JVTO026 Invocation of the Inverse MCTF Process

1
JVT-O026Invocation of theInverse MCTF Process

• Panasonic Singapore Laboratories
• MenHuang Lee

2
Introduction

• MCTF structure not fixed
• Switch dynamically between Haar filter and 5/3
  transform filter
• Multiple reference frames possible
• Inter-partition prediction/update steps removed
  for low delay mode operation
• In SVC WD 1.0, not clear when inverse MCTF is
  invoked
• In JSVM S/W, inverse MCTF invoked at start of
  next GOP

3
Problems

• Significant time delay to complete inverse MCTF
  of whole GOP
• Periodic complexity peaks to perform inverse MCTF
  of whole GOP
• Large memory requirement to buffer all pictures
  in a GOP until inverse MCTF process is invoked
• Low delay mode operation not possible

4
Proposed Solution

• Define inverse MCTF process such that inverse
  update/prediction steps are distributed across
  all pictures of a partition, as soon as the step
  can be performed
• When to invoke inverse MCTF?
• How to determine when an inverse
  update/prediction steps can be performed?
• What to do during inverse MCTF?

5
When to invoke inverse MCTF?

• After all slices of the current picture, pic, is
  decoded from the bitstream
• Bitstream-decoded picture ? decoded from video
  stream but before it undergoes the inverse MCTF
  process

6
How to determine when a step can be performed?

• Define, initialize, use update a set of
  variables for each picture, pic

7
How to determine when a step can be performed?
8
How to determine when a step can be performed?
(curL0, curL1) (1, 0)
(curL0, curL1) (1, 1)
9
How to determine when a step can be performed?
10
How to determine when a step can be performed?
(0, 1)
(1, 0)
(1, 0)
(1, 1)
11
What to do during inverse MCTF?
(1, 0)
(1, 1)
(1, 0)
(2, 0)
(1, 2)
(2, 1)
(1, 0)
(0, 1)
(1, 0)
(1, 1)
(0, 2)
(2, 0)
12
What to do during inverse MCTF?
13
Illustration
coding order
1
0
2
4
6
5
7
3
temporal level
0
display order
3
prediction
2
update
2
prediction
1
update
1
prediction
0
update
L
0
GOP border
GOP border
14
Proposed Modification to SVC WD

• S.8 Decoding process - added description of
  when to invoke inverse MCTF process
• S.8.8 Inverse motion-compensated filtering
  process - replaced
• S.8.8.3 Check for inverse prediction process -
  added
• S.8.8.4 Check for inverse update process - added

15
Conclusion

• Inverse update/prediction steps distributed
  across all pictures of a partition, as soon as
  the step can be performed
• Propose when to invoke inverse MCTF
• Propose how to determine when an inverse
  update/prediction steps can be performed, via a
  set of variables
• Propose what to do during inverse MCTF
• Reduce complexity, spreading periodic complexity
  peaks over time
• Reduce time delay, support low delay mode
  operation
• Reduce memory requirement
• No addition of syntax element
• No effect on coding efficiency
