OH1 Project Charter

• Develop an OH1, Next-Generation Network that is
  reliable, redundant, and demonstrates quality of
  service characteristics by effectively
  aggregating the converged (voice, data, video)
  communications needs of Ohio state government
  that includes 120 agencies, boards, and
  commissions.
• Allow other governmental entities to leverage the
  service and/or pricing derived out of the state
  telecommunication investment. Other governmental
  entities may include
• 384 courts, 118 clerks offices, integrated
  justice partners, the public, and related state
  agencies to a secure centralized data repository
• 2,300 local governments
• 700 public library facilities
• Over 2,500 K-12 facilities

3
OH1 Goals

• Identify Network Alternatives
• Develop technical, support and financial
  requirements
• Surface technology issues
• Examine feasibility of utilizing a private fiber
  infrastructure
• Develop strategic network architecture
• Design
• Services (data, video, voice)
• Security
• Support

4
OH1 Quality Factors / Principles
QUALITY FACTORS PERSPECTIVE PRINCIPLES
SCALABILITY Architecture is modular, utilizes state of art technology and has the capability to scale to future growth and technological change. Modular Design Gigabit Design Vendor Independent Architecture
RELIABILITY Facility utilizes industry standard equipment and protocols and is designed in a fully redundant and fault tolerant fashion. Fully Redundant and Fault Tolerant Design Gigabit Design Redundant WAN Connectivity
PERFORMANCE Production network utilizes state of art (fiber based) high speed connectivity and processing. Multi-Tier Load Balancing Gigabit Design Dedicated Out of Band Management Network
AVAILABILITY Facility utilizes fully redundant logical network constructs that increase scalability, optimize fault tolerance and load-balancing, thus ensuring high availability. Multi-Tier Load Balancing Fully Redundant and Fault Tolerant Design Redundant WAN Connectivity Gigabit Design
MANAGEABILITY Facility utilizes processes based on industry best practices and state of the art technology utilizing dedicated secure networks. Dedicated Out of Band Management Network Dedicated Access Network
SECURITY Facility utilizes double firewalls at multiple levels and separates management networks from production networks Double Firewall Principle Multi-vendor, multi-layer Firewall Design Dedicated Out of Band Management Network
MAINTAINABILITY Facility provides a dedicated and secure access network to ensure timely and efficient access to state agency applications. Dedicated Access Network
5
Project Approach
OH1 Project Objective Create a statewide
communication vision, strategy, and enterprise
architecture with a governance model that reduces
operational risk and effectively aggregates
bandwidth.
Lifecycle Methodology
Perform Network Traffic and Capacity Analysis
Gather and Analyze Network Requirements
RecommendNetworkArchitecture
Business Case Development
Marketing Plan Development
Project Phases
Current Network Architecture
Project Kickoff

• Identify key sources for business and network
  detail
• Collect data via interviews, surveys, focus
  groups, etc.
• Document technical and functional requirements

• Review current network environment
• Compile and update network documentation
• Review financial information related to the
  network
• Review strategic plans and existing projects

• Collect critical utilization data on current
  network
• Identify new network requirements and project
  future traffic demands
• Document analysis

• Develop critical design criteria and parameters
• Identify network architecture alternatives
• Identify estimated cost
• Assess impact of new and emerging technologies
• Develop cost benefit analysis

• Develop preliminary business case
• Assess risk and complexity
• Refine and final-ize business case
• Develop deploy-ment strategy

• Identify guiding principles and philosophies
• Define categories of products and target
  audiences
• Develop catalog of specific service offerings
• Identify programs to communicate service
  offerings

• Develop Project Charter
• Develop Project Plan
• Identify key contacts
• Develop a Strategy for Communications

KeyDeliverables
6
Current Ohio Infrastructure
7
Current Environment

1. 98.5 of the lines currently on State of Ohio
   Multi-Agency Communications Systems (SOMACS)
   contract will be affected by the expiration of
   the contract. (12931 lines out of 13127)
2. There are 7538 Lottery Analog lines that are part
   of the SOMAC contract.
3. The remaining 5393 lines support DS0, DS1, DS3,
   OC3, 0C12, OC48, FE, GE traffic throughout the
   agencies.
4. 1.5 of the lines currently on other contracts
   will not necessarily expire at the same time as
   SOMACS. (196 lines out of 13127)
5. 21 of 5393 lines have a presence in the county
   that a POP for TFN is located.
6. Core WAN protocols include TCP/IP, IPX,
   Transactional Bridging, AppleTalk, Vines and
   CLNS.
7. Network Management Applications include HP
   Openview, IBM/Tivoli, Cabletron Spectrum, CA
   Unicenter TNG, ATT Accumaster and SUN NetManager

8
OH1 Future Network Architecture

• State Fiber Network and Service Provider Networks
  will be dual connected to provide additional
  level of connectivity and redundancy
• The network addressing tags will be maintained
  and routing is enabled between the two networks
  to enable communication between services as
  required

9
State Fiber Network Design
10
State Owned Fiber Service Provider OH1 Network

• Description
• The State Fiber Network would constitute the
  foundational backbone for the statewide network
• Last Mile Connectivity would be provisioned
  either to State Fiber Network or Service Provider
  POPs depending on distance, availability and
  cost
• Interconnectivity between State Fiber Network and
  Service providers (telcos, cable, fiber, and
  wireless) will provide core network redundancy.
  Routing and switching information would be
  maintained across the entire network
• Required services (data, video, voice) would be
  made available to the agencies on demand
• The State may elect to manage the OH1 network
  including the ring and switching layers
• OARnet will manage the fiber ring optics
• The number of wavelengths (lambdas) enabled would
  be proportional to the number of services (data,
  video, voice) enabled

11
OH1 Proposed Network Map over TFN
12
OH1 Network Architecture
Advantages Risks
Highly redundant Since two diverse independent networks (private fiber service provider) will be used, high redundancy may be achieved Highly scalable Since the optical backbone is leveraged, services can be enabled on demand Increased Last Mile Options, due to additional POP locations and service provider options Potential for lower cost per location Since two options will be available to each location, sites can be provisioned after taking into account last mile options Connection via Service Providers Connection via State Fiber Network POPs The two networks need to exchange routing/switching information leading to complexities Operational and service complexities Management and control issues
13
Sample Connectivity
14
Sample Local Office Connectivity
15
Sample Last Mile Connectivity
Layer 2/3 Switch
OH1 POP
Transport Core
Printer
PCs

• POP
• Layer 2/3 Switch

Medium/ Large Location
Layer 2/3 Switch
Servers
10/100/1000
Workstations
Small Location
16
Last Mile Connectivity with Firewall Option
Layer 2/3 Switch
OH1 POP
Transport Core
Printer
Firewall
PCs

• POP
• Layer 2/3 Switch

Medium/ Large Location
Layer 2/3 Switch
Servers
10/100/1000
Firewall
Workstations
Small Location
17
Next Steps

• Review and finalize OH1 network architecture,
  including POP locations and Last Mile options
• Validate traffic modeling statistics
• Current application
• Future applications
• Review security approach
• Develop Business Plan
