Title: Corporate PPT Template


1
(No Transcript)
2
A DBA Perspective to J2EE
  • Debu PandaPrincipal Product Manager
  • Oracle Application Server Development
  • http//radio.weblogs.com/0135826/

3
Impedance Mismatch
I love my objects and beans
I love my tables
Developer
DBA
4
Agenda
  • Application Server Overview
  • J2EE Overview
  • Persistence Options and related concerns
  • Entity Bean Lifecycle for the DBAs
  • Messaging and Advanced Queuing
  • J2EE Security and OID/Single Sign On
  • Additional Resources and Next Steps

5
What is An application Server
  • Middleware between users and database systems
  • Provides frameworks for building and deploying
    applications
  • Security
  • Transactions
  • Business Intelligence
  • Self-service Portal
  • Web Services
  • Caching and Hi-Availability
  • Increasingly Application Servers are becoming an
    O/S for servers !
  • Major Players Oracle, BEA, IBM

6
Oracle Application Server 10g Integrated
Middleware Platform
Management Security
Clustering Caching
Rapid Application Development
7
Mind boggling J2EE
JSP
Servlet
JDBC
JTA
EJB
JMS
JNDI
JCA
J2EE
8
What is J2EE?
  • Java 2 Enterprise Edition (J2EE)
  • Platform to build scalable and portable
    applications in Java
  • Relies on a number of Java specifications
  • Servlets, JSPs, EJB, JMS, JDBC, JTA, JNDI, etc.
  • DBAs care most about JDBC,JTA and EJB
  • JDBC Java APIs for Database access
  • JTA Java APIs to manage transactions
  • EJB Enterprise JavaBeans
  • Oracle Application Server Containers for J2EE
    (OC4J) is J2EE 1.4 compliant

9
Develop J2EE Applications with Oracle
Application Server
Servlets
JSP
OHS
http
EJBs (Session, Entity, MDBs)
Browser
EJB Client
RMI
JMS
JNDI
JCA
JTA
Java Mail
JAAS
JDBC
CORBA Client
RMI-over-IIOP
J2EE Container
Java VM
Oracle Application Server
10
What is a J2EE Container
  • J2EE applications run in a special environment
    called a J2EE Container/Server
  • Oracles container is named OracleAS Containers
    for J2EE (OC4J)

EJB Container
Web Container
Interfaces
Client
EJB Bean
Servlet/JSP
Home
J2EE Server
11
J2EE Architecture
JDBC / J2CA
12
What is JDBC
  • Standard API for accessing relational databases
    from Java
  • Issue SQL statements
  • Call server-side procedural logic
  • Conceptually similar to ODBC

13
JDBC Driver
  • Translates JDBC method calls to vendor-specific
    database commands
  • Implements interfaces defined in the java.sql and
    javax.sql packages
  • Can also provide a vendors extensions to the
    JDBC standard

Database
Database commands
JDBC calls
Driver
Database
14
Oracle JDBC Drivers
Remote Database
Oracle Database
Thin Driver (Type IV)
Java Engine
Java Sockets
Server-Side Thin Driver
Java Sockets
SQL Engine PL/SQL Engine
Server-Side Internal Driver
OCI Driver (Type II)
KPRB C Library
OCI C Library
15
Sample JDBC URLs for Oracle
  • Thin driver
  • OCI driver
  • Server-Side internal driver

jdbcoraclethin_at_
jdbcoraclethin_at_dbdev.acme.com1521ORCL
jdbcoracleoci_at_
jdbcoracleoci_at_dbdev
jdbcoraclekprb
16
Connecting to the Database
Issue statement
Close
Connect
Process results
  • Register the driver
  • Connect to the database

DriverManager.registerDriver (new oracle.jdbc.Ora
cleDriver())
Connection conn DriverManager.getConnection ("j
dbcoraclethin_at_myhost1521orcl", "scott",
"tiger")
17
JNDI Data Sources
  • Newer way to access connection information
  • More flexible, portable than hard-coding URLs
  • Look up connection details by logical name
  • Typical for J2EE applications

Context ctx new InitialContext()
OracleDataSource ods (OracleDataSource)ctx.
lookup("jdbc/TestDB") Connection conn
ods.getConnection()
18
Connection Pooling and Caching
  • Reuse an existing physical connection
  • Closing the connection releases it back to be
    reused
  • Useful for stateless applications
  • Maintaining a set of Pooled Connections is called
    Connection Caching

JDBC Connection
Database
PooledConnection
PooledConnection
PooledConnection
Connection Caching
19
Java Servlets and JSP Pages
  • Server-side Java components
  • Reside in the J2EE Web Tier
  • Dynamic Web content generation

20
Java Servlets
  • Fundamental Java API for Internet Communication
  • Typically HTML generation
  • Can also deliver other datatypes including binary
    XML, WML, GIF
  • Foundation for JavaServer Pages

21
Java Servlet Example
public class HelloServlet extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse
response) throws ServletException,
IOException PrintWriter out
response.getWriter() out.setContentType(
text/html) out.println("")
out.println(Hello There!")
out.println("")
out.close()
22
JavaServer Pages
  • HTML pages with embedded Java
  • In contrast to servlets (Java with embedded HTML
    )
  • Same performance and portability benefits from
    servlet technology but with the ease of use of
    HTML
  • Best of both worlds for Web designers and Web
    developers

23
JSP Example
Hello!
Today is java.util.Date()
24
What is EJB
  • Reusable components that run inside a container
  • Can be accessed either
  • Either local and remote Java programs
  • CORBA compliant client
  • EJB Container provides support for
  • Persistence
  • Access control
  • Transactions

25
Types of EJBs
  • Session Beans encapsulate business logic
  • Transient in nature, cannot survive crash !
  • Stateless Perform a task e.g. charge a credit
  • Stateful Maintains state between calls e.g.
    shopping cart
  • Entity Beans persistent in nature
  • Representation of data
  • Two types Bean Managed Persistence (BMP),
    Container Managed Persistence (CMP)
  • Message Driven beans
  • A Java Message Service (JMS) listener (listens
    on a Topic or Queue)
  • Reliably consume message
  • Can work with Oracle Advanced Queueing

26
Enterprise JavaBean Review
OC4J
EJB container
EJB home object
EJB home interface
EJB bean
EJB client
EJB remote object
EJB remote interface
JMS client
Database
JMS Listener
MDB bean
Enterprise Services Naming, Transactions, Security
27
Entity Beans Uncovered
  • Represent persistent objects
  • Have a Primary key for unique identification
  • BMP requires developers to code all persistence
  • Use JDBC to perform persistence
  • CMP requires container to do the persistence
    based on declarations
  • Container does database access based on
    declarations by developer

28
Container Managed Relationships
  • Only between CMP EJBs
  • Supports 1-1, 1-M, and M-M
  • Relationships can be unidirectional or
    bi-directional
  • Relationships are persistent just like EJBs
  • Can have DELETE-CASCADE property


29
Entity Bean Life Cycle
30
Entity Bean Lifecycle and database
31
J2EE Persistence Options
  • J2EE standards based options are
  • Direct JDBC from web-tier or EJB session beans
  • Entity beans with Bean Managed Persistence
  • Entity beans with Container Managed Persistence
  • Additional technologies
  • Java-to-relational frameworks such as OracleAS
    TopLink
  • Oracle ADF (Application Development Framework)

32
Direct Access with JDBC
  • Developer codes all interactions with database
  • Queries, inserts, updates, deletes using JDBC API
  • Common design pattern used Data Access Objects
  • Separates persistence from business logic
  • Avoids putting JDBC code directly in Servlet/JSPs
  • Nil to low overhead from container
  • Developer is responsible for opening/closing
    resources
  • Transactions managed programmatically
  • Concurrency considerations
  • DBA Concerns Review SQL

33
Bean Managed Persistence
  • Using BMP
  • All database interactions are manually coded
  • Container calls your code when it performs an
    operation
  • Container still ultimately in control
  • Provides some implementation flexibility
  • Map to 1 or more tables, different storage
    systems
  • Make use of existing stored procedures
  • Performance perceptions and reality
  • Developer coded may be better than container
    generated
  • Inherent problem with (n 1) SQL calls
  • DBA Concerns Database schema is coded into bean,
    Review SQL

34
Container Managed Persistence
  • Using CMP
  • Developer specifies persistent attributes of
    object
  • Developer specifies how entity object maps to
    database
  • All JDBC code generated by container
  • Container is responsible for managing persistence
  • Container maintains relationships between objects
  • Requires less code than JDBC and BMP
  • Choice for persistence in J2EE Applications
  • DBA Concerns Many !! If you are not using
    Oracle Application Server

35
CMP development and deployment Concerns
  • Container Managed Tables
  • Containers creates the tables and names those
  • Ask your developers to map to your schema
  • Container creates Primary key
  • If no primary key is assigned in Entity bean
  • OC4J names this column autoid by default
  • Container Managed Relationship
  • May create an extra table for maintaining
    relationship
  • You can use foreign key for mapping 1-M

36
Performance Concerns
  • Container generates the SQL
  • SQL statement that can cause performance
    degradation by making full table scans or
    unnecessary joins
  • Unnecessary Extra SQL statements
  • Developers specify finder methods that can make
    full table scans
  • How to tune database for use with CMPs

37
Optimizing CMP Entity beans for Oracle database
  • Reduce database operations
  • Use right concurrency mode and locking strategy
  • Tune your SQL/database

38
Reduce Database Operations
  • Enforce primary key constraint at database level
  • Avoid extra SQL for constraint checking by
    container
  • Exploit DELETE CASCADE at database level
  • Container generate multiple SQL statements
  • Defer EJB creation to end of transaction
  • This avoids an extra UPDATE statement
  • Batch update operations to end of transaction
  • Exploit eager loading of relationship
  • Reduce round trips with pre-fetch size
  • Avoid N1 problem by switching off lazy-loading

39
Use Right Locking/Isolation Mode
  • Choose the right isolation level for entity beans
  • Avoid if possible at the bean level
  • COMMITTED performs better than Serializable
  • Choose right locking mode
  • Use Optimistic and Read-Only if possible
  • Pessimistic uses SELECT FOR UPDATE
  • Avoid database calls with Read-Only patterns

40
Database Tuning Tips for CMPs
  • Make sure that your finder /select method uses
    indexes.
  • Exploit statement caching by the container
  • Avoid findAll() on large tables as this makes
    full table scans
  • Most EJB systems are OLTP in nature so tuning
    redo is important
  • The basics of tuning any database are valid for
    EJBs
  • Use Statspack to find bottlenecks and tune your DB

41
OracleAS Toplink TheMost Compelling Option
  • Improves developer productivity by providing a
    flexible O-R Framework
  • Avoiding manual coding of interactions with
    database
  • Have years of experience in Java to Relational
    mapping
  • Can be used in any J2EE application
  • Servlets/JSPs / EJBs (BMP/CMP)
  • Reduces the load on database
  • Resolving the N1 problem
  • By using caching data in the middle-tier and
    reading Just In Time
  • Minimizing database calls
  • Utilize the features provided by databases
  • Respect and work with database locks

42
DB Configurations concern
  • Database user passwords
  • Used in data-sources for connection pooling
  • Stored in clear text, can be encrypted !
  • Changes require restart of container
  • OC4J uses an Oracle database for commit
    coordinator for 2-Phase commit
  • Requires a 9i database as commit coordinator
  • Requires database links

?
43
Message Driven Beans
  • A message driven bean is a stateless,
    asynchronous bean for processing JMS messages
  • Exist within a pool, receive and process incoming
    messages from a JMS queue or topic
  • Invoked by the container to handle each incoming
    message from the queue or topic

44
JMS and Oracle AQ
  • OC4J uses two JMS providers
  • OC4J JMS Internal/in-memory JMS
  • OracleJMS based in Oracle AQ
  • JMS uses
  • Queues single consumer
  • Topics multiple consumers
  • OracleJMS persists messages in AQ tables
  • As DBAs you have to manage these objects

45
Security concepts
  • Identity management
  • Authentication Is this the right guy?
  • Authorization Does his/she have this privilege?
  • Encryption - Any body hearing?

46
Identity Management
  • Programmatic vs. Declarative
  • Programmatic
  • May use a Database to store user id/passwords
  • May use a LDAP compliant directory like OID
  • Declarative
  • JAZN-LDAP requires OID
  • Oracles Single Sign-on uses Oracle DB/OID

47
OID Architectural Overview
OID clients
LDAP
OID
LDAP over SSL
Oracle Net connections
Directory administration
Oracle database
48
Benefits of OID
  • OID provides
  • Delegated Administration Service (DAS)
  • Failover in cluster configurations
  • Support for Oracle Real Application Clusters
  • Oracle Directory Integration platform, to
    synchronize with other enterprise repositories
    including third-party LDAP directories
  • Password policy management

49
Security Vulnerability
Database Storage Sys NAS
Web Servers
Application Servers
A.
B.
C.
Unprotected transaction zone!
50
Security threats to your Database
Database Storage Sys NAS
Web Servers
Application Servers
Unprotected transaction zone!
Oracle10g, 9i, DB2, some other database? Server,
mainframe, or something else? NAS, SAN,
etc? Regardless of where the DATA is stored and
how it is stored, the DATA must be must be
protected against the many threats.
51
Summary
  • J2EE is a popular platform
  • Persistence is the greatest challenge for
    developers and may impact DBAs life
  • DBAs and Developers work together to improve the
    quality of J2EE applications

52
otn.oracle.com
Join Over 3,000,000 Developers!
Free Technical Advice
Free Software Downloads
http//otn.oracle.com
53
FREE
  • Develop your career with Oracles experts
  • Web services, Forms Upgrade to the Web, TopLink,
    Business Intelligence, Integration, J2EE, Linux
  • Connect with your peers
  • Sign up at http//otn.oracle.com/events/otnworksho
    p

54
A
About PowerShow.com
