Models and Issuesin Data Stream Systems

• EVREN AYORAK
• 2001700537

2
Abstract

• The need for and research issues arising from a
  new model of data processing.
• Review past work relevant to data stream systems
  and current projects in that area.
• Explore topics in stream query languages, new
  requirements and challenges in query processing,
  and algorithmic issues.

3
Outline

• The Data Stream Model
• Review of Data Stream Projects
• Queries of Data Streams
• Stanfords Proposal for DSMS
• Algorithmic Issues

4
The Data Stream Model

• Data streams differ from conventional stored
  relation model
• Data elements in the stream arrive online
• System has no control over order in which data
  elements to be processed
• Data streams are potentially unbounded in size
• Once an element from a data stream has been
  processed, it is discarded or archived. It cannot
  be retrieved easily unless it is stored in
  memory, which is small relative to the size of
  data streams
• Operating in data stream model does not preclude
  use of data in conventional stored relations.

5
Queries

• One-time queries and Continuous queries
• One-time queries
• Evaluated once over a point-in-time snapshot of
  data set
• Continuous queries
• Evaluated continuously as data streams continue
  to arrive
• May be stored and updated as new data arrives, or
  may produce data streams themselves

6
Queries

• Predefined and Ad hoc queries
• Predefined
• Supplied to data stream management system before
  any relevant data has arrived
• Usually continuous queries
• Scheduled one-time queries possible
• Ad hoc
• Can be either one-time or continuous queries
• Complicates design of data stream management
  system (DSMS), because they are not known in
  advance for purposes of query optimization and
  correctly answering it may require referencing
  data that may have already arrived on data
  streams and potentially have already been
  discarded

7
Motivating Examples

• Web-based financial search engine that evaluates
  queries over real-time streaming financial data
  such as stock tickers and news feeds.
• Modern security applications.
• Provides integrated security platform providing
  services such as firewall support and intrusion
  detection over multi-gigabit network packet
  streams.
• Needs to perform complex stream processing
  including URL-filtering based on table lookups
  and correlation across multiple network traffic
  flows.
• Large web site monitor web logs online to enable
  applications such as personalization, performance
  monitoring, and load-balancing. (e.g., Yahoo)
• Sensor monitoring
• Network traffic management

8
Review of Data Stream Projects

• Tapestry System
• Continuous queries used for content-based
  filtering over an append-only database of email
  and bulletin board messages
• Restricted subset of SQL used as query language
  in order to provide guarantees about efficient
  evaluation and append-only results

9
Review of Data Stream Projects

• Alert system
• Mechanism for implementing event-condition-action
  style triggers in conventional SQL database
• Used continuous queries defined over special
  append-only active tables
• XFilter content-based filtering system
• Efficient filtering of XML documents based on
  user profiles as continuous queries in XPath
  language

10
Review of Data Stream Projects

• Xyleme
• Similar to Xfilter (content-based filtering
  system)
• Enables high throughput with restricted query
  language
• Tribeca stream database manager
• Restricted querying capability over network
  packet streams
• Tangram stream query processing system
• Used stream processing techniques to analyze
  large quantities of stored data

11
Review of Data Stream Projects

• OpenCQ
• Support continuous queries for monitoring
  persistent data sets spread over wide-area
  network.
• Uses query processing algorithm based on
  incremental view maintenance.
• NiagraCQ
• Support continuous queries for monitoring
  persistent data sets spread over wide-area
  network.
• Addresses scalability in number of queries by
  proposing techniques for grouping continuous
  queries for efficient evaluation.
• Problem of supporting blocking operators in query
  plans over data streams discussed
• Viglas and Naughton proposed rate-based
  optimization for queries over data streams (based
  on stream-arrival and data-processing rates)

12
Review of Data Stream Projects

• Chronicle data model
• Append-only ordered sequences of tuples
  (chronicles), a form of data streams
• Defined restricted view definition language and
  algebra (chronicle algebra) that operates over
  chronicles together with traditional relations.
• Focus was to ensure that views defined in
  chronicle algebra could be maintained
  incrementally without storing any of the
  chronicles.
• Seshadri, Livny, and Ramakrishhnan proposed an
  algebra and a declarative query language for
  querying ordered relations
• Related work in this area includes work on
  temporal and time-series databases, where the
  ordering of tuples that can be implied by time
  can be used in querying, indexing, and query
  optimization.

13
Review of Data Stream Projects

• Materialized views relates to continuous queries
• Materialized views are really queries that need
  to be reevaluated or incrementally updated
  whenever the base data changes
• Important work in this area
• Self-maintenanceEnsuring that enough data has
  been saved to maintain a view even when the base
  data is unavailable
• Data expirationDetermining when certain base
  data can be discarded without compromising the
  ability to maintain a view
• Differences where continuous queries may
• Involve streams rather than store results
• Deal with append-only input data
• Provide approximate rather than exact answers
• Processing strategy may adapt as characteristics
  of data streams change

14
Review of Data Stream Projects

• Telegraph project
• Uses adaptive query engine to process queries
  efficiently in volatile and unpredictable
  environments.
• Query execution strategies over data streams
  generated by sensors
• Processing techniques for multiple continuous
  queries.
• Tukwila system
• Supports query processing, in order to perform
  dynamic data integration over autonomous data
  sources

15
Review of Data Stream Projects

• Aurora Project
• New data processing system targeted towards
  stream monitoring applications
• Consists of large network of triggers
• Each trigger is data-flow graph with each node
  being one among seven built-in operators
• For each stream monitoring application using
  system, an application administrator creates and
  adds one or more triggers into trigger network
• Performs compile-time optimization and run-time
  optimization of trigger network
• Detects resource overload and perform load
  shedding based on application-specific measures
  of QoS

16
Queries of Data Streams

• Unbounded Memory Requirements
• Approximate Query Answering
• Sliding Windows
• Batch Processing, Sampling, and Synopses
• Blocking Operators
• Queries Referencing Past Data

17
Unbounded Memory Requirements

• Since data streams are potentially unbounded in
  size, amount of storage required to compute exact
  answer to the query may grow without bound
• External memory algorithms for handling data sets
  larger than main memory cannot be used.
• Do not support continuous queries
• Too slow real-time response
• With new data constantly arriving even as old
  data is being processed, amount of computation
  time per data element must be low
• Interested in algorithms that are able to confine
  themselves to main memory without accessing disk

18
Approximate Query Answering

• Since we limited to bounded amount of memory, it
  may not be possible to produce exact answers
• High-quality approximate answers can be an
  acceptable solution
• Techniques for data reduction and synopsis
  construction
• Sketches
• Random sampling
• Histograms
• Wavelets

19
Sliding Windows

• Evaluate query over sliding window of recent data
  from streams
• Attractive Properties
• Well-defined and understood
• Deterministic so there is no danger that bad
  random choices will produce bad approximation
• Emphasizes recent data, which in many real-world
  applications is more important than old data

Window
Future Data
Past Data
Recent Data
20
Sliding Windows

• Research Issues
• How do we define timestamps over streams to
  facilitate use of windows?
• How do we implementation of sliding window
  queries?
• What is their impact on query optimization?
• If window is too big to fit in main memory, how
  can we give approximate answers using only
  available memory?

21
Sliding Windows

• Differences in sequence and temporal DB and
  stream computation model
• Temporal DB
• Concerned with full history of each data value
  over time
• Stream system concerned with processing new data
  elements on-the-fly
• Sequence DB
• Attempt to produce query plans that allow for
  stream access.
• A single scan of input data is sufficient to
  evaluate plan and amount of memory required for
  plan evaluation is constant, independent of data.

• Assumes that DB system has control over which
  sequence to process tuples from next (e.g.,
  merging multiple sequences, which cannot be
  assumed in stream system)

22
Batch Processing, Sampling, and Synopses

• Dont process data elements as it arrives
• Resort to sampling or batch processing technique
  to speed up query execution
• Framework
• Query answered using data structures that can be
  maintained incrementally
• Data structure supports two operations
• update(tuple) updates data structure as each new
  data element arrives
• computeAnswer() produces new or updated results
  to query
• Best case scenario is that both operations are
  fast relative to arrival rate of elements in data
  streams no special techniques needed

23
Batch Processing

• update(tuple) is fast but computeAnswer() is slow
• Data elements buffered as they arrive
• Answer to query is computed periodically as time
  permits
• Does not cause any uncertainty about accuracy of
  answer, sacrificing timeliness instead.
• Good when data streams are bursty

24
Sampling

• computeAnswer() fast, but update(tuple) slow
• Some tuples skipped altogether so query is
  evaluated over sample of data stream rather than
  over entire data stream.
• Give confidence bounds on degree of error
  introduced by sampling process
• For many situations and queries involving joins,
  it is not reliable

25
Synopsis Data Structures

• computeAnswer() fast, and update(tuple) fast
• Used for queries where no exact data structure
  with desired properties exists
• Approximate data structure that maintains small
  synopsis or sketch of data rather than exact
  representation, so computation per data element
  is low.

26
Blocking Operators

• Query operator that is unable to produce the
  first tuple of its output until it has seen its
  entire input. (e.g., sorting, aggregation
  operators like SUM)
• Since streams may be infinite, a blocking
  operator using a stream as one of its inputs will
  never see entire input and will never produce
  output
• Operators that are root of tree of query
  operators are more tractable than operators that
  are interior nodes in tree, producing results
  that feed to other operators.
• Aggregation operator at root produces a single
  value or small number of values and updates to
  answer can be streamed out as they are produced
• When answer is larger like in a sort, it is more
  practical to maintain a data structure with
  up-to-date answer rather than retransmitting an
  entire answer
• Results produced by blocking operators may
  continue to change over time, so operators
  consuming those results cannot make reliable
  decisions based on results at intermediate stage
  of query execution

27
Blocking Operators

• We can handle operators as interior nodes in
  query tree by replacing them with non-blocking
  analogs
• juggle operator is a non-blocking version of
  sort. It aims to locally reorder a data stream so
  that tuples that come earlier in desired sort
  order are produced before tuples that come later
  in sort order, although some tuples may be
  delivered out of order

28
Blocking Operators

• Tucker et al. suggested augmenting data streams
  with assertions about what can and cannot appear
  in remainder of data stream
• Assertions (punctuations) interleaved with data
  elements in stream
• Example with assertion for all future tuples,
  daynumber ? 10
• Aggregation operator that was grouping by
  daynumber could stream out its answers for all
  daynumbers lt 10
• Join operator could discard all its saved state
  relating to previously-seen tuples in joining
  stream with daynumber lt 10

daynumber ? 10
daynumber lt 10
Assertion daynumber ? 10
29
Queries Referencing Past Data

• Ad hoc queries that are issued after some data
  has already been discarded may be impossible to
  answer accurately
• One solution is to only allow ad hoc queries that
  reference future data. It may be acceptable in
  some applications
• Another solution is to maintain summaries of data
  streams (synopses or aggregates) that can
  approximate answers to future ad hoc queries
• Problem similar to problems in physical DB design
  such as selection of indexes and materialized
  views, but in traditional DB design, we can still
  get the right answer at higher cost if no index
  present. But in stream model, if no summary
  structure present, we cant get the answer

30
Stanfords Proposal for DSMS

• STREAM (Stanford Stream Data Manager)
• Query Language for a DSMS
• Timestamps in Streams
• Query Processing Architecture of a DSMS

31
Query Language for a DSMS

• Modified version of SQL
• Allowed the FROM clause to refer to streams as
  well as relations
• Allowing optional window specification to be
  provided after a stream that is supplied into a
  querys FROM clause
• Sliding window requires an ordering of data
  stream elements, using implicit timestamp
  attached to each data element
• Example Compute average call length, considering
  only ten most recent long-distance calls placed
  by each customer

SELECT AVG(S.minutes) FROM Calls SPARTITION BY
S.customer_id ROWS 10 PRECEEDING WHERE
S.typeLong Distance
32
Timestamps in Streams

• Timestamps are ambiguous for streams derived from
  multiple streams (e.g., join)
• Previous example uses implicit timestamps, in
  which system adds a special field to each
  incoming tuple
• Explicit timestamp is data attribute used as a
  timestamp.
• Used when each tuple corresponds to real-world
  event at particular time that is of importance to
  meaning of tuple
• Drawback is that tuples may not arrive in same
  order as timestamps tuples with later
  timestamps may come before tuples with earlier
  timestamps. Makes it difficult to perform sliding
  window computation
• But if input stream is almost-sorted, we can
  fix it with a little buffering.

33
Timestamps in Streams

• Methods of assigning timestamps output of binary
  operators
• Provide no guarantee about output order of tuples
  from a join operator.
• Assume that tuples that arrive earlier are likely
  to pass through join earlier.
• Each tuple that is produced by join op is assign
  implicit timestamp that is set to time that it
  was produced by join op
• Flexible in implementation
• But impossible to impose defined deterministic
  sliding window semantics on results of subqueries

34
Timestamps in Streams

• User specifies as part of query what timestamp is
  to be assigned to tuples resulting from join of
  multiple streams
• Order in which streams are listed in FROM clause
  of query represents a prioritization of streams
• Implementation can be difficult (e.g., if output
  is to be sorted by timestamp, join op needs to
  buffer output until it can be determine that
  future input tuples will not disrupt ordering of
  output tuples)

SELECT FROM S1ROWS 1000 PRECEEDING, S2ROWS
100 PRECEEDING WHERE S1.A S2.B
Output tuple will have same timestamp as S1
35
Timestamps in Streams

• Best-effort

36
Query Processing Architecture

• Query execution plans consist of operators
  connected by queues
• Operators scheduled for execution by central
  scheduler
• During execution operator reads data from its
  input queues, updates synopsis structure and
  writes results to output queues
• Period of execution of operator determined
  dynamically by scheduler and operator returns
  control back to scheduler once period expires

37
Query Processing Architecture

• To handle stream data characteristic
  fluctuations, operators are adaptive (primarily
  to memory)
• Trading accuracy for memory
• Operator maximizes accuracy of output based on
  size of available memory
• Handles dynamic changes in size of its available
  memory
• Example For a sliding window join, the larger
  the window, the better the approximation

38
Query Processing Architecture

• Issues in Memory Management
• How do different query ops produce approximate
  answers under limited memory?
• How approximate results behave when operators are
  composed in query results?
• How can the DSMS allocate memory to operators to
  maximize accuracy of answer?
• How can DSMS reallocate memory among operators
  under changing conditions?
• How does the query optimizer come up with a query
  plan when given a query with best memory
  allocation and minimizes approximation? Should
  plans be modified when conditions changed?
• Since synopses can be shared among query plans,
  how do we optimally consider a set of queries,
  which may be weighted by importance?

39
Query Processing Architecture

• Issues in Scheduling
• Scheduler needs to provide rate synchronization
  within operators and pipelined operators in query
  plans
• Time-varying arrival rates of data streams and
  time-varying output rates of operators complicate
  matters
• Need to take into account
• Memory allocation across operators
• Mgt of buffers for incoming streams
• Availability of synopses on disk (instead of
  memory)
• Performance requirements of individual queries

40
Algorithmic Issues

• Random Samples
• Sketching Techniques
• Histograms
• Sliding Windows
• Negative Results
• Miscellaneous algorithms

41
Random Samples

• Used as summary structure in many scenarios where
  small sample is expected to capture essential
  characteristics of data set
• Easiest form of summarization
• Other synopses can be built from sample itself

42
Sketching Techniques

• Building summary of data stream using small
  amount of memory
• Makes it possible to estimate answer to certain
  queries (like distance queries) over data set
• F0 is number of distinct values in S
• F1 is the length of S
• F2 is the self-join size
• F? is the most frequent items multiplicity

43
Histograms

• V-Optimal Histogram approximate distribution of a
  set of values by a piecewise-constant function so
  as to minimize the sum of squared error.
• Equi-Width Histograms partition the domain into
  buckets such that the number of values falling
  into each bucket is uniform across all buckets.
  They maintain quantiles for the underlying data
  distribution as the bucket boundaries.
• End-Biased Histograms maintain exact counts of
  items that occur with frequency above a
  threshold, and approximate other counts by an
  uniform distribution.

44
Wavelets

• Uses to provide a summary representation of data
• Wavelet coefficients are projections of the given
  signal onto an orthogonal set of basis vector
• Choice of basis vectors determines type of
  wavelets
• Haar wavelets are used in DB for ease of
  computation
• The signal reconstructed from top few wavelet
  coefficients best approximate the original signal

45
Sliding Windows

• Prevent stale data from influencing analysis and
  statistics
• Serve as tool for approximation in face of
  bounded memory
• Open problems
• Clustering
• Maintaining top wavelet coefficients
• Maintaining statistics like variance
• Computing correlated aggregates

46
Negative Results

• Emerging set of negative results on space-time
  requirements of algorithms that operate in stream
  model
• Henzinger, Raghavan, and Rajagopalan provided
  space lower bounds for concrete problems in
  stream model, derived from results in
  communication complexity
• Alon, Matia, Szeged provided almost tight lower
  bounds for computing the frequency moments.
• General lower bound techique for sampling-based
  algorithms presented by Bar-Yoseef et al.

47
Other Algorithms

• Data Mining Decision tree are another form of
  synopsis used for prediction
• Multiple Streams Computing simple functions in
  distributed environment
• Reduction of Streams In list-efficient
  algorithms, instead of being presented one data
  item at a time, they are implicitly presented
  with a list of data items in a succinct form
• Property Testing Programs that make one pass
  over data and using small space verify if the
  data satisfies a certain property
• Measuring Sortedness Useful in determining the
  choice of a sort algorithm for underlying data

48
Conclusion

• Adaption to some existing techniques to the
  proposed model can be performed
• Exact answers from a data stream query is
  probably not possible
• There are a lot of ongoing projects that deal
  with streams

49
References

• Babcock, Brian, S Babu, M Datar, R Motwani, J
  Widom
• Models and Issues in Data Stream Systems. In
  Proc. ACM SIGMOD/PODS 2002. June 3-5, 2002.
  Madison, Wisconsin.

50
End of Presentation
