Infiniband enables scalable Real Application Clusters

1
Infiniband enables scalable Real Application
Clusters Update Spring 2008

• Sumanta Chatterjee, Oracle
• Richard Frank, Oracle

2
What is Oracle Real Application Clusters (RAC)
Database?
Public Network to Grid Computing Nodes
Database
Instance 1
Instance 2
Instance 3
Instance 4

SGA 4
SGA 1
SGA 2
SGA 3
Private Network

• Multiple Instances
• One Database
• SGA database memory of all instances aggregated
  and appears as one single database to
  applications through Cache Fusion.

3
RAC for SAP Benchmark ResultsScalability
4
Advantages of RAC

• Performance
• Increase performance of a RAC database by adding
  additional servers to the cluster.
• Fault Tolerance
• A RAC database is made up of multiple instance.
  While performance may degrade, loss of an
  instance does not bring down the entire database.

• Scalability
• Scale a RAC database by adding instances to the
  cluster database.

5
Shifting Trend in Deployment Paradigm
Application Tier on Commodity servers
Application Tier on Commodity servers
Database Tier
Database Tier on Commodity Servers
Application and Database on Same SMP Server

• Monolithic SMP
• Application
• Database

• Mixed Configuration
• Commodity Application Servers
• SMP Database Servers

• Grid Computing
• All Commodity Servers

Past
Present
Future
6
Commodity Cluster Requires Unified Fabric for
efficient scalable IPC Storage I/O

• RDS / IB shows significant real world application
  performance gains
• 50 less CPU than IP over IB, UDP
• ½ latency of UDP (no user-mode acks)
• 50 faster cache to cache Oracle block throughput
  (ping)
• Scales well beyond GE (600 mbytes ran out of
  CPU)
• Minimal Oracle code change
• Supports fail-over across and within HCAs
• Certified for 16 nodes (64 processors)
• GA in 10g r2 (10.2.0.3).

7
Current Status

• Several TPC-H benchmarks with RDS and SRP
• Large scale deployments at several Oracle
  customer sites.
• Many pilot projects are in progress.
• Folks waiting for RDS on OFED
• 16 nodes Oracle 11G RAC certification of OFED
  1.2.5.5 submitted for audit
• Voltaire and Qlogic have completed platform
  certification. Audit in progress.
• Certification on Unix in progress

8
RDS- Communication model

• Works well with existing IPC clients
• Parallel Query communications
• Buffer cache fusion
• Working on providing support for additional
  clients with RDMA plus atomic operations
• We expect significant performance improvements
  with RDMA
• With Atomics, even greater scalabilities and
  performance can be gained.
• Incentives for simple NICs to add RDMA Atomics

9
RDS - evolution

• RDS v2 with b-copy send, rev in OFED 1.2.5.5
• New features in RDS v3 available in OFED 1.3
• supports RDMA read RDMA write
• Introduces cmsgs for asynchronous operation
  submit and completion notifications
• Large data transfers presently up to 1 MB. Will
  go up to 8 MB

10
RDS v4

• Plans for RDS v4
• Masked fetch_and_add
• Masked compare_and_swap
• Zero copy completions via cmsg
• RDS V4 will also be more portable - we will work
  to abstract out the generic RDS operations from
  O/S primitive support and network operations. A
  platform that provides the O/S network
  primitives library - should be able to take all
  the generic RDS code - as is.

11
RDS Compatibility

• Linux request to all IB vendors
• Please ensure compatibility across HCAs, switches
• Ideally RDS driver in OFED ported to all
  platforms
• Advantages include
• One code body wider testing
• Interoperability across platforms
• Towards this end, we plan to
• Abstract RDS protocol driver generically (OS,
  RDMA)
