NSGIC MidYear Meeting Geography Update U. S. Census Bureau

1
NSGIC Mid-Year Meeting Geography UpdateU. S.
Census Bureau

• Robert A. LaMacchia
• Chief, Geography Division
• U. S. Census Bureau
• March 15, 2005

2
Topics

• MTAIP
• Current Status
• Maintenance
• Road to 2010 Census

3
MTAIP Vision

• A Seamless Digital Map of the United States Where
  Street Centerlines Are Based on
  State/County/Local/Tribal GIS Files and the
  Digital Features Are Publicly Available Via
  Standard OGC Protocols

4
TIGER

• 1988 The First Nationwide Digital Street
  Centerline File
• 2008 Improved Nationwide Digital Street
  Centerline File Consistent with GPS
• Support the 2010 Census Operations Beginning in
  GFY2009

5
Thank You For Making The Vision Come to Fruition

• For the GIS Files you have provided
• For the Metadata you have provided
• For Helping With TED
• For Reviewing Future Work Schedule

6
MTAIP Source Acquisition Strategy

• Government GIS Files
• Must pass 7.6 meter CE95 spatial accuracy
• No restrictions on derivative products
• We recognize that it takes labor for States to
  provide the data to Census
• We will make available an external hard drive to
  make the transfer of data easier (no need to cut
  CDs or DVDs)

7
MTAIP Source Acquisition Strategy

• Harris Corporation responsible for all remaining
  source acquisition
• Existing Imagery (especially NAIP)
• Subcontracts for centerline extraction
• Existing Commercial GIS Files
• Last Resort
• Subcontract for Street Centerline collection
• New Imagery Collection where total cost less than
  Street Centerline collection

8
Governmental Sources(Entire Counties)

• Over 2000 counties acquired
• Evaluated over 1500 counties
• Two/Thirds Of The Files Evaluated Are 7.6 meters
  CE95 Or Better In Spatial Accuracy

9
What About The Failed Files

• They have attributes that can improve TIGER
• Planned
• Develop new software
• To utilize the attributes
• Case-by-case basis after evaluation

10
An Option For Failed Files

• Improve these files so they meet the spatial
  accuracy requirement
• Source Provider May Rework
• Harris Corporation May Improve Spatial Accuracy
• Must be less expensive than other options, such
  as a commercial GIS file or extraction from
  imagery
• Census must be able to obtain permission from the
  source provider

11
Status Maps

• Are Available On The Web
• http//ftp2.census.gov/geo/maps/mtaip_status
• When The Web Page Is Completed
• http//www.census.gov/geo/mtaip_status/mtaip_sm.ht
  ml

12
Objective 1 MTAIP Production Schedule
800
700
600
IN PROGRESS
500
DONE
400
300

D O N E
200
100
0
GFY 2003
GFY 2004
GFY 2005
GFY 2006
GFY 2007
GFY 2008
250
600
610
700
690
383
Initial Realignment
Based Presidents FY06 Budget Submission and
Full Future Funding Available
13
MTAIP Production Schedule

• Counties are scheduled in early summer each year
  for the next fiscal year
• Schedule for the remaining counties is revised
  each summer
• Need to have all government provided files in
  house by April, 2006
• Fiscal Year 2005 county workload is specified in
  contract

14
FY05 Plans

• List of Counties for Improvement
• 251 Tribal/State/County GIS
• 14 Partial Counties
• 345 Harris Acquired Sources
• Commercial GIS
• Existing imagery centerline extraction
• Field Collect

15
FY06-FY08 Planning

• Estimating where we will have existing GIS files
• We will modify our current proposal based on your
  comments
• Last files need to be ready to go to Harris
  during FY07
• Need to have all counties back from Harris by
  April, 2008
• Necessary to allow for Census processing and
  preparations for Address Canvassing Operations

16
MTAIP Feedback to source providers

• Report on spatial evaluation of the provided
  source
• 2004 TIGER/Line files First Edition
• Includes feature level metadata on coordinates
• State/local/tribal source providers will be
  provided with a Local Edition TIGER/Line File
• Will include additional record types (beyond
  those in the 2004 TIGER/Line File) that will
  contain local feature name and/or address range
  information as provided to the Census Bureau
  (except for single address address ranges)

17
Maintenance

• Where possible, we would like to obtain a later
  version of the State/County/Local/Tribal files to
  further update TIGER
• This processing would be done by the Census
  Bureau
• As part of 2010 Census, there will be a complete
  address canvass that will
• Capture Master Address File structure points
• This is Confidential (Title 13) Information
• Capture new street features using a GPS-equipped
  device
• Will be available in future releases of TIGER

18
Maintenance Post 2010

• Census will continue to update TIGER based on
  newer versions of Government GIS files
• Census Bureau Field Operations
• Staff will use GPS equipped devices to continue
  to locate new housing units/MAF structure points
• We continue to want your thoughts on how we might
  work with you to update areas where there are no
  files
• How to target
• Use of available imagery
• Can the private sector help?

19
TIGER Availability

• Traditional Web-based Downloads
• Via OGC Standard Protocols
• Web Feature Server
• Web Map Server

20
Road to 2010 Census

• LUCA
• Local Update of Census Addresses
• Statistical Areas Program
• Census 2000 Participants will be invited to
  participate in the 2010 program
• Anticipate a fully electronic program
• Where we have realigned TIGER to the local GIS
  file, participant only needs to submit the
  proposed Statistical Area Plan as boundary files
• Looking at a method for our Regional Offices to
  Review the plans via a web-based application

21
Road to 2010 Census

• Boundary and Annexation Survey extended to all
  incorporated places beginning in 2008 to support
  the 2010 Census
• Boundary Validation Program
• Summer of 2010
• Boundaries to be used for data tabulation

22
Questions?
Robert LaMacchia Geography Division 301-763-2131 r
obert.a.lamacchia_at_census.gov
