Title: Foot and Ankle Fractures


1
Foot and Ankle Fractures
  • Foot and Ankle Fractures

2
Anatomy
  • Three groups of stabilizing ligaments
  • 1)Lateral
  • -anterior talofibular ligament (ATFL)
  • -calcaneofibular ligament (CFL)
  • -posterior talofibular ligament (PTFL).
  • -limit ankle inversion and prevent anterior and
    lateral subluxation of the talus

3
(No Transcript)
4
Anatomy
  • 2)Medial
  • -deltoid ligament (group of four ligaments)
  • -anterior and posterior tibiotalar
  • -tibionavicular
  • -tibiocalcaneal
  • -stabilize the joint during eversion and
    prevent talar subluxation
  • -20-50 stronger than lateral ligaments

5
History
  • History
  • -mechanism of injury
  • -ankle and foot position during the injury
  • -any sounds heard at the time injury
  • -previous history of ankle injury, any knee or
    foot pain
  • -degree of function after the event.

6
Physical Exam
  • Inspection
  • -deformity, ecchymosis, swelling, perfusion
  • ROM (normal)
  • -30 to 50 degrees plantar flexion
  • -20 degrees dorsiflexion
  • -25 degrees inversion and eversion
  • -15 degrees of adduction
  • -30 degrees of abduction
  • Palpation
  • -individual ligaments (MCL,LCL, syndesmotic) and
    tendons
  • -the joints above and below the ankle
  • -important proximal fibula (Maisonneuve
    fracture) and the base of the fifth metatarsal
    ("dancer's fracture").

7
Special Tests
  • Anterior Drawer
  • -integrity of the ATFL
  • -grasp the heel with one hand and apply a
    posterior force to the tibia with the other hand,
    while drawing the heel forward.
  • -laxity is compared with the opposite
    (uninjured) ankle.
  • -positive test a difference of 2 mm
    subluxation compared with the opposite side or a
    visible dimpling of the anterior skin of the
    affected ankle (suction sign)
  • Squeeze Test
  • -tests the integrity of the syndesmotic
    ligaments
  • -examiner places his hand 6 to 8 inches below
    the knee and squeezes the tibia and fibula
    together
  • -positive test results in pain in the ankle,
    which indicates injury of the syndesmotic
    ligament

8
X-rays
  • X-rays
  • -approx. 10-15 of all traumatic radiographs are
    of the ankle
  • -80 of all ankle injuries get an x-ray, fewer
    than 15 have a significant fracture
  • Views
  • -AP, lateral, mortise view (15-20 degrees of
    internal rotation)
  • -AP malleoli, plafond, talar dome, lateral
    process of the talus
  • -Lateral ant/post tibial margins, talar neck,
    post, talar process and calcaneus
  • -Mortise most important view, medial clear
    space should not exceed 4mm

9
(No Transcript)
10
Xray Measurments
11
Ankle Fractures
12
Classification
  • Danis-Weber
  • -based on mechanism of injury
  • -three fracture types (i.e., A, B, C ), defined
    by the location of the fibular fracture
  • -A - below the tibiotalar joint
  • -B - at the level of the tibiotalar joint
  • -C - above the tibiotalar joint

13
Unimalleolar Fractures
  • Lateral
  • -any avulsion lt3mm in size can be treated as an
    ankle sprain

14
Unimalleolar Fractures- Lateral
  • Stability depends on the location of the fracture
  • -Type A (below tibiotalar joint)
  • -no medial tenderness
  • -BN walking cast
  • -f/u 1wk to ensure no displacement
  • -non-wt bearing x3wks then wt bearing for
    another 3-5 wks
  • -medial tenderness (check mortise for
    displacement)
  • -ortho consult

15
Unimalleolar Fractures- Lateral
  • Type B and C (at or above the tibiotalar
  • joint)
  • -orthopedic consult ?ORIF
  • -type B 50 associated with tibiofibular
    disruption

16
Unimalleolar Fractures-Medial
  • Medial
  • -commonly associated with lateral and posterior
  • malleolar disruption
  • -need to examine entire length of the fibula
  • (Maisonneuve )
  •  Isolated medial fracture (nondisplaced)
  • -non wt bearing x3 wks, f/u after 1 wk
  • -wt bearing another 3-5 wks
  • -if very active can ORIF initially!!!

17
Bimalleolar Fractures
  • Management
  • -disruption of two elements of the ring
  • -ortho consult
  • -management controversial (ORIF vs closed
    reduction and close f/u)

18
Trimalleolar Fractures (Cottons fracture)
  • Management
  • -disruption of three parts of the ring
    (medial/lateral/posterior)
  • -ortho consult
  • -ORIF

19
Pilon ?
20
Pilon Fractures (Bad!)
  • Mechanism
  • -axial compression
  • -talus driven into the plafond
  • -usually comminuted and displaced with extensive
    soft tissue swelling
  • -look for associated injuries
  • -calcaneus, femoral neck, acetabulum, lumbar
    vertebrae
  • Management
  • -emergent ortho consult

21
Tillaux ?
22
Tillaux fracture (Pediatric)
  • SH type III of the lateral tibial epiphysis
  • -extreme eversion and lateral rotation
  • -adolescence
  • -medial aspect of epiphysis is closed
  • -fracture of the lateral aspect and into joint
  • Management
  • -ortho consult ORIF

23
(No Transcript)
24
Foot Fractures
25
Anatomy
  • Anatomy
  • -27 bones, 57 articulations
  • -Hindfoot calcaneus and talus
  • -Midfoot cuboid, navicular, and three
    cuneiforms
  • -Forefoot metatarsals, phalanges, and sesamoids
  • -Subtalar joint
  • -formed by three articulations between the
    inferior talus and calcaneus
  • -Inversion and eversion of the hindfoot through
    the subtalar joint

26
Anatomy
  • -Tarsometatarsal, or Lisfranc's joint
  • -connects the midfoot and the forefoot
  • -Blood supply
  • - anterior and posterior tibial arteries
  • -Nerve supply
  • -peroneal (deep and superficial), posterior
    tibial, saphenous and sural nerves

27
X-rays
  • Xrays
  • -AP, lateral, oblique(45 degrees of internal
  • rotation)
  • -AP and oblique
  • -best image for the forefoot and midfoot
  • -Lateral
  • -best image for the hindfoot and soft tissues

28
Foot Fractures
29
Talar
  • Talus
  • General
  • -second most common fractured tarsal
  • -3 parts head, neck, body
  • -prone to dislocation with foot in plantar
    flexion
  • -tenuous blood supply risk of avascular
    necrosis

30
Fractures - Talus
  • Minor
  • -chip s treated like sprains
  • Treatment
  • -as above tx as sprain
  • -fragments gt5mm may need excision
  • Major
  • -involve head (5-10 of all talar s), neck
    (50 of all major s) and body (23 of all talar
    s)
  • -high energy mechanism

31
Fractures TalusClassification
  • Classification (Hawkins)
  • Type I fractures
  • -nondisplaced and lack joint involvement
  • risk AVN approx. 10
  • Type II fractures
  • -displacement of the talar neck with subluxation
    or dislocation of the subtalar joint and
    preservation of the ankle joint
  • Type III fractures
  • -displaced with dislocation of the talus from
    both the subtalar and ankle joints
  • -risk AVN gt70
  • Type IV fracture
  • -type II injury with associated talar head
    dislocation

32
Fractures - Talus
  • Treatment
  • -all require ortho consult
  • -any significant displacement/dislocation,
    attempt closed reduction in the ED
  • -grasp midfoot and apply longitudinal traction
    while plantar flexing the foot

33
Calcaneus (Lovers )
  • General
  • -5x more common in men
  • -largest and most frequently fractured tarsal
    bone
  • -falls (axial load) or twisting mechanisms
  • -extra-articular (25-35) good prognosis
  • -intra-articular (70-75) not so good
    prognosis!
  • -look for associated fractures
  • -gt50 cases have associated other extremity or
    spinal fractures
  • -7 bilateral
  • -50 will have long-term disability

34
Calcaneus s
  • X-ray
  • -Boehlers angle (20-40 degrees)
  • -suspect fracture if lt20 degrees
  • Treatment
  • -ortho consult
  • -?ORIF vs conservative management

35
Navicular
  •  General
  • -most common midfoot
  • -blood supply tenuous, risk AVN
  • -classification dorsal avulsion (47 all
    navicular s), tuberosity and body s
  • -mechanism usually eversion injury
  • -pain over the dorsal and medial aspect of foot
    with swelling

36
Navicular
  • Treatment
  • Avulsion
  • -walking cast 4-6wks and ortho f/u
  • Tuberosity and body
  • -not displaced, cast (non wt bearing
    initially) with close f/u
  • -if displaced or gt20 articular surface area
    will require ORIF

37
LisFranc ?
38
Lisfranc Injury (tarsometatarsal
fractures/dislocations)
  • General
  • -damage to the tarsometatarsal joint (any or
    dislocation to this area is termed a Lisfranc
    injury)
  • -commonly missed injury
  • -4 incidence per year of tarsometatarsal
    injuries in collegiate football players
  • -early recognition and anatomical alignment with
    internal fixation is necessary for satisfactory
    results
  • -mechanism high-energy needed to disrupt
    ligament, rotational force( e.g MVA)
  • -clinical severe midfoot pain, significant
    swelling and ecchymosis, inability to wt bear

39
Classification
  • Classification
  • 1)Total Incongruity
  • 2)Partial Incongruity
  • 3)Divergent
  • (Homolateral/Divergent, Type A,B,C)

40
X-ray Findings
  • 1. The medial shaft of the second metatarsal
    should be aligned with the medial aspect of the
    middle cuneiform on the anteroposterior view.
  • 2. The medial shaft of the fourth metatarsal
    should be aligned with the medial aspect of the
    cuboid on the oblique view.
  • 3. The first metatarsal cuneiform articulation
    should have no incongruency.
  • 4. A "fleck sign" should be sought in the medial
    cuneiform-second metatarsal space. This
    represents an avulsion of the Lisfranc ligament.
  • 5. The naviculocuneiform articulation should be
    evaluated for subluxation.
  • 6. A compression fracture of the cuboid should
    be sought.

41
Lisfranc - Treatment
  • Treatment
  • The key to successful outcome in the Lisfranc
  • injuries is anatomical alignment
  • -Nondisplaced
  • -treated with a non-weight-bearing cast for 6
    weeks followed by a weight-bearing cast for an
    additional 4 to 6 weeks.
  • -Displaced fractures (gt2mm) ORIF

42
Metatarsal s
  • Treatment
  • -2nd 4th conservative with well padded
  • shoe
  • -1st - ORIF
  • Exception
  • -displaced (gt3mm or angulated-plantar direction
    gt10 degrees)
  • -closed reduction
  • -/- pinning if unstable
  • -non wt bearing cast 4-6 wks

43
Jones
  • Jones
  • -transverse gt15mm from the proximal end of the
    bone (high rate delayed/nonunion)
  • -occur in gt50 pts with conservative therapy)
  • Treatment
  • -ortho f/u
  • -non-wt bearing cast 6-8 weeks or ORIF

44
X-Rays
45
(No Transcript)
46

47

48
(No Transcript)
49

50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
