Pushover analysis

1
Static Pushover Analysis

• Performance Based Design
• Modeling for Pushover Analysis
• Use of the Pushover Curve
• M. Iqbal Suharwardy
• Computers and Structures, Inc.
• Static Pushover Analysis for Seismic Design
• March 22, 1999

2
Performance Check of Structures

• Purpose
• How will a structure perform when subjected to a
  given level of earthquake?
• Definition of structural performance
• Definition of earthquake level
• Determination of performance level

3
Performance Check of Structures

• Process
• Recently released guidelines for Seismic
  Rehabilitation of Buildings
• ATC-40
• FEMA 273 (ATC-33)

4
Types of Performance Checks

• Linear Static Analysis
• Linear Dynamic Analysis
• Nonlinear Static Analysis(Pushover Analysis)
• Nonlinear Dynamic Analysis

5
Performance Check Using Pushover
Expected Performance Point for given Earthquake
Force Measure
Performance Limits (IO, LS, CP)
Deformation Measure
Goal is to predict peak response of building and
components for a given earthquake
6
Why Do Pushover Analysis?

• Design Earthquakes cause nonlinear behavior
• Better understand building behavior- Identify
  weak elements- Realistic prediction of element
  demands
• Less conservative acceptance criteria can be used
  with consequences understood

7
Steps in Performance Check

• Construct Pushover curve
• Select earthquake level(s) to check
• Select performance level(s) to check
• Select acceptance criteria for each performance
  level
• Verify acceptance
• Capacity Spectrum Method (ATC-40)
• Displacement Coefficient Method (FEMA 273)

8
Constructing Pushover Curve

• Define Structural Model
• Elements (components)
• Strength - deformation properties
• Define Loads
• Gravity
• Lateral load pattern
• Select Control Displacements or Drifts
• Perform Pushover Analysis

9
Pushover Modeling

• Definition of Structural Model
• 3D or 2D
• Primary and Secondary Elements (components)
• Non structural Elements
• Foundation flexibility
• P-Delta effects

10
Pushover Modeling (Elements)

• Types
• Truss - yielding and buckling
• 3D Beam - major direction flexural and shear
  hinging
• 3D Column - P-M-M interaction and shear hinging
• Panel zone - Shear yielding
• In-fill panel - Shear failure
• Shear wall - P-M-Shear interaction!
• Spring - for foundation modeling

11
Pushover Modeling (Properties)

• Force-Deformation Relationship

C
B
Force
D
E
A
Deformation
12
Pushover Modeling (Properties)

• Force-Deformation (Back bone Curve)

Force
Deformation
13
Pushover Modeling (Beam Element)

• Three dimensional Beam Element

Span Loads
Flexible Connection
Shear Hinge
Plastic Hinge
Rigid Zone
14
Pushover Modeling (Column Element)

• Three dimensional Column Element

Shear Hinge
Plastic Hinge
Rigid Zone
15
Pushover Modeling (Column Element)

• Axial Load - Moment Interaction (Concrete)

P
M
16
Pushover Modeling (Column Element)

• Axial Load - Moment Interaction (Steel)

17
Pushover Modeling (Loads)

• Start with Gravity Loads
• Dead Load
• Some portion of Live Load
• Select Lateral Load Pattern
• Lateral Load Patterns (Vertical Distribution)
• Lateral Load Horizontal Distribution
• Torsional Effects
• Orthogonal Effects

18
Pushover Modeling (Loads)

• Lateral Load Patterns (Vertical Distribution)

Mode 1
Code Lateral
Uniform
19
Pushover Analysis (Control)

• Force controlled analysis
• Deformation controlled analysis
• Roof Displacement
• Generalized Displacement Definitions
• Limit of analysis
• Instability - loss of gravity load carrying
  capacity
• Excessive distortions

20
Pushover Analysis (Solution Schemes)

• Event by Event Strategies
• Manual
• Newton-Raphson Type Strategies
• Constant stiffness iterations
• Tangent stiffness iterations
• Problem of degradation of strength
• Ritz Modes (Reduced Space) Strategies

21
Pushover Analysis (Solution Schemes)

• Event by Event Strategy

Base Shear
Roof Displacement
22
Pushover Analysis (Solution Schemes)

• Problem of Degradation of Strength

Base Shear
Roof Displacement
23
Pushover Analysis (Results)
Force Measure
Deformation Measure
24
Pushover Analysis (Results)
25
Use of Pushover Curve

• Capacity Spectrum Method - detailed in ATC-40 -
  and as alternate method in FEMA-273
• Displacement Coefficient Method - detailed in
  FEMA-273

26
Use of Pushover Curve (ATC-40)

• Construct Capacity Spectrum
• Estimate Equivalent Damping
• Determine Demand Spectrum
• Determine Performance Point
• Verify Acceptance

27
Use of Pushover Curve (ATC-40)

• Constructing Capacity Spectrum

Spectral Acceleration
Base Shear
Roof Displacement
Spectral Displacement
28
Use of Pushover Curve (ATC-40)

• Constructing Capacity Spectrum

The displaced shape at any point on the pushover
curve is used to obtain an equivalent SDOF
system. a is the mass participation and relates
the base shears PF is the participation factor
and relates the roof displacement to the SDOF
displacement
Equivalent SDOF
MDOF
29
Use of Pushover Curve (ATC-40)

• Constructing Capacity Spectrum

Spectral Acceleration
Spectral Displacement
30
Use of Pushover Curve (ATC-40)

• Estimation of Equivalent Viscous Damping

Spectral Acceleration
Spectral Displacement
31
Use of Pushover Curve (ATC-40)

• Estimation of Equivalent Damping

Spectral Acceleration
Eso
Spectral Displacement
Ed
32
Use of Pushover Curve (ATC-40)

• Response Spectrum (5 damping)

2.5CA
CV/T
Spectral Acceleration
Time Period
33
Use of Pushover Curve (ATC-40)

• Response Spectrum (5 damping)
• CA and CV depend on
• - Seismic zone (0.075 to 0.4)
• - Nearness to fault and source type (1 to 2)
• - Soil Type (1 to 2.5)
• - Level of Earthquake (0.5 to 1.5)

34
Use of Pushover Curve (ATC-40)

• Reduced Spectrum (Effective damping)

2.5CA/Bs
Spectral Acceleration
CV/(T BL)
Time Period
35
Use of Pushover Curve (ATC-40)

• Acceleration-Displacement Response Spectrum

T0
Sd SaT2/4p2
Spectral Acceleration
Spectral Acceleration
T0
Spectral Displacement
Time Period
36
Use of Pushover Curve (ATC-40)

• Performance Point

Demand Spectrum for effectivedamping at
performance point
Spectral Acceleration
Capacity Spectrum
Spectral Displacement
37
Use of Pushover Curve (ATC-40)

• Performance Point

Spectral Acceleration
Spectral Displacement
38
Use of Pushover Curve (ATC-40)

• Verification of Acceptance

Expected Performance Point for given Earthquake
Force Measure
Performance Limits (IO, LS, CP)
Deformation Measure
39
Use of Pushover Curve (ATC-40)
40
Use of Pushover Curve (FEMA-273)

• (Displacement Coefficient Method)
• Estimate Target Displacement
• Verify Acceptance

41
Use of Pushover Curve (FEMA-273)

• Estimation of Target Displacement
• Estimate effective elastic stiffness, Ke
• Estimate post yield stiffness, Ks
• Estimate effective fundamental period, Te
• Calculate target roof displacement as

42
Use of Pushover Curve (FEMA-273)

• Estimation of Target Displacement
• C0 Relates spectral to roof displacement
• C1 Modifier for inelastic displacement
• C2 Modifier for hysteresis loop shape
• C3 Modifier for second order effects

43
Use of Pushover Curve (ATC-40)

• Estimation of Effective Elastic Period, Te

Vy
aKe Ks
Estimate Te using Ke Estimate Elastic Spectral
Displacement
.6Vy
Base Shear
Ke
Roof Displacement
44
Use of Pushover Curve (FEMA-273)

• Calculation of C0
• Relates spectral to roof displacement
• - use modal participation factor for control
  node from first mode
• - or use modal participation factor for control
  node from deflected shape at the target
  displacement
• - or use tables based on number of stories and
  varies from 1 to 1.5

45
Use of Pushover Curve (FEMA-273)

• Calculation of C1
• Modifier for inelastic displacement

C1 1 (R-1)T0/Te/R
R is elastic strength demand to yield strength
Spectral Acceleration
C1 1
T0
Time Period
46
Use of Pushover Curve (FEMA-273)

• Calculation of C2
• Modifier for hysteresis loop shape
• - from Tables
• - depends on Framing Type (degrading
  strength)
• - depends on Performance Level
• - depends on Effective Period
• - varies from 1.0 to 1.5

47
Use of Pushover Curve (FEMA-273)

• Calculation of C3
• Modifier for dynamic second order effects
• C3 1 if post yield slope, a is positive
• else
• C3 1 a(R-1)3/2 /Te

48
Use of Pushover Curve (FEMA-273)

• Verification of Acceptance

Target Displacement (or corresponding
deformation) for given Earthquake
Force Measure
Performance Limits (IO, LS, CP)
Deformation Measure
49
Use of Pushover Curve

• Do these methods work?
• Comparisons with
• - Nonlinear time history analysis
• - Single degree of freedom systems
• - Multi-degree of freedom systems
• - Observed damage
• How do they compare with each other?

50
SAP2000/ETABS Pushover Options

• SAP2000 released September, 1998
• Full 3D implementation
• Single model for - linear static analysis -
  linear response spectrum analysis - linear time
  history analysis - nonlinear time history
  analysis - nonlinear static pushover analysis -
  steel and concrete design

51
SAP2000/ETABS Pushover Options

• Generally follows ATC-40 FEMA 273
• Available Pushover Element Types - 3D truss
  (axial hinge) - 3D beam (moment and shear
  hinges) - 3D column (P-M-M and shear hinges) -
  Shells, Solids, etc. considered linear - Panel
  zone (later) - 3D column (Fiber hinge) (later)
  - Shear wall (plasticity model) (later) -
  Nonlinear springs (later)

52
SAP2000/ETABS Pushover Options

• Force-Deformation Relationship

D
C
B
Force
E
F
A
Deformation
53
SAP2000/ETABS Pushover Options

• Three dimensional Beam Element

Span Loads
Flexible Connection
Shear Hinge
Plastic Hinge
Rigid Zone
54
SAP2000/ETABS Pushover Options

• Strength - deformation and P-M-M curves can be
  calculated by program for - steel beams
  (FEMA 273) - steel columns (FEMA 273) - shear
  hinges in EBF Links (FEMA 273) - concrete beams
  (ATC-40) - concrete columns (ATC-40) - shear
  hinges in coupling beams (ATC-40)

55
SAP2000/ETABS Pushover Options

• Gravity Load Analysis - Nodal Loads - Element
  Loads - Load controlled Analysis
• Pushover analysis - Starts from gravity loads -
  Nodal Load Patterns (user, modal, mass) -
  Multi-step Displacement or Drift controlled

56
SAP2000/ETABS Pushover Options

• Available Results for each step of loading -
  Base Shear - Element Forces - Section Forces -
  Joint Displacements - Drifts - Element Hinge
  Deformations - Limit Points (acceptance
  criteria) reached

57
SAP2000/ETABS Pushover Options

• Pushover Curve Postprocessing (ATC-40) -
  Conversion to Capacity Spectrum - Calculation of
  Effective Period (per step) - Calculation of
  Effective Damping (per step) - Calculation of
  Demand Spectrum (per step) - Location of
  Performance Point - Limit Points (acceptance
  criteria) reached

58
SAP2000/ETABS Pushover Options

• Visual Display for each step
• - Deformed Shape - Member Force Diagrams -
  Hinge Locations and Stages
• Graphs
• - Base Shear vs Roof Displacement - Capacity
  Curve - Demand Curve - Demand Spectra at
  different dampings - Effective period lines
