Module 2

1
Module 2

• Product Overview

2
Module Objectives

• Describe Extreme Switch Product Family
• Understand Extreme Architecture
• Describe Product Features and Functional Summary
• Discuss Extremes Compliance to IEEE Standards
• Define ExtremeWare Software Features
• Summary

3
Extreme Product Family
4
Products

• Summit Switches
• Summit1
• Summit4
• Summit24
• Summit48
• Summit7i
• Alpine 3804 and 3808
• BlackDiamond 6800 Chassis-based Switch
• ExtremeWare Software
• ExtremeWare Enterprise Manager - EEM

5
Extreme Architecture

• Wire-speed forwarding is made possible through
  Extremes proprietary ASIC design
• The switch fabric is comprised of a collection of
  ASIC chipsets

6
Extreme Architecture

• Each forwarding slice is capable of supporting
  1 Gigabit Ethernet interface or 8 Fast Ethernet
  interfaces at wire speed

7
Extreme Architecture

• Extreme currently supports two configurations
• a four slice and
• an eight slice solution

8
Extreme Architecture

• The final products are market-targeted switches
  sharing identical technology and interfaces.

9
Product Summary Overview
Summit Switch Family
24
10
Summit1

• 17.5 Gbps backplane
• 8 ports of gigabit ethernet
• 6 SX multi-mode ports
• Two GBIC connectors (SX/LX)
• Serial port
• Redundant Power Supply port

11
Summit4

• 17.5 Gbps backplane
• 16 10/100 auto sensing UTP ethernet ports
• 6 SX Gigabit Ethernet Ports
• Serial port
• Redundant Power Supply port

12
Summit24

• 8.5 Gbps backplane
• 24-10/100 auto-sensing UTP ethernet ports
• 1-1000 Mbps gigabit ethernet port
• Port 25 GBIC Based with a redundant Physical
  layer connector
• Serial port
• Redundant Power Supply port

13
Summit48

• 17.5 Gbps backplane
• 48 10/100 auto sensing UTP ethernet ports
• 2 1000 Mbps gigabit ethernet ports
• Port 49 and 50 GBIC-based with a redundant
  physical-layer connector
• Serial port
• Redundant Power Supply port

14
Summit48 Detail
Classroom Labs will be performed on this switch
LEDs are ordered left to right, top to
bottom Power Green - Summit powered up Yellow -
Primary RPS has failed MGMT Green Flashing -
Normal operation, download in progress, Solid -
POST in progress Yellow - Switch failed POST
(power on self test), or fan failure
Packet Yellow - Frames being transmitted/received
on this port Off - no activity Status Green solid
- link is present port is enabled Green flashing
- Link is present port disabled Off - Link is
not present
15
Summit7i

• 64 Gbps non-blocking switch fabric bandwidth
• Wire-speed IP IPX routing
• 48 million pps
• 32 Gigabit Ethernet ports
• 28 autosensing 100/1000BASE-T or 1000BASE-SX
  ports
• 4 GBIC-based 1000BASE-X ports

16
Alpine 3808 and 3804 Ethernet Service
Provisioning Switch

• IP TDM (fixed-latency transport)
• SONET-like reliability
• Bandwidth by the slice
• Usage-based billing
• Integrated WDM
• Virtual MAN (vMAN) services
• BGP4
• Long-reach optics

17
Alpine 3808 and 3804 Ethernet Service
Provisioning Switch

• Maximum redundancy and reliability
• Dual load sharing power supplies
• Hot swappable I/O modules and fan tray
• Specialized interface modules
• Distance capable GBICs - 70 Km
• WDMi - 35 Km
• Packet over SONET
• High density
• 12 Inches deep
• 32-port 10/100, 24-port 100FX
• 4-port 1000BASE-X, 1000BASE-T
• Performance 64 Gbps/48 Million pps

18
The BlackDiamond 6808

• A ten slot chassis, eight port blades, two for
  switching fabrics
• Up to 256 10/100 ports, full non-blocking
• Up to 32 Gigabit ports, full non-blocking
• 64Gbps non-blocking switching fabric
• 48 Mpps wire speed IP routing
• Fault tolerant switching fabric
• Redundant load sharing, hot swappable power
  supplies
• Hot-swappable fan tray, port and switch modules

19
The BlackDiamond 6816

• A twenty slot chassis, sixteen port blades, four
  for switching fabrics
• Up to 1,536 10/100BASE-TX ports
• Up to 192 1000BASE-T ports
• Up to 192 1000BASE-X ports
• 256 Gbps non-blocking switch fabric
• 192 million pps routing and switching performance
• Wire-speed IP/IPX routing and switching
• Passive backplane supports quad-redundant,
  load-sharing and hot-swappable switch fabrics

20
Extreme Switches At-A-Glance
21
Extreme Functional Summary

• IP Routing Performance Rating
• IEEE 802.3 compliance
• CPU for management and control
• Ports and Interfaces
• Distances on Fiber runs SX/LX
• Power budgets for SX/LX
• Software Features

22
IP Routing Performance Rating

• Summit switches Route IP at line rate on all
  ports, all the time
• IP routing performance is rated at
• Summit1 - 11.9 million PPS
• Summit24 - 5.0 million PPS
• Summit4 - 11.3 million PPS
• Summit48 - 10.1 million PPS
• Summit7i - 48 million PPS
• BlackDiamond 6808 - 48 million PPS
• BlackDiamond 6816 - 192 million pps

23
IEEE 802.3 Standards Compliance

• IEEE 802.3ab
• 1000BaseT
• IEEE 802.3u
• 100BaseTX
• IEEE 802.3z
• 1000BaseX (SX and LX)

24
802.3z Transmission Distances
Bandwidth Capacity (or Modal Bandwidth) of the
Fiber
10 micron SMF
10,000 meters with Extreme on both ends
25
Power Budget For SX/LX

• SX multi-mode Power Budget of 7db
• LX Multi-mode Power Budget of 7.5db
• LX Single Mode 2km Power Budget of 5.5db
• LX10 Single Mode 10KM Power Budget of 5.5db

26
CPU For Management and Control

• Instantiate entries in forwarding table
• Up to 32K MAC entries in FDB
• Up to 32K Host Routes in IPFDB
• Up to 16K multicast group/source network pairs
• Up to 32K FLOWS (IPQoS)
• Maintains route tables in Layer 3
• Up to 8000 routes
• 32 Mb Dram

27
Ports and Interfaces

• Default auto-sensing in 10/100 and Gig ports
• All FE ports are full or half duplex configurable
• Modular GbE interface - GBIC - Gigabit Interface
  Converter
• Hot swappable for either SX or LX

28
ExtremeWare Management Software
Command Line Interface
Standard MIBs Extreme MIB
29
ExtremeWare CLI and Telnet Sample
30
ExtremeWare Software - VISTA

• ExtremeWare Vista
• Web-based management
• Built-in HTTP server
• Menu selections for Configurations, Statistics,
  and Support

31
ExtremeWare Supported Features

• Console and Telnet CLI connection
• ExtremeWare VISTA Web-based management interface
• Load Sharing on multiple ports
• VLANs and support for IEEE 802.1Q 802.1p
• STP - IEEE 802.1D w/ multiple STP domains
• Policy-based Quality of Service (QoS)
• Wire-speed IP routing
• Routing Protocols - RIPv1, RIPv2, OSPF
• IP Multinetting
• DHCP/BOOTP Relay

32
ExtremeWare Features cont.

• Route Redistribution (RIP-OSPF, OSPF-RIP)
• Wire-Speed IP multicast routing support
• Multicast Protocols - DVMRP, IGMP, PIM-DM
• IGMP snooping to control IP multicast traffic
• IPX Routing
• Extreme Standby Routing Protocol
• SNMP and RMON Support
• Port mirroring

33
ExtremeWare Enterprise Manager 2.0

• Provides unified management of Extreme switches
  via a three tiered architecture consisting of a
  Server, Database and Client

• Server and database run on NT 4.0 and Solaris 2.6
  and 2.7
• Clients run in a web browser
• Java-enabled standard-based open architecture
• SmartTrap optimizes network efficiency
• HP OpenView integration
• Centralized information with built-in relational
  database
• Multi-user access and security
• Enterprise management of VLAN and Policy-Based
  QoS

34
Switch Management

• Telnet, Command Line Interface
• Web Interface
• Logging
• SNMP
• MIBII
• Bridge MIB
• RMON - EtherStats, History, Alarms, Events

35
Software Features Summary

• Load Sharing (Trunking)
• 2 or 4 ports
• Open Implementation
• Up to 256 VLANs for Summits, 1024 for
  BlackDiamond
• Port-based with tagging
• Protocol-sensitive
• Combination
• Up to 64 instances of Spanning Tree

36
Software Features Summary

• Quality of Service
• Bandwidth Reservation
• Priority
• IP Routing
• Line-Rate Layer 3
• RIP, OSPF, DVMRP, PIM-DM
• IPX Routing

37
Summary

• Describe Extreme Switch Product Family
• Understand Extreme Architecture
• Describe Product Features and Functional Summary
• Discuss Extremes Compliance to IEEE Standards
• Define ExtremeWare Software Features
