Extracting the Ham from Spam

1
Extracting the Hamfrom Spam

• David J. Young

2
Introduction

• History
• Spam
• Terminology
• ASSP
• Benchmarks
• Demo
• Questions

3
History

• Where did the term spam come from?

4
SPiced hAM
5
SPAM sketch
http//www.youtube.com/results?search_queryspamm
ontypython
http//video.google.com/videosearch?qspammontyp
ython

• Scene  A cafe.  One table is occupied by a group
  of Vikings wearing horned helmets.  Whenever the
  word "spam" is repeated, they begin singing
  and/or chanting.  A man and his wife enter.  The
  man is played by Eric Idle, the wife is played by
  Graham Chapman (in drag), and the waitress is
  played by Terry Jones, also in drag.
• ManYou sit here, dear.WifeAll
  right.ManMorning!WaitressMorning!ManWell,
  what've you got?WaitressWell, there's egg and
  bacon egg sausage and bacon egg and spam egg
  bacon and spam egg bacon sausage and spam spam
  bacon sausage and spam spam egg spam spam bacon
  and spam spam sausage spam spam bacon spam
  tomato and spamVikingsSpam spam spam
  spam...Waitress...spam spam spam egg and spam
  spam spam spam spam spam spam baked beans spam
  spam spam...VikingsSpam! Lovely spam! Lovely
  spam!Waitress...or Lobster Thermidor a Crevette
  with a mornay sauce served in a Provencale manner
  with shallots and aubergines garnished with
  truffle pate, brandy and with a fried egg on top
  and spam.WifeHave you got anything without
  spam?WaitressWell, there's spam egg sausage and
  spam, that's not got much spam in it.WifeI don't
  want ANY spam!ManWhy can't she have egg bacon
  spam and sausage?WifeTHAT'S got spam in
  it!ManHasn't got as much spam in it as spam egg
  sausage and spam, has it?VikingsSpam spam spam
  spam... (Crescendo through next few
  lines...)WifeCould you do the egg bacon spam and
  sausage without the spam then?WaitressUrgghh!Wife
  What do you mean 'Urgghh'? I don't like
  spam!VikingsLovely spam! Wonderful
  spam!WaitressShut up!VikingsLovely spam!
  Wonderful spam!WaitressShut up! (Vikings stop)
  Bloody Vikings! You can't have egg bacon spam and
  sausage without the spam.WifeI don't like
  spam!ManSshh, dear, don't cause a fuss. I'll
  have your spam. I love it. I'm having spam spam
  spam spam spam spam spam beaked beans spam spam
  spam and spam!VikingsSpam spam spam spam. Lovely
  spam! Wonderful spam!WaitressShut up!! Baked
  beans are off.ManWell could I have her spam
  instead of the baked beans then?WaitressYou mean
  spam spam spam spam spam spam... (but it is too
  late and the Vikings drown her words)VikingsSpam
  spam spam spam. Lovely spam! Wonderful spam! Spam
  spa-a-a-a-a-am spam spa-a-a-a-a-am spam. Lovely
  spam! Lovely spam! Lovely spam! Lovely spam!
  Lovely spam! Spam spam spam spam!

6
Spam Spam Spam lyrics

• Lovely spam, wonderful spa-a-m,Lovely spam,
  wonderful S Spam,Spa-a-a-a-a-a-a-am,Spa-a-a-a-a-
  a-a-am,SPA-A-A-A-A-A-A-AM,SPA-A-A-A-A-A-A-AM,LO
  VELY SPAM, LOVELY SPAM,LOVELY SPAM, LOVELY
  SPAM,LOVELY SPA-A-A-A-AM...SPA-AM, SPA-AM,
  SPA-AM, SPA-A-A-AM!

7
What is spam?

• Unsolicited Bulk e-mail (UBE)
• Unsolicited Commerical Email (UCE)
• The abuse of electronic messaging systems to
  send unsolicited, undesired bulk messages

8
The cost of spam

• Productivity It is estimated that 80-85 of all
  email is spam
• Payload may contain malware (virus, worm, trojan,
  etc.)
• Internet bandwidth

9
How do spammers gete-mail addresses?

• Replying to a spam e-mail
• Auto-responders (vacation)
• Viewing HTML spam (web beacons)
• Clicking on URLs to websites listed in spam
• Chain e-mail (MUA virus)
• Mining
• Usenet postings/message boards/chat rooms
• Usenet article message-IDs
• Company or personal websites
• DNS SOA records
• whois database
• Opt-out websites
• E-mail worms harvesting address books
• Shady businesses selling addresses to spammers
• Dictionary attacks
• Zombies

10
Anti-spam best practices

• Turn off email preview
• Use throw away email addresses
• Do not use an auto responder
• Do not read spam
• Do not click on URLs in spam
• Give your e-mail address only to closely trusted
  acquaintances
• Use images or other obfuscation techniques
• Googling for your email address
• Use a good spam filter

11
Terminology
Not Identified as SPAM Identified as SPAM
Not SPAM (Negative) True Negative False Negative (SPAM)
SPAM (Positive) False Positive True Positive (SPAM)
12
xxxxx Listing

• Whitelisting
• A list of email addresses which would generally
  never send you spam
• Blacklisting
• A list of email addresses or domains you do not
  wish to receive any email from
• Greylisting
• Temporarily reject an unknown email by imposing a
  fixed delay before accepting email (ASSP calls
  this Delaying due to a name conflict)
• Redlisting
• Keeps an address off the whitelist

13
More ASSP terms

• Spam Lover
• Spam Bucket
• Honeypot
• Postmaster
• Bayesian
• MTA
• MUA
• SMTP

14
Processing matrix
Filtered Mail Unfiltered Mail
Contributes to whitelist Normal ASSP operation Spam Lover
Doesnt contribute to whitelist Redlist (but does contribute to spam/nospam collections) No processing (also doesnt contribute to spam/nospam collections)
15
What is ASSP?

• Anti-Spam SMTP Proxy
• An Open Source platform-independent transparent
  SMTP proxy server that leverages numerous
  methodologies and technologies to both rigidly
  and adaptively identify spam.
• -- wikipedia.org

16
Theory of Operation

• When you install ASSP a colony of
  super-intelligent thermophilus bacteria takes up
  residence on your CPU and begin reading all your
  email. They communicate using radio waves
  directly with the CPU and interface with the ASSP
  software choosing between spam and nonspam mail.
• If you choose to read further this myth will be
  sadly dispelled, and I take no responsibility for
  the consequences.
• However, you can always refer your users to this
  slide to prove to them that their email is
  actually being filtered by super-intelligent
  bacteria.

17
True Theory of Operation

• ASSP uses three complementary strategies to allow
  good email and to block unsolicited email
• Whitelisting
• Spambuckets
• Bayesian filtering
• Local mail domain users are not whitelisted

18
ASSP Implementation

• Version 1.2.5
• It is a single Perl script
• 360 KB
• 10,000 lines
• Built in web server
• Built in Pseudo-SMTP server

19
ASSP Target User Base

• ASSPs primary target audience is mail
  administrators or system administrators at
  smallish institutions. If you operate an ISP or a
  mailhost with a heterogeneous user base, you may
  not have a good enough consensus about what is
  considered spam or is not. It should work well
  with between 1 and 300 client addresses and a
  mail volume of up to around 100,000 messages per
  day. Testing has not been done to verify these
  ranges
• ASSP is not for the following
• Individual clients -- ASSP must be installed
  together with a SMTP server
• Domains which receive mail indirectly, for
  example if you use fetchmail

20
ASSP Philosophy

• Reject SPAM before the SMTP server
• Work with any SMTP MTA
• Adapt quickly as spammers change attack
  strategies
• Require low maintenance after initial setup

21
Main ASSP capabilities

• Automatic Whitelisting
• Spam Traps
• Bayesian filtering
• Greylist
• Whitelist RE Matching
• Email interface
• Mail Analyzer
• Automatic Statistics
• SPF (Sender Policy Framework)
• DNSBL (DNS Black Lists)
• ClamAV virus scanner
• Mail host Headers

22
ASSP Features

• Uses existing MTA and MUAs
• Runs on Linux, Unix, Windows, OS X, and more
• Automatic whitelist no-one you email will ever
  be blocked
• Redlist keeps an address off the whitelist
• Uses honeypot type spambucket addresses to
  automatically recognize spam and update your spam
  database
• Bayesian filter intelligently classifies email
  into spam and non-spam
• Supports site-defined regular expressions to
  identify spam or non-spam email
• Accepts whitelist submissions and spam error
  reports by authorized email
• Browser based setup
• Keeps spam statistics for your site
• Recognizes Mime encoded and other camouflaged
  spam
• Can listen on more than one smtp port
• Basic anti-virus filtering using the ClamAV virus
  databases
• Optionally blocks no mail but adds an email
  header and/or updates the message subject
  (SPAM)
• Can block spam-bombs (when spammers forge your
  domain in the from field)
• More

23
ASSP Flexibility

• Whitelist-only mode
• Dont filter, just tag subject line
• Let specific addresses receive SPAM
• Use a mail list behind ASSP
• Use ASSP with redundant MX domains
• Web based configuration

24
ASSP Mail Processing

• What order does ASSP process mail to check if it
  is spam?
• Local or whitelisted?
• Blacklisted Domain?
• Spam Helo?
• Addressed to spam-bucket?
• Mail bomb?
• Blocked attachment?
• Matches expression to identify non-spam?
• Matches expression to identify spam?
• Bayesian evaluation
• If the message is identified as spam at any step
  along the way it goes to the spam directory. If
  the message is local or whitelisted it goes to
  the notspam directory.

25
Installation Overview

• Install ASSP and dependencies
• Configure ASSP
• Put ASSP in test mode
• Modify mail flow of test user(s)
• Test that it is working
• Prime the system
• Create the Bayesian database
• Automate daily Bayesian database updates
• Monitor spam filtering
• Correct false negatives and false positives
• Take ASSP out of test mode
• Train user community
• Modify mail flow of trained users

26
ASSP Installation

• Install Perl
• Install Perl modules from CPAN
• CompressZlib NEEDED - Standard Perl
  installation
• DigestMD5 NEEDED - Standard Perl installation
• TimeHiRes NEEDED - Standard Perl installation
• NetDNS NEEDED TO RUN RBL, SPF and 1.2.X
• EmailValid OPTIONAL, BUT ADVISED
• FileReadBackwards OPTIONAL, BUT ADVISED
• MailSPFQuery OPTIONAL
• MailSRS OPTIONAL
• SysSyslog OPTIONAL
• NetLDAP OPTIONAL NEEDED IF YOU RUN LDAP
• Win32Daemon NEEDED to run as a service on
  Windows
• No installation script
• GUNZIP assp.tar.gz to /usr/local/assp
• In /usr/local create the following directories
• assp/spam
• assp/notspam
• assp/errors

27
Configure ASSP

• Start ASSP
• perl assp.pl
• Configure ASSP
• http//127.0.0.155555
• Login ltemptygt
• Password nospam4me (default)
• Beware of the Show Advanced Configuration Option

28
ASSP Configuration
29
Initial Configuration

• Change values for
• Web Admin Password
• Accept All Mail
• Local Domains
• Spam Error
• Spam Addresses
• Addresses of recipients at your site that only
  receive spam (website spam-bait, ex-employees)

30
Mail Flow
Internet
Mail Svr
Clients
Inbound
Outbound
Internet
Mail Svr
Clients
with ASSP
Internet
ASSP
Mail Svr
Clients
Inbound
Outbound
Internet
ASSP
Mail Svr
Clients
Internet
Mail Svr
ASSP
Clients
Invalid
31
Email Flow
Internet
ASSP
GroupWise/ Exchange
Clients
MTA
Inbound
Outbound
Internet
GroupWise/ Exchange
Clients
MTA
ASSP
smtp0
white
red
black
grey
25
125
ASSP
MTA
in
out
Bayesian DB
Errors
spam
Not spam
32
1999
This is an email that is being sent to the
Internet. Th This is an email that is
33
2003
34
2004
GroupWise
Internet MTA
GWIA
MTA
sendmail
Virtuser table
aliases
POA
35
2006
GroupWise
Internet MTA
GWIA
MTA
sendmail
Virtuser table
aliases
POA
36
Phase In
GroupWise
Internet MTA
GWIA
MTA
sendmail
Virtuser table
aliases
POA
37
Flow with Anti-Virus
Internet
ASSP
Mail Svr
Clients
Antivirus
Inbound
Internet
ASSP
Clients
Outbound
Mail Svr
Antivirus
38
Flow with Groupware
Internet
ASSP
Groupware
Clients
MTA
Inbound
Outbound
Internet
Groupware
Clients
MTA
ASSP

• To use ASSP with Exchange, Lotus Notes or
  GroupWise, youll also need to implement a
  smarthost relay like sendmail, qmail, postfix,
  exim or one in a number of others

39
DNSBL vs Greylist

• The ASSP Greylist supercedes DNSBL
• ASSP Greylist is not to be confused with
  Greylisting
• Use of DNSBL is discouraged (If a DNSBL lookup
  blocks, ASSP will block due to its multiplex
  design)

40
Penalty Box

• This will blacklist an SMTP server for about 72
  hours or so from sending to your server if they
  violate basic SMTP connection conventions over a
  certain threshold.

41
SMTP Ports

• For example, internet mail needs to connect to
  ASSP on port 25 (ASSP's listen port), and ASSP
  can proxy to your mail server on port 125 (or any
  port you choose) -- ASSP's SMTP Destination. You
  need to change your mail server to match.

42
Sender Notification

• With most client-based filters (POPFile,
  SpamBayes, SpamAssassin) senders receive NO
  NOTIFICATION if their mail isn't delivered. With
  most of these solutions, the user bears full
  responsibility to VERIFY that no good mail is
  blocked.
• ASSPs solution to this is that when spam is
  blocked the SENDER RECEIVES NOTIFICATION, and it
  does this without generating non-delivery reports
  that bounce and bounce again because spammers
  forge their from address.

43
Catch-22

• Issue Lets say a client receives a
  non-delivery report, how can he (not in
  whitelist) send a message to the organization if
  he is still not in whitelist? I mean, if the
  recipient or assp admin does not receive the
  notification, they will not know that there is a
  false positive and will not add the unknown
  client to whitelist...
• Solution Set up an email address and put it in
  the Spam-Lover Address configuration option.
  Then modify the spam error message to direct
  people to "500 Mail appears to be unsolicited
  (spam) -- please forward this email to
  not-spam_at_mydomain.com if you feel this is in
  error."Any false positives that bounce back to
  clients will hopefully be reported to the Mail
  Admin via the spam lover address (they just
  forward it), assuming they read the rejected
  email.

44
Email Interface

• Any user can help to improve ASSPs spam
  filtering accuracy. Users can use it to add
  addresses to the whitelist, report spam, or
  false-positives. To use it, you must have it
  enabeled in the configuration, and have names set
  for the addresses. The interface only accepts
  mail addressed to addresses at any of your
  localdomains, and only from "Accept All Mail"
  hosts, or authenticated SMTP connections.
• assp-white -- for whitelist additions
• assp-spam -- to report spam that got through
• assp-notspam -- to report mis-categorized spam
• Whitelisting Assuming that your local-domain is
  yourdomain.com, to add addresses to the
  whitelist, youd create a message to
  assp-white_at_yourdomain.com. You can either put the
  addresses in the body of the message, or as
  recipients of the message. For example, if you
  wanted to add all the addresses in your address
  book to the whitelist, create a message to
  assp-white_at_yourdomain.com and then add your
  entire address book to the BCC part of the
  message and click send. Note that no mail will be
  delivered to any address except
  assp-white_at_yourdomain.com (and that won't
  actually be passed to your mail transport).
  Within a short time you'll receive a response
  from ASSP showing the results of your mail.
• False Negatives To report a spam that got
  through, simply forward the mail to
  assp-spam_at_yourdomain.com. It's best to forward it
  as an attachment, but you can just forward it
  normally if you must. In a short time you will
  receive a confirmation.
• False Positives The process is the same to
  report a miscategorized spam, but send it to
  assp-notspam_at_yourdomain.com.

45
Spam Report
46
Benchmarks

• Spam Bucket
• Ex-employee that left the company 5 years ago
• Receives 50-80 spam mails per day

47
Filter effectiveness

• SpamAssassin 60-65 effective in 2004
• Deteriorated to 11 by 2006
• (267 of 2238 True Positives)
• ASSP in first 3 weeks of operation 99.7
• (1336 of 1340 True Positives)

48
ASSP vs SpamAssassin

• SpamAssassin
• is difficult to install
• great investment in hand-made regular expressions
  and header analysis to identify spam
• Hand-crafted expressions are brittle as spammers
  adjust their strategies
• Requires frequent updates to accurately identify
  spam
• ASSP
• is low maintenance
• is easy to install
• is a complete spam blocking solution, not just a
  filter that must be integrated into your MTA
• works with nearly every MTA on any OS
• Poorly documented

49
Before ASSP
50
Turning ASSP on
51
With ASSP
52
stat.pl Statistics
root_at_smtp perl stat.pl /tmp/m.log As of Mon
Jan 22 214846 2007 the mail logfile shows 0
proxy / smtp connections 253 were dropped for
attempted relays (0.0 of total). 31523
messages, 16758 were spam (53.2) in 65 days for
485.0 messages per day or 257.8 spams per
day 1518 additions to / verifications of the
whitelist (23.4 per day) 14643 were judged spam
by the bayesian filter (87.4 of spam) 2115 were
to spam addresses (12.6 of spam) 0 were rejected
for executable attachments (0 of spam) 10121
were sent from local clients (68.5 of
nonspam) 842 were from whitelisted addresses
(5.7 of nonspam) 0 messages were passed to
SPAMLOVERs 3802 were ok after a bayesian check
(25.8 of nonspam) 1498 addresses are on the
whitelist 0 hits on the blacklist 0 resulted in
spam (0.0 of Bayesian spam, 0.0 of blacklist
hits) 0 resulted in non-spam (0.000 of blacklist
hits)
53
ASSP Statistics
54
Issues

• Vacation
• Auto Replies
• TLS and secure SMTP
• ASSP is site based, not per-user

55
Lessons Learned

• Whitelist spambucket Bayesian is a great spam
  filtering strategy
• The default is SPF failures will filter even if
  whitelisted
• Be very careful what you put in the relay hosts
  list
• ASSP is not multi-process or multi-threaded

56
Utilities

• rebuildspamdb.pl
• repair.pl
• move2num.pl
• stat.pl

57
Demo

• Web configuration
• Mail analyzer

58
Resources on the Internet

• http//www.spamland.com
• http//antispam.yahoo.com
• http//www.openspf.org

59
Questions
