Dynamic Reconfiguration with Binary Translation: Breaking the ILP Barrier with Software Compatibilit

1
Dynamic Reconfiguration with Binary Translation
Breaking the ILP Barrier with Software
Compatibility

• Antonio Carlos S. Beck Filho caco_at_inf.ufrgs.br
• Luigi Carro
• carro_at_inf.ufrgs.br
• Informatics Institute - LSE
• Federal University of Rio Grande do Sul
• Brazil

2
Motivation

• Complex

3
Motivation

• How to increase performance with low energy
  consumption?
• Using a reconfigurable array!

4
Motivation

• How to increase performance with low energy
  consumption?
• Using a reconfigurable array!

Binary Translation (BT)
5
Motivation

• How to increase performance with low energy
  consumption?
• Using a reconfigurable array!

• Special tools and/or compilers are needed

• No software compatibility!
• What happens to the design cycle?

6
Outline

• Introduction
• The Java processors
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

7
Outline

• Introduction
• The Java processors
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

8
Introduction
1

• Advantages of using a reconfigurable array
• Speeds up sequences of instructions that are not
  necessarily data independent

9
Introduction
1

• Parallel Architecture

Time (clock cycles)
Data dependent instructions same color
10
Introduction
1

• Dynamic Analysis (BT)
• Allows to find sequences of instructions to be
  executed in the array at run-time

11
Introduction
1

• Dynamic analysis in recent works
• Fine-Grain arrays and FPGAs
• Increases the complexity of detection
• Increases the cache responsible for keeping the
  configurations
• Just in critical parts of the software
• In this work
• Coarse-Grain Array
• Detection of the instructions becomes simpler
• Small amount of memory required
• Optimizes any sequence in the software
• Technology independent

12
Introduction
1

• Java processor as case study
• Object Oriented
• Modeling
• Programming
• Validation
• Multiplatform
• Widely spread
• Moreover, makes the detection algorithm and the
  routing simpler

13
Introduction
1

• Java Processor

Coarse-Grain Reconfigurable Array
Dynamic Detection (Binary Translation)
Performance
Energy Consumption
14
Outline

• Introduction
• The Java processors
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

15
Femtojava Pipelined
2

• Five Stages

Instruction Fetch
Operand Fetch
Decoding
Write Back
Execution
16
Femtojava VLIW
2

• The VLIW version basically is an extension of the
  pipelined one
• 2, 4 or 8 instructions/packet
• VLIW packet has a variable size
• Functional Units replicated

17
Outline

• Introduction
• The Java processors
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

18
The Reconfigurable Array
3

• The coarse-grain array is tightly coupled
• Decreases the overhead in the communication
• No external access to the array

19
The Reconfigurable Array
3

• The coarse-grain array is tightly coupled
• Decreases the overhead in the communication
• No external access to the array
• It is formed by one or more basic cells

20
The Reconfigurable Array
3

• The coarse-grain array is tightly coupled
• Decreases the overhead in the communication
• No external access to the array
• It is formed by one or more basic cells
• With one multiplier

21
The Reconfigurable Array
3

• The coarse-grain array is tightly coupled
• Decreases the overhead in the communication
• No external access to the array
• It is formed by one or more basic cells
• With one multiplier
• A sequence of seven sets of basic functional units

22
How it works?
3
Instruction flow
5A 32 B7
4C 63
Instruction Fetch
Operand Fetch
Decoding
Write Back
Execution
23
How it works?
3
Sequence found!
Instruction Fetch
Operand Fetch
Decoding
Write Back
Execution
24
How it works?
3
Instruction Fetch
Operand Fetch
Decoding
Write Back
Execution
25
How it works?
3
Instruction Fetch
Operand Fetch
Decoding
Write Back
Execution
26
How it works?
3
Instruction Fetch
Operand Fetch
Decoding
Write Back
Execution
27
Outline

• Introduction
• The Java processors
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

28
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
Stack
29
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
10
30
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
5
10
31
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
50
32
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
50
33
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
3
50
34
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
4
3
50
35
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
48
50
36
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
48
50
37
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
98
38
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
98
39
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
40
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
41
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore

• These instructions depend on each other!

42
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
6
43
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
7
6
44
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
42
45
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
42
46
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
47
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
48
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
49
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
50
How BT Works
4
Sequence of instructions
Bipush 10 Bipush 5 Imul Bipush 3 Bipush
4 Ishl Iadd Istore Bipush 6 Bipush 7 Imul Istore
Operand Block 1 First Sequence
Operand Block 2 Second Sequence
51
Outline

• Introduction
• The Java processor
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

52
Results - Benchmarks
5

• A set of algorithms were executed in the
  architectures
• Sin Calculation
• Sort Bubble
• Sort Select
• Sort Quick (10 and 100 elements)
• Search Binary
• Search Sequential
• IMDCT (plus three unrolled versions)
• Floating Point Sums emulation
• Full MP3 Player

53
Results - Performance
5
54
Results - Performance
5
55
Results - Performance
5
56
Results - Performance
5
57
Results - Performance
5
58
Results - Performance
5
59
Results - Performance
5
60
Results - Performance
5
61
Results - Performance
5
62
Results - Performance
5
63
Results - Performance
5
64
Results - Performance
5
Bubble 10 3.4x faster Bubble 100 5.5x faster
65
Energy consumption - ROM
5
66
Energy consumption - RAM
5
67
Energy Consumption - Core
5
68
Energy Consumption - Total
5
69
Results - Area
5
Pipelined
VLIW 2
FEMTOJAVA REC. ARRAY 4 cells 5 dif.
reconfigurations
VLIW 4
VLIW 8
70
Results - Area
5
Low Power
Reconfiguration Cache
VLIW 2
Femtojava Pipelined
BT Logic
Data Cache
VLIW 4
VLIW 8
Reconfigurable Array
71
Outline

• Introduction
• The Java processor
• The reconfigurable array
• How the BT algorithm works
• Results
• Conclusions and Future Work

72
Conclusions
6

• With BT, a reconfigurable array and Java we
  achieve at the same time
• Software portability
• Performance
• Low Energy Consumption

73
Future Work
6

• Use dynamic analysis with CMP
• At run-time detects which is the best core to
  execute the software at certain time
• Implement the BT and reconfigurable array in
  traditional RISC machines
• What are the differences of implementation?
• Tradeoffs analysis

74
