Parameter Binding

1
Parameter Binding PHP
Protecting your web application from SQL
injection attacks
Revision based on presentation feedback added
simple introduction to prepared statements added
better introduction to SQL injection mentioned
risk of cross-site scripting attacks if no input
filtering in addition to use of parameter
binding removed MSSQL page added at last minute
(was on stored procedures not prepared statements
- -( )

• Grant Paton-Simpson
• Paton-Simpson Associates Ltd
• www.p-s.co.nz

2
Introduction

• PHP easy to start, easy to get into bad
  programming habits (esp if not a programmer -) )
• Easy to write code to interact with a database
• e.g. staff_id _POST'staff_id'
• strSQL "SELECT salary FROM tblstaff WHERE
  staff_id staff_id"
• And this is how major texts teach it too
• The (major) problem - SQL injection

3
SQL Injection

• User input should always be treated as dangerous,
  esp when interacting with a database
• Example - Instead of the user entering "8" in the
  ID textbox, they enter "8 OR 11"
• or enter "bogus' OR 11" into the password field
• or write "bogus' DROP ..."
• Open Sesame!
• Very common one estimate is about 1 in 8
  websites or possibly much higherhttp//portal.spi
  dynamics.com/blogs/msutton/archive/2006/09/26/How-
  Prevalent-Are-SQL-Injection-Vulnerabilities_3F00_.
  aspx

4
Parameter binding as response

• Solutions input filtering etc and possibly
  parameter binding
• What is parameter binding? You make a query
  template and define the input parameterse.g.
  "SELECT FROM tblTable WHERE id?"Then you
  feed it the parameters (in this case, the
  id)Will not change the syntax of the statement,
  only the value of the input. The input stays
  safely contained in its place
• NB may need input filtering anyway to prevent
  Cross-site scripting attacks no point
  faithfully storing a dangerous script in your
  database and serving it up to your unsuspecting
  users

5
Parameter Binding A Minimum Standard?

• Focusing here on parameter binding
• To some people, saying "I don't use parameter
  binding" is like saying "I lock my house with
  sellotape"!
• The following quote from slashdot is typical of
  many
• http//it.slashdot.org/comments.pl?threshold5mod
  ethreadcommentsort0opChangesid191584
• "That bears reiterating. If you are passing user
  input to a database in anything but a bind
  variable, you are incompetent. Period. End of
  story.
• I've seen it so many times. Why do programmers
  think that it's a good idea to write their own
  escape routines when every database has a
  facility for denoting what is variable data and
  what is not? Unbelievable."

6
Unfair criticism?

• Not necessary if already using thorough input
  filtering/ validation and presumably
  mysqli_real_escape_string mysqli_real_escape_s
  tring is NOT absolutely bulletproof under all
  circumstances in particular if you change to a
  multibyte charset (other than UTF-8, which is
  safe) in your script - see http//ilia.ws/archives
  /103-mysql_real_escape_string-versus-Prepared-Stat
  ements.html
• Often simpler, cleaner code when avoiding binding
• There are all sorts of downsides to using
  prepared statements (more on that later)
• Not just a straight substitution
• changing existing code can be impractical
  (nothing is probably absolutely impossible ...
  but it could get very, very ugly, and complicated)

7
Not just a straight substitution

• May be hard to wrap in classes
• Although I managed with the help of
  call_user_func_array() on the bind method of stmt
  etc, often the interface was no simpler, just
  non-standard!
• Lots less flexibility (part of the logic of
  explicitly binding to parameters and not changing
  the actual semantics of the query template)
• Can't replace "SELECT FROM tblfoo filter"
  where filter will sometimes be a WHERE clause
  and sometimes be an empty string
• "placeholders are not allowed ... to specify
  both operands of a binary operator such as the
  equal sign. The latter restriction is necessary
  because it would be impossible to determine the
  parameter type.http//www.php.net/manual/en/funct
  ion.mysqli-stmt-prepare.php
• Can't change list of fields displayed etc etc etc

8
List of Problems with Prepared Statements in PHP

• 1. Query cache does not work
• 2. Extra server round trip required if statement
  used only once
• 3. Not all statements can be prepared. So you
  cant use prepared API exclusively youll need to
  fall back to normal API for some statements
• 4. Newer and sometimes buggy code. I had a lot of
  problems with PHP prepared statements. It is
  getting better but still it is less mature than
  standard API
• 5. You cant use placeholders in place of all
  identifiers. For example you cant use them for
  table name. In certain version it even does not
  work for LIMIT boundaries
• 6. Inconvenient list handling. Unlike in for
  example PEAR emulated prepard statements there is
  no nice way to pass list of values to IN
• 7. Harder tracing. Logs were now fixed to include
  full statement text not only Execute but in
  SHOW INNODB STATUS you would still see statements
  without actual values - quite inconvenient for
  analyses. http//www.mysqlperformanceblog.com/20
  06/08/02/mysql-prepared-statements/

9
More balanced approach

• Prepared statements can potentially have lots of
  benefits ...
• ... but there can be some issues/problems with
  using prepared statements some generic and some
  specific to the language implementation
• So ... worth learning how to use when appropriate

10
Different implementations

• Not a language-specific skill/approach
• Python example
• Never do this -- insecure!
• symbol 'IBM'
• c.execute("... where symbol 's'" symbol)
• Do this instead
• t (symbol,)
• c.execute('select from stocks where symbol?',
  t)
• Will focus on PHP and MySQL using mysqli (could
  also use PDO or PEARDB or other databases)

11
More on Python implementation

• SQLite in Python http//www.sqlite.org/lang_expr.
  html
• Parameters can take several forms
• ?NNN A question mark followed by a number NNN
  holds a spot for the NNN-th parameter. NNN must
  be between 1 and 999.
• ? A question mark that is not followed by a
  number holds a spot for the next unused
  parameter.
• AAAA A colon followed by an identifier name
  holds a spot for a named parameter with the name
  AAAA. Named parameters are also numbered. The
  number assigned is the next unused number. To
  avoid confusion, it is best to avoid mixing named
  and numbered parameters.

12
Prepared Statements in MySQL/PHP

• Best to use the mysqli extension (PHP 5 and
  MySQL 4.1)
• George Schlossnagle made some classes to
  implement a mysql version in Advanced PHP
  Programming 2004 p.48 (only to demonstrate the
  Adaptor design pattern) but it is probably safer
  to use the built-in version
• Prepared Statements in MySQL - about both
  security or performance

13
mysqli Should I make the change?

• Some people believe the mysqli extension is
  slower than mysql unless you are running prepared
  statements (which can be the fastest depending on
  the query and level of reuse)
• The developer of mysqli says mysqli is faster and
  more secure (plus more features etc)
• MySQL has developed a tool to help PHP
  programmers switch code from mysql to
  mysqlihttp//forge.mysql.com/wiki/Converting_to_M
  ySQLi

14
Template and placeholders

• Two flavours of prepared statements bound
  parameter and bound result (http//devzone.zend.co
  m/node/view/id/686)
• Focus here on bound parameter prepared statements
• A query template is created and sent to the MySQL
  server. The MySQL server receives the query
  template, validates it to ensure that it is
  well-formed, parses it to ensure that it is
  meaningful, and stores it in a special buffer. It
  then returns a special handle that can later be
  used to reference the prepared statement.
• When a query needs to be made, data to fill in
  the template is sent to the MySQL server, and
  then a complete query is formed and then
  executed.

15
Possible Performance Benefits

• If query "template" reused, lots less data to
  send around (only the changes), so much better
  for repeated queries
• BUT can be slower - two round-trips to the
  server, which can slow down simple queries that
  are only executed a single time
  http//dev.mysql.com/tech-resources/articles/4.1/p
  repared-statements.html
• Sends data around in binary form rather than as
  text
• MySQL pre-4.1 used text protocol for data
  transfer - query was sent as text and result
  returned back as text. ... number 123 would be
  sent as string 123?. ... serious performance
  implication - queries had to be parsed fully each
  time, all return values had to be converted to
  the strings on server side and back on the client
  side, which is pretty expensive especially for
  certain data types. Furthermore BLOBs require
  escaping as not all characters could be used in
  textual protocol, which not only consumed time
  but also required extra memory consumption both
  on server and client (http//www.mysqlperformance
  blog.com/2006/08/02/mysql-prepared-statements/)

16
Security Benefits

• The data for the query does not need to be passed
  through a function like mysql_real_escape_string()
  to ensure that no SQL injection attacks occur.
  Instead, the MySQL client and server work
  together to ensure that the sent data is handled
  safely when it is combined with the prepared
  statement (http//devzone.zend.com/node/view/id/68
  6)
• escaping is ... unnecessary when dealing with
  prepared statements. The separation of the data
  allows MySQL to automatically take into account
  these characters and they do not need to be
  escaped using any special function
  (http//dev.mysql.com/tech-resources/articles/4.1/
  prepared-statements.html)

17
mysqli Syntax

• stmt mysqli-gtprepare("INSERT INTO
  CountryLanguage VALUES (?, ?, ?, ?)")
• stmt-gtbind_param('sssd', code, language,
  official, percent)
• code 'DEU' language 'Bavarian' official
  "F" percent 11.2
• stmt-gtexecute()
• sssd string, string, string, double/float (i is
  integer, and b is blob s is for anything other
  than the rest really inc dates)
• bind types enable data to be encoded for greater
  efficiency

18
Extra details using mysqli

• input variables must be bound before executing
  the statement
• output variables must be bound after executing
  the prepared statement (PHP5 Power Programming
  Gutmans, Bakken Rethans, Prentice Hall, 2005,
  p.157).
• remember to close prepared statements - Many
  memory leaks reported in MySQL Server turned out
  to be prepare statements or cursors which were
  forgotten to be closed. Watch Com_stmt_prepare
  and Com_stmt_close to see if youre closing all
  prepared statements. In newer versions you can
  also use prepared_stmt_count variable to track
  number of open statements diretly. You can also
  adjust max_prepared_stmt_count variable which
  limits how many statements can be open at the
  same time to avoid overloadhttp//www.mysqlperfor
  manceblog.com/2006/08/02/mysql-prepared-statements
  /

19
PDO and Prepared Statements

• PDO provides a data-access abstraction layer,
  which means that, regardless of which database
  you're using, you use the same functions to issue
  queries and fetch data. PDO does not provide a
  database abstraction it doesn't rewrite SQL or
  emulate missing features.
• Prepared statements are so useful that they are
  the only feature that PDO will emulate for
  drivers that don't support them. This ensures
  that you will be able to use the same data access
  paradigm regardless of the capabilities of the
  database (http//nz.php.net/pdo)
• PHP 5.1 onwards only

20
PDO Syntax

• Either positional or named placeholders
• Positional using "?"
• stmt dbh-gtprepare("INSERT INTO REGISTRY
  (name, value) VALUES (?, ?)")
• stmt-gtbindParam(1, name)
• Named using "" prefix
• stmt dbh-gtprepare("INSERT INTO REGISTRY
  (name, value) VALUES (name, value)")
• stmt-gtbindParam('name', name)

21
Links

• Article by Zak Greant and Georg Richter
  http//devzone.zend.com/node/view/id/686
• MySQL articlehttp//dev.mysql.com/tech-resources/
  articles/4.1/prepared-statements.html
• PDO on PHP net http//nz.php.net/pdo
• MySQL Performance Blog http//www.mysqlperformanc
  eblog.com/2006/08/02/mysql-prepared-statements/
