Challenges in Wind Turbine Components

1
Challenges in Wind Turbine Components

• Charles D. Schultz, PE
• Beyta Gear Service
• Winfield, Illinois

2
What is going on in Wind Energy?
3
Activity on a national scale
4
Progress has been made but much remains to be
done!
5
It is all about jobs!
6
Domestic Content Progress
7
US Wind Resource Map

• US is the Saudi Arabia of wind
• Transmission of power from central plains to
  coasts is a problem
• Even states that arent colorful have wind
  potential

8
Examples of Components

• Blade Hubs are huge castings up to 15,000
  pounds
• Gearbox Assemblies weigh up to 60,000 pounds and
  are getting larger
• Chassis are big fabrications or castings up to
  40,000 pounds and getting larger

9
Towers Blades

• Transport issues, 50 meter lengths 40 ton
  weights
• High cost items
• Potential for big improvements
• Big incentive to make locally

10
Big Market, Long Term Potential
11
Where are the problems?
12
Quality is a given

• Due to high cost of warranty work all parts have
  strict quality specifications
• Tolerances test equipment capabilities
• Documentation requirements similar to aircraft
  industry
• Little acceptance of non-conformances
• Metallurgical cleanliness at aircraft levels
• Expect to cut up lots of samples for
  metallurgical checks

13
Consistency is Mandatory

• Expect customers to dictate suppliers, methods,
  and even tooling
• Customers will have quality observers in your
  facility
• Once a method is approved changes are difficult
  to make
• Rework especially in thermal processing- is
  subject to extreme scrutiny

14
Big portion of value is in the Nacelle
15
Large, precision gearboxes required

• Aerospace precision in a mining machine sized
  package
• Quality levels far in excess of industrial
  equipment
• Huge warranty and maintenance costs

16
Other Geared Products
17
Planetary designs predominate
18
Typical Gearbox Parts
19
Typical Pinion

• Not dissimilar to industrial gearing
• Large cross sections challenge heat treat
  response
• 18CrNiMo7-6 typical material
• Current weights up to 2500 pounds and getting
  bigger

20
Typical Sun Pinion

• Large thru hole helps heat treat response
• 18CrNiMo7-6 typical material
• Heat treat distortion common
• Current weights up to 2000 pounds and getting
  bigger

21
Typical Gear

• Not dissimilar to industrial gears
• Large cross sections challenge heat treat
  response
• 18CrNiMo7-6 typical material
• Super finishing issues
• Current weights to 10,000 pounds and getting
  bigger

22
Typical Splined Hub

• Typically thru hardened but some nitrided or
  induction hardened
• Length up to 30 is a shaping challenge
• 42CrMo4 typical material
• Current weights up to 2500 pounds and getting
  bigger

23
Typical Ring Gear

• As large as 3 meters
• Many thru hardened
• Nitriding popular
• Induction hardening is also used
• Carburizing possible but problematic
• Shot peening and super finishing issues

24
Typical Planet

• Lots of planets needed 3, 4, or 5 per stage
• Precision size matching within sets
• 18CrNiMo7-6 typical material
• Current weights up to 2200 pounds and getting
  larger

25
Serial Production not job shop!

• 7,000 turbines per year 27 per day
• 10,000,000 cars per year 38,462 per day
• Typical large industrial gear shop does less than
  5 gearboxes per day
• Aircraft production similar in quality and
  complexity is on the order of 1000 per year

26
Thermal Processing Issues

• Large parts require large furnaces
• Economic load sizes typically over 5,000
• Large teeth require deep cases
• Cycle times of 60 hours not uncommon
• Aerospace quality required at all steps

27
Volume price pressure drive equipment purchases

• Customers want lowest possible costs
• Existing job shop equipment cant keep up
• New technology offers improved quality with
  faster cycle times

28
Dramatic Cycle Time Reductions Possible

• Shaping an internal ring takes 30 hours
• Gashing takes 3 hours
• Hobbing a gear can take 8 to 10 hours
• Gashing takes less than 2 hours

29
Big non-chip making investments needed

• SPC needed on everything
• 100 magnaflux, UT, nital etch typical
• Shot peening required on everything
• Full met lab checks on every furnace load
• Verification of geometry requires big CMM
• Everything that can be inspected must be
  inspected

30
Big investments needed in QC
Super Finishing required on many components To
achieve 4 to 8 AA surface finish
31
An Industrial Challenge worthy of a great nation!

• Potential to transform the economy
• Positive environmental impact
• Huge export market available
• US was once the world leader in wind energy and
  can be once again
• Plenty of room for innovation at all levels of
  the business
