serial port for local management

37
IE-MiniFiberLinX-II
  • Smallest fiber optic demarcation device on the
    market.
  • Enables delivery of high-speed Internet, Ethernet
    Private Line and Transparent LAN services over
    fiber to customer premises.
  • Also acts as copper to fiber media converter
  • Allows lower-cost copper-port switches to connect
    to the fiber network
  • Functions as a CPE solution
  • Pairs with iMcV-FiberLinX-II module for a
    complete host/remote solution

38
IE-MiniFiberLinX-II
  • Industrial Ethernet means
  • Extended power options
  • 802.3af PD
  • 5VDC (external power brick)
  • External 5VDC to 60VDC
  • DIN rail mountable
  • Supports operating temps of -45C to 70C
  • Robust management
  • Operators can monitor the entire link between two
    locations.
  • Management traffic and customer data are
    isolated.
  • QoS Support
  • IEEE 802.1p-based packet prioritization

39
IE-MiniFiberLinX-II Application
  • Solar panels power remote 802.3af-compliant (PSE)
    Access Point (AP)
  • AP sends power and data over Ethernet to
    IE-MiniFiberLinX-II
  • IE-MiniFiberLinX-II delivers data over fiber to
    Central Office

40
AccessEtherLinX Family
  • Two Versions
  • AccessEtherLinX/4 4x 10/100 ports, 1x fiber,
  • AccessEtherLinX/3 3x 10/100 ports, 1x fiber
  • Offers rate limiting/bandwidth on all ports
    independently
  • Write/read Layer 2 VLAN tags on downlinks
    (perfect for traffic classification)
  • Data can be switched via tagging
  • Up to 4,094 VLAN ID tags per downlink
  • Write 802.1p bit on downlink traffic, two
    priority queues internal in the device, passes
    p-tag
  • FTTE (enterprise access) and MAN networks
  • Internal (/4) and External (/3) power supplies

AccessEtherLinX/4
AccessEtherLinX/3
41
IMC Networks Successes AccessEtherLinX
  • Belgian service provider delivering FTTB access,
    3 copper ports in use (1 x Internet, 1 x VPN, 1 x
    VoIP)
  • Austrian carrier providing FTTB access within a
    building
  • VLAN tagging was a critical feature for traffic
    management
  • UK Office parks Privately owned fiber network,
    sells access to companies based in office parks
  • Swedish Carrier provisioning FTTB services for
    1,500 customers
  • Offering 2Mbps (PRI-ISN) and 10Mbps, 100Mbps
    1000Mbps (Ethernet)

42
IMC Networks Successes AccessEtherLinX (cont.)
  • Swedish Carrier competing with Utfors/Telenor to
    offer FTTB services over the whole of Sweden
  • iMediaCenter/18x (POP) and AEL/4 (CPE)
  • Plans to upgrade CPE links to Gigabit Ethernet in
    2006
  • Croatian Telco deploying FTTB in Zagreb (Croatian
    market liberalized in 2005)
  • Currently, 350 business customers
  • Core switches from Nortel
  • Common themes with AE/4
  • Splitting a fiber and providing secure VLAN
    Tagging
  • Rate limiting (sell bandwidth)
  • 802.1p -VoIP prioritization

43
AccessEtherLinX/4 Application Diagram
44
IMC Networks Media Converters Overview
  • Protocols Supported
  • Form Factors
  • Standalone (CPE)
  • Internal vs. External Power Supply
  • 802.3af PSE Option
  • Industrial Ethernet (IE)
  • Modular (iMcV Series modules)
  • Internal PC Card McPC
  • Chassis Options
  • Managed 6 and 20 slot
  • Unmanaged 1, 4, 8 and 12
  • SNMP Management
  • iView2

45
Current Protocols Supported
(T1) (E1) Ethernet E3
T3/DS3 Fast OC3 OC12 Fibre
Channel (1.544) (2.048) (10)
(34) (54) Ethernet (155) (622)
(1.062)
(100)
Gigabit Ethernet


(1.250)
Typical LAN/WAN Protocol
Typical MAN/WAN Protocol
From 1.5 Mbps to 1.2 Gbps, All Solutions are
Offered
46
Standalone Media Converters
  • Standard Size (McBasic)
  • PoE (802.3af) and non-PoE versions
  • Internal Power Supply
  • Miniature (MiniMc)
  • External Power Supply
  • Industrial Equipment (IE - extended temperature
    and enhanced powering options) and non-IE
    versions
  • Multi-port Customer Premise Equipment (CPE)
    (AccessConverter/3)

47
Standalone Conversion The McBasic Family
  • Rugged, standalone chassis with internal power
    supply
  • Six year warranty
  • Link loss and fiber alert, notify users of silent
    failures
  • LEDs indicate link and activity for
    troubleshooting
  • Covers all types of Ethernet
  • 10Mbps, 10/100Mbps, 100Mbps, 1000Mbps
  • Both multi-mode and single-mode fiber (SC or ST)
  • Single strand fiber (SSF), single-mode available
    on 100Mbps and Gigabit products

48
Product Line Extension Power Over Ethernet
  • PoE Power over Ethernet
  • A method by which DC power is supplied via
    traditional Cat 5 (or higher) cabling
  • The Standard IEEE 802.3af (ratified June 2003)
  • Pre-standard - Several vendors developed PoE-like
    equipment e.g. Cisco (Inline Power), PowerDsine
  • (Power over LAN) etc.
  • Two types of equipment
  • PSE Power Sourcing Equipment i.e. supplies power
  • PD Powered Device i.e. receives power

49
PoE Benefits
50
PSE-McBasic
  • 100 Mbps Fast Ethernet Media Converter
  • Power Sourcing Equipment (PSE)
  • RJ-45 supplies power (45 VDC, 15w) to an end
    device
  • Typical applications- convert fiber to copper
    AND power a PoE compliant
  • VoIP Telephone
  • 802.11 Access Point
  • IP Video camera

51
PSE-McBasic Installation Example
52
PD Switch
  • Uses 802.3ah PoE to receive its power via
    Twisted-Pair cables
  • Eliminates need for costly separate power runs to
    device
  • Provides a dedicated port for High Priority
    applications
  • Increases network range by an additional 100m
  • Inexpensively increases port density

PD Switch
53
PD Switch Application
54
MiniMc Product Line
55
MiniMc Miniature Standalone Media Converter
  • Low cost, high quality, zero intervention
  • Uses switching technology to negotiate the copper
    link, copper supports auto-MDI/MDI-X
  • Fiber forced to 100Mbps Full Duplex
  • Multi-mode, single-mode and single-strand fiber
    is offered
  • External power supply

Plug in and forget!
56
MiniMc Chassis and Powering Options
  • Power the MiniMc Converter in one of three ways
  • External power supply
  • Via an 18 slot chassis (IE-PowerTray/18 extended
    temperature performance, AC or DC options
    available)
  • Use a USB power supply cable
  • Unique feature only applicable to TP-TX/FX

57
MiniMc Application Manta Cam
  • Integrated with Sony IP Camera for underwater
    operation
  • Camera has been operating 24x7 in the Monterey
    (CA) Aquarium for three months
  • 99.9 availability
  • Its rugged, reliable construction makes the
    MiniMc ideal for such applications

58
Gigabit Speed MiniMcs Switching or Fixed Speeds
  • Next Generation Gigabit media converters
  • Two Families
  • MiniMc-Gigabit Copper and FX ports are 1000 FDX
  • Giga-MiniMc 10/100/1000 switching to 1000FDX
  • Smallest Gigabit converters on the market
  • Low Cost Use external power supply or install
    into the PowerTray/18

59
Giga-MiniMc Application
60
IE-Giga-MiniMc
  • Operates in harsh temperature environments
  • -31 to 158F (-35 to 70C)
  • Provides true Gigabit speed over copper and fiber
  • 10/100/1000 Mbps switch
  • Compact and Flexible Design
  • Smallest on the market
  • Din Rail mountable
  • Available now

IE-Giga-MiniMc
61
IE-Giga-MiniMc Application
62
AccessConverter/3
  • Three port fiber to copper media converter
  • Fiber mounted at the REAR of the unit (for fiber
    management unit - FMU)
  • Typical applications
  • FTTH Currently, 1,500 units installed in Sweden
  • Share a single fiber run between PC, Access Point
    and IP camera

63
Product Line Extension Industrial Ethernet (IE)
64
What is Industrial Ethernet (IE)?
  • An IMC Networks term that applies to hardware
    that is designed to work in rugged or industrial
    environments
  • Supports extended operating temperatures (less
    than 0C or greater than 50C)

65
IE-MiniMc
  • Classic MiniMc functionality i.e. 10/100 copper
    to 100 fiber.
  • Multiple power options
  • 802.3af-compliant Powered Device (PD)
  • 5VDC (external power brick)
  • External 5VDC to 60VDC
  • Inbuilt sensor to avoid overloading
  • DIN rail mountable
  • Supports operating temps -35C to 70C

66
IE-ModeConverter
  • Modular, compact mode converter designed for use
    with two SFPs
  • Mix and match standard single and multi-mode
    fiber, single strand fiber and CWDM wavelengths,
    just by replacing the SFPs
  • Multiple Powering options
  • DC power, can be cascaded
  • AC power with optional DC and AC power, with
    optional AC adapter
  • Multiple Mounting Options
  • DIN-rail mounting capabilities for added
    flexibility
  • Mounts in IE-PowerTray/18, for high density
    deployments
  • Extended temperature performance of -35 to 70C
    (0 to 50C with AC adapter)

IE-ModeConverter
67
IE-ModeConverter
68
Modules Overview
  • Both Managed and Unmanaged Modules Available
  • Managed designated by iMcV prefixes
  • i intelligent
  • Mc Media Converter
  • V Vertical
  • i.e. iMcV-FiberLinX
  • Unmanaged Just Mc
  • i.e. McLIM, McPIM

Cards are installed horizontally in
iMediaChassis/3 and /6
69
iMcV Managed Modules
70
A Wide Range of Available Modules
  • Multiple Managed Conversion and Mode Types
    Include
  • Copper to Fiber
  • TDM-Based Protocol Independent Converters
  • T1/E1/J1 or DS3/E3 to Ethernet Conversion
  • Gigabit Conversion and All Combinations of Lower
    Ethernet Speeds
  • Fiber to Fiber
  • Mode Converters S2MM, S2SM, M2MM
  • Wave Division Multiplexing (WDM)
  • Coaxial (BNC) to Copper 50 and 75 Ohm impedance
  • And More Fiber Options
  • Single Strand Fiber
  • Coarse Wavelength Division Multiplexing (CWDM)
  • SFP Ports

71
TDM Extension iMcV-T1/E1/J1
  • Smallest T1/E1/J1 converter on the market
  • Installs in single- or multi-slot chassis
  • Supports in-band, remote SNMP-management, without
    the need for an SNMP chassis at the remote end
  • Single-strand fiber support
  • Mix data and voice over a duplex fiber pair
  • Must be deployed in pairs
  • RJ-48 copper interface
  • Repeater or LineTerm versions available

iMcV-T1/E1/J1 Module in MediaChassis/1
72
TDM Extension iMcV-T1/E1/J1 (cont.)
  • Typical customers
  • Telcos offering T1/E1/J1 services over fiber
  • Companies renting dark-fiber can put their
    internal PBX voice traffic over a spare fiber or
    fiber strand (SSF)
  • Break the T1/E1/J1 copper distance limitations by
    using single-mode fiber

73
TDM Extension iMcV-DS3/E3/STS-1
  • High-speed coaxial-to-fiber optic converter
  • DS3/STS-1 US standards (45Mbps), E3 European
    (34Mbps)
  • Extends transmission distances of copper-based
    router and ATM switch interfaces
  • DS3/E3 is the next step up from T1/E1 and it
    provides large businesses with more bandwidth
  • Must be deployed in pairs
  • Repeater or LineTerm versions available

74
iMcV-DS3/E3/STS-1 Application Remote PBX
Extension over Fiber
75
Gigabit Conversion iMcV-Giga-MediaLinX
  • Triple speed conversion
  • Convert 10 Mbps, 100 Mbps or 1000 Mbps copper to
    1000 Mbps fiber
  • Module installs into an iMediaChassis or
    standalone chassis
  • Typical applications
  • Used as both a speed AND media converter
  • Offers customer a future proof upgrade
  • Start today at 10 or 100Mbps, upgrade to 1000Mbps
    tomorrow

76
iMcV-Giga-MediaLinX (cont.)
  • Copper Port Can be auto-sense (default), hard
    coded or configured for selective advertising
  • Fiber Port 1000 Mbps Full Duplex (default), or
    Half-Duplex
  • Configure via dip switches or via SNMP

77
PC Card Converter McPC
  • Installs into PCI or ISA slot, for clutter-free
    conversion
  • More compact than a standalone media converter
  • Ideal for Fiber to the Desktop (FTTD)
    applications
  • Connect to the PCs Ethernet jack with a very
    short cable
  • Supports UTP to fiber or coaxial media
    conversions for a variety of Ethernet data rates
  • 10, 100, 10/100 Switching, 10/100 Autosensing,
    Gigabit

78
Fiber Mode Converters
  • Protocol-independent, physical layer fiber mode
    converters
  • Connect dissimilar fiber types or wavelengths
  • Ex Extend multi-mode switch interfaces over
    single-mode fiber cabling up to 100Km.
  • Three versions
  • Single- to Multi-Mode
  • Single- to Single-Mode
  • Multi- to Multi-Mode

79
Wavelength Division Multiplexing (WDM) Modules
  • Passive, 2-channel WDM technology virtually
    doubles existing duplex fiber capacity
  • Speed Protocol independent, supports 1310 nm
    and 1550 nm single mode fiber
  • Ideal for combining legacy ATM circuits and
    Gigabit Ethernet over same fiber pair
  • Two Versions
  • iMcV-WDM Module
  • Standalone WDM Chassis

WDM Chassis
iMcV-WDM Module
80
WDM Application
The above diagram illustrates how two fiber
sources (1310nm and 1550nm) can be multiplexed
onto a single fiber pair.
81
Unmanaged Converter Modules
  • Mc-series designed for MediaConverter Series
    Chassis
  • Three Families
  • McPIM 10Mbps Copper to Coax or Fiber
  • McLIM 10/100 Copper to 100Mbps fiber
  • McGigabit 1000Base-T copper to 1000Base- LX/SX
    Fiber

McGigabit Unmanaged Module
82
Chassis Overview
83
iMediaChassis/20 20 slot
  • i means intelligent i.e. managed
  • 20-slots for Modules, 1-slot for SNMP
  • All boards are hot swappable
  • Settings are preserved when SNMP module is
    exchanged
  • Supports SNMPv1 or SNMPv2c, and telnet
    capabilities
  • Bigger hot-swappable power supply units (400W AC
    or 300W DC)
  • Monitor fan speed and dual temperature zone
  • User replaceable fans
  • Last gasp alarm
  • Operational temperature up to 50C

84
iMediaChassis/6 6 slot
  • 6-Slot Managed Chassis
  • Offering dual PSU (mix match AC DC power
    supplies in same chassis)
  • Support for six modules and SNMP board
  • Targeted users
  • More demanding environments
  • Telco grade solutions (NEBS-III pending)
  • Compatible with ALL existing iMcV modules

85
iMediaChassis/3
  • Rack-mountable 1u high
  • Support for up to 3 modules
  • SNMP-manageable with use of SNMP module
  • Single or dual power supplies for versatile
    powering options
  • AC
  • DC
  • AC/DC (New)
  • 2DC (New)
  • 2AC (New

86
MediaChassis/1 and /2
  • Unmanaged chassis for iMcV, but supports
    management of any modules with onboard logic (eg.
    FiberLinX)
  • Mix and match iMcV slide-in converter modules
  • Internal AC or DC power options
  • Wall mount and rack mount options

87
IE-MediaChassis
  • Single slot chassis for IE-iMcV modules
  • Offers many of the same features as IE-MiniMc
  • DIN rail mounting
  • Extended temperature -40C to 70C depending on
    module
  • Multiple power options
  • AC Adapter with 5VDC output (included)
  • 7 - 50V DC terminal block

88
IE-MediaChassis/2-DC
  • 2-slot chassis for IE-iMcV modules
  • Operates in harsh temperature environments
  • -31 to 158F (-35 to 70C)
  • DC Power supply

89
MediaConverter Chassis Series
  • Unmanaged media converters
  • Standalone AC power versions
  • MediaConverter/1 and /4
  • Rackmount AC or DC versions
  • AC MediaConverter/8 or /12
  • DC MediaConverter/12
  • Use with unmanaged Mc modules (McLIM, McPIM,
    McGigabit)

90
Network Management a Critical Advantage
91
- What is it?
  • A Simple Network Management Protocol (SNMP) -
    based element management system
  • Intuitive Graphical User Interface (GUI) format
    provides a real-life representation of all
    installed IMC Networks equipment
  • Enables network managers to configure, update,
    manage and monitor IMC Networks' solutions from a
    central location.
  • Most applications are up and running within 5
    minutes
  • Included free with IMC Networks intelligent
    FTTx, Optical Access and Media Conversion
    solutions.

92
Feature list
93
Customer Advantage
  • No need to purchase other software
  • Advanced trap handling can locate exact point of
    cable failure (90 of all system failures)
  • Full graphical interface
  • Automatic firmware and GUI interface file
    downloads
  • Supports multiple platforms and operating
    systems
  • Windows Standalone (NT/2000/XP)
  • Includes NNM version for HP OpenView
  • Windows Webserver under IIS (NT/2000/XP)
  • Java Version
  • Includes standalone, servlet and NMM versions

94
Features
  • View Hardware Inventory and Profile
  • Module type, fiber type, link status, interface
    name
  • Chassis revision, agent revision
  • Configuration/Troubleshooting
  • Enable/disable ports, configure FiberAlert,
    LinkLoss and Auto-Negotiation
  • View MIB, RMON and Transmission information
  • Program traps for loss of link, loss of power,
    over heating, voltage jitter and authentication
    failure
  • Run loopback tests

Chassis, module, port number and port admin
name are returned within the TRAP frame
95
Features cont.
  • View Environmental Information
  • Internal temperature, voltage load, fan speed
  • Configure Managed Services
  • Set Base VLAN Priority
  • Configure protection against broadcast storms
  • Bandwidth management
  • Set QoS parameters

FiberLinX-II, IE-MiniFiberLinX and
AccessEtherLinX/3 /4 only
96
GUI
Network Outline
97
SNMP Module
98
Advanced Module AccessEtherLinX/4
99
SNMP Trap configuration
100
Additional Product Categories
  • Small Form Factor Pluggable (SFP) Optical
    Transceivers
  • Power Sourcing Midspan Equipment (802.3af
    PoE-compliant)
  • CCTV Cable TV Converter

101
Small Form-Factor Pluggable Transceivers (IE-SFPs)
  • IE-SFP modules are extended temperature (IE),
    modular transceivers
  • Benefits of IE-SFPs
  • More and more high-end network equipment is being
    designed with SFP ports to accommodate the SFP
    modules
  • Easier upgrades from one fiber type to the other
    (multi-mode to single mode, dual strand to single
    strand)
  • Cost effective replace just the SFP, not the
    hardware
  • Hot swappable means easier maintenance no need
    to take other customers down

102
Choosing the Right IE-SFP
  • IMC Networks offers a wide range of IE-SFP
    modules, for a variety of networking needs
  • Different wavelength types
  • Multi-mode (MM) versus Single-mode (SM)
  • Standard versus Single-strand Bi-Directional
    (BiDi/SSF)
  • Course Wave Division Multiplexing (CWDM)
  • Several protocol independent versions to choose
    from
  • 155 Mbps (supports Fast Ethernet)
  • 1.25 Gbps (supports Gigabit Ethernet)
  • Extended Diagnostics (DDMI) also available
  • Temperature
  • Supply Voltage
  • Laser Bias Current
  • TX Power
  • RX Power

103
PSE Midspan
  • Modular device for providing power and data over
    the same CAT 5 cable
  • PSE Power Sourcing Equipment
  • 802.3af complaint
  • Installs in managed IMC Networks chassis

104
PSE Midspan Application
  • Takes the unpowered Cat 5 and Ethernet data in
    and launches it out with power (data unchanged)

105
McCCTV Converter
  • Twisted pair Ethernet to coaxial media converter
  • Allows easy upgrades to IP-Based network cameras
    without having to replace legacy coaxial indoor
    wiring
  • Deploys as a point to point solution
  • Internal power supply

McCCTV Standalone Converter
106
IMC Networks RoHS Policy
  • What is RoHS?
  • The Restriction of Hazardous Substances in
    Electrical and Electronic Equipment (RoHS)
    Directive, passed into law by the European Union.
  • What Does It Require and Who is Affected?
  • It affects manufacturers and distributors of
    electrical and electronic equipment containing
    lead, cadmium and other toxic materials.
  • After July 1, 2006 the use of these materials was
    banned in new products sold in Europe.
  • How are IMC Networks Products Affected?
  • Telecommunications equipment such as IMC
    Networks products is exempt until 2010, but
    because of IMC Networks commitment to the
    environment, the company has been compliant since
    July 2006.
  • Are All IMC Networks Products Compliant?
  • The only exceptions are products for which RoHS
    compliant components are not available.

107
New and Ongoing Product Innovations
  • Product Line Extensions
  • PoE (Power over Ethernet)
  • Industrial Equipment (IE) rugged media converters
  • Higher speeds Gigabit and beyond
  • New Conversion Protocols and Interfaces
  • TDM over Ethernet
  • SFP ports added to core products
  • Single Strand Fiber (SSF) incorporated into
    product line
  • CWDM Coarse Wave Division Multiplexing
  • Improved SNMP Management iView2 update

108
Questions Answers
  • Contact Info
  • Sales sales_at_imcnetworks.com
  • Support support_at_imcnetworks.com
  • Fiber Consulting Services fcs_at_imcnetworks.com
  • Marketing marketing_at_imcnetworks.com
  • US Headquarters 1-949-465-3000
About PowerShow.com
