Chapter 20 The Lymphatic System

1
Chapter 20The Lymphatic System
Use the video clip CH 20 - Lymph Node Anatomy
for a review of lymph node structure
G.R. Pitts, J.R. Schiller, and James F. Thompson,
Ph.D.
2
The Lymphatic System

• Basic organization
• Lymph fluid in lymph vessels
• Structures organs with lymphatic tissue, red
  bone marrow, liver and spleen
• Functions
• return interstitial fluid and proteins to the
  blood
• transport dietary fats to adipose tissue
• protect against cancer infection
• resistance - fight off disease
• nonspecific resistance - general protection
  against disease
• immunity - specific protection
• susceptibility - lack of resistance

3
Lymph Flow

• More fluid moves out of the blood capillaries by
  filtration than returns by reabsorption -
  Starlings Law
• 3Ll day of lymph is generated
• Proteins escaped from the blood or secreted by
  tissues are transferred back to the blood by the
  lymphatics
• Lymph flow is facilitated by muscle pumps, the
  respiratory pump, valves, and smooth muscle (in
  the walls of the trunks thoracic duct)
• Smaller vessels drain into larger vessels

4
Lymphatic Capillaries

• Blind ended, covered vessels between cells,
  larger than capillaries
• Not found in avascular tissues (CNS, cartilage)
  nor in the splenic pulp, and bone marrow

5
Lymphatic Capillaries

• Structure/Function regulates fluid flow
• Anchoring filaments - from lymphatic endothelium
  attach to surrounding tissues
• Endothelial cells overlap
• high hydrostatic fluid pressure separates cells,
  fluid into caps
• hydrostatic fluid pressure in cap prevents fluid
  movement out

minivalve
6
Lymph Flow Follows Venous Circulation

• Lymph vessels have the same organization and
  routing as the vascular tree

7
Lymphatic Flow (cont.)

• Lymphatic vessels have no separate pump (heart)
• All lymph returns to the vena cava and to the
  right side of the heart

8
Lymphatic Flow (cont.)

• Lymph ducts
• Right lymphatic duct
• about ½ inch long
• drains lymph from upper right side of body (arm
  head)

• Thoracic (left) duct
• main collecting duct of the lymphatic system
• 38-45 cm long
• drains 75 of body
• begins as a dilation known as the cisterna chyli
  located anterior to lumbar disk 2

9
Lymphatic Flow (cont.)

• Lymph returns to the venous drainage through
  right and left lymphatic ducts at the junction of
  the internal jugular and subclavian veins

10
Summary of Lymphatic Vessels

• Lymph Flow from smallest to largest
• Capillaries ? vessels ? trunks ? ducts
• Lymph vessels anastomose and supply and drain
  lymph nodes along their course

11
Two Main Types Of Lymphocytes

• B lymphocytes B cells
• attack microbes, especially bacteria
• develop into plasma cells to produce antibodies
  (Ab)
• bind to antigen to form antibody-antigen (Ag-Ab)
  complexes
• complexes prevents Ag from interacting with other
  body cells or molecules
• memory B cells dormant until future exposure to
  Ag
• T lymphocytes T cells
• regulate many immune responses
• attack viruses, fungi, transplants, cancer, some
  bacteria
• 4 types of T cells
• cytotoxic (killer) T cells - destroy foreign
  invaders
• helper T cells - assist B cells and cytotoxic T
  cells
• suppressor T cells help bring immune response
  to an end
• memory T cells - dormant until future exposure to
  Ag

12
Lymphocyte Development

• primary lymphatic organs - site of lymphocyte (B
  cell and T cell) production
• bone marrow - produces B cells, immature T cells
• T cells migrate to the thymus gland to mature or
  die if determined to be improper
• secondary lymphatic organs
• sites of activated immune responses
• lymphatic nodules (lymph follicles)
• lymph nodes, spleen, tonsils

13
Other Lymphoid Tissue Cells

• Macrophages Dendritic cells
• Phagocytize foreign substances and cells
• Transport them to lymphatic tissues
• Process foreign things into individual antigens
• Present Ags to T B lymphocyte to help activate
  them
• Reticular cells
• Similar to fibroblasts
• Produce reticular fibers (stroma) that provide
  the framing structure for other cells in lymphoid
  organs

14
Lymphatic Tissue - General

• Stroma of reticular connective tissue (except
  thymus)
• Parenchyma of macrophages, B and T lymphocytes,
  occasional other leukocytes
• May or may not have a connective tissue capsule

15
Lymphatic Organs Thymus Gland

• Thymus Gland
• Two lobes between the sternum and the heart
• Thymocytes produce hormones
• Atrophies with age (starting 20)
• Structure/Function
• Outer cortex immature T cells
• screened for functional capacity
• stimulated to proliferation
• stimulated to maturation
• Inner medulla
• defective T cells degenerate
• mature T cells move into blood

16
Lymphatic Organs Lymph Nodes

• Anatomy
• oval, bean shaped small structures scattered
  throughout body along lymph vessels
• may be deep or superficial
• concentrated along the respiratory tree and GI
  tract, in the mammary glands, axillae, and groin
• filter lymph fluid to trap foreign organisms,
  cell debris, and tumor cells

17
Circulation in the Lymph Nodes

• Lymph enters via a number of afferent lymphatic
  vessels
• It then enters a large subcapsular sinus and
  travels into a number of smaller sinuses
• It meanders through these sinuses and exits the
  node at the hilus via efferent vessels
• The node acts as a settling tank, because there
  are fewer efferent vessels, lymph stagnates
  somewhat in the node
• This allows lymphocytes and macrophages time to
  carry out their protective functions

Only lymph nodes filter lymph!
18
Cancer Metastasizes To Lymph Nodes
Cancer cells from the tumor are first trapped in
a lymph node
19
Lymphatic Organs - Spleen

• largest lymphoid organ in the body
• fibrous capsule with arteries, veins, and
  efferent lymph vessels
• located between stomach and diaphragm

20
Spleen Functions White Pulp

• a site of immune surveillance and response
• macrophages phagocytize bacteria, worn-out RBC's,
  platelets
• hemoglobin is recycled and components transferred
  to liver
• macrophage antigen-presentation and lymphocyte
  activation and proliferation
• some B cells mature into plasma cells

21
Spleen Functions Red Pulp

• Site of fetal erythrocyte production (normally
  ceases after birth)
• Stores 1 L of blood which can be released
  during an emergency (hemorrhage)

22
Unencapsulated Lymphatic Tissue

• Diffuse lymphatic tissue
• Small scattered patchs
• In nearly every organ
• Lymphoid follicles (nodules)
• More organized, more cellular clusters

small bronchus
23
Mucosa-Associated Lymphatic Tissue (MALT)
found in the lamina propria of mucous membranes
of the GI tract, respiratory tract, urinary
tract, and reproductive tract
Peyers patches in the intestines
24
Lymphatic Organs - Tonsils

• lymphoid tissue beneath the mucosae
• tonsilar crypts trap micro-organisms
• immune cells destroy the micro-organisms
• palantine tonsils largest and most frequently
  infected

25
Lymphadenopathy
Enlarged lymph nodes due to increased drainage
from inflammatory lesions or infections. Associat
ed with malignant and nonmalignant diseases.
Lymphocyte leukemia with severe lymphadenopathy
26
Hodgkins Diseaseone of thesignificant
malignant lymphomas
Cervical lymph nodes
27
Burkitts Lymphoma
Commonly found in central Africa and New
Guinea. Associated with Epstein-Barr virus which
causes infectious mononucleiosis in North America
and Europe. Rarer American type has extensive
marrow replacement. Cancerous cell is a B
lymphocyte.
28
End Chapter 20
