Title: Connection Setup


1
STREAM CONTROL TRANSMISSION PROTOCOL (SCTP)
2
SCTP service model
  • connection oriented
  • reliable data transfer
  • - no loss
  • - no duplicates
  • - data integrity
  • ordered / unordered delivery
  • TCP provides only ordered service.
  • If the application desires unordered service,
  • it has the option of using UDP
    unreliable
  • SCTP separates data reliability from
    ordered delivery
  • SCTP can provide unordered service with
    reliability
  • SCTP can provide ordered service with
    reliability

3
  • SCTP preserves message boundaries
  • TCP is byte-oriented. Applications must
    add their own
  • record marking to delineate messages.
  • concept of chunks
  • security against SYN flooding attack
  • multi-homing
  • multi-streaming
  • message fragmentation and bundling
  • congestion control

4
Comparison between SCTP, TCP and UDP
5
SCTP PDU format
1 common header chunks (control or data)
6
Motivation
  • Many applications need reliable message delivery
    they do so by delineating a TCP stream
  • TCP provides both strict-ordering and reliability
    many applications may not need both

7
Motivation (contd)
  • HTTP is one such application
  • While transferring multiple embedded files we
    only want
  • Reliable file transfer for each file
  • Partial ordering for the packets of each file but
    not total ordering amongst all the packets
  • TCP provides more than this (but overhead?)
  • SCTP may help (how? later)

8
HTTP Server Architecture
Multiple File Transfer (Embedded files) - TCP
Child process
9
HTTP Server Architecture
Multiple Files Transfer (Embedded Files) - SCTP
Child process
10
Reason
Server
Client
3
2
1
3
2
3
2
1
3
2
1
1
File 2
File 3
TCP Receive buffer in kernel
TCP Send buffer in kernel
11
Reason
Server
Client
3
3
2
2
3
2
1
3
2
1
1
1
File 2
File 3
SCTP Receive buffer in kernel
SCTP Receive buffer in kernel
12
Multi-homing
13
multi-homing
single-homed SCTP endpoint
multi-homed SCTP endpoint
Host B
Host A
application
IP1160.15.82.20 IP2161.10.8.221 IP310.1.61.11
application
200
100
SCTP
SCTP
B2
B3
B1
A1
IP128.33.6.12
endpoint128.33.6.12 100
endpoint160.15.82.20, 161.10.8.221, 10.1.61.11
200
SCTP association
Host A
Host B
application
application
IP1160.15.82.20 IP2161.10.8.221 IP310.1.61.11
100
200
SCTP
SCTP
A1
B2
B3
B1
IP128.33.6.12
association 128.33.6.12 100
160.15.82.20, 161.10.8.221, 10.1.61.11 200
14
X
  • What happens if a primary fails?
  • TCP connection is broken
  • whereas SCTP association can continue to
    transmit to an alternate destination
  • address

15
failure detection
  • Host A monitors reachability of the primary
    destination address of Host B

Host A
Host B
application
application
primary
100
alternates
200
SCTP
SCTP
A1
B2
B3
B1
SACK
DATA
  • error_count is a variable associated
  • with each destination address of a
  • host. It is set to zero initially.
  • Host A starts the retransmission timer
  • If timer expires
  • increment error_count
  • If error_count threshold
  • state inactive
  • If Host A receives SACK before timer expires
  • error_count 0 state active

16
  • Host A monitors reachability of alternate
    destination addresses of Host B

Host A
Host B
application
application
100
primary
200
alternates
SCTP
SCTP
A1
B2
B3
B1
HEARTBEAT
HEARTBEAT-ACK
  • HEARTBEAT is sent periodically to each
    alternate address
  • When a HEARTBEAT is sent
  • increment error_count
  • If error_count threshold
  • state inactive
  • If Host A receives a HEARTBEAT-ACK
  • error_count 0 state active
  • When the primary destination address is
    detected unreachable
  • SCTP sender chooses 1 of the REACHABLE,
    alternate destination addresses
  • as primary

17
association setup
How many way handshake ?
V verification tag I initiation tag
Host A
Host B
closed
  • mandatory -
  • type
  • chunk flags
  • chunk length
  • initiation tag
  • a_rwnd
  • outbound streams
  • maximum inbound streams
  • initial TSN
  • optional -
  • addresses(IPv4,IPv6, hostname)
  • supported address types
  • ECN capable
  • cookie preservative

INIT (V0) (ITagA)
cookie wait
closed
18
SCTP INIT PDU
19
association setup
V verification tag I initiation tag
Host A
Host B
closed
INIT (V0) (ITagA)
cookie wait
closed
INIT-ACK (VTagA) (ITagB)
  • mandatory
  • All fields present in mandatory INIT
  • state cookie
  • optional -
  • addresses(IPv4,IPv6, hostname)
  • ECN Capable
  • error reporting for unrecognized
  • parameters

20
association setup
V verification tag I initiation tag
Host B
Host A
closed
INIT (V0) (ITagA)
  • type
  • chunk flags
  • chunk length
  • state cookie
  • DATA chunk can be sent along with COOKIE-ECHO

cookie wait
INIT-ACK (VTagA) (ITagB)
closed
COOKIE-ECHO (VTagB)
cookie echoed
21
why COOKIE ???
attackers
Flooded!!
victim
130.2.4.15
128.3.4.5
SYN
SYN
buffer holding half-open (pending) connections
SYN
228.3.14.5
192.10.2.8
SYN
SYN
SYN
190.13.4.1
SYN
SYN
221.3.5.10
TCP SYN flooding attack
  • There is no ACK in response to the SYN-ACK,
    hence connection
  • remains half-open
  • Other genuine clients cannot open connections
    to the victim
  • The victim is unable to provide service

22
how does COOKIE help ?
Host B receives INIT
  • Receiver of INIT does not make the
  • Transmission Control Block (TCB) i.e no
  • pending connection information kept
  • Remains in CLOSED state
  • In case of attack, COOKIE-ECHO wont
  • arrive but receiver is unaffected

Send INIT_ACK with COOKIE
Prepare COOKIE
23
how does COOKIE help ?
Host B receives INIT
Send INIT_ACK with COOKIE
Prepare COOKIE
Host B receives COOKIE-ECHO
invalid
Extract Validate COOKIE
Discard SCTP PDU
valid
yes
Sender can request longer cookie life next time
through the Cookie - preservative parameter in
the INIT chunk
Send ERROR chunk
COOKIE expired ?
no
Unpack COOKIE and build association TCB
Discard SCTP PDU
24
association setup
V verification tag I initiation tag
Host A
Host B
closed
  • type
  • chunk flags
  • chunk length
  • DATA chunk can be sent along with COOKIE-ACK

INIT (V0) (ITagA)
cookie wait
INIT-ACK (VTagA) (ITagB)
closed
COOKIE-ECHO (VTagB)
cookie echoed
COOKIE-ACK (VTagA)
4 way handshake !
established
established
25
association shutdown
Host A
Host B
upper layer invokes SHUTDOWN
established
established
DATA
DATA
shutdown_pending
SACK
SHUTDOWN
shutdown_sent
26
stop accepting data
SHUTDOWN
DATA
shutdown_sent
shutdown_received
SHUTDOWN SACK
SHUTDOWN_ACK
shutdown_ack_sent
SHUTDOWN_COMPLETE
delete TCB
closed
delete TCB
closed
27
when should a SACK be sent ?
Host B
Host A
DATA (TSN 1)
Endpoint sends DATA to its peer, always bundle a
SACK chunk to ack any new DATA chunks
SACK 1 DATA
DATA (TSN 2)
If no DATA to be sent to the peer, then SACK is
DELAYED Delay 200 to 500 ms
200 ms
SACK 2
DATA (TSN 2)
Duplicate data chunks immediately send SACK
without any delay
SACK 2
28
when should a SACK be sent ?
Host A
Host B
DATA (TSN 3)
Must send a SACK for every other SCTP PDU
received without any delay
DATA (TSN 4)
200 ms
SACK 4
DATA (TSN 5)
One or more TSNs missing immediately send SACK
with Gap Ack blocks without any delay
X
DATA (TSN 6)
SACK 4
29
summary
  • SCTP PDU 1 common header 1 or more chunks
    ( control or data)
  • Association setup 4 way handshake (INIT,
    INIT-ACK, COOKIE-ECHO,
  • COOKIE_ACK)
  • COOKIE mechanism to prevent SYN flooding
    attack
  • Graceful shutdown(SHUTDOWN, SHUTDOWN-ACK,
  • SHUTDOWN-COMPLETE) no half-close as in TCP
  • Separates reliability from ordered delivery
  • Preserves message boundaries
  • SACK chunks to ack cumulative TSN gap ack
    blocks duplicate TSNs
  • Achieves link / path redundancy by supporting
    multi-homed hosts along with
  • reachability check

30
References
  • Randall R. Stewart, Qiaobing Xie.
  • Stream Control Transmission Protocol (SCTP) A
    Reference Guide
  • Stewart et. al. Stream Contol Transmission
    Protocol RFC-2960, October 2000.
  • URL http//www.ietf.org/rfc/rfc2960.txt
  • SCTP for Beginners
  • URLhttp//tdrwww.exp-math.uni
    essen.de/inhalt/forschung/sctp_fb/index.html
  • SCTP overview
  • http//www.sctp.org/sctpoverview.html
  • SCTP tutorial
  • http//www.iec.org/online/tutorials/sctp/
  • SCTP applicability statement
  • http//www.ietf.org/rfc/rfc3257.txt

31
References
Slides collected from various sources including
Keyur Shah, Sourabh Ladha, P. Amer, P. Conrad,
Sam Baskinger
