Open Source Network Management Tools

1
Open Source Network Management Tools

• Bruce Zamaere
• bsiza_at_kth.se

2
Overview

• Introduction
• NOC Philosophy
• Available Tools

3
introduction

• wikipedia A network operations center (or NOC,
  pronounced nock) is one or more locations from
  which control is exercised over a computer,
  television broadcast, or telecommunications
  network.

4
Functions of a NOC

• Responsible for monitoring the network for alarms
  or adverse conditions (e.g. power failures, link
  failure)
• NOC staff analyze problems, troubleshooting,
  collaborate with other technicians on site.
• NOC tracks issues/problems until they are
  resolved.
• Problems not solved within a specified time frame
  can be escalated to the appropriate personnel.
• Standard Operating Procedures exists that detail
  how to remedy issues/problems.

5
NOC Philosophy

• (Adapted from RedHat documentation)
• Automate everything
• Document everything
• Communicate as much as possible
• Know your resources
• Know your users
• Know your business
• Security cannot be an afterthought
• Plan ahead

6
Purpose

• NOCs are dedicated to monitoring and coordinating
  network operations.
• This requires that the following functional areas
  are addressed

7
MRTG

• Multi Router Traffic Grapher
• http//oss.oetiker.ch/mrtg/
• Based on SNMP
• Used to monitor traffic load on network links.
• Many hacks exist to allow you to monitor other
  things (e.g. incoming / outgoing emails, cache
  hits and misses)

8
(No Transcript)
9
Weathermap 4RRD

• Generates network weather maps.
• Shows the network link utilization on the network
  map by color scheme
• Data used to create graph are acquired from
  RRDTool databases or MRTG HTML files

10
(No Transcript)
11
(No Transcript)
12
Nagios

• http//www.nagios.org/
• an enterprise-class network and server monitoring
  system.
• Useful for
• Monitoring of network services.
• Monitoring of host resources (processor load,
  disk usage, system logs)
• Contact notifications when service or host
  problems occur and get resolved (via e-mail,
  SMS).
• You can define event handlers that execute when
  triggered by certain events. (Proactive problem
  resolution)

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
OpenNMS

• http//www.opennms.org
• Functionalities
• High performance
• A single instance of OpenNMS supports monitoring
  of a large number of nodes.
• Automation
• OpenNMS minimizes the amount of manual
  configuration.
• Rule-based configuration
• Flexible rules can be used to specify what
  services are polled on what devices.

19
(No Transcript)
20
ZABBIX

• http//www.zabbix.com
• Functionalities
• Performance monitoring
• User alerts
• Monitoring of log files
• Logging services
• Capacity planning
• Assuring and monitoring of SLA
• High level view of IT resources and services
• Graphical representation of collected information
• Network maps

21
(No Transcript)
22
Cacti

• http//www.cacti.net
• Similar to MRTG.
• Based on RRDtool.
• Offers excellent graphing capabilities.
• Has extensive templates.

23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
NTop

• http//ntop.org
• Network probe that shows network activity just
  like top.

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Request Tracker

• http//bestpractical.com/rt/
• Tracks data/conversations/requests.
• Convenient for end users.
• Highly customizable.
• Easy to install (hmm)

32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
Security Tools

• Some security tools to consider
• NetFilter IP Tables Firewall
• WireShark Protocol analyzer
• Snort Intrusion detection
• Netcat Feature rich tool. Great for debugging.
• Nessus Vulnerability scanner
• Many many more

36
Recommended Reading

• Practice of System and Network administration by
  Thomas A. Limoncelli
• How to accelerate your Internet E-book
  http//bwmo.net/
• Red Hat Linux Network Management Tools (CD-ROM
  included) (Paperback) By Steven Maxwell.
