Title: IP MPLS Virtual Private Networks


1
IP MPLS Virtual Private Networks
  • Presented by
  • Chris Chase

2
MPLS Concept
  • Outgrowth of IP Switching (e.g., MPOA, Epsilons
    IP Switching, Ciscos tag switching)
  • Key concept

Separate routing (the selection of paths through
the network) from forwarding/switching plus an
abstraction of aggregation
3
Non-MPLS Routing
  • Hierarchical topology - edge and backbone routers
  • Forward packet - lookup route at each hop

4
Routing with MPLS
  • Interior routes are assigned Labels that identify
    a connection/path Called a Label Switched Path
    (LSP) instead
  • of a PVC

5
Routing with MPLS
  • Interior routes are assigned Labels that identify
    a connection/path Called a Label Switched Path
    (LSP) instead of a PVC

6
Routing with MPLS
  • Traffic Engineering can use alternative to the
    IGP shortest path

7
Routing with MPLS
  • Interior routes are assigned Labels that identify
    a connection/path. Called a Label Switched Path
    (LSP) instead of a PVC.

8
MPLS Decouples routing and forwarding
  • IP packet header only examined at ingress PER
  • Hierarchy of routing/Label Stacking
  • Interior knows nothing about external addresses
    or routes
  • Only needs to know how to get between edges
    (PERs)
  • Enables very efficient explicit routing
  • Explicit routing in IPv4/v6 is expensive
  • Use explicit route for LSP instead of OSPF route

VPN Scale
9
History
  • IP cut through switching
  • Improve performance and provide QoS to IP
  • Multiprotocol over ATM (MPOA)
  • Epsilons IP Switching
  • Ascends IP Navigator
  • Ciscos tag switching
  • IBMs Aris
  • 1997
  • Needed alternative to SVC service for FR and ATM
  • Provider based IP VPN concept conceived
  • MPLS work initiated at IETF
  • A technology solution looking for a problem

10
Killer Applications of MPLS
  • IP VPNs
  • Provider Based, Simple, scalable, layer 2
    security
  • Overlapping, private addressing plans
  • Layer 2 VPNs FR, Ethernet, Circuit services
  • Traffic Engineering
  • Deliver service guarantees similar to FR/ATM
  • Fast reroute
  • Hierarchical Networks
  • Carriers carrier
  • Universal control plane
  • Label Optical (Lambda), Sonet/TDM, Spatial
    (ports/conduits)
  • GMPLS and Optical UNI
  • Not really an advantage Performance

11
The Basics
12
Generic MPLS Encapsulation
  • MPLS does not define a link layer protocol no
    framing provided
  • A shim header between link and network protocol
  • New LLC and PID defined for Ethernet, PPP, ATM,
    FR to carry label
  • Can stack tags/labels. Stack bit indicates end
    of stack.
  • There is no protocol ID field to indicate type of
    encapsulated packet.
  • Protocol of encapsulated packet is implied by the
    label
  • Indicated when the label is signaled (next slide)

13
Forwarding Equivalence Class (FEC) and Hierarchy
  • FEC All packets with the same forwarding
    requirements
  • i.e., same path, same QoS (policing, scheduling,
    discard)
  • COS bits can modify packet handling
  • Many different FEC types
  • IPv4, IPv6, FR, ATM, Ethernet VLAN
  • FEC ? label all packets in this class get the
    same label
  • Can stack labels (end of stack bit)
  • ? Hierarchy of equivalence classes
  • Hierarchy of routing
  • VPNs L3 and L2
  • Traffic engineering

14
Multi-protocol
  • Forwarding/Switching is content agnostic
  • Can carry IP, FR, ATM, Ethernet, anything
  • Label represents base common treatment shared by
    all packets with that label (FEC)
  • Control Plane (Routing and signaling) is content
    agnostic
  • IP control plane
  • Routing OSPF, IS-IS, BGP, PIM
  • Signaling LDP, CR-LDP, RSVP-TE, BGPext,
    PIMext
  • CoS Diff-serv
  • Many Layer 2 technologies, e.g, FR and ATM, have
    been fitted to MPLS
  • MPLS is not ATM
  • But ATM switches can be MPLS switches

15
Standards
  • IETF
  • First RFCs
  • 2702 (TE reqs), 3031 (arch), 3032 (stack
    encoding), 3034 (FR), 3035 (ATM VC), 3036 (LDP),
    2547 (VPN), 3107 (BGP), etc.
  • Drafts GMPLS, BGP, Multicast, Fast Recovery, L2
    VPNs,
  • http//www.ietf.org/html.charters/mpls-charter.htm
    l
  • L3 VPN
  • http//www.ietf.org/html.charters/ppvpn-charter.ht
    ml
  • draft-ietf-ppvpn-rfc2547bis-04.txt
  • L2 VPN
  • http//www.ietf.org/html.charters/pwe3-charter.htm
    l
  • Additional ITU work, MPLS and ATM Forum

16
Layer 3 MPLS VPN The Next Generation IP WAN
  • Based on 2547 draft
  • Another tool in the WAN toolbox for the network
    architect

17
Traditional Point-to-Point WANs
  • Rely on a hub architecture

18
Dual Star - Redundancy
19
Aggregation/Distribution Layer Scaling through
hierarchy
20
Domains of Enterprise WANs
  • Private lines
  • FR/ATM VC
  • Private line replacement
  • Hub-and-spoke
  • Very reliable, trusted, common
  • Site-to-site Internet VPN (i.e., IPSEC tunnels)
  • Point-to-point topologies (typically
    hub-and-spoke)
  • Extranets (also SSL)
  • Remote access
  • Footprint
  • Outsourced versus do-it-yourself
  • L3 MPLS VPN
  • Layer 3 IP routing outsourced to carrier
  • Following slides
  • They complement each other

21
L3 MPLS VPN 2547 style
  • Provider-based VPN
  • Vis-à-vis CPE-based tunneling VPN, e.g., L2TP
    with IPSEC
  • Others Virtual router VPNs, Layer 2 MPLS VPNs
  • IP MPLS VPN defined as a set of interfaces
  • Interface PPP, FR/ATM VC, Ethernet Vlan, LT2P
  • VPN membership assigned when provisioned
  • Customer interface standard IP, no MPLS
  • VPN appears as an Autonomous System (AS)
  • Customer router peers with this AS - a transit
    only AS in between customers sites
  • Private - separated from other VPNs
  • Like having your own little Internet

22
MPLS VPN Layer 3 IP Architecture
PER Provider Edge Router CER Customer Edge
Router LSR Label Switch Router
MPLS Network
LSR
LSR
LSR
OSPF
BGP or other protocol or Static Routes
PER
PER
IBGP
CER
Access IP serial link Encapsulated in PPP or
FR/ATM PVC or Ethernet
CER
23
MPLS VPN Value Adds vs. Other VPNs
  • Any to Any IP Connectivity
  • Optimal Routing without SVCs
  • Improved delay by avoiding tandem routing through
    a hub
  • Offload hub router
  • Any IP address scheme - Intranets and extranets
  • Circuit Consolidation eliminate aggregation
    layer
  • Diversity via IP routing - simplified DRO
  • Ease of network expansion
  • Access technology agnostic
  • FR, ATM, PPP over DS0-OC48 Ethernet
  • IP Class of Service
  • Provider-based IP VPN
  • No CPE-based tunneling and encryption
    equipment/software nor PKI management.

24
Combined Services
25
Load Balancing From VPN toward customer
Cust site Network A
26
Outbound Route Filtering (ORF)
  • Allowing a CER to communicate route filter to PER
  • Dynamically transferred through BGP

27
Class of Service Concepts
  • The ability for user to differentiate traffic
  • A provider could differentiate in many ways
  • Isolation - keep traffic in different classes
    from unfairly impacting each other
  • Performance
  • Bandwidth
  • Delay
  • Discard
  • Service
  • Availability
  • Support
  • Network engineer view as a toolset to manage
    traffic
  • As opposed to the marketing/management view
    around perception

28
IP Header Class of Service Marking
29
CoS via IP Packet Marking
  • CE classifies traffic per packet via marking
  • IP Diffserv Codepoints (Precedence bits)
  • Marking interpreted ?
  • Separate queuing per class
  • Per class resource scheduling, e.g.,
  • Priority queuing
  • Bandwidth scheduling (WFQ)
  • Drop differentiation
  • Packets marked discard eligible above class
    bandwidth
  • Transmitted when not congested

30
VPN CoS
31
CoS Marking Transparency Using MPLS
  • Users dont want packet markings to change
  • And some older systems TCP breaks
  • Provider can indicate reclassification by marking
    label instead of remarking IP packet

32
RFC2547 Constrained Route Distribution
  • Route Targets (RT) are used to constrain
    connectivity
  • Keeps VPNs separate
  • Creates topology within VPN
  • Concept of Hub and Spoke route policies used as
    building blocks
  • Hub and Spokes have a certain RT import and
    export list
  • Hub sites can see other hub and spoke routes
  • Spokes see only hub routes
  • Combine/compose to create VPN topology
  • Union of multiple hubs and spokes create
    arbitrary topologies
  • These slides dont show the explicit RT
    import/export lists
  • Hub types are shown as Hi and spoke types as Si

33
Any-to-Any Topology
34
Hub and Spoke Topology
  • Hi hub interfaces, Si spoke interfaces.
    The term hub and spoke just refers to how
    routes are constrained.
  • Si can only exchange routes with Hi. Hi
    exchanges routes with all Hi and with Si.
    Specifically in terms of route targets (RTs), Hi
    exports RT_Hi and imports RT_Hi, RT_Si, while
    Si exports RT_Si and imports RT_Hi.

35
Hub and Spoke Topology
  • Here we combine connectivity policies. Using H0,
    all hubs talk to each other.
  • By taking such unions of policies completely
    arbitrary bi-directional connectivity graphs can
    be realized (in fact completely arbitrary
    uni-directional graphs could be achieved which
    might be applicable for something like a
    firewall).

36
Note RTs only Constrain Routes
  • This does not use access lists that filter
    packets!
  • BGP MPLS VPN technology constrains route
    distribution (i.e., connectivity), they do not
    require per packet manipulation (which does not
    scale nor manage well).
  • Packets always follow routes (in the reverse
    direction of route flow)
  • But constraint of a specific route is not
    sufficient to constrain the reachability of a
    destination matching the route!
  • Overlapping routes (e.g., aggregates or defaults)
    can cause problems.

36
37
Tradeoffs of L3 MPLS VPN
  • For all the IP values-adds the drawbacks are
  • Have to route with provider!
  • Troubleshooting is more difficult than L2 WANs
  • L2 has clear demarc ? connection up or down.
  • Convergence is slower
  • Route changes have to propagate through provider
    routers
  • Certain routing problems are more difficult to
    solve
  • Some problems are more easily solved with direct
    topology manipulation
  • E.g., hub connectivity based on source
  • Peering model rather than flat model a
    different paradigm
  • Only IP no IPX, SNA, DECNET, Appletalk
  • Have to tunnel
  • Technology not as mature

37
38
Customer Support
  • Layer 2 services are easier to support
  • A customer doesnt call if his FR-connected
    routers arent seeing the same set of routes
  • Layer 3 VPN
  • Customer calls
  • I cant see my route. Help me troubleshoot my
    network.
  • Customer visible provider-based tools can help
    sectionalize and show customer whether there is a
    problem with provider network without getting a
    technician on the line.

38
39
Comments about CER-PER Protocol
  • 2547 VPNs are a peering architecture!
  • Static
  • Stable, but fill out order form
  • Only can detect local link failure
  • BGP
  • Many policies geared towards multihoming
    peering
  • Load balancing and ORF
  • OSPF
  • Changes intra-area to inter-area ? backdoor
    always preferred
  • EIGRP
  • Proprietary
  • Without ability to summarize need ability to
    avoid going active
  • CER acts as stub ? can loop (count to infinity)
    without new feature

40
How MPLS and 2547 VPNs Work
  • Quick BGP intro
  • LDP operation
  • 2547 VPNs
  • Follow the VPN route and label
  • Follow the packet

40
41
BGP Basics
  • BGP - fairly simple protocol
  • Uses TCP for reliable delivery
  • Distributes appearance/change and
    withdraw/disappearance of routes in route table
  • Routing Information Base (RIB) BGP route table
  • eBGP between AS
  • iBGP within AS
  • AS_PATH list of where route has been
  • Next hop
  • Other attributes are about policy, i.e., which
    route is best

42
Route Reflector scaling IBGP among AS edges
42
43
Route Reflector
  • Updates in RIB from inbound peer type are sent to
    outbound peer type in table below
  • Client is a special kind of IBGP neighbor
  • Any BGP router with a neighbor designated as a
    client is a route reflector

43
44
A Label Switched Path LSP
  • The downstream node assigns label
  • Often called an MPLS tunnel payload headers are
    not
  • Inspected inside of an LSP.

44
45
LSPs are Unidirectional
  • Destination FEC based
  • Cant distinguish upstream sender
  • LSPs merge
  • Results in multipoint-to-point LSPs

45
46
Penultimate Hop Popping
  • Look up the label ? pop look up header
    underneath
  • Why even bother sending a label?

PUSH
SWAP
IP Lookup
POP
666
IP
233
IP
46
47
Follow the Route and Follow the Packet
CR1 at Site 1 has a packet addressed to a host in
network Z at Site 2. How does it get there?
48
Label Distribution in Interior
  • For links configured for label switching
  • Node sends out periodic UDP Hello all router
    subnet broadcast on well-know LDP UDP port
  • Contains IP address for desired LDP session and
    desired label space
  • Creates a TCP-based LDP session to any node
    answering Hello
  • Session is initiated by node with lower
    advertised IP address
  • Each node advertises routes (FEC) and labels to
    all LDP peers
  • Node picks a local label for each route in its
    routing table and advertises this to everyone
  • Called downstream, unsolicited and independent
    control mode
  • The upstream node only installs into its label
    forwarding table where the downstream node is the
    next hop for the route (FEC)
  • Note in this mode if there is a reroute that
    changes the next hop the label is just rebound
    locally no signaling upstream
  • Much faster reroute compared to ATM, but local
    label assignment does not guarantee LSP is in
    place
  • ATM-LSRs work differently

49
LSP Setup for OSPF Route to PER2
50
How MPLS VPNs Work
  • 1) Follow the routes
  • Each VPN on a PER has a private routing table
  • Called a Virtual Routing Forwarding (vrf) table
  • vrf is assigned attributes that are unique to the
    VPN
  • Route Targets (RT) - attached to VPN routes.
  • only vrfs with common RTs share routes with each
    other
  • Route Distinguishers (RD) - appended to routes to
    ensure uniqueness even if VPNs have overlapping
    address spaces
  • Creates a new address family called vpnv4
    RDipv4
  • Note RTs and RDs are not applied to packets
  • 2) Follow the packet
  • A stack of two labels is used to forward the
    packet on the interior LSP and then external
    interface

51
VPN extensions
  • Route Target (RT)
  • BGP 64 bit extended community value
  • First 16bit identify as RT type. Other 48 bit is
    variable
  • Conventional format ASNX, i.e., 16b32b
  • Route Distinguisher
  • 64 bit, first 16 identify RD type
  • 48 bit selectable with format convention ASNX,
    i.e., 16b32b

52
Distributing Customer Routes
53
Customer Routes Distributed via IBGP with Label
IPFR Cloud
LSR3
LSR2
LSR1
PER1
PER2
LNK2
IBGP msg
Network Z
CR1
RD1Z, L4, RT1, PER2
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ? L4,CR2,LNK2
CR2
Li - labels
LSP
54
Only vrfs with Matching RTs Import Route
IPFR Cloud
LSR3
LNK1 data vrf1 vrf1 RT1, RD2 table Rt
Z ? L4, PER2 PER2 ? L1, LSR1
LSR2
LSR1
PER1
PER2
LNK2
Network Z
CR1
CR2
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ?L4,CR2,LNK2
Li - labels
LSP
55
Purpose of BGP Label
  • Indicates which vrf and optionally which
    interface on the egress PER
  • Locally, the egress PER will treat labels in two
    possible ways
  • Non-aggregate label is associated with an
    external route
  • Will be switched directly to an outgoing
    interface
  • IP header is not examined
  • Aggregate label is associated with a locally
    originated or directly connected route
  • Packet will be looked up in the vrf context

56
CR1 learns RT Z via BGP (or statically
configured)
IPFR Cloud
LSR3
LNK1 data vrf1 vrf1 RT1, RD2 table Rt
Z ? L4, PER2 PER2 ? L1, LSR1
LSR2
LSR1
PER1
PER2
Network Z
CR1
table Rt Z ? PER1
CR2
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ?L4,CR2,LNK2
Li - labels
LSP
57
Packet for Rt Z forwarded by CR1
IPFR Cloud
LSR3
LNK1 data vrf1 vrf1 RT1, RD1 table Rt
Z ? L4, PER2 PER2 ? L1, LSR1
LSR2
LSR1
PER1
PER2
Route Z
Z packet
CR1
table Rt Z? PER1,LNK1
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ?L4,CR2,LNK2
CR2
Li - labels
LSP
58
Top label is label-switched through interior
IPFR Cloud
LSR3
L2? pop
LNK1 data vrf1 vrf1 RT1, RD1 table Rt
Z ? L4, PER2 PER2 ? L1, LSR1
L1? L2
LSR2
LSR1
PER1
PER2
L1L4Z packet
Route Z
CR1
CR2
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ?L4,CR2,LNK2
Li - labels
LSP
59
Top label popped at end of LSP
IPFR Cloud
LSR3
LSR2
LSR1
L4Z packet
PER1
PER2
Route Z
CR1
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ?L4,CR2,LNK2
CR2
Li - labels
LSP
60
Inner label determines egress interface and then
is popped.
IPFR Cloud
LSR3
LSR2
LSR1
Zpacket
PER1
PER2
Route Z
CR1
LNK2 data vrf1 vrf1 RT1, RD1 table Rt
Z ?L4,CR2,LNK2
CR2
Li - labels
LSP
61
MPLS in Core Not Needed
  • MPLS for IGP domain serves as a tunneling method
    among PERs
  • Could use other tunneling methods
  • Advantages to MPLS
  • Full mesh of LSP tunnels automatically created
  • Can use MPLS TE
  • Internet draft to use IP or GRE tunneling
  • Automatically (treat vpnv4 BGP next hop as a
    recursive encapsulation)

62
MPLS VPN Security
  • There is a private routing table for each VPN
    (vrf)
  • VPN membership Identity associated with each
    access connection
  • VPN membership is not determined by IP header,
    only by interface (e.g., DLCI, VPI/VCI, PPP, VLAN
    tag).
  • Label and RT for VPN attached to routes
    advertised for interface.
  • Route and its matching label are only imported by
    routing tables that match the VPN RT.
  • Impossible for a packet on a PVC in one vrf to
    spoof its way or jump into another vrf

63
MPLS VPN Security
  • Requires correct provisioning of connections and
    RTs
  • ? Same as FR/ATM security
  • Given correct provisioning it is impossible for
    packet to jump from one PVC to another PVC
  • If you dont need encryption on FR/ATM/P-L then
    dont need it here
  • If you would encrypt over FR/ATM/P-L then you
    would also encrypt here

64
MPLS VPN Scale for the Carrier
  • Can the MPLS VPN technology scale to meet the
    size of the market?
  • Can it be managed at scale?
  • Does this have anything to do with the Internet?

65
All Those Routes
  • Can be a lot of routes in the service
  • The aggregate over all VPNs
  • There is no summarization of routes!
  • BUT
  • No VPN state in backbone LSRs, only in PERs.
  • PER only holds routes for VPNs touching it.
  • Route Reflectors (RR) only handle VPNs they touch

66
Large Corporate Intranet vs Internet
  • Intranet Private Corporate Network
  • aka VPN
  • P/L or FR/ATM VCs
  • Recent survey - total number of U.S. enterprises
    using FR at 35,000
  • Tens to thousands of sites
  • 95 ? T1
  • Internet corporate access from Intranet
  • ? 10 Corporate gateways
  • ? T1

67
Modeling Large Enterprise VPNs
  • Based on customer observations and business
    nature of large corps
  • Large sites, N, for N100 10,000
  • routes KN C
  • K 2, 3, 10
  • one route always for CER-PER link
  • Largest FR/ATM customer N 20,000 sites
  • 95 lt T1
  • BW utilization lt 25

68
Constraints
  • User Plane forwarding (pps)
  • vrf/MPLS cost is small
  • Control Plane
  • Interior (IGP) component is independent of
    MPLS/VPN
  • Space (memory)
  • vrf and BGP session overhead small compared to
    route space
  • Signaling/Routing (CPU)
  • most important in transient situations (e.g.,
    link failures)
  • Public resources
  • e.g, registered IPv4 addresses, RTs among
    partners
  • OSS

69
Divide and Conquer
  • How to keep dimensions within constraints?
  • (i) State reduction
  • (ii) Partition
  • (iii) Distribute
  • Forwarding
  • Control plane

70
State Reduction
  • Route Summarization
  • In middle of customer network
  • not really an option, maybe greenfield intranets
  • Limit the routes in a VPN
  • Keep allowed routes commensurate with number of
    interfaces purchased
  • vrf route limit
  • Use carriers carrier
  • Providers, non-enterprise, that have lots of
    routes, few ports

71
Partitioning
  • Limit VPNs touching a PER
  • To avoid poor PER utilization aggregate and
    fan-out
  • Groom up interfaces rather than push PER toward
    CE
  • Fan out across PERs in a POP
  • Limit VPNs touching RR
  • (i) Via RTs and ORF requires RT assignment
    strategy
  • (ii) Via communities
  • (iii) Via PER-RR mutually exclusive VPN subsets
  • ? PERs and RRs only need to handle the largest
    enterprise customer VPN

72
Distributing Forwarding and Control
  • Distributed forwarding
  • All modern routers have distributed user
    (forwarding) plane
  • BUT most have centralized control
  • Low CER speeds ? lots CERs/PER ? more likely to
    be constrained by control plane limits than
    packets per second
  • Distributed control
  • CER-PER routing and vrf tables limited to
    necessary interfaces
  • Central controller has no vrf tables, vpnv4 route
    tables, or CER peering protocols

73
IP Multicast VPN Solution
  • It is based on Multicast Domain
    (draft-rosen-vpn-mcast-05.txt)
  • P and PE routers multicast enabled
  • Provider internal multicast routing tables
  • Globally PEs configured to run PIM (global
    instance) with adjacent P routers
  • PEs maintain PIM adjacencies with CE devices
  • Normal PIM configuration in customer network
  • PIM modes, RPs , multicast addressing

74
Multicast Tunnels and the default MDTs
CE
PE
Provider Network
Per VRF MDT
CE
PE
PE
CE
  • Per mvrf default multicast distribution tree
    (default MDT) using traditional PIM within
    backbone
  • MDT used to distribute end customer multicast
    packets and PIM control messages
  • Access to the MDT is via a multicast GRE tunnel
    interface on PE
  • Each PE in VPN is a leaf _and_ root on the MDT
  • For efficiency (but more state) can launch per
    session (S,G) MDTs for a VPN

75
Using an MDT
C-packet SRCPC1 DST225.1.1.1
C-packet SRCPC1 DST225.1.1.1
P-packet SRCLo1 DST234.10.10.1
PE
PE
CE
CE
Lo1
MDT GROUP ADDRESS 234.10.10.1
Receiver
SRC
  • Forwarding onto the MDT is done in encapsulated
    packets off PE
  • GRE or IP-in-IP
  • C-Packets - customer control and data packets
  • P-Packets provider control and data packets
  • Destination Address MDT group address for VRF
  • Source Address IP address of PE M-BGP peering
    address
  • C-packet becomes a P-packet when encapsulated
  • MPLS is NOT used!

76
IP Traffic Engineering and MPLS
  • Improving utilization of backbone resources

77
The Multi-Commodity Flow Problem
  • The traffic engineering problem
  • Find a feasible solution
  • Find a min cost solution
  • Find feasible and min cost solution with single
    node or link deletion

Demands d(i,j) from node i to j Constraints -
link capacity b(i,j) Costs, e.g., link costs
C(i,j) Path (route) p(k) variables for each
demand
78
Explicit Routing
  • Solutions to the arbitrary TE problem require
    specifying the explicit route (path) for each
    demand
  • Could calculate explicit routes satisfying
    constraints offline
  • Then specify explicit routes in network without
    constraints

79
Constraint-based Shortest Path First (CSPF)
  • Can let the network enforce constraints
  • CSPF distributed algorithm
  • Given full knowledge of network resource
    allocation
  • Route a demand by
  • Pruning network to only feasible paths
  • Pick shortest path
  • Compromise to solving the full TE problem

80
IP TE
  • Metric Manipulation
  • i.e., pick OSPF weights to create feasible
    solution
  • Limited in problems that it can solve
  • Simple Topology and capacity augmentation
  • Tends to over-engineer or restrict topology
  • Source Route
  • IPv4 option that allows explicit route
  • Very costly, not practical
  • ? No efficient explicit routing nor knowledge of
    network resource allocation

81
Making it Fit with Plain IP Routing
Link size 1, d(1,2) 0.75, d(1,3) 0.5,
d(1,4) 0.5 Cant pick OSPF weights that work
82
ATM TE
  • ATM routing (PNNI) has knowledge of resource
    usage
  • Bandwidth booked per trunk
  • Performs CSPF to find feasible path for
  • New demand
  • Rerouted demand
  • Feasibility referred to as Call Admission Control

83
Making it Fit with ATM switching
Link size 1, d(1,2) 0.75, d(1,3) 0.5,
d(1,4) 0.5
84
IP over ATM
  • The way to build ISP backbones not too long ago
  • Allowed efficiently utilizing a limited number of
    costly facilities shared among routers
  • Typically a full mesh of ATM PVCs is created
    among the backbone routers
  • PVCs sized to router endpoint demand
  • But
  • Led to N2 IP peering
  • IP router investment outstripped speed of ATM

85
MPLS TE for IP
  • Provides efficient explicit routing for IP
  • Can communicate resource constraints
  • But not an overlay routing design
  • Routers not in a full peering mesh
  • Uses IP-based control plane protocols rather than
    a different protocol
  • RSVP-TE uses extensions of RSVP to carry labels
    and additional constraints

86
How RSVP-TE Works
  • PATH downstream contains explicit hops and
    bandwidth
  • RESV upstream contains labels

RESV with labels
87
Online CSPF with OSPF-TE
  • Can use RSVP-TE without resource reservation
  • Calculate constrained paths offline
  • For online CSPF need
  • Knowledge of resource assignment in network
  • Add resources to OSPF link states
  • i.e., bandwidth available per class (diff-serv)
  • Flood changes in resource allocation
  • Unlike normal OSPF which just floods when link
    up/down changes
  • Now use RSVP-TE with non-zero reservations per
    class (diff-serv)
  • Similar to ATM PNNI

88
MPLS Fast Reroute
  • Using MPLS TE to improve availability
  • RSVP-TE creates backup tunnels
  • On failure of protected LSP, packets are shoved
    down backup LSP tunnel
  • Switchover is faster than waiting for CSPF to
    calculate and signal a new LSP
  • For local repair (link or node) can recover
    100ms or better
  • Backup LSP is already in place, so as soon as the
    failure is detected locally the headend just
    needs to reprogram the label FIB

89
Link Protection
  • Create backup LSP around link to Next Hop
  • With or without reservation
  • Can also backup normal LDP LSP

90
Node Protection
  • Create backup tunnel LSP for two hops away
    (next-next hop)
  • Backs up RSVP-TE tunnel
  • Learns labels from RESV recorded route of
    protected tunnel

91
Path Protection
  • Create an end-to-end diverse backup tunnel
  • Slower than local protection have to wait for
    headend to detect failure

92
What are Layer 2 VPNs?
  • Defined at the IETF PPVPN and PWE3 groups
  • http//www.ietf.org/internet-drafts/draft-ietf-ppv
    pn-l2vpn-requirements-00.txt
  • http//www.ietf.org/html.charters/pwe3-charter.htm
    l
  • Point-to-point
  • Virtual Private Wire Service (VPWS)
  • Offers FR, ATM and Ethernet pvc-like services
  • Nothing new here have been available for many
    years
  • Multi-point Ethernet Bridging
  • Virtual Private LAN Service (VPLS)
  • Similar to the Transparent LAN Services
  • Around for a while using standard Ethernet
    switching
  • But VPLS is more scalable over the WAN

93
So what?
  • IP or MPLS as the multi-service carrier core
  • Was ATM, but ATM didnt keep up with IP
    investments
  • On one core network carrier can put
  • Internet, Voice (trunking and service), FR,
    Ethernet, ATM, L3 IP VPN, IPSEC VPN
  • Finally, network convergence for the carrier??
  • New market for struggling carriers
  • Some newer providers only built fiber transport
    and IP backbone for Internet service and no ATM
    backbone
  • They are eager to go after the Enterprise WAN
    business
  • L2 VPNs can be built on their existing IP
    infrastructure
  • For Customers nothing really new, just more
    competitors for their WAN

94
Business Communications Review, Jan 2002 chart
from Vertical Systems
95
Tunneling
  • PE-to-PE tunnel
  • L2TP
  • MPLS
  • Multiplexer field
  • One tunnel, many connections called Pseudo Wires
  • Control field
  • Optional sequence number (detect out of order
    packets)
  • Protocol specific control bits (e.g., DE, FECN,
    CLP, PTI)

96
Encapsulations
  • L2TPv3 purely connectionless with IP header
  • No new technology in carrier IP backbone but
  • Spoofable
  • Cookie provides no strong verification
  • No QoS other than diff-serv
  • MPLS
  • Less overhead
  • Can use MPLS TE

97
L2 MPLS VPN Example FR
  • Directed LDP between PE pair exchanges FEC and
    label for a particular pseudo wire

DLCI 200
CER
MPLS Network
DLCI 100
PER
CER
PE
PVCs within tunnels
DLCI 300
PER
CER
L1 L2 Cw FR PDU
FR PVC from DLCI 100 to 300
98
VPLS Virtual Private LAN Service
  • Multipoint to multipoint service
  • Any-to-any
  • Does LAN bridging, MAC address learning
  • While Ethernet frame based
  • IT IS ACCESS TECHNOLOGY AGNOSTIC
  • Dont have to use GigE
  • Can use Ethernet bridging over other access types
  • i.e., bridged over FR/ATM/PPP for NxDS0, T1,
    NxT1, T3 or bridged over SONET
  • Any protocol not just IP e.g., IPX, DECNET
  • No routing with carrier! but
  • More than a few dozen sites on a VPN (single
    LAN)?
  • No Spanning Tree, so just connect routers

99
State of the Art
  • OAM work still needs a lot of work
  • Fault detection/isolation, performance
    measurement, probing
  • Little Call Admission Control
  • How to map bandwidth resources and classes onto
    tunnels
  • No Multi-AS implementations
  • Minimal legacy interworking
  • Just glue connections at dumb interconnect to
    ATM

100
MPLS to Prem or in the Enterprise?
  • Can run MPLS to CER
  • By running BGP CER-CER
  • Can create own VPNs (vpnv4) on top of providers
  • Tenant service
  • Hierarchy of ipv4 routing
  • 3rd tier ISP backbone outsourcing (carriers of
    carrier)
  • But dont need MPLS for tunneling CER-CER
  • Use IP tunneling with transparent
    interoperability with carrier
  • MPLS in private network
  • Create own VPNs (essentially an internal carrier)
  • For traffic engineering IP

101
Completed PHASE I- MPLS Please Continue to the
Next Phase
102
Performance Engineering in MPLS-based VPNs
  • Susan Hilton
  • Enterprise Network Consultant

103
Performance Engineering
  • Rationale
  • CoS Foundation Technologies
  • Service Implementation
  • Applied Performance Engineering

104
Not All Traffic is Equal
APPLICATIONS
Interactive Data
3-Tier ERP
Bulk Transfer
Interactive Voice
BANDWIDTH
LOW
MEDIUM
HI
MEDIUM
DELAY
LOW
MEDIUM
HIGH
LOW
SERVICE METRICS
JITTER
MEDIUM
MEDIUM
HIGH
LOW
105
Multi-Application Networks
  • Mixing applications with similar traffic
    characteristics and similar performance
    requirements is simply a sizing exercise
  • Statistical multiplication
  • Mixing applications with conflicting traffic
    characteristics often causes some to not meet
    Response Time requirements
  • Even with sufficient bandwidth deployed!


106
Traffic Profiles and basic QoS requirements
Voice, Video and Data
Bandwidth per call depends on codec and
sampling-rate
Similar performance requirements as VoIP, but
radically different traffic patterns
Traffic patterns for Data vary among applications
(and even among different versions of the same
application)
  • Latency 150 ms
  • Jitter 30 ms
  • Loss 1
  • One-way requirements
  • Latency 150 ms
  • Jitter 30 ms
  • Loss 1
  • One-way requirements
  • Data Classes
  • Mission-Critical Apps
  • Transactional/Interactive Apps
  • Bulk Data Apps
  • Best Effort Apps (Default)

107
Data Classifications Application Examples

108
Performance Engineering
  • Includes
  • Network Engineering
  • Capacity Planning
  • Traffic Engineering
  • Bandwidth management
  • congestion management/avoidance to ensure the
    availability of high priority traffic and at the
    same time increase the network efficiency
  • What is performance engineering?
  • The process of engineering a network to assure
    that applications attain their required
    performance.
  • Provide defined service metrics for different
    applications

109
Service Metrics
  • Bandwidth
  • Delay/Latency
  • Time it takes a packet to travel from origination
    to destination
  • Distance, switching, insertion, queuing
  • Jitter (Variability in Delay)
  • Latency that is unpredictable 1st packet 10ms
    delay, 2nd packet 30ms delay. (Early/late
    packets)
  • Packet Loss
  • Buffer Overflows, Selective discards, Line Errors

110
Technology Evolution - General Attributes
  • Increase in
  • Connectivity
  • Shared Resources (lt?)
  • Path Variance
  • Delay
  • Delay Variance
  • Decrease in
  • Per connection engineering

Most connectivity Most delay Least
cost Least connectivity Least delay Most
cost
I
VPNS
L2 VPN
FR
PL
111
Technology Evolution - Future Direction
I
COS
VPNS
  • Connectivity
  • Shared Resources (lt?)

I
COS
L2 VPN
VPNS
COS
  • Class-of-Service features added to improve
  • Path Variance
  • Delay
  • Delay Variance

FR
L2 VPN
COS
ATM
PL
PL
112
QoS / CoSWhats the Difference?
  • QoS Quality of Service
  • Absolute Metrics, Contracted parameters
  • Each flow must be engineered independently
  • Addresses the service requirements of different
    applications in order to provide more than best
    effort service for specific applications
  • CoS Class of Service
  • Relative treatment of contending flows
  • Implies that flows can be categorized or
    differentiated!
  • The implementation that provides QoS
  • Used interchangeably in this session

113
Is Bandwidth the Answer?
  • Just deploy more bandwidth
  • Queuing Delay is f(link speed)
  • Bandwidth is cheap
  • QoS is complicated
  • MAYBE for LAN, MAN
  • Maybe even for WAN backbone
  • WAN edge will remain a bottleneck for
    foreseeable future

114
Why IP QoS is Needed
  • Enterprise networks are migrating toward IP
    transport
  • Best effort is not good enough
  • Engineered performance is required for
    enterprise applications.
  • Emerging applications (VOIP, Streaming) are
    highly sensitive to delay, jitter (delay
    variation), and packet loss.
  • Need performance/reliability of private networks
    with ubiquity/cost advantage of Internet.
  • One approach MPLS

115
CoS for IP VPNs
  • Traditional techniques do not work for mesh
    topologies as we will see.
  • Egress port speed is still a bottleneck
  • The Service needs to participate in CoS solution.

116
CoS Foundation Technologies
  • Advanced Queuing
  • Queue Management
  • Traffic Shaping
  • Classification and Marking
  • Fragmentation

117
Advanced Queuing
  • Advanced Queuing is any technique that transmits
    packets in a different order than they were
    received.
  • I.e. Not FIFO
  • These techniques only kick-in when there is
    congestion. (I.e. if there is no queuing, then
    there is no advanced queuing.
  • Advanced queuing only makes sense where there is
    a speed mismatch.
  • I.e arrival rate is greater than departure rate.

118
Priority Queuing
In
  • Prioritization allows specified traffic to
    preempt competing traffic.
  • Can be multiple levels of priority.
  • (4 in Cisco)
  • Higher priority traffic can starve lower
    priority traffic.

Out
119
Bandwidth Allocation
  • Also called
  • Custom Queuing
  • Weighted Round Robin
  • Each traffic type gets a relative allocation of
    the bandwidth.
  • bits, bytes, packets

In
10
5
3
1
1
Out
120
Bandwidth Allocation Considerations
  • Cycle Time
  • All buckets are served in each cycle. (No
    priority)
  • More buckets ? longer cycle time
  • Unused allocation shared proportionately across
    remaining traffic types.
  • Cisco de-queuing quirk
  • Always serve at least 1 packet, even if it is
    bigger than allocation
  • No concept of credit or deficit.

121
Fair Queue
  • Not all packets are equal
  • Large and small packets
  • Part of sparse or heavy peer to peer
  • More or less time sensitive to application
  • Scheduling algorithms basic
  • When a packet within a flow arrives, calculate
    when it would get served as part of each flow
  • Process packets in this order (not necessarily at
    this time)

3
2
5
1
4
122
Weighted and Flow Based
  • Simple algorithm works well to give everyone a
    fair share. Some problems -
  • Sparse flows must wait even though they require
    little bandwidth (high jitter)
  • High priority packets must wait
  • Assign weights to scheduled times based on
  • Precedence
  • Sparse or heavy flow (Cisco Flow Based WFQ)
  • Other

123
Weighted Fair Queuing
  • No defined traffic classes
  • Packets hashed to 1 of 64 queues
  • Hash ? f (SourceIP, Source Port, DestIP,
    DestPort)
  • Possibility of bulk and interactive with same
    hash
  • Weighted Fair means each queue has equal weight
    (1)
  • Each Packet is scheduled at arrival time
  • Schedule Time Queue Tail (Weight Length)
  • De-Queue based on Schedule Time
  • Calendar Queuing

0
1
1000
Hash
2
125
3
150
300
200
250
310
64
60
120
180
240
300
124
Flow Based WFQ more detail
  • Detects bandwidth of layer 4 flows (also know as
    conversations)
  • Classifies traffic into as many as 64 bins
  • Allocates bandwidth equally across all flows
  • Light flows get the bandwidth they need, heavy
    flows share the remaining bandwidth
  • On by default in Cisco low speed interfaces

125
Class-Based Weighted Fair Queuing
  • A Hybrid
  • Class-Based
  • Defined Classes instead of hashing
  • Weighted Fair Queuing
  • Weighted Fair Queuing with defined weight
  • Schedule Time Queue Tail (Weight Length)

0
Weight
400
Class-Mapping
4
A
100 bytes
300
600
B
2
150 bytes
150 bytes
C
600
1200
10
60 bytes
60 bytes
126
Class-Based Weighted Fair Queuing
  • Weight of a traffic class is implied by Bandwidth
  • Weight 1/(BW Percent)
  • Behavior is opposite of WFQ
  • Higher BW Higher Priority

Example Class A FTP BW 10 ? Weight
10 Class B Telnet BW 90 ? Weight
1.111
0
Weight
15,000
Class-Mapping
10
A
1500 bytes
B
244, 198, 132, 66
1.1
60 bytes each
127
CBWFQ - Cisco
  • Unlike WFQ that applies relative priority, CBWFQ
    enables absolute guarantees
  • Assigns flows to classes
  • Allocation to a class can be based on almost
    anything
  • Made up of many parts
  • FQ Fair Queue, nobody gets it all
  • W Weighs applied to queues
  • CB Class Based, uses class to define queues
  • None of this applies unless there is a queue to
    manage. When no congestion, no priority is
    assigned.
  • Only available Cisco solution for high speed
    router ports (above E1, with possible exception
    of DS3 Frame Relay)
  • Weights are applied per class
  • Generally uses Flow Based WFQ within a class
  • Includes a special class Low Latency Queue (LLQ)

128
Configuring CBWFQ (Cisco)
  • Policy-map defines the classes
  • Class-map assigns packets to a class
  • Service-policy invokes the policy on an interface

class-map class1 match access-group
101 class-map class2 match input-interface
s0 ! policy-map policy1 class class1 bandwidth
50 queue-limit 100 class class2 bandwidth
20 queue-limit 35 class class-default fair-qu
eue interface atm0.1 point-to-point ip address
10.10.10.1 255.255.255.252 pvc atlanta
1/105 vbr-nrt 40000 72000 32 service-policy
out policy1
129
Low Latency Queue - LLQ
  • A special queue defined by the policy-map
  • Applies strict priority up to the bandwidth
    specified will not serve any other queue until
    the LLQ is empty
  • Drops packets above the specified bandwidth
    WRED and queue depth do not apply
  • Invoked by using the priority command in place
    of the bandwidth command

130
Queue Management
  • Queue Depth is specified in policy-map
  • CBWFQ defines how queues are served but what
    happens when a particular queue gets too big?
  • Packets are discarded
  • Tail Drop drops all packets arriving after the
    queue is full
  • Weighted Random Early Detection (WRED)

131
Queue Management Tail Drop
  • Tail Drop, Global Synchronization, WRED
  • Tail drop tends to affect all flows in a queue.
    This effect is called global synchronization.
    All flows crank up their windows, congestion
    occurs, tail drop drops all arriving packets, all
    widows reset.

Queue Full
Total BW Utilization
Individual TCP Sessions
132
Queue Management - WRED
  • Weighted Random Early Detect
  • WRED drops a few random packets before congestion
    reaches the queue depth threshold. This causes a
    small number of flows to reset their TCP/IP
    window while the remaining flows continue to use
    available bandwidth.
  • Effective for large number of flows,
    questionable for enterprise.
  • Can specify differing WRED threshold based on IP
    Prec.

Queue Full
WRED Thresh
Total BW Utilization
Average Utilization After WRED drop.
Individual TCP Sessions
133
Tail Drop vs. WRED
  • Tail drop tends to affect all flows in a queue.
    This effect is called global synchronization.
    All flows crank up their windows, congestion
    occurs, tail drop drops all arriving packets, all
    widows reset.
  • WRED drops a few random packets before congestion
    reaches the queue depth threshold. This causes a
    small number of flows to reset their TCP/IP
    window.

134
Traffic Shaping
  • Traffic shaping is a tool to move a queue
    from one place in a network to another.
  • Queues only occur where there is a speed
    mismatch.
  • If arrival rate gt departure rate -gt queue
  • Traffic Shaping forces a speed mismatch in a
    router to prevent a speed mismatch in a network.

135
Traffic Shaping
FR Network
Router
Router
136
Mesh Based Shaping
  • In mesh topologies, where is the choke point?
    That is where a queue will build!

Router
Router
  • Can we control this queue at the high speed end?
    NO, because of other remote sites.

137
Value of MPLS Traffic Shaping
  • Unlike mesh PVCs, MPLS services can apply shaping
    in the cloud to manage the queue

Router
Router
138
Policing / Shaping Two Sides of the Same Coin
  • A service subscription has an implied traffic
    contract
  • Service provider Polices arriving packets against
    the contract
  • Customer Shapes traffic to assure conformance to
    the contract

139
Policing
  • Policing
  • Enforce a traffic contract
  • Pass all traffic within contract
  • Out of contract
  • Drop
  • Or mark as out of contract
  • DE Bit in frame relay networks
  • CLP in ATM networks
  • IP Precedence or DSCP in IP networks

140
What happens to Non-Conforming Traffic
  • Mark but do not discard, unless congestion
  • OR
  • Drop

141
Classification and Marking
  • Need to identify packets in order to determine
    what service level is required (classification)
  • Supported by marking or coloring
  • Marking is done in the IP header

20 bytes
142
Marking IP Precedence
  • Type of Service provides 8 bits
  • Bits 0-2 IP Precedence

143
Marking DSCP
  • Start with IP Precedence 3 bits (Class Selectors)
  • Add Drop Precedence Levels of 3 bits

144
Marking DSCP
  • The second three bits are used for Per Hop
    Behavior or Drop Probability
  • Applies to Class 1-4 or Assured Forwarding (AF)
  • Provides more flexibility

145
Fragmentation
  • On low speed (lt768K) ports, queueing is not
    enough
  • Insertion (serialization) delay is an issue
  • Insertion packet size (bits)/line speed
  • Example (15008)/56 214 msec
  • Objective for voice is 10 msec insertion delay
    per packet

146
Insertion Delays
Fn(line speed)
Fn(packet length)
100 bytes
100 bytes
500 bytes
128Kbps
64Kbps
56Kbps
128Kbps
64Kbps
t
t
t
6.25ms
31.25ms
14ms
12.5ms
62.5ms
800bits /56K 14ms 100bytes / 7 14ms
(8100)(1/128K 1/64K) 18.75ms
(8500)(1/128K 1/ 64K) 93.75ms
56Kbps7bytes/ms
147
Fragmentation Compression
  • Even with optimal queuing treatment, performance
    may not be acceptable.
  • The best treatment that can be obtained with
    strict prioritization is queuing delay of O(1/2
    of a packet).
  • I.e. Best case, prioritized packet gets
    transmitted immediately.
  • Worst case, prioritized packet has to wait for
    the currently transmitting packet to finish.
  • On average, wait time for prioritized packet is ½
    of a non-prioritized packet.
  • This is still substantial delay (and jitter) for
    low speed ports.
  • Fragmentation Compression is a means to make
    the low priority packets smaller so O(1/2
    packet delay is smaller)

148
Head of Line Blocking
  • Real time traffic arrives but a 1500 byte packet
    is just starting transmission
  • LLQ/CBWFQ gives only priority if the line has not
    started to send the packet There is no
    preemptive capability..
  • The 1500-byte frame takes 187.5 ms to serialize
    on a 64-kbps access. Real time traffic have to
    wait. This is HOL Blocking
  • Link Fragmentation and Interleaving (LFI) is the
    mechanism fragment large data frames into
    regularly sized pieces and to interleave small
    real time packets into the flow.

149
Head of Line Blocking
150
Fragmentation
  • MTU
  • Dangerous many apps set Do Not Fragment
  • Can be done at source, but no very practical
  • FRF.12
  • Fragment data packets
  • Prioritize voice packets
  • Voice only, not suitable for priority data
  • No LFI
  • ATM Interworking is complicated
  • ML-PPP
  • Best generic solution
  • More overhead than FRF.12, but OK with compression

151
Fragmentation
Packet Size (bytes)
Link Speed
T
About PowerShow.com
