Title: Anomaly Recovery and the Mars Exploration Rovers


1
Anomaly Recovery and the Mars Exploration Rovers
  • Beth Dewell and Jacob Matijevic

2
The Mars Exploration Rover
3
Introduction
  • Currently MER A(Spirit) Sol 856 MER
    B(Opportunity) Sol 836
  • Each Rover has spent over two years on the
    surface of Mars
  • Variation in terrain, changing environment, and
    problems in operation from the surface of another
    planet were taken into account in the system
    design
  • A long-range planning team prepares outlines of
    future activities
  • Strategic plan guides the operation through the
    creation of near term objectives for vehicle
    activity
  • Each day a separate team (on each vehicle)
    prepares a set of sequences of commands that
    implement the objectives for a short period (1-3
    days commonly) of the strategic plan
  • Tactical plan is a set of sequences prepared
    based on the best knowledge of the state of the
    vehicle
  • Constraints times of communication, data
    storage, time and energy available

4
System Design
  • Computer built around a RAD-6000 CPU (Rad6k),
    RAM and non-volatile memory(FLASH and EEPROM)
  • Energy
  • Collected from the solar array
  • Channeled along the system power bus that is
    supported by two Li-ion batteries
  • Power not required to support loads recharges
    batteries
  • Batteries support loads drawing power in excess
    of that supplied by the solar panel
  • Power in excess of loads and recharge required
    by the batteries is channeled to an external
    shunt radiator
  • Regulation and distribution of power is managed
    by 2 battery control boards (BCBs)
  • Batteries also supply power to the mission clock
    with an alarm clock feature, programmable by
    software
  • Mobility
  • Six wheeled driven, four wheeled steered vehicle
  • Communications
  • X-band a Small Deep Space Transponder, and two
    Solid State Power Amplifiers, supported by a
    body-fixed, monopole Low Gain Antenna (LGA) and a
    High Gain Antenna (HGA)
  • UHF a transceiver, supported by a body-fixed,
    monopole antenna

5
Flight Software Design
  • Autonomous Operations
  • Maintains the vehicle in the state needed to
    receive and act upon commands, execute sequences
    of commands when available, and collect and
    format data for transmission
  • Support wakeups (i.e., boot of the CPU) and
    shutdowns as part of normal operations
  • Wakeup is scheduled once each day when energy
    production from the solar array can support the
    load associated with the CPU and supporting
    electronics
  • BCB determines if energy sufficiently meets
    criteria
  • A shutdown is controlled by parameters,
    established to ensure a power and thermal balance
  • Communications
  • Timed events maintained in an onboard
    communication windows table (X-band and UHF)
  • At any given time table contains about 6 weeks of
    timed events, covering uplink and downlink
  • Sequenced Control
  • Sequenced commands are on-board and controlling
    vehicle activities including wakeup/shutdown
    times

6
Flight Software Telemetry and Exception Response
  • 3 Types of Flight software telemetry
  • Event reports (EVRs)
  • Engineering data (EHA)
  • Data products
  • Exception Response
  • Warning An EVR (warning) may be written in the
    record to note the occurrence
  • Fault Ongoing process or sequence ended
  • EVRs, EHA, and perhaps a fault data product are
    generated for the record
  • Fatal FSW autonomously reboots when an
    unrecoverable problem is encountered
  • No time to document conditions at the time of the
    fatal
  • FSW temporarily stores a small number of EVRs in
    EEPROM during execution to be recovered after the
    reboot has been accomplished
  • Autonomous mode results

7
When a problem occurs
  • Outline the strategy for resolving the problem
    and continue, as possible
  • Types of Problems
  • Simply sequence did not fully execute
  • Component performance unexpected or incomplete
  • Additional data may be requested
  • An engineering test is scheduled
  • Typically, other parts of the rover are
    unaffected by the component anomaly, so the
    beginnings of corrective action begin
  • For persistent component problem, an anomaly team
    is formed and a multi-sol investigation is
    initiated
  • Moves the corrective action from a tactical
    response to a strategic response, often requiring
    experts to help in diagnosis and recovery
  • Tactical process otherwise continues doing
    science as possible while recovery strategy is
    developed and demonstrated

8
Major MER Anomalies
  • Software Anomalies
  • FLASH
  • A race condition, initialization counter
  • Another race condition, imaging interface
  • Corrupted command conjunction test
  • Exception in evaluation of a DDI during mobility
  • Upload fault during forward link commanding
  • Hardware Anomalies
  • Stuck-on Heater
  • RF drive actuator
  • RF Steering actuator
  • IDD azimuth actuator
  • Environmentally Induced Anomalies
  • Clock Fault
  • 'Potato' Rock
  • Embedding in terrain

9
A race condition, initialization counter
  • Sol 131 on Spirit
  • Vehicle was unexpectedly in autonomous operation
    no sequences were active on board
  • Fatal exception from the FSW initialization
    module was noted in the EVR log in telemetry
  • Problem
  • Vulnerability which occurs when the
    initialization module was attempting to increment
    the initialization counter
  • Counter resides in non-volatile memory
  • Writing to this memory required permission from a
    separate software service that managed access to
    the memory
  • Between the request and the grant of access to
    write to the memory location, another software
    module had requested, been granted access and had
    written to non-volatile memory
  • The initialization module, finding it could not
    write the initialization counter, declared an
    exception resulting in a fatal condition

10
Initialization counter, contd
  • All processes time-share the use of the single
    CPU
  • No guarantee that the three actions desired by
    the initialization module (i.e., request, being
    granted write access, and writing to memory)
    occur contiguously
  • Vulnerability viewed as a function of the number
    of processes in operation at the time of the
    write of the initialization counter
  • Vulnerability duration a few microseconds to
    perform the three actions within about a 4 minute
    window during initialization
  • Advisory given with added restriction of IDD use
    during the 4-minute window
  • Likelihood of recurrence was deemed so slight as
    to not warrant further action
  • No FSW change
  • Understood race condition between software
    modules a race that the initialization module
    won for many initializations (over 560 at that
    time) and many sols since this occurrence

11
Initialization counter Recurrence Resolution
  • Recurrence
  • Spirit on sol 209
  • Opportunity on sol 596
  • Opportunity on sol 622
  • Occurred during initialization in preparation for
    an afternoon UHF communication window
  • The FSW response caused the loss of that
    communication window
  • No telemetry, leaving the recovery team to sift
    through many possibilities for the problem
  • Next uplink window, sol 623, commands were issued
    and sequence control was regained
  • Due to the delay in recovery of a sol after the
    sol 622 event, team enforced a 'keep out zone'
    for operations after wakeup
  • Due to energy considerations, only enforced
    during the wakeup prior to an afternoon UHF pass
  • Ensured that a recurrence would not jeopardize
    the return of engineering and science data needed
    to plan for the next sol

12
Stuck-on Heater
  • Sol 2 on Opportunity
  • First overnight UHF pass on sol 2 at 0330 LST
    nighttime loads from sol 1 2300 LST to sol 2
    330 LST were 0.5Amps larger than predicted
  • Next communication session showed that the
    additional load had remained on until 10 LST
  • Dissipated 180 W-hrs
  • Highest likelihood fault Rover Power
    Distribution Unit (RPDU) load unexpectedly
    powered on
  • Load size, on/off times, temperature narrowed
    down to an IDD heater circuit
  • Off/on times correlate to predicted thermostat
    box switch times
  • Temp. sensor on MI near the IDD heater circuit
    recorded overnight rise

13
Stuck-on Heater Implications
  • Rover still completely functional as designed
  • Energy drain reduces energy available for science
    activities
  • Especially important in Winter
  • Spacecraft survival an issue

14
Stuck-on Heater Recovery Deep Sleep
  • Deep Sleep
  • Remove batteries from power bus
  • Causes Battery Control Board to not be powered
  • Only mission clock and alarm clock powered
  • Faulty heater circuit turned off at night
  • At dawn, BCBs awakened when sufficient light
    hits solar arrays
  • Net savings 180W-hr/sol
  • Implemented 1st time on sol 101-102 permanently
    on sol 206
  • Could be temporarily disabled on a nightly basis
    by command
  • Survival heaters for the miniTES and Rover
    Electronics Module, which are normally left on
    during the night, were taken off-line
  • Colder temperatures on the miniTES (routinely
    below the acceptable flight temperature limits)
    have undoubtedly contributed to a degradation of
    this instrument on Opportunity
  • This degradation has not been experienced by the
    miniTES on Spirit

15
'Potato' Rock
  • Sol 339 on Spirit
  • A planned drive up Husband Hill
  • At the first turn command in the drive sequence,
    the rover was commanded to turn in place within
    18 seconds
  • In the last 2 seconds, the right rear wheel
    current spiked and the drive motor actuator
    stalled
  • Sol 339 data revealed A rock was lodged between
    the inner ring of the wheel and the actuators

16
'Potato' Rock Recovery
  • Sol 340
  • Rock dislodged from the actuator by spinning the
    right rear wheel in the opposite direction
  • Rock was now inside the wheel
  • Sol 343
  • - Right rear wheel was straightened, and then the
    drive and steering actuators were temporarily
    disabled
  • - Two small 0.3 meter arcing drives were
    attempted using the remaining 5 wheels
  • - Rock remained inside the wheel
  • Sol 344
  • The rover was commanded to back down the hill
    (all actuators enabled this time)
  • Rock remained inside the wheel

17
'Potato' Rock Recovery, contd
  • Sol 345
  • - Turn in place to drive back down the hill, and
    to perform a final turn in place
  • Rock remained inside the wheel
  • Sol 346
  • - Two drives and one more turn in place were
    commanded
  • - Afternoon images confirmed the rock was out of
    the wheel
  • Sols 348-350
  • - Nominal Operations resumed

18
'Potato' Rock Analysis
  • Rock jamming in the mobility mechanisms had
    occurred on prior rover systems
  • MER system had additional external clearances
    around the wheels and the drive actuator
    mechanisms
  • Wheel wells not 'closed out' due to weight
    considerations
  • Despite these provisions, vehicle geometry, loose
    rocks, and regolith of the terrain on Husband
    Hill made this rock jamming possible

19
Closing Thoughts
  • The system was designed to anticipate a number of
    likely faults and conditions due to sequence
    execution and environmental change, which led to
    an operational flexibility reducing recovery
    time.
  • Less than 5 (about 30 sols out of 850 sols of
    operations) have been devoted to recovery on
    each of the vehicles.
  • These considerations will likely be present in
    any future surface mission.
About PowerShow.com
