Using Alcoa to Specify a UNIX File System

1
Using Alcoa to Specify a UNIX File System

• Specification of some structures and operations
  in a File System

2
Alcoa

• Predicate logic to specify a system of objects.
  (quantifiers, subsets, relations)
• Can only describe a two state relationship.
  Missing a sequential composition operator.

current
next
OK
NO
time0
time1
time2
3
Alcoa
4
Alcoa Tool

• Finds an instance which satisfies the
  specification.
• Finds contradictions.
• See an example of the specification.
• Preservation of some logical statement through an
  operation.

5
current
next
operation
Does invariant hold here?
Invariant holds here.
a b c is true
Is a b c true?
Alcoa will check this and give counterexamples if
not true.
6
File System Basics
Directory Entry
Inode
Directory Entry
Inode
Directory Entry
7
File System Basics
Directory Entry
Inode
2
Directory Entry
Inode
Directory Entry
1
8
File System Basics
Datablocks
Directory Entry
Inode
2
Directory Entry
Inode
Directory Entry
1
9
Atomic Actions Ordering

• Imagine the system crashing while making changes
  to the file system.
• How should the atomic actions be ordered such
  that the file system can be recovered?

10
Atomic Actions Ordering
Directory Entry
a
Inode
rename a b
11
Atomic Actions Ordering
Directory Entry
a
Inode
rename a b
Lost inode if system crashes here.
12
Atomic Actions Ordering
Directory Entry
a
Inode
rename a b
13
Atomic Actions Ordering
Directory Entry
a
Inode
b
rename a b
14
Atomic Actions Ordering
Directory Entry
a
Inode
b
rename a b
15
Atomic Actions Ordering

• From Metadata Update Performance in File
  Systems by G. Ganger, Y. Patt
• Operations
• Link removal
• Link addition
• Block allocation
• Block de-allocation

16
Link Addition

• 1. Link count in inode incremented.
• 2. Pointer to inode added to the list of
  directory entries.

Link Count
DirEntry
Inode
1
17
Link Addition

• 1. Link count in inode incremented.
• 2. Pointer to inode added to the list of
  directory entries.

Link Count
DirEntry
Inode
2
18
Link Addition

• 1. Link count in inode incremented.
• 2. Pointer to inode added to the list of
  directory entries.

Link Count
DirEntry
Inode
2
DirEntry
19
Link Deletion

• 1. Directory Entry is removed first.
• 2. Link Count is decremented.

Link Count
DirEntry
Inode
2
DirEntry
20
Link Deletion

• 1. Directory Entry is removed first.
• 2. Link Count is decremented.

Link Count
DirEntry
Inode
2
21
Link Deletion

• 1. Directory Entry is removed first.
• 2. Link Count is decremented.

Link Count
DirEntry
Inode
1
22
The Problem

• Finding preserved invariant was not easy.
• No lost inodes. All allocated inodes are
  pointed to by a directory entry. is not an
  invariant.
• Reverse engineering the invariant.
• Tool helped determine which invariants are wrong.

23
Discovered Invariants

• If an inodes link count is zero, there are no
  directory entries pointing to the inode.
• At all times, an inodes link count is higher
  than the number of directory entries pointing to
  an inode.

24
Discovered Invariants

• If an inodes link count is zero, there are no
  directory entries pointing to the inode.
• Important when recovering after a crash so that
  an inode is not accidently deallocated.

25
Using the Invariants

• Weakened the precondition of the operations to
  see if the invariants are preserved.
• Some interesting configurations
• Link count much higher than the actual number of
  directory entries.

26
Other Issues

• Relations in Alcoa can be
• A function, surjective, partial/total, injective
• Abstraction design decision
• Choosing relation type forces specification
  writer to be careful and specific.

27
Other Issues

• Alcoa does not have numbers.
• Link Count was tricky to model.
• Inverse relations.
• Alcoa allows this and inadvertently used.
• Many invariants do not hold because of the
  intermediate stages.
• Tricky specifying an invariant.

28
Other Issues

• Must clearly specify the precondition and
  postcondition of an operation.
• Hoare Triple
• Instance finding useful for careless errors such
  as typos.
• b in UsedB
• b not in UsedB
