Title: Lighting Control Solutions for Staefa Control System


1
Lighting Control Solutions for Staefa Control
System
2
Benefits of Lighting Control
  • Excellent Return on Investment (R.O.I.) for owner
    by reducing electric utility bill by up to 10-40
  • Lowers operating costs and minimizes lamp on time
  • Time between lamp replacements can be increased
  • Monitoring of lighting usage provides information
    to optimize operations which improves bottom line
  • Paybacks typically range from 1-4 years depending
    on each facilities operation and lighting load
  • Reduced electrical consumption can lower air
    pollution
  • Reduces cooling load caused by unneeded use of
    lights

3
Lighting Control Savings
  • Pick your local /kWh rate and move horizontally
    to the column with your anticipated hours saved
    per day. The intersection of the two is the
    payback. Note-Based on 32 relay TRIATEK panel,
    277V,16 amps/relay, 8 hours labor at 65/hour.

4
Lighting Control by Function (Retail/Department
Stores)
Escalators/Elevators
Accent lights
Sales lights
Pre open lights
5
Lighting Control by Area Offices/Educational/Indu
strial
Zone 3 Acctg
Zone 1 Admin
Zone 2 Sales
Zone 8 R D
Zone 4 office
Zone 9 Common
Zone 7 Mktg
Zone 6 Engineering
Zone 5 Customer Service
6
TRIATEK Reduces Lighting Control Design Liability
  • Utilize TRIATEK Engineers and Application
    Specialists to determine the best system for your
    project requirements
  • Utilize TRIATEK AutoCad drawings to reduce your
    production costs
  • Utilize TRIATEK Sales Engineers to meet with you
    and or your customer to identify cost savings and
    system benefits
  • TRIATEK can provide the widest selection of
    lighting control solutions from motion sensors to
    programmable relay panels to programmable circuit
    breaker panels
  • Toll free assistance and 24 hour/day, 7 days/week
    web access at www.triatek.com

7
Integrated Lighting Control with TRIATEK
  • Seamless Integration to Staefa Control System
  • One operator console for control of lighting
    circuits and HVAC equipment
  • Reduces operator training time and improves
    productivity
  • Single source responsibility from Staefa Control
    System dealer for both HVAC and lighting control
  • Low cost Staefa Control System Interface (by
    System One)
  • TRIATEK offers the broadest line of networkable
    lighting control panels, programmable circuit
    breaker panels and telephone override system

8
TRIATEK Adds Value toStaefa Control System
Staefa MS1800 Workstation
Staefa Network
2-wire TRIATEK Telephone Override Network
2-wire TRIATEK Lighting Control Network
System One TRIATEK Telephone Interface
System One TRIATEK Lighting Interface
TRIATEK Telephone Override System
TRIATEK Lighting Control Panels
Users can call from the telephone on their desk
to override lighting and HVAC
9
TRIATEK Programmable Circuit Breaker Panel
  • Over current protection with on/off control in
    one panel
  • Provides circuit breaker status
  • Multiple panel sizes
  • Main Lug or Main Breaker configurations
  • Copper bus interiors (better than aluminum)
  • Multiple circuit breaker panels (up to 60
    circuits) can be controlled with one RCS
    Controller
  • New construction or retrofit
  • Model RCS-1000 Series

10
Cutaway view of Remote Control Circuit Breaker
Switching Mechanism
Overcurrent Protection
Positive Feedback
Contacts
Trip Lever
Status Window
11
TRIATEK RCS-1000 Programmable CircuitBreaker
Panel
Lighting circuits
277 Volt, 20A loads -Fan coil units -Unit
ventilators -Exhaust fans
High Voltage Section
Motion Sensors
TRIATEK
Low Voltage Section
Override Switches
12
RCS-1000 Controller Factory Mounted to Panelboard
TRIATEK RCS-1000 Remote Control Circuit Breakers
TRIATEK RCS-1000 Controller
13
RCS-1000 Controller Remote Mounted to Panelboard
TRIATEK RCS-1000 Controller controls up to 60
Remote Control Circuit Breakers
Control wires from TRIATEK RCS-1000 Controller to
Remote Control Circuit Breakers can be up to 50
feet away
14
RCS-1000 Lowers Installed Cost By Controlling
Multiple Panels in Electrical Room
Control wires from TRIATEK RCS-1000 Controller to
Remote Control Circuit Breakers can be up to 50
feet away
TRIATEK RCS-1000 Controller
15
RCS-1000 Lowers Installed Cost By Controlling
Panels in other Electrical Rooms
RCS-1000 Remote Control Circuit Breakers on floor
above RCS-1000 Controller
RCS-1000 Controller can control up to 60 Remote
Control Circuit Breakers. This example controls
lighting on floor above and below.
To RCS-1000 Remote Control Circuit Breakers on
floor below
16
TRIATEK 8 Relay Lighting Control Panel
  • LP-2800 Series
  • 1 to 8 General Electric RR7 relays
  • Ideal for areas with up to 8 relays to be
    controlled
  • 16 programmable switch inputs
  • RS-485 Capability
  • UL Listed
  • CSA Approved
  • Low Cost
  • Full lighting control features

17
TRIATEK Lighting Control Panels
  • LP-2500 Series (Commanded feedback)

  • 1-16, 1-32, 1-48 or 1-60 relay configurations
  • Up to 277 volt (347V Canadian), 20 amp, single
    pole loads
  • Ideal for medium to large buildings
  • 24 programmable switch inputs, up to 120
  • LP-2600 Series (Positive feedback)
  • 1-16, 1-32, 1-48 or 1-60 relay configurations
  • Up to 277 volt (347V Canadian), 20 amp
  • Ideal for medium to large buildings
  • 24 programmable switch inputs, up to 120

18
Upgrade existing lighting control systems to Year
2000
  • Less expensive than total replacement
  • Uses existing GE RR7, GE RR9, Lithonia PanelMax ,
    Reliant 2R7/2R9, Douglas relays
  • Uses existing relay panel
  • Quick and easy installation
  • No high voltage rewiring required
  • Accepts existing momentary switches
  • Utilizes most of customers original investment
    versus total replacement
  • 24 programmable switch inputs, up to 120 per kit
  • Model LP-2500 or LP-2600 Upgrade Kit

19
TRIATEKs Conversion Kit to Retrofit Low Voltage
switching
Color Coded Harness Matches existing relay
Butt Splices
Relay Interface Board
Switch Inputs
TRIATEK Lighting Controller
20
Lighting system before TRIATEK Installation
Existing Tub to be used
Existing HV wiring to be used
Existing Relays to be used
Existing Relays to be used
Existing Transformer to be used
Existing Switch wires to be used
Controller to be replaced
21
TRIATEK Conversion Kit After Installation
Existing HV wiring
TRIATEK Controller replaced old Controller
Existing GE Relays
TRIATEK Relay Interface Boards
TRIATEK GE relay wiring harnesses
22
TRIATEKs LP-PK Software for Easy Set-Up
Soft-wiring of relays to lighting zones just
point and click to include a relay
Easy to use TRIATEK software for lighting panel
set-up
23
Override Lighting from any touch-tone Telephone
  • Users can override lighting and HVAC from
    touch-tone telephone
  • Easy to understand human voice prompts
  • User ID can be password protected
  • Override from any Touch-tone phone
  • Hassle free override of users area any time
  • No need to schedule after hours use with Building
    Automation Operator
  • UL Listed, FCC part 68 approved
  • Handles up to 8,191 users and passwords
  • Model TI-4500 Series

24
Override Lighting from Push- Button Switches in
the Building
Momentary Pushbutton (two switch input)
Momentary On/Off (one switch input)
Momentary On/Off Toggle (two switch input)
Cleaning Switch Maintained with Key
  • Press a momentary push button to turn on lights
  • Press a momentary push button to turn on lights.
    Lights will stay on for programmable time between
    1 minute and 18 hours, then flash to warn users,
    and turn off after programmable time between 1-60
    minutes.

25
Override Lighting from Push- Button Switches in
the Building
  • Users can press a momentary push button to turn
    off lights
  • Users can press a momentary push button to turn
    on lights and push again to turn off lights
  • Maintained switch from Motion/Occupancy sensor
    can turn on and off lights
  • Users can press a momentary push button to turn
    on or off 1/3, 2/3 or 3/3 of lamps in lighting
    fixture

26
TRIATEKs Light Level Sensors for Daylight
Harvesting
Indoor
Outdoor
Skylight Atrium
27
TRIATEK Motion Sensors
Ceiling Mount
28
TRIATEK GeneralLighting Control Features
  • Year 2000 Compliant
  • Can switch up to 277V, 20A loads
  • UL Listed, CSA approved, Approved by New York
    City
  • Programmable switch inputs for override of
    lighting
  • Programmable switch input polarity
  • LEDs indicate zone and relay status
  • Programmable grouping of relays into zones
  • Flash Warning Option
  • Programmable On-Time After Flash

29
TRIATEK GeneralLighting Control Features
  • Multi-Level Lighting
  • Interfaces to Motion an Occupancy Sensors
  • EPROM and EEPROM self diagnostics
  • Rugged construction
  • Modular design for easy expansion
  • Powered by 120 or 277 volts AC, field selectable
  • Seamless Integration to most Building Automation
    Systems

30
TRIATEK Lighting Control Installations
  • Hewlett-Packard
  • Martin Marietta
  • Motorola
  • US West
  • Sears Department Stores
  • J.C. Penney World HQ
  • Dept. of Transportation, CT
  • Dept. of Transportation, WA
  • Levi Strauss
  • General Services Administration
  • Nissan
  • U.S. Department of Energy
  • Jack Kent Cooke Stadium-Washington Redskins
  • Comiskey Park-Chicago White Sox
  • Ericsson Stadium-Carolina Panthers
  • AAA Automobile Club
  • Merck Pharmaceutical
  • State of Tennessee
  • Bloomingdales
  • Macys Department Stores
  • Smith Barney
  • Warner Brothers
  • others available on request

31
TRIATEK Lighting Control Support Services
  • Product Specification Sheets for submittals
  • Consultant Specifying Guide
  • Pricing Guide
  • AutoCad drawing templates
  • Lighting Schedule templates
  • Installation and Application Guides
  • System Design Service
  • Internet web site - www.triatek.com
