Title: Nitro-tuff Tubes


1
(No Transcript)
2
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Commercial Fluid Power
Processing Capabilities
Tubing
HONING 0.480 to 46.000 ID up to 85 feet in
Length SKIVING 1-1/2 to 12 ID lengths from
17 to 288 GUNDRILLING Up to 2.562 ID lengths
to 192 TREPANNING 32 Rounds and 20 Squares
lengths to 40 feet BORING 60 ID lengths to
144, 20ID lengths to 32 Feet TURNING 60 OD x
58, 28OD x 30 Feet, 16OD x 50 Feet CNC
TURNING 16OD x 10 Feet SAWING 20
OD GRINDING 1.375 to 11.750OD x 35 Feet
Raw/Bored
Since 1951 Commercial Fluid Power has been
distributing and processing precision tubing and
bar to the World markets. We pride ourselves in
delivering a quality product with the technical
expertise you demand. Our tubing inventory
includes carbon, alloy, and stainless steel in
raw or processed conditions including honed
tubing, suitable to hone, CPID and CPOD products.
Our bar inventory includes CPO, IHC, Nitro-tuff
and stainless steel chrome plated shafting.
Custom size or custom material inquiries are
welcome. We purchase and certify our material to
meet the stringent requirements of ASTM as well
as Commercial Fluid Power specifications. Our in
house capabilities include sawing, straightening,
gun-drilling, trepanning, boring, honing, skive
and roller burnishing, turning, grinding, welding
and fabricating Our Quality systems and
certifications are available for Customer review.
Our quality program includes ISO 9002 Quality
System as well as NIST Gage Traceability.
Honed/Skived
Chrome OD
Chrome ID
Bar
CPO
IHC
Stainless
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
3
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
NITRO-tuff TUBESTM are stronger, tougher and last longer.
Choose NITRO-tuff TUBESTM for Your CPID and CPOD Applications.
Excellent Corrosion Protection from 100 to 250 Hours.(1)
Offers Some Dent Resistance with a Seal Friendly Hardened Wear Surface of 64 to 71 HRC
Machine with Standard Carbide Inserts. Shallow case area from 50-40 HRC _at_ 0.020" deep.
Suitable for Inertia or Friction Welding. Can be Painted.
NITRO-tuff TUBESTM will never flake or peel.
Environmentally Safe and Sound
NITRO-tuffTubesTM are exclusively available through Commercial Fluid Power in the United States. Call for Current Pricing and Material Availability. Visit our Web Site at http//www.CommercialFluidPower.com for more information.
Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44720 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105


(1) Tested per ASTM B117 Latest Revision NSS Neutral Salt Spray Test
Rating of 10 per ASTM B537 Latest Revision No Corrosion to the unaided eye.
4
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Material Selection
  • Produced to ASTM A513 Type 5 Latest Revision
  • Produced to CFP-1000
  • Yield/Tensile Ratio
  • Maximum Yield

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44720 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105

5
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Testing Material Before Processing
  • Confirm Size Change from Nitriding
  • Test for Mechanical Properties
  • Yield/Tensile
  • Elongation/ROA

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44720 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105

6
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Testing Results
  • Adjust Honing to Meet Growth
  • Confirm Mechanical Properties
  • Yield/Tensile
  • Elongation/ROA

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44702 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105

7
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Honing Inspection
  • Coefficient of Thermal Expansion
  • Surface Finish
  • Profilometer
  • Borescope/Camera Inspection

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44702 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105

8
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Nitro-tuff Treatment
  • Test for Corrosion Resistance
  • ASTM B117 Rating 10 ASTM B537
  • Microscope to verify Nitrided Layer
  • Thickness

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44720 (330) 433-2700 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105

9
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Final Inspection
  • Size Control
  • Dial Bore Gage/Air Gages
  • Surface Finish
  • Visual-Profilometer-Borescope Camera

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44720 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105


10
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
PROCESSING NITRO-tuff TUBESTM
  • Distribution
  • Heat Number and Batch Identity
  • Packaging (CFP-1000)
  • Shipments

Commercial Fluid Power Dover 2997 Progress Street Dover OH 44622 (800) 346-2601 (330) 343-6391
Commercial Fluid Power Canton 320 Witwer St NE Canton OH 44720 (330) 433-2270 (330) 433-2273
Commercial Fluid Power Atlanta 1433 Technology Pkwy Rome GA 30165 (800) 766-6066 ((706) 232-2564
Commercial Fluid Power Pittsburgh 144 McKinney St Titusville PA 16354 (800) 458-3847 (814) 827-6678
Commercial Fluid Power Chicago 1500 Genesis Drive LaPorte IN 46350 (800) 358-8466 (219) 324-5105

11
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff products are the growing choice for
economical corrosion resistant bars and tubes for
fluid power applications. This process is an
effective alternative to CPID and CPOD
tubing. Nitro-tuff tubes simply outperform and
outlast hard chrome plated products. With
superior corrosion resistance, better lubrication
retention, and improved wear resistance.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
12
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Tubes are exclusively available
through Commercial Fluid Power in the United
States. Nitro-tuff Tubes can replace your current
CPID and CPOD material requirements.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
13
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Cost Bar Hours Tested Dent ECO Friendly Color
Stainless Steel Chrome Plated 1000 No Poor No Chrome
Nitro-tuff Nano S- Stainless Steel 1000 Yes Poor Yes Chrome
Nickel Plus Chrome 0.0015/0.001" 1000 Yes Poor No Chrome
Nickel Plus Chrome 0.0005/0.0005" 150 No Poor No Chrome
Induction Hardened 0.001" Per Side 48 No Excellent No Chrome
  Induction Hardened 0.0005" Per Side 24 No Excellent No Chrome
  Nitro-tuff Polished 150 Yes Limited Yes Silver
  Nitro-tuff Standard Black 150 Yes Limited Yes Black
  Chrome Plated 0.001" per side 48 No Poor No Chrome
Chrome Plated 0.0005" per side 24 No Poor No Chrome
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
14
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff is an atmospheric furnace treatment
developed and patented in the early 1980's. It
combines a balance of the high surface hardness
and excellent corrosion resistance. Nitro-tuff
tubes and bars are approved and specified on
agricultural equipment, sprayers, snowplow
cylinders, truck lift gates, tractors, refuse
vehicles, military equipment, and many more
applications where surface protection is critical.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio Nortth Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
15
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff The furnace sequence entails
nitrocarburizing the steel lengths at elevated
temperatures in an ammonia atmosphere with
exothermic gases followed by an oxidizing step.
This process generates a thin (0.001") uniform
and extremely hard (64 to 71 Rc) iron nitride
layer infused with a film of iron oxide.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
16
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Beneath the iron nitride layer is a
nitrogen-enriched hardened diffusion zone. The
diffusion zone functions as a light hardened case
with a hardness gradient ranging from the mid
50s Rc just below the iron nitride layer to
approximately 40 Rc at 0.015" depth. This
combination of a hard 64-71 HRC outer shell and a
40-50 HRC diffusion layer offers some dent
resistance.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
17
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Surface Hardness 64 Rc min. to 71 Rc max. 0.001
40-50 Rc diffusion zone 0.015 Surface Finish 16
Ra max. Corrosion Resistance Nitro-tuff 150
Plus hours Tested Per NSST ASTM B117 Rating 10
per per ASTM B537
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North CantoOhio Rome Georgia
Titusville Pennsylvania La Porte Indiana
18
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Machining is similar to machining a
CPO rod. These rods should be given the same
attention to chucking and holding the work piece
as with any other precision and polished machined
component. Ceramics inserts are not needed.
Carbide is recommended for at least the diffusion
and top coat in total _at_ 0.016 in depth. After
this depth HSS can be used.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
19
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Machining Nitro-tuff Bars and
Nitro-tuff Tubes are case-hardened material.
Like any hardened steel, 90? corners and sharp
leading edges should be rounded. Oblique angles
(rounded corners) should be applied to the edges
of cross-drilled holes. Remove the hardened
surface layer prior to cross drilling.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
20
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Welding Nitro-tuff products in the
same fashion as chrome plated steel. As with
chrome plate, the laying of a weld bead directly
on the wear surface should be avoided as it can
create weld porosity. The nitrogen-enriched
surface should be removed at the weld site
(machine, chamfer or grind) so as to create a
groove for the weld.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
21
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Welding Nitro-tuff products treated
products are ideally suited for friction/inertia
welding. Like chrome, a heat affected zone 1/8
to 1/4 immediately adjacent to the weld site can
reduce both hardness and corrosion resistance.
This area is not considered a wear site and is
usually painted along with the clevis or rod
end..
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio Bedford Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana Los
Angeles California
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
22
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff Nitro-tuff should not be used in
environments over 500 Degrees Fahrenheit. Nitro-tu
ff are not resistant to sulfuric or hydrochloric
acids (commonly used to etch steel). Nitro-tuff
products are not suitable for field repairs.
(Patch Plating)
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
23
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Nitro-tuff As with any surface hardened tube or
bar Nitro-tuff products are not suitable for
bending. A Nitro-tuff bar or an IHC bar will
break in half when subjected to an extreme side
load. IHC and Nitro-tuff bars have similar
bending attributes.
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
24
Honed Tubing, Chrome Bar
OD and ID Processing Services
Nitro-tuff Tubes
Get the Commercial Fluid Power Advantage. Steel
Velocity The Service You Demand!
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
25
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
26
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
27
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
28
Dover Ohio North Canton Ohio Rome Georgia
Titusville Pennsylvania La Porte Indiana
29
Commercial Fluid Power Your Partner Today,
Tomorrow and The Future!
About PowerShow.com
