Decision Tree Models in Data Mining

1
Decision Tree Models in Data Mining

• Matthew J. Liberatore
• Thomas Coghlan

2
Decision Trees in Data Mining

• Decision Trees can be used to predict a
  categorical or a continuous target (called
  regression trees in the latter case)
• Like logistic regression and neural networks
  decision trees can be applied for classification
  and prediction
• Unlike these methods no equations are estimated
• A tree structure of rules over the input
  variables are used to classify or predict the
  cases according to the target variable
• The rules are of an IF-THEN form for example
• If Risk Low, then predict on-time payment of a
  loan

3
Decision Tree Approach

• A decision tree represents a hierarchical
  segmentation of the data
• The original segment is called the root node and
  is the entire data set
• The root node is partitioned into two or more
  segments by applying a series of simple rules
  over an input variables
• For example, risk low, risk not low
• Each rule assigns the observations to a segment
  based on its input value
• Each resulting segment can be further partitioned
  into sub-segments, and so on
• For example risk low can be partitioned into
  income low and income not low
• The segments are also called nodes, and the final
  segments are called leaf nodes or leaves

4
Decision Tree Example Loan Payment

• Income
• lt 30k gt 30k
• Age Credit Score
• lt 25 gt25 lt 600 gt 600
• not on-time on-time
  not on-time on-time

5
Growing the Decision Tree

• Growing the tree involves successively
  partitioning the data recursively partitioning
• If an input variable is binary, then the two
  categories can be used to split the data
• If an input variable is interval, a splitting
  value is used to classify the data into two
  segments
• For example, if household income is interval and
  there are 100 possible incomes in the data set,
  then there are 100 possible splitting values
• For example, income lt 30k, and income gt 30k

6
Evaluating the partitions

• When the target is categorical, for each
  partition of an input variable a chi-square
  statistic is computed
• A contingency table is formed that maps
  responders and non-responders against the
  partitioned input variable
• For example, the null hypothesis might be that
  there is no difference between people with income
  lt30k and those with income gt30k in making an
  on-time loan payment
• The lower the significance or p-value, the more
  likely that we reject this hypothesis, meaning
  that this income split is a discriminating factor

7
Contingency Table
lt30k gt30k total
Payment on-time
Payment not on-time
total
8
Chi-Square Statistic

• The chi-square statistic computes a measure of
  how different the number of observations is in
  each of the four cells as compared to the
  expected number
• The p-value associated with the null hypothesis
  is computed
• Enterprise Miner then computes the logworth of
  the p-value, logworth - log10(p-value)
• The split that generates the highest logworth for
  a given input variable is selected

9
Growing the Tree

• In our loan payment example, we have three
  interval-valued input variables income, age, and
  credit score
• We compute the logworth of the best split for
  each of these variables
• We then select the variable that has the highest
  logworth and use its split suppose it is income
• Under each of the two income nodes, we then find
  the logworth of the best split of age and credit
  score and continue the process --
• subject to meeting the threshold on the
  significance of the chi-square value for
  splitting and other stopping criteria (described
  later)

10
Other Splitting Criteria for a Categorical Target

• The gini and entropy measures are based on how
  heterogeneous the observations are at a given
  node
• relates to the mix of responders and
  non-responders at the node
• Let p1 and p0 represent the proportion of
  responders and non-responders at a node,
  respectively
• If two observations are chosen (with replacement)
  from a node, the probability that they are either
  both responders or both non-responders is (p1)2
  (p0)2
• The gini index 1 (p1)2 (p0)2, the
  probability that both observations are different
• Best case is a gini index of 0 (all observations
  are the same)
• An index of ½ means both groups equally
  represented

11
Other Splitting Criteria for a Categorical Target

• The rarity of an event is defined as -log2(pi)
• Entropy sums up the rarity of response and
  non-response over all observations
• Entropy ranges from the best case of 0 (all
  responders or all non-responders) to 1 (equal mix
  of responders and non-responders)

12
Splitting Criteria for a Continuous (Interval)
Target

• An F-statistic is used to measure the degree of
  separation of a split for an interval target,
  such as revenue
• Similar to the sum of squares discussion under
  multiple regression, the F-statistic is based on
  the ratio of the sum of squares between the
  groups and the sum of squares within groups, both
  adjusted for the number of degrees of freedom
• The null hypothesis is that there is no
  difference in the target mean between the two
  groups
• As before, the logworth of the p-value is computed

13
Some Adjustments

• The more possible splits of an input variable,
  the less accurate the p-value (bigger chance of
  rejecting the null hypothesis)
• If there are m splits, the Bonferroni adjustment
  adjusts the p-value of the best case by
  subtracting log10(m) from the logworth
• If Time of Kass Adjustment is set to before then
  the p-values of the splits are compared with
  Bonferroni adjustment

14
Some Adjustments

• Setting Split Adjustment property to Yes means
  that the significance of the p-value can be
  adjusted by the depth of the tree
• For example, at the fourth split, a calculate
  p-value of 0.04 becomes 0.0424 0.64, making
  the split statistically insignificant
• This leads to rejecting more splits, limiting the
  size of the tree
• Tree growth can also be controlled by setting
• Leaf Size property (minimum number of
  observations in a leaf)
• Split Size property (minimum number of
  observations to allow a node to be split)
• Maximum Depth property (maximum number of
  generation of nodes)

15
Some Results

• The posterior probabilities are the proportions
  of responders and non-responders at each node
• A node is classified as a responder or
  non-responder depending on which posterior
  probability is the largest
• In selecting the best tree, one can use
  Misclassification, Lift, or Average Squared Error

16
Creating a Decision Tree Model in Enterprise
Miner

• Open the bankrupt project, and create a new
  diagram called Bankrupt_DecTree
• Drag and drop the bankrupt data node and the
  Decision Tree node (from the model tab) onto the
  diagram
• Connect the nodes

17
Select ProbChisq for the Criterion under
Splitting RuleChange Use Input Once to Yes
(otherwise, the same variable can appear more
than once in the tree)
18
Under Subtree select Misclassification for
Assessment MeasureKeep defaults under P-Value
Adjustment and Output VariablesUnder Score set
Variable Selection to No (otherwise variables
with importance values greater than 0.05 are set
as rejected and not considered by the tree)
19
The Decision Tree has only one split on RE/TA.
The misclassification rate is 0.15 (3/20), with 2
false negatives and 1 false positive. The
cumulative lift is somewhat lower than the best
cumulative lift, and starts out at 1.777 vs. the
best value of 2.000.
20
Under Subtree, set Method to Largest and rerun.
The result show that another split is added,
using EBIT/TA. However, the misclassification
rate is unchanged at 0.15. This result shows that
setting Method to Assessment and
Misclassification for Assessment Measure finds
the smallest tree having the lowest
misclassification
21
Model Comparison

• The Model Comparison node under the Assess tab
  can be used to compare several different models
• Create a diagram called Full Model that includes
  the bankrupt data node connected into the
  regression, decision tree, and neural network
  nodes
• Connect the three model nodes into the Model
  Comparison node, and connect it and the
  bankrupt_score data node into a Score node

22
For Regression, set Selection Model to none for
Neural Network, set Model Selection Criterion to
Average Error, and the Network properties as
before for Decision Tree, set Assessment Measure
as Average Squared Error, and the other
properties as before. This puts each of the
models on a similar basis for fit. For Model
Comparison set Selection Criterion as Average
Squared Error.
23
Neural Network is selected, although Regression
is nearly identical in average squared error.
The Receiver Operating Characteristic (ROC) curve
shows sensitivity (true positives) vs.
1-specificity (false positives) for various
cutoff probabilities of a response. The chart
shows that no matter what the cutoff
probabilities are, regression and neural network
classify 100 of responders as responders
(sensitivity) and 0 of non-responders as
responders (1-specificity). Decision tree
performs reasonably well, as indicated by the
area above the diagonal line.
