Chapter 23 (Part 1)

1
Chapter 23 (Part 1)

• Recombinant DNA Technology

2
Recombinant DNA Technology

• Methods for isolating, manipulating, and
  amplifying identifiable DNA sequences.
• Allows us to study the structure and function of
  individual genes.
• Allows for the directed genetic manipulation of
  organism (modify gene function, insert novel
  genes)

3
Cloning

• Clone a collection of molecules or cells, all
  identical to an original molecule or cell
• To "clone a gene" is to make many copies of it -
  for example, in a population of bacteria
• Gene can be an exact copy of a natural gene
• Gene can be an altered version of a natural gene
• Recombinant DNA technology makes it possible
• Allows for in vitro manipulation of a individual
  gene

4
Tools Needed for Cloning(Think of it as a
cutting and pasting process)

• cDNA or genomic library (source of DNA to cut)
• Plasmid (where you want to paste it)
• Restriction enzymes (scissors)
• DNA ligase (paste)
• E. coli (biological machine needed to amplify
  DNA)

5
Plasmids

• Naturally occurring extrachromosomal DNA
• Self replicating circular double stranded DNA
  molecules that have their own origin of
  replication
• Usually present in multiple copies per cell
• Plasmids can be cleaved by restriction enzymes,
  leaving sticky ends
• Artificial plasmids can be constructed by linking
  new DNA fragments to the sticky ends of plasmid

6
Cloning Vector

• Required features
• Origin of replication
• Selectable marker
• Screenable marker for recombinant molecules
• Cloning sites

7
Restriction Enzymes

• Bacteria protect themselves from attack by
  viruses and other bacteria using a
  restriction/modification system.
• Allows bacteria to recognize and destroy foreign
  DNA
• Bacteria contain DNA methylases that modify their
  chromosomal DNA at specific sequences.
• Also contain restriction endonucleases that
  recognize and cleave these same sequences when
  they are not methylated

8
Restriction Modification System
9
Restriction Enzymes

• Type I Contain methylase and endonulcease
  fuctions. Require ATP for hydrolysis and
  S-adenosylmethionine for methylation
• Type II contain only endonulcease function,.
  Does not require ATP for hydrolysis.
• Both types recognize palindrome sequences
  (sequences that read the same if read forward or
  backwards e.g. BOB or DEED

10
Type II Restriction Enzymes

• Names use 3-letter italicized code
• 1st letter - genus 2nd,3rd - species
• Following letter denotes strain
• EcoRI is the first restriction enzyme found in
  the R strain of E. coli

11
Sticky-end cutter
Blunt-end cutter
12
Restriction Enzymes

• Restriction enzymes can recognize specific 4
  base, 6 base, 8 base sequences.
• The probability that a given piece of DNA will
  contain a specific restriction site is n4
• n the number of bases in the restriction site
• So for a 6 base cutter (64), you would expect to
  find your site every 1300 base pairs. So in a
  10,000 bp fragment there is likely to by 7 or 8
  restriction sites corresponding to your enzyme.
• You can characterize DNA fragments using gel
  electrophoresis

13
T4 DNA Ligase
14
(No Transcript)
15
Transformation

• All of the previous steps were performed in
  vitro.
• We have generated a very small amount of a
  recombinant plasmid
• Need to amplify in bacteria to get enough to work
  with.
• Transformation process to mobilize DNA into
  bacterial host
• Select for transformed bacteria on specific
  antibiotic that corresponds to the antibiotic
  resistance gene present on the plasmid

16
How to produce a recombinant protein
0.1 to 1 of cellular protein
10 to 70 of cellular protein
17
Cloning a gene from a DNA libraries

• Any particular gene may represent a tiny, tiny
  fraction of the DNA in a given cell
• Can't isolate it directly
• Trick is to find the fragment or fragments in the
  library that contains the desired gene

18
cDNA
19
cDNA Library
cDNA
20
Library Screening

• DNA probe hydridization
• Requires that you know the protein or amino acid
  sequence of the gene of interest.
• Need to denature (make single stranded) and
  immobilize the DNA from each clone of the library
  to a filter (nitrocellulose or nylon)
• Make a labeled single stranded DNA/RNA probe (can
  use radioactive of fluorescent analogous of
  specific nucleotide triphosphates)
• Labeled single stranded DNA/RNA fragments will
  base pair (hydridize) with the target DNA on the
  filter
• Identify clones that are labeled.

21
DNA hydridization screening for specific gene

• Requires that you know something about the gene
  sequence
• Can get sequence information form purified protein

22
Now that we have the gene, what do we do with it?

• We could use it make a lot of protein in a
  microbial protein expression system
• We could use it to genetically manipulate
  organisms
• We could use it as a diagnostic tool

23
Why use recombinant Proteins?

• Proteins are often only available in small
  amounts in a given tissue
• Tissue sources may not be readily available
• It is time consuming and expensive to purify
  protein from tissues
• It is difficult to obtain absolutely pure protein


24
Insulin

• Was first purified from human pancreas from
  cadavers and then from pig pancreas.
• Genentec expressed insulin gene in microbial host
• Can grow microbes in large fermenters to produce
  unlimited supply of insulin.

25
(No Transcript)
26
Recombinant proteins are also important to
research

• For enzyme analysis need pure protein
• For structural analysis need lots (milligram
  amounts) of very pure protein
• Need pure proteins to make diagnostic tools such
  as antibodies

27
Genetic Modification of Higher Organisms

• Can introduce gene into animals and plants
• These modified organism are powerful research
  tools to study the effect of a specific gene
  product on metabolism, development etc.
• Has also been used to develop improved
  agricultural products

28
(No Transcript)
29
Genetically Engineered Salmon Is Bigger Better?
30
http//www.agwest.sk.ca/sabic_index_tp.shtml
31
Plant Genetic Engineering

• Improved Agricultural Production
• Herbicide Resistance
• Pest Resistance
• Improved Nutrition
• Vitamins - Golden Rice, Vitamin E
• Increase essential Amino Acid Content
• Chemical Synthesis
• Bio-plastics
• Bio-diesel
• Lubricants/detergents
• Rubber

32
(No Transcript)
33
GMO Concerns

• Ecological Concern
• Potential Food Allergens
• Antibiotic Resistance

34
GMO Benefits

• Lower application of herbicides and pesticides
• Creation of foods with increased nutrition
• Creation of bio-based alternative to petroleum
  based products

http//www.colostate.edu/programs/lifesciences/Tra
nsgenicCrops/
