INDUSTRY TRENDS

1
INDUSTRY TRENDS

• 2006 Heavy Duty Seminar

2
CHANGING REQUIREMENTS FOR HEAVY DUTY LUBRICANTS
3
Performance Categories
API Performance Categories for Diesel Engine Oils
Category
Service Definition
CJ-4 2007 Emission Engines Low SAPS
CI-4 Plus 2003 Increased soot
control CI-4 2002 Low Emission,
Four Stroke Engine with EGR and Low Sulfur
Fuel CH-4 1998 Low Emission, Four Stroke Engine
Both High and Low Sulfur Fuel CG-4 1994 Low
Emission, Four-Stroke Engines Using 0.05
Sulfur Fuel CF-4 1991 Low Emission
Engines CF-2 Severe Duty Two-Stroke Cycle
Engines CF Turbocharged Engines or High Sulfur
Fuel
Heavy Duty


4
The Future of Heavy Duty LubricantsAfter-treat
ment Compatible Lubricants with ULSD
5
FUTURE CHANGES

• Further reduction in emissions drive CJ-4
• Development/Implementation in 2005-2007
• Will require after-treatment devices
• Reduced zinc, sulfur phosphorus and low ash
  technology for after-treatment device
  compatibility
• UltraLow sulfur (15 PPM) fuel
• Increased use of higher quality base stocks
• Backward compatibility issues ?
• Radical Changes to our product tiers/concepts ?

6
Worldwide Emission Requirements
US 2002/2004
Euro III (2000)
PM, g/kW-hr ESC test
Japan 2005
Euro V (2008)
Euro IV (2005)
US 2007
NOx, g/kW-hr ESC test
7
CJ-4 Technical Update

• New category intended to lubricate and protect
  2007 model year engines
• Production starts 4Q 2006
• Engines are now on road under restricted testing
• Also in the same timeline, ULSD, Ultra-Low Sulfur
  diesel
• Emissions for 2007 are very reduced in both NOx
  and particulate matter

8
CJ-4 Technical Update

• All major diesel engine OEMs will be using
  increased EGR (CAT Acert) and after-treatment
• DPF (Diesel Particulate Filter) will require oils
  with less ash for long term protection
• The ash plugging issue is still under discussion
  among the OEMs

9
(No Transcript)
10
PC-10 Chemical Limits

• Sulfated Ash, Phosphorus, Sulfur, (SAPS)
• Sulfated Ash 1 wt max
• Phosphorus 0.12 wt max
• Sulfur .4 wt max
• Approved June 2004

11
CI-4 Plus vs CJ-4

• CI-4 Plus
• TBN 10-12 plus
• ASH 1.2-1.5
• Phosphorus .14

• CJ-4
• TBN 7-8 possibly 9.5
• ASH 1 max
• Phosphorus .12

12
New Engine Tests

• Cummins ISM
• Rolling valve train wear
• Replaces M11 EGR
• Cummins ISB
• Sliding valve train wear
• Cat C-13
• Piston deposit and oil consumption
• Mack T-12
• Ring and liner wear
• Replaces T-10

13
(No Transcript)
14
(No Transcript)
15
Engine test differences

• T-12 is more severe than T-10 on Pb corrosion and
  oxidation
• Cummins ISM and ISB demonstrate rolling and
  sliding valve train wear
• T-11 limits are more severe than CI-4 Plus

16
New OEM Specs.

• Caterpillar ECF-2 and ECF-3
• ECF-1 will be dropped
• ECF-2 Delayed until 2007
• Off-Highway and pre- 07 engines
• No longer an ash max but will have 1 min
• CH-4 minimum quality level
• ECF-3 mirrors CJ-4, self certifying but Cat wants
  data.

17
New OEM Specs.

• Cummins 20081
• Very strict ash limit 1.00
• Tighter T-12 limits
• Tighter injector screw weight loss in ISM
• Tighter cam lobe wear in ISB

18
New OEM Specs.

• Mack EO-O Premium Plus
• Tighter T-12 Limits
• Tighter limits on cam lobe wear in ISB

19
Engine Efficiency Factors

• Air Management
• Head Design
• Turbochargers
• Valve timing
• Fuel Delivery
• Electronics
• After-Treatment
• Oxidation Catalyst
• Particulate Filters

20
How does EGR reduce NOx?

• Re-circulated exhaust will displace O2 reducing
  the chance to react with N2 during combustion
• Exhaust gas will also reduce combustion pressure
  and temperature
• All reduces NOx levels coming out of the stack
• Fuel economy?????

21
What is EGR?Exhaust Gas Recirculation
EGR Duct Heat Exchanger
EGR Control Valve
Intake
Exhaust

• EGR lowers O2 and reduces peak temperatures and
  pressures
• EGR gasses are cooled to improve volumetric
  efficiency

Hot Exhaust Gas
Fresh Intake Air
N
22
DPF (Diesel Particulate Filter)

• Catch and hold particulates
• Non-combustible matter must be manually removed
  during some type of scheduled maintenance
• OEMs do not want engine oil adding anything to
  the process
• Need for low SAPS oil
• This issue is still not final

23
Diesel Particulate Filters

• DPF Function
• Catch and hold exhaust particles for further
  processing
• Regeneration soot and combustible fractions
  oxidized in the DPF
• Maintenance non-combustibles remain in the DPF
  and must be removed periodically

24
2007/2010 Emissions Technologies
Reference Peterbilt
25
Diesel oxidation catalysts

• Full flow units that act very much like an
  automotive catalytic converter.
• Gases flow over a catalyst that burns
  contaminants and reduces them to CO2 and water.
• Can be installed as muffler replacements because
  of smaller size.

26
Lean NOx Adsorber
Diesel Injector
DOC
LNA
NOx Sensor
Filter
DOC
Diesel Oxidation Catalyst
Valves
Bypass
Reference Volvo
27
Kendall API CJ-4

• Kendall Super-D XA (Exhaust Advantage)
• Fully Licensed as API CJ-4/CI-4 Plus/
  CI-4/CH-4/SM, SAE 15W-40
• Synthetic Blend, 0.98 Ash, TBN 9.6
• Backward Compatible, Useable with Diesel Fuel up
  to 500 PPM Sulfur (consult OEM)
• CAT ECF-3, Cummins 20081, DDC 93K218, Mack EO-O,
  MB 228.3 Volvo VDS-4

28
76 API CJ-4 Products

• Guardol ECT (Emissions Compatible Technology)
• Fully Licensed as API CJ-4/CI-4 PLUS/
  CI-4/CH-4/SM, SAE 15W-40
• Synthetic Blend, 0.98 Ash, TBN 9.6
• Backward Compatible, Useable with Diesel Fuel up
  to 500 PPM Sulfur (consult OEM)
• CAT ECF-3, Cummins 20081, DDC 93K218, Mack EO-O,
  MB 228.3 Volvo VDS-4

29
76 API CJ-4 Products (cont)

• Fleet Supreme EC (Emissions Compatible)
• Fully Licensed as API CJ-4/CI-4 PLUS/
  CI-4/CH-4/SM, SAE 15W-40
• 0.97 Ash, TBN 8.0
• Backward Compatible, Useable with Diesel Fuel up
  to 500 PPM Sulfur (consult OEM)
• CAT ECF-3, Cummins 20081, DDC 93K218, Mack EO-O,
  MB 228.3 Volvo VDS-4

30
What is ACERT?

• Two-stage turbocharging with electronically
  controlled wastegate
• Pilot injection and possible multiple injection
  events
• Some internal EGR from valve overlap
• Exhaust oxidation catalyst
• Goal Is To Reduce Peak Combustion Chamber
  Temperatures and Therefore Reduce NOx Formation

31
ACERT Technology for 2007

• Clean Gas Induction (CGI)
• Draws inert gas from downstream of the DPF
• DPFs will have active regeneration. Regeneration
  will only take place when needed.
• soot free intake charge

32
Low Pressure Turbocharger
PCM
Drivers
High Pressure Turbocharger

• Twin turbochargers

33
C-13 Piston and Ring Pack Design
