A Practical Approach to Anemia

1
A Practical Approach to Anemia
How to efficiently and accurately work up an
anemic patient ?

• Dr.R.V.S.N.Sarma., M.D., M.Sc., (Canada)
• Consultant Physician Chest Specialist
• Visit us at www.drsarma.in

2
What is Anemia ?

• Important to remember
• Anemia is a clinical sign of disease
• It is not a single disease by itself
• Need to look for the underlying cause !
• Will we ignore a fever with out investigation ?
• Its diagnosis is not that simple !! Well make it
• Its very common and imp. in our practice
• Drug Rx. depends on the cause

3
Definition of Anemia

• Decrease in the quantum of circulating red blood
  cell mass and there by ? O2 carrying capacity
• Most common hematological disorder by far
• Almost always a secondary disorder
• As such, critical for all practitioners to know
  how to evaluate / determine its cause / treat

4
Normal Red Cells
No nucleus, enzyme packets Biconcave discs Haem
Gl Center 1/3 pallor Pink cytoplasm (Hb
filled) Cell size 7- 8 µ - capill. 2 µ EM
pathway, HMP Negative charge no phago Na less,
K more inside 100-120 days life span
5
The Factory Bone Marrow
Sternum, pelvis, vertebrae, long bones, skull
bones, Tibia (paed) From stem cells
(pleuripotent) 75 of marrow for WBC 25 of BM
for Red cells Erythrod / Granulocyte Ratio
13 EG ratio increases in Anemia Large white
areas are marrow fat
6
Hemoglobin (Hb)
7
(No Transcript)
8
(No Transcript)
9
First Question

• The onset of Anemia
• Acute versus chronic
• Clues
• Hemodynamic stability
• Previous CBC
• Overt blood loss

10
Screening Tests Anemia

• Clinical Signs and symptoms of Anemia
• Look for bleeding all possible sites
• Look for the causes for anemia
• Routine Hemoglobin examination
• Cut off marks for Hb
• US lt 13.5 g WHO lt 12.5 g
• India (ICMR) Less than 12 g

11
Clinical Signs to be looked for

• Skin / mucosal pallor,
• Skin dryness, palmar creases
• Bald tongue, Glossitis
• Mouth ulcers, Rectal exam
• Jaundice, Purpura
• Lymph adenopathy
• Hepato-splenomegaly
• Breathlessness
• Tachycardia, CHF
• Bleeding, Occult Blood

12
PCV or Hematocrit

• 57 Plasma
• 1 Buffy coat WBC
• 42 Hct (PCV)

13
The Three Primary Measures

• Measurement Normal Range
• RBC count (RCC) 5 million 4 to 5.7
• Hemoglobin 15 g 12 to 17
• Hematocrit (PCV) 45 38 to 50
• A x 3 B x 3 C - This is the rule of thumb
• Check whether this holds good in a given result
• If not -indicates micro or macrocytosis or
  hypochro.

14
The Three Derived Indicies

• Measurement Normal Range
• RCC 5 million 4 to 5.7
• Hemoglobin 15 g 12 to 17
• Hematocrit 45 38 to 50
• MCV C A x 10 90 fl
• MCH B A x 10 30 pg
• MCHC () B C x 100 33

15
Types of Anemia
16
Causes of Anemia

• Decreased production of Red Cells
• - Hypo proliferative, marrow failure
• Increased destruction of Red Cells
• - Hemolysis (decreased survival of RBC)
• Loss of Red Cells due to bleeding
• - Acute / chronic blood loss (hemorrhagic)
• M P x S ( L)

17
Hypoproliferative Anemias
18
Anemia Second Test

• RETICULOCYTE COUNT

• RBC to be or Apprentice RBC
• Fragments of nuclear material
• RNA strands which stain blue

Normal Less than 2
19
Reticulocyte
No definite nucleus Reticulum of RNA Deep blue
staining Light blue cytoplasm Cell size about 10 µ
20
Reticulocytes
Leishmans
Supravital
21
Reticulocyte Production Index

• For example, the RPI is calculated as follows
• Reticulocyte count 9
• Hb content 7.5 g
• Correction for Anemia
• 9 x (7.5 15) 9 x 0.5 4.5
• Correction for life span
• 4.5 2 2.25
• 3. Thus, the RPI is 2.25

22
Anemia
Hb lt 12, Hct lt 38
Hemolytic
Hypoproliferative
RPI lt 2
RPI gt 2
23
Workup Third Test

• The next step is What is the size of RBC ?
• MCV indicates the Red cell volume (size)
• Both the MCH MCHC tell Hb content of RBC
• If the RPI is 2 or less
• We are dealing with either
• Hypoproliferative Anemia (lack of raw material)
• Maturation defect with less production
• Bone marrow suppression (primary/ secondary)

24
Red Cell Size
25
Mean Cell Volume (MCV)

• RBC size is measured indirectly by
• The Mean Cell Volume (MCV) and RDW

26
Anemia Workup - MCV
27
Anemia Workup 4th TestRed cell Distribution
Width RDW
RDW lt 13 Mean 90 fl
RDW is 13 MCV 90 fl
28
Red cell Distribution Width - RDW
MCV
Microcytic
Normocytic
Macrocytic
Left
Mean 90
Right
29
Anemia Workup - 5th TestPeripheral Smear Study

• Are all RBC of the same size ?
• Are all RBC of the same normal discoid shape ?
• How is the colour (Hb content) saturation ?
• Are all the RBC of same colour/ multi coloured ?
• Are there any RBC inclusions ?
• Are there any hemo-parasites in the RBC ?
• Are leucocytes normal in number and D.C ?
• Is platelet distribution adequate ?

30
IDA -CBC
31
Severe Hypochromia
32
Microcytic Hypochromic - IDA
33
Microcytic Hypochromic Anemia
34
IDA Summary

• Microcytic MCV lt 80 fl, RBC lt 6 µ
• RDW Widened and shifted to left
• Hypochromic MCH lt 27 pg, MCHC lt 30
• RPI lt 2
• Retic. count May be gt 2
• Serum ferritin Very low lt 33 (p mols/L)
• TIBC Increased gt 340 (µg/dL)
• BM Iron stain Iron is Absent
• Response to Fe Rx. Excellent

35
IDA- Some Nuggets

• Look for occult blood loss 2 days non veg. free
• Pica and Pagophagia Ice sucking
• Absorption of Haem Iron gt Fe gt Fe
• Food, Phytates, Ca, Phosphate, antacids
  ?absorption
• Ascorbic acid ?absorption
• Oral iron Rx. always is the best, ? Carbonyl Fe
• FeSO4 is the best. Reserve parenteral Rx.
• Packed cell transfusion in emergency
• Continue Fe Rx at least 2 months after normal Hb
• 1 gram ?in Hb every week can be expected
• Always supplement protein for the Globin component

36
Microcytic Anemias
MCV lt 80 fl Serum Ferritin TIBC BM Perls stain
Iron Def. Anemia ?? ?? 0
Chronic Infection ?? ??
Thalassemia ?? N
Hemoglobinopathy N N
Lead poisoning N N
Sideroblastic ?? N
37
Ringed Sideroblasts in BM
Prussian Blue Stain
38
Macrocytic Anemias

• A. Megaloblastic Macrocytic B12 and Folate?
• B. Non Megaloblastic Macrocytic Anemias
• Liver disease/alcohol
• Hemoglobinopathies
• Metabolic disorders, Hypothyroidism
• Myelodystrophy, BM infiltration
• Accelerated Erythropoesis - ?destruction
• Drugs (cytotoxics, immuno suppressants, AZT,
  anticonvulsants)

39
Anemia - Macrocytic (MCV gt 100)

• Premature gray hair consider MBA
• Macrocytic anemias may be asymptomatic until
• the Hb is as low as 6 grams
• MCV 100-110 fl
• must look for other causes of macrocytosis
• MCV gt 110 fl
• almost always folate or B12 deficiency

40
Macrocytosis of Alcoholism

• 25-96 of alcoholics
• MCV elevation usually slight (100-110 fl)
• Minimal or no anemia
• Macrocytes round (not oval)
• Neutrophil hyper segmentation absent
• Folate stores normal
• Smoking increases the Red Cell Mass

41
Megaloblastic Hematopoiesis

• Marrow failure due to
• Disrupted DNA synth. ineffective erythropoesis
• Giant precursors (Megaloblasts)
• Nuclear Cytoplasmic dyssynchrony in marrow
• Neutrophil hyper segmentation macro ovalocytes
• Anemia (and often leukopenia thrombocytopenia)
• Almost always due to B12 or folate deficiency

42
MBA
43
Macrocytosis -MBA
44
Anisocytosis - Macrocytic Anemia
45
HSN - MBA
46
Basophilic Stippling - MBA
BS occurs in Lead poisoning also
47
Megalocyte in PS
48
MBA - BM
49
MBA - BM
50
Megaloblast FA deficiency
51
Pernicious Anemia - Tongue
Bald, smooth, lemon yellowish red tongue
52
Normocytic Anemias

1. Chronic diseases, CKD
2. Early IDA
3. Hemoglobinopathies
4. Primary marrow disorders
5. Combined deficiencies
6. Increased destruction
7. Anemia of investigations -ICU

53
Anemia of Chronic Disease

• Thyroid diseases
• Malignancy
• Collagen Vascular Disease
• Rheumatoid Arthritis
• SLE
• Polymyositis
• Polyarteritis Nodosa

• IBD
• Ulcerative Colitis
• Crohns Disease
• Chronic Infections
• HIV, Osteomyelitis
• Tuberculosis
• CKD, Renal Failure

54
Dimorphic Anemia

• Folate Fe deficiency (pregnancy, alcoholism)
• B12 Fe deficiency (PA with atrophic gastritis)
• Thalassemia minor B12 or folate deficiency
• Fe deficiency hemolysis (prosthetic valve)
• Folate deficiency hemolysis (Hb SS disease)
• Peripheral smear exam is critical to assess these
• RDW is increased very much

55
(No Transcript)
56
Let us look at some reports of patients

• In order to make a differential diagnosis

57
Test Done Value Remarks
RBC 3.96 million/c mm Decreased
Hb 9.7 g Decreased
Hematocrit 23.9 Decreasd
MCV 60.4 fl Microcytosis
MCH 24.6 pg/l Hypochromia
MCHC 40.5 Not relevant
RC and RPI 4 , 1.29 Not Hemolytic
Peripheral Smear Microcytic hypochromic DD of Microcytic
Serum Ferritin 46 pmol/l Boarderline
TIBC 390 µg/dl Elevated
BM Iron stain Absent Clinches IDA
58
Test Done Value Remarks
RBC 3.86 million/c mm Decreased
Hb 10.4 g Decreased
Hematocrit 26.9 Decreasd
MCV 69.7 fl Microcytosis
MCH 25.8 pg/l Hypochromia
MCHC 38.66 Not relevant
RC and RPI 5 , 1.73 Not Hemolytic
Peripheral Smear Microcytic hypochromic DD of Microcytic
Serum Ferritin 320 pmol/l High
TIBC 300 µg/dl Normal
BM Iron stain Ringed sideroblasts Clinches SBA
59
Test Done Value Remarks
RBC 2.69 million/c mm Decreased
Hb 10.6 g Decreased
Hematocrit 31.6 Decreasd
MCV 117.5 fl Macrocytosis (Severe)
MCH 39.4 pg/l Hyperchromia
MCHC 33.5 Normal
RC and RPI 5 , 1.76 Not Hemolytic
Peripheral Smear Macrocytic Hyperchromic DD of Macrocytic
Serum Ferritin 240 pmol/l Normal (Not required)
TIBC 338 µg/dl Normal (Not required)
BM Exam Megaloblastic BM Clinches MBA (F, B12)
60
Test Done Value Remarks
RBC 3.09 million/c mm Decreased
Hb 10.6 g Decreased
Hematocrit 31.6 Decreasd
MCV 102.3 fl Macrocytosis (Moderate)
MCH 34.3 pg/l Hyperchromia
MCHC 33.5 Normal
RC and RPI 3 , 1.06 Not Hemolytic
Peripheral Smear Macrocytic Hyperchromic DD of Macrocytic
Serum Ferritin 240 pmol/l Normal (Not required)
TIBC 338 µg/dl Normal (Not required)
BM Exam Normoblastic BM Clinches MCA (Chr D)
61
Test Done Value Remarks
RBC 3.10 million/c mm Decreased
Hb 9.3 g Decreased
Hematocrit 27.9 Decreasd
MCV 90 fl Normocytosis
MCH 30.0 pg/l Normochromia
MCHC 33.3 Normal
RC and RPI 1.5 , 0.47 Not Hemolytic
Peripheral Smear Normocytic Normochromic DD of Normocytic A
Serum Ferritin 240 pmol/l Normal (Not required)
TIBC 338 µg/dl Normal (Not required)
BM Exam Normoblastic BM CLD, ALD, CKD, Drugs
62
Test Done Value Remarks
RBC 3.81 million/c mm Decreased
Hb 11.1 g Decreased
Hematocrit 33.3 Decreasd
MCV 87.4 fl Normocytosis
MCH 29.2 pg/l Normochromia
MCHC 33.33 Normal
RC and RPI 10 , 3.70 Hemolytic
Peripheral Smear Piokilo, Aniso, target cells DD of Hemolytic Anemia
Serum Ferritin 240 pmol/l Normal (Not required)
TIBC 338 µg/dl Normal (Not required)
BM Exam E G Ratio is 2 1 Hypercellular marrow
63
Anemia - Summary

• If Hb is low Do not start on Iron straight
  away
• Ask for RCC, Hematocrit Derive MCV, MCH, MCHC
• Order for Reticulocyte count Is RPI lt 2 or gt
  2
• Thoroughly look for blood loss acute / chronic
  / occult
• Is it hypo-proliferative or hemolytic or
  hemorrhagic Anemia
• If hypo proliferative Microcytic or Macrocytic?
  (MCV, RDW)
• If microcytic IDA or others Sr Ferritin TIBC,
  BM Iron
• If macrocytic Megaloblastic (B12, FA) or
  Normoblastic BM
• If normocytic Anemia of chr. Disease Liver,
  CKD, Ca
• Peripheral smear study for RBC size, shape,
  colouration etc.
• If retic. count is ?- HA work up Hb EP, spl.
  tests

64
RBC Size AnisocytosisDifferent sizes of RBC
65
PoikilocytosisDifferent Shapes of RBC
66
Polychromasia - Spherocytosis
67
Target Cells

• Liver Disease
• Thalassemia
• Hb D Disease
• Post splenectomy

68
Tear Drop Cells

• Myelofibosis
• Infiltration of BM
• Tumours of BM
• Thalassemia

69
Hair on end - Thalassemia Major
70
Drepanocytes - SS
71
Sickle Cell Anemia
72
Autosplenectomy - SS
Normal spleen is 8 to 12 cm
73
Hemolytic Anemia

• Anemia of increased RBC destruction
• Normochromic, normocytic anemia
• Shortened RBC survival
• Reticulocytosis due to ? RBC destruction
• Will not be symptomatic until the RBC life
  span is
• reduced to 20 days BM compensates 6 times

74
Tests Used to Diagnose Hemolysis

1. Reticulocyte count
2. Combined with serial Hb
3. Hemoglobin electrophotesis
4. Serum LDH
5. Serum bilirubin
6. Haptoglobin
7. Urine hemosiderin
8. Hemoglobinuria

75
Findings in Hemolytic Anemia
Reticulocyte count and RPI Increased
Serum Unconjugated Bilirubin Increased
Serum LDH 1 LDH 2 Increased
Serum Haptoglobin Decreased
Urine Hemoglobin Present
Urine Hemosiderin Present
Urine Urobilinogen Increased
Cr 51 labeled RBC life span Decreased
76
Tests to define the cause of hemolysis

1. Hemoglobin electrophoresis
2. Hemoglobin A2 (ßeta-Thalassemia trait)
3. RBC enzymes (G6PD, PK, etc)
4. Direct indirect antiglobulin tests (immune)
5. Cold agglutinins
6. Osmotic fragility (spherocytosis)
7. Acid hemolysis test (PNH)
8. Clotting profile (DIC)

77
MAHA
Micro Angiopathic Hemolytic Anemia
78
MAHA
Micro Angiopathic Hemolytic Anemia
79
Hyperactive BM SkullHemolytic Anemia
80
Spherocytosis
81
Spherocytosis
Hereditary Spherocytosis
82
Spherocytosis
83
Elliptocytes
Hereditary Elliptocytosis, B12 or Folate?
84
StomatocytesSlit like central pallor in RBC

• Liver Disease
• Acute Alcoholism
• H Stomatocyosis
• Malignancies

85
EchinocytesEvenly distributed spicules gt 10

• Uremia
• Peptic ulcer
• Gastric Ca
• PK-D
• Called Burr Cells

86
Acanthocytes5-8 spikes of varying length,
irregular intervals
Called Spur Cells, Occur in A H A
87
Shistocytes
Fragmented, Helmet or triangle shaped RBC

• MAHA
• Prosthetic valves
• Uremia
• Malignant HT

88
Leukoplakia - Aplastic Anemia

1. Chloramphenicol
2. Neomercazole
3. Sulfonamides
4. Analgin
5. Phenytoin
6. Butazolidin group
7. Anti Ca drugs

89
Normal BM High Power
E G 1 3
90
Shift in E G Ratio
E G 2 1
91
BM - Aplastic Anemia
92
Myelofibrosis
93
Post transfusion - CBC
94
Howell-Jolly Bodies
Absence of Splenic function Nuclear chromatin in
RBC
95
Pelger-Huet Anomaly

• Inherited condition
• PMN - Spectacles
• Heterozygous
• Homozygous fatal
• Neutrophil Bands ?
• Normal WCC
• No e/o infection

96
Thank You ALL
