Anatomy of a Planet

1
Anatomy of a Planet
2
(No Transcript)
3
(No Transcript)
4
Origin of the Solar System

• Gravitational collapse of huge gas dust cloud
• Rotation around a central mass
• Disk shaped cloud
• Temperature variations segregated matter
• Small particles accreted into larger
  planetesimals, finally planets

5
(No Transcript)
6
The Earth is a layered (differentiated)
body -chemistry -density -pressure -heat
7
How do we know? Drilling -wells drilled into
Earth are mostly in the upper 7 km of the crust
Deepest well Russian well in northern Kola
Peninsula20 year effort to drill a 12 km hole.
Target depth was 15 km.Costs are more than 100
million
8
(No Transcript)
9
Ordinary Chondritic Meteorite -composition of
asteroids and the early solar system
-pyroxene chondrule in thinsection
-chondrules
10
Achondritic Meteorite -differentiated planetary
crust?
11
Iron Meteorites -actually mixture of Fe and
Ni -planetary cores?
12
(No Transcript)
13
(No Transcript)
14
Earths Internal Structure

• The solid Earth has a layered structure
• Layers defined by composition and physical
  properties
• Compositional layers
• crust - mantle - core
• Physical layers
• lithosphere - asthenosphere - mesosphere - outer
  core - inner core

15
(No Transcript)
16
Compositional Layers

• Crust
• Continental crust
• Thicker than oceanic crust - up to 75 km
• Less dense - 2.7 g/cm3

• Oceanic crust
• Thinner than continental crust - about 8 km
• More dense - 3.0 g/cm3

17
Compositional Layers

• Mantle
• Largest layer in the Earth
• 2900 km thick
• 82 by volume
• 68 by mass
• Composed of silicate rocks with abundant iron and
  magnesium
• Density ranges from 3.2 to 5 g/cm3
• Fragments found in some volcanic rocks

18
(No Transcript)
19
Compositional Layers

• Core
• Central mass about 7000km in diameter
• Average density of 10.8 g/cm3
• 16 by volume, 32 of mass
• Indirect evidence of composition
• Metallic iron

20
Physical Layers

• Outer Core
• 2270 km thick
• Liquid, flows
• Flow creates magnetic field
• Inner Core
• 1200 km thick
• Solid

21
Dr. Inge Lehmann (1888-1993) -discoverer of the
Earth's inner core. -Danish seismologist -discov
ered the P discontinuity P-wave deflections at
inner-outer core boundary
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Seismic Structure of the Earth

• Seismic wave velocities vary with depth
• Variation with depth is not regular
• Discontinuities exist at certain depths
• Represent discrete changes in the layered Earth
  structure

27
Refraction waves passing from material of one
density to a material with a different density
change pathway bent.
28
(No Transcript)
29
(No Transcript)
30
Outermost Layers of the Solid Earth
Low velocity zone -partially molten?
31
(No Transcript)
32
Laboratory Experimentation
Piston-cylinder Apparatus -pressures up to 5 GPa
50,000X atmos pressure -workhouse for Upper
Mantle research
Piston-Cylinder 5 Gpa range
33
The Multi-Anvil -pressures up to 50 GPa 500,000X
atmospheric -Lower Mantle Outer Core
34
The Diamond Anvil -pressures up to 400 GPa -100
to 200 GPa commonly
35
Schematic of the Diamond Anvil Cell
