Reliability Analysis for Dams and Levees

1
Reliability Analysis for Dams and Levees

• Thomas F. Wolff, Ph.D., P.E.
• Michigan State University
• Grand Rapids Branch ASCE
• September 2002

2
Hodges Village Dam
3
Walter F. George Dam
4
Herbert Hoover Dike
5
Some Background

• Corps of Engineers moving to probabilistic
  benefit-cost analysis for water resource
  investment decisions (pushed from above)
• Geotechnical engineers must quantify relative
  reliability of embankments and other geotechnical
  features
• Initial implementation must build on existing
  programs and methodology and be practical within
  resource constraints

6
Some Practical Problems

• Given possibility of an earthquake and a high
  pool, what is the chance of a catastrophic breach
  ? (Wappapello Dam, St. Louis District, 1985)
• Given navigation structures of differing
  condition, how can they be ranked for investment
  purposes ? (OCE, 1991 )
• What is the annualized probability of
  unsatisfactory performance for components of
  Corps structures ? (1992 - 1997)

7
Some More Practical Problems

• For a levee or dam, how does Pr(f) change with
  water height ? (Levee guidance and Hodges Village
  Dam)
• How to characterize the annual probability of
  failure for segments of very long embankments ?
  (Herbert Hoover Dike)
• How to characterize the annual risk of adverse
  seepage in jointed limestone ? (Walter F. George
  Dam)

8
General Approaches Event Tree
Close to levee p 0.6
given some water level
0.09
Carries material p0.3
Sand Boil p 0.5
Not close p 0.4
0.06
Doesnt p 0.7
0.35
Most problems of interest involve or could be
represented by an event tree..
9
Probabilities for the Event Tree

• f (Uncertainty in parameter values)
• Monte Carlo method
• FOSM methods
• point estimate
• Taylors Series
• Mean Value
• Hasofer-Lind
• Frequency Basis
• Exponential, Weibull, or other lifetime
  distribution
• Judgmental Values
• Expert elicitation

10
Pr(f) Function of Parameter Uncertainty

• Identify performance function and limit state,
  typically ln(FS) 0
• Identify random variables, X i
• Characterize random variables,
• EX, s x, r
• Determine EFS, sFS
• Determine Reliability Index, b
• Assume Distribution and calculate
• Pr(f) f(b)

11
The Probability of Failure
Answers the question, how accurately can FS be
calculated?, given measure of confidence in input
values
12
The Reliability Index, b
E
FS
ln

b s ln FS
b

s
FS
ln
Pr (U)
13
Taylors series, mean-value FOSM approach
14
Slope Stability Results, Lock Dam No. 2
15
Lognormal distribution on FS, LD 2
EFS 2.41 s FS 0.51 b 4.11
16
Change in FS and Pr(f)
( Duncans Mine Problem from Uncertainty 96
Conference)

• Evaluate shape change of probability density
  function due to drainage.
• Provide enough drainage to obtain b gt 4

FS 1.3, VFS - 10
FS 1.5, VFS 10
17
Pros and Cons of b, Pr(U)

• Advantages
• Plug and Chug
• fairly easy to understand with some training
• provides some insight about the problem

• Disadvantages
• Still need better practical tools for complex
  problems
• Non-unique, can be seriously in error
• No inherent time component
• only accounts for uncertainties related to
  parameter values and models

18
Physical Meaning of b, Pr(f)

• Reliability Index, b
• By how many standard deviations of the
  performance functions does the expected condition
  exceed the limit state?
• Pr(f) or Pr(U)
• If a large number of statistically similar
  structures (were designed) (were constructed)
  (existed) in these same conditions (in parallel
  universes?), what fraction would fail or perform
  unsatisfactorily?
• Has No Time or Frequency Basis !

19
Frequency-based Probabilities

• Represent probability of event per time period
• Poisson / exponential model well-recognized in
  floods and earthquakes
• Weibull model permits increasing or decreasing
  event rates as f(t), well developed in mechanical
  electrical appliactions
• Some application in material deterioration
• Requires historical data to fit

20
Pros and Cons of Frequency Models

• Advantages
• Can be checked against reality and history
• Can obtain confidence limits on the number of
  events
• Is compatible with economic analysis

• Disadvantages
• Need historical data
• Uncertainty in extending into future
• Need homogeneous or replicate data sets
• Ignores site-specific variations in structural
  condition

21
Judgmental Probabilities

• Mathematically equivalent to previous two, can be
  handled in same way
• Can be obtained by Expert Elicitation
• a systematic method of quantifying individual
  judgments and developing some consensus, in the
  absence of means to quantify frequency data or
  parameter uncertainty

22
Pros and Cons of Judgmental Probabilities

• Advantages
• Gives you a number when nothing else will
• May be better reality check than parameter
  uncertainty approach
• permits consideration of site-specific
  information
• Some experience in application to dams

• Disadvantages
• Distrusted by some (including some within Federal
  Agencies)
• Some consider values less accurate than
  calculated ones
• Non-unique values
• Who is an expert?

23
An ApplicationLevee Reliability f (Water
Level)

• Previous Corps policy treated substandard levees
  as not present for benefit calculations
• New policy assumes levee present with some
  probability, a function of water level
• First approach by Corps took relationship linear,
  R 1 at base, R 0 at crown
• New research to develop functional shape

24
Levee Failure Modes

• Underseepage
• Slope Stability
• Internal erosion from through-seepage
• External erosion
• through-seepage
• current velocity
• wave attack
• animal burrows, cracking, etc., may require
  judgmental models
• Combine using system reliability methods

25
Pervious Sand Levee Example
26
FOSM Underseepage Analysis
27
Pr (underseepage failure) vs H
28
Probabilistic Case HistoryHodges Village Dam

• A dry reservoir
• Notable seepage at high water events
• Very pervious soils with no cutoff

29
Probabilistic Case HistoryHodges Village Dam

• Required probabilistic analysis to demonstrate
  economic justification
• Random variables
• horizontal conductivity
• conductivity ratio
• critical gradient
• FASTSEEP analyses using Taylors series to obtain
  probabilistic moments of FS

30
Probabilistic Case HistoryHodges Village Dam
31
Probabilistic Case HistoryHodges Village Dam

• Pr (failure) Pr (FS lt 1)
• This is a conditional probability, given the
  modeled pool, which has an annual probability of
  occurrence

32
Probabilistic Case HistoryHodges Village Dam

• Annual Pr (failure) Pr (FS lt 1)pool level
  Pr (pool level)Integrated over all possible
  pool levels

33
Probabilistic Case HistoryHodges Village Dam
34
Probabilistic Case HistoryWalter F. George Lock
and Dam
35
Probabilistic Case HistoryWalter F. George Lock
and Dam

• Has had several known seepage events in 40 year
  history
• From Weibull or Poisson frequency analysis, can
  determine the probability distribution on the
  number of future events

36
Probabilistic Case HistoryWalter F. George Lock
and Dam
37
Probabilistic Case HistoryWalter F. George Lock
and Dam
38
Probabilistic Case HistoryHerbert Hoover Dike

• 128 mile long dike surrounds Lake Okeechobee, FL
• Built without cutoffs or filtered seepage control
  system
• Boils and sloughing occur at high pool levels
• Failure expected in 100 yr event (El 21)

39
Probabilistic Case HistoryHerbert Hoover Dike

• Random variables
• hydraulic conductivities and ratio
• piping criteria
• Seepage analysis
• FASTSEEP
• Probabilistic model
• Taylors series

40
Probabilistic Case HistoryHerbert Hoover Dike

• Pr (failure) Pr (FS lt 1)
• Similar to Hodges Village, this is a conditional
  probability, given the occurrence of the modeled
  pool, which is has an annual probability
• Consideration of length effects
• long levee is analogous to system of discrete
  links in a chain a link is hundreds of feet or
  meters

41
Questions
Has the theory developed sufficiently for use in
practical applications?

• Yes
• Comparative reliability problems
• Water vs. Sand vs. Clay pressures on walls,
  different b for same FS
• Event tree for identifying relative risks

• No
• Tools for complex geometries
• Absolute reliability
• Spatial correlation where data are sparse
• Time-dependent change in geotechnical parameters
• Accurate annual risk costs

42
Questions
When and where are the theories used most
appropriately?

• FOSM Reliability Index
• Reliability Comparisons
• structure to structure
• component to component
• before and after a repair
• relative to desired target value
• Insight to Uncertainty Contributions

43
Questions
When and where are the theories used most
appropriately?

• Frequency - Based Probability
• Earthquake and Flood recurrence, with conditional
  geotechnical probability values attached thereto
• Recurring random events where good models are not
  available scour, through-seepage, impact loads,
  etc.
• Wearing-in, wearing-out, corrosion, fatigue

44
Questions
When and where are the theories used most
appropriately?

• Expert Elicitation
• Hard problems without good frequency data or
  analytical models
• seepage in rock
• likelihood of finding seepage entrance
• likelihood of effecting a repair before distress
  is catastrophic

45
Questions
What Methods are Recommended for Reliability
Assessments of Foundations and Structures ?

• Define purpose of analysis
• Select simplest reasonable approach consistent
  with purpose
• Build an event tree
• Fill in probability values using whichever of
  three approaches is appropriate to that node
• Understand and admit relative vs absolute
  probability values

46
Questions
Are time-dependent reliability analysis possible
for geotechnical problems? How?

• YES
• Conditional probability values tied to
  time-dependent events such as earthquake
  acceleration or water level
• NO
• variation of strength, permeability, geometry
  (scour), etc especially within resource
  constraints of planning studies

47
Needs

• A Lot of Training
• Develop familarity and feeling for techniques by
  practicing engineers
• Research
• Computer tools for practical probabilistic
  seepage and slope stability analysis for complex
  problems
• Characterizing and using real mixed data sets, of
  mixed type and quality, on practical problems,
  including spatial correlation issues
• Approaches and tools for Monte Carlo analysis

48
How accurately can Pr(f) be calculated?

• Not very accurately (my opinion) --Many
  ill-defined links in process
• variations in deterministic and probabilistic
  models
• different methods of characterizing soil
  parameters
• f - c strength envelopes are difficult
• slope is a system of slip surfaces
• distributions of permeability and permeability
  ratio
• difficult to quantify spatial correlation in
  practice
• difficult to account for length of embankments
• difficult to account for independence vs
  correlation of multiple monoliths, multiple
  footings, etc.
