Computer Architecture: Intro Lecture 8 The Control Path

1
Computer Architecture IntroLecture 8- The
Control Path

• J. Schmalzel
• S. Mandayam

2
Control Path

• Hard-wired control
• Sequencer
• Microprogramming (also may see Microsequencer)

3
Microprogrammed Control

• A control unit w/ binary control values stored in
  microprogram memory
• This memory is local to the CPU and is not main
  memorywhere program instructions are stored

4
ROM (RAM) Table Lookup

• Expensivebut highly reconfigurablemethod to
  perform combinatorial decoding/encoding functions
• Table lookup technique
• FPGA CLB

5
Return to the FA

• Full Adder

6
Full Adder Truth Table
Sum-of-Product Boolean expressions for S and
Co S CiAB CiAB CiAB CiAB Co
CiAB CiAB CiAB CiAB
7
FA Implementation using ROM
Inputs are ROM ADDRESSES Outputs are ROM CONTENTS
(DATA)
Am-1 A2 A1 A0
Dn-1 D2 D1 D0
. .
8
Example 16 x 4 ROM
9
Example 16 x 4 ROM
10
Things to Watch for

• Unused bits
• Dont cares

11
Structure for ?P Control
NAG
CAR
ROM
CDR
12
Questions, Comments, Discussion
