CPSC 503 Computational Linguistics

1
CPSC 503Computational Linguistics

• Parsing
• Lecture 12
• Giuseppe Carenini

2
Today 27/2

• Top-down (TD)
• Bottom-up (BU)
• Comparing TD and BU
• TD depth-first left-to-right
• Adding BU Filtering
• The Early Algorithm

3
Parsing with CFGs

• Valid parse trees

• Sequence of words

I prefer a morning flight
Parser
CFG

• Assign valid trees covers all and only the
  elements of the input and has an S at the top

4
Parsing as Search

• CFG

• Search space of possible parse trees

• S -gt NP VP
• S -gt Aux NP VP
• NP -gt Det Noun
• VP -gt Verb
• Det -gt a
• Noun -gt flight
• Verb -gt left
• Aux -gt do, does

• defines

• Parsing find all trees that cover all and only
  the words in the input

5
Constraints on Search

• Sequence of words

• Valid parse trees

I prefer a morning flight
Parser
CFG (search space)

• Search Strategies
• Top-down or goal-directed
• Bottom-up or data-directed

6
Top-Down Parsing

• Since were trying to find trees rooted with an S
  (Sentences) start with the rules that give us an
  S.
• Then work your way down from there to the words.

7
Next step Top Down Space

• When POS categories are reached, reject trees
  whose leaves fail to match all words in the input

8
Bottom-Up Parsing

• Of course, we also want trees that cover the
  input words. So start with trees that link up
  with the words in the right way.
• Then work your way up from there.

9
Two more steps Bottom-Up Space
10
Top-Down vs. Bottom-Up

• Top-down
• Only searches for trees that can be answers
• But suggests trees that are not consistent with
  the words
• Bottom-up
• Only forms trees consistent with the words
• Suggest trees that make no sense globally

11
So Combine Them

• Top-down control strategy to generate trees
• Bottom-up to filter out inappropriate parses

• Top-down Control strategy
• Depth vs. Breadth first
• Which node to try to expand next
• Which grammar rule to use to expand a node

• (left-most)

• (textual order)

12
Top-Down, Depth-First, Left-to-Right Search
Sample sentence Does this flight include a
meal?
13
Example
Does this flight include a meal?
14
Example
Does this flight include a meal?
flight
flight
15
Example
Does this flight include a meal?
flight
flight
16
Adding Bottom-up Filtering

• The following sequence was a waste of time
  because an NP cannot generate a parse tree
  starting with an AUX

Aux
Aux
Aux
Aux
17
Bottom-Up Filtering
18
Problems with TD-BU-filtering

• Left recursion
• Ambiguity
• Repeated Parsing

• SOLUTION Earley Algorithm
• (once again dynamic programming!)

19
(1) Left-Recursion

• These rules appears in most English grammars
• S -gt S and S
• VP -gt VP PP
• NP -gt NP PP

20
(2) Ambiguity

• I shot an elephant in my pajamas

21
(3) Repeated Work

• Parsing is hard, and slow. Its wasteful to redo
  stuff over and over and over.
• Consider an attempt to top-down parse the
  following as an NP
• A flight from Indi to Houston on TWA

22

• starts from.

• NP -gt Det Nom
• NP-gt NP PP
• Nom -gt Noun

• fails and backtracks

flight
23

• restarts from.

• NP -gt Det Nom
• NP-gt NP PP
• Nom -gt Noun

• fails and backtracks

flight
24

• restarts from.

• fails and backtracks..

flight
25

• restarts from.

• Success!

26

• 4

• But.

• 3

• 2

• 1

27
Dynamic Programming

• Fills tables with solution to subproblems

Parsing sub-trees consistent with the input,
once discovered, are stored and can be reused

• Does not fall prey to left-recursion
• Stores ambiguous parse compactly
• Does not do (avoidable) repeated work

28
Earley Parsing

• Fills a table in a single sweep over the input
  words
• Table is length N1 N is number of words
• Table entries represent
• Completed constituents and their locations
• In-progress constituents
• Predicted constituents

29
States

• The table-entries are called states and are
  represented with dotted-rules.
• S -gt ? VP A VP is predicted
• NP -gt Det ? Nominal An NP is in progress
• VP -gt V NP ? A VP has been found

30
States/Locations

• Each state has a location indicating the portion
  of the input it applies to
• S -gt ? VP 0,0 A VP is predicted at the
  start of the sentence
• NP -gt Det ? Nominal 1,2 An NP is in progress
  the Det goes from 1 to 2
• VP -gt V NP ? 0,3 A VP has been found
  starting at 0 and ending at 3

31
Graphically
S -gt ? VP 0,0 NP -gt Det ? Nominal 1,2 VP
-gt V NP ? 0,3
32
Earley answer

• As with most dynamic programming approaches, the
  answer is found by looking in the table in the
  right place.
• In this case, the following state should be in
  the final column

S gt ?? 0,n1

• i.e., an S state the that spans from 0 to n1 and
  is complete.

33
Earley processes

• So sweep through the table from 0 to n1
• New predicted states are created
• E.g., S -gt ? VP 0,0 gt VP -gt ? Verb 0,0
• New incomplete states are created by advancing
  existing states as new constituents are
  discovered
• E.g., VP -gt ? Verb NP .. gt VP -gt Verb ? NP
  ..
• New complete states are created in the same way.
• E.g., VP -gt Verb ? NP .. gt VP -gt Verb NP ?..


34
Example
Book that flight

• We should find an S from 0 to 3 that is a
  completed state

35
Example
Book that flight
36
So far only a recognizer

• To generate all parses
• When old states waiting for the just completed
  constituent are updated gt add a pointer from
  each updated to completed
• Then simply read off all the backpointers from
  every complete S in the last column of the table

37
Earley and Left Recursion

• So Earley solves the left-recursion problem
  without having to alter the grammar or
  artificially limiting the search.
• Never place a state into the chart thats already
  there
• Copy states before advancing them

38
Earley and Left Recursion 1

• S -gt NP VP
• NP -gt NP PP
• The first rule predicts
• S -gt ? NP VP 0,0 that adds
• NP -gt ? NP PP 0,0
• stops there since adding any subsequent
  prediction would be fruitless

39
Earley and Left Recursion 2

• When a state gets advanced make a copy and leave
  the original alone
• Say we have NP -gt ? NP PP 0,0
• We find an NP from 0 to 2 so we create
• NP -gt NP ? PP 0,2
• But we leave the original state as is

40
Dynamic Programming Approaches

• Earley
• Top-down, no filtering, no restriction on grammar
  form
• CYK
• Bottom-up, no filtering, grammars restricted to
  Chomsky-Normal Form (CNF)

41
Next Time

• Read Chpt. 11 Features and Unification
