Title: Congestion Control contd: Brief Version


1
Congestion Control (contd) Brief Version
  • Shivkumar Kalyanaraman
  • Rensselaer Polytechnic Institute
  • shivkuma_at_ecse.rpi.edu
  • http//www.ecse.rpi.edu/Homepages/shivkuma
  • Based in part upon slides of Prof. Raj Jain
    (OSU), Srini Seshan (CMU), J. Kurose (U Mass),
    I.Stoica (UCB)

2
Overview
  • Queue Management Schemes RED, ARED, FRED, BLUE,
    REM
  • TCP Congestion Control (CC) Modeling, TCP
    Friendly CC
  • Accumulation-based Schemes TCP Vegas, Monaco
  • Static Optimization Framework Model for
    Congestion Control
  • Explicit Rate Feedback Schemes (ATM ABR ERICA)
  • Refs Chap 13.21, 13.22 in Comer textbook
  • Floyd and Jacobson "Random Early Detection
    gateways for Congestion Avoidance"
  • Ramakrishnan and Jain, A Binary Feedback Scheme
    for Congestion Avoidance in Computer Networks
    with a Connectionless Network Layer,
  • Padhye et al, "Modeling TCP Throughput A Simple
    Model and its Empirical Validation"
  • Low, Lapsley "Optimization Flow Control, I
    Basic Algorithm and Convergence"
  • Kalyanaraman et al "The ERICA Switch Algorithm
    for ABR Traffic Management in ATM Networks"
  • Harrison et al "An Edge-based Framework for Flow
    Control"

3
Queuing Disciplines
  • Each router must implement some queuing
    discipline
  • Queuing allocates bandwidth and buffer space
  • Bandwidth which packet to serve next
    (scheduling)
  • Buffer space which packet to drop next (buff
    mgmt)
  • Queuing also affects latency

Traffic Sources
Traffic Classes
Class A
Class B
Class C
Drop
Scheduling
Buffer Management
4
Typical Internet Queuing
  • FIFO First-In-first-out
  • Simplest choice
  • Used widely in the Internet
  • Implies single class of traffic
  • Drop-tail
  • Arriving packets get dropped when queue is full
    regardless of flow or importance
  • Important distinction
  • FIFO scheduling discipline
  • Drop-tail drop (buffer management) policy

5
Active Queue Management (AQM)
6
FIFO Drop-tail Problems
  • FIFO Issues In a FIFO discipline, the service
    seen by a flow is convoluted with the arrivals of
    packets from all other flows!
  • No isolation between flows full burden on e2e
    control
  • No policing send more packets ? get more service
  • Drop-tail issues
  • Need large buffers to maintain high utilization
  • Larger buffers gt larger steady state
    queues/delays
  • Synchronization end hosts react to same events
    because of burst loss patterns
  • Lock-out few flows can monopolize queue space

7
Design Objectives
  • Keep throughput high and delay low (i.e. knee)
  • Accommodate bursts
  • Queue size should reflect ability to accept
    bursts rather than steady-state queuing
  • Improve TCP performance with minimal hardware
    changes

8
Queue Management Ideas/Mechanisms
  • Synchronization, lock-out
  • Random drop drop a randomly chosen packet
  • High steady-state queuing vs burstiness
  • Early drop Drop packets before queue full
  • Do not drop packets too early confusion
    between burstiness and overload
  • Misbehaving vs Fragile flows
  • Drop packets proportional to queue occupancy of
    flow
  • Explicitly protect fragile flows from packet loss
    (eg color them or classify them on the fly)
  • Drop packets vs Mark packets
  • Dropping packets interacts w/ reliability
    mechanisms
  • Mark packets need to trust end-systems to
    respond!

9
Packet Drop Dimensions
Aggregation
Single class
Per-connection state
Class-based queuing
Drop position
Tail
Head
Random location
Early drop
Overflow drop
10
Random Early Detection (RED)
Min thresh
Max thresh
Average Queue Length
P(drop)
1.0
maxP
minth
maxth
Avg queue length
11
Random Early Detection (RED)
  • Maintain running average of queue length
  • Low pass filtering
  • If avg Q lt minth do nothing
  • Low queuing, send packets through
  • If avg Q gt maxth, drop packet
  • Protection from misbehaving sources
  • Else mark (or drop) packet in a manner
    proportional to queue length bias to protect
    against synchronization
  • Pb maxp(avg - minth) / (maxth - minth)
  • Further, bias Pb by history of unmarked packets
  • Pa Pb/(1 - countPb)

12
RED Issues
  • Issues
  • Breaks synchronization well
  • Extremely sensitive to parameter settings
  • Wild queue oscillations upon load changes
  • Fail to prevent buffer overflow as sources
    increases
  • Does not help fragile flows (eg small window
    flows or retransmitted packets)
  • Does not adequately isolate cooperative flows
    from non-cooperative flows
  • Isolation
  • Fair queuing achieves isolation using per-flow
    state
  • RED penalty box Monitor history for packet
    drops, identify flows that use disproportionate
    bandwidth

13
REM Athuraliya Low 2000
  • Main ideas
  • Decouple congestion performance measure
  • Price adjusted to match rate and clear buffer
  • Marking probability exponential in price

REM
RED
1
Avg queue
14
Comparison of AQM Performance
15
Explicit 1-bit Feedback ECN
16
Explicit 1-bit Feedback DECbit
  • Basic ideas
  • Mark packets instead of dropping them
  • Special support at both routers and e2e
  • Scheme
  • On congestion, router sets congestion indication
    (CI) bit on packet
  • Receiver relays bit to sender
  • Sender adjusts sending rate
  • Key design questions
  • When to set CI bit?
  • How does sender respond to CI?

17
Setting CI Bit
Queue length
Current time
Time
Previous cycle
Current cycle
Averaging interval
AVG queue length (previous busyidle current
interval)/(averaging interval)
18
DECbit Source
  • Source averages across acks in window
  • Congestion if gt 50 of bits set
  • Will detect congestion earlier than TCP
  • Additive increase, multiplicative decrease
  • Decrease factor 0.875
  • Increase factor 1 packet
  • After change, ignore DECbit for packets in flight
    (vs. TCP ignore other drops in window)
  • No slow start

19
Congestion Control Models
  • Loss-based TCP Reno etc
  • Accumulation-based schemes TCP Vegas, Monaco
  • Use per-flow queue contribution (backlog) as a
    congestion estimate instead of loss rate
  • Explicit rate-based feedback
  • Controller at bottleneck assigns rates to each
    flow
  • Packet Pair congestion control Not covered
  • WFQ at bottlenecks isolates flows, and gives fair
    rates
  • Packet-pair probing discovers this rate and sets
    source rate to that.

20
TCP Reno (Jacobson 1990)
window
time
CA
SS
SS Slow Start CA Congestion Avoidance
21
TCP Vegas (Brakmo Peterson 1994)
window
time
CA
SS
  • Converges, no retransmission
  • provided buffer is large enough

22
Accumulation-Based Congestion Control (a.k.a
delay-based)
23
Accumulation-based Congestion Control
  • Allocate bandwidth by managing queue
  • Packet buffered is a necessary condition for
    being serviced
  • For FIFO scheduling, this is also a sufficient
    condition
  • gt we can control buffered packets to control
    flow rates

queue
link
router
router
source
destination
23
24
Queue vs Accumulation Behavior
  • queue qij(t) -- info of flow i queued in a fifo
    router j
  • accumulation ai(t) -- info of flow i queued in a
    set of fifo routers 1J
  • the collective queuing behavior of a set of fifo
    routers looks similar to that of one single fifo
    router

24
25
Accumulation-Based Control Policy
  • control objective keep
  • if ,no way to probe increase of available
    bw
  • control algorithm

25
26
Accumulation Single Queue
  • flow i at router j
  • arrival curve Aij(t)
  • service curve Sij(t)
  • cumulative
  • continuous
  • non-decreasing
  • if no loss, then

26
27
Accumulation Series of Queues
27
28
Accumulation Distributed, Time-shifted Sum
29
Accumulation Estimation Monaco


time
1
j
j1
J
30
Accumulation Estimation Monaco
1
jf
Jf
jf1
djf
fi
data
µij
?i,j1
µi
?i
ctrl
Jb
jb1
jb
1
djb
ctrl
out-of-bd ctrl
classifier
fifo
in-band ctrl, data pkt
30
31
Monaco Congestion Control Scheme
  • congestion estimation
  • out-of-band and in-band control packets
  • congestion response
  • if qm lt a, cwnd(k1) cwnd(k) 1
  • if qm gt ß, cwnd(k1) cwnd(k) 1 1 a lt ß
    3

31
32
TCP Vegas
  • congestion estimation
  • define qv ( cwnd / rttp cwnd / rtt ) rttp
  • where rttp is round trip propagation delay
    (basertt)
  • congestion response
  • if qv lt a, cwnd(k1) cwnd(k) 1
  • if qv gt ß, cwnd(k1) cwnd(k) 1 1 a lt ß
    3

32
33
Vegas Accumulation Estimator
  • the physical meaning of qv
  • rtt rttp rttq rttq is queuing time
  • qv ( cwnd / rttp cwnd / rtt ) rttp
  • ( cwnd / rtt ) ( rtt rttp )
  • ( cwnd / rtt ) rttq if rtt is typical
  • sending rate rttq littles law
  • packets backlogged littles law again
  • so vegas maintains a ß number of packets queued
    inside the network
  • it adjusts sending rate additively to achieve this

33
34
Accumulation Estimation Vegas
  • Backlogv

34
35
Vegas vs. Monaco estimators
  • Vegas accumulation estimator
  • ingress-based
  • round trip (forward data path and backward ack
    path)
  • sensitive to ack path queuing delay
  • sensitive to round trip propagation delay
    measurement error
  • Monaco accumulation estimator
  • egress-based
  • one way (only forward data path)
  • insensitive to ack path queuing delay
  • no need to explicitly know one way propagation
    delay

36
Queue, Utilization w/ Basertt Errors
36
37
Explicit Rate (ER) Feedback Based Congestion
Control
38
ATM ABR Explicit Rate Feedback
RM Cell
Source
Destination
  • Sources regulate transmission using a rate
    parameter
  • Feedback scheme
  • Every (n1)th cell is an RM (control) cell
    containing current cell rate, allowed cell rate,
    etc
  • Switches adjust the rate using rich information
    about congestion to calculate explicit, multi-bit
    feedback
  • Destination returns the RM cell to the source
  • Control policy Sources adjust to the new rate

39
ERICA Design Goals
  • Allows utilization to be 100 (better tracking)
  • Allows operation at any point between the knee
    and the cliff
  • The queue length can be set to any desired value
    (tracking).
  • Max-min fairness (fairness)

100
Link Utilization
Throughput
Time
Load
QueueLength
Delay
50
Load
40
Efficiency vs Fairness OSU Scheme
  • Efficiency high utilization
  • Fairness Equal allocations for contending
    sources
  • Worry about fairness after utilization close to
    100 utilization . Target Utilization (U) and
    Target Utilization Band (TUB).

overload region
worry about fairness here
999591
TotalLoad
TUB
U
underload region
Time
41
ERICA Switch Algorithm
  • Overload Input rate/Target rate
  • Fair Share Target rate/ of active VCs
  • This VCs Share VCs rate /Overload
  • ER Max(Fair Share, This VCs Share)
  • ER in Cell Min(ER in Cell, ER)
  • This is the basic algorithm.
  • Has more steps for improved fairness, queue
    management, transient spike suppression,
    averaging of metrics.

42
TCP Rate Control Eg Packeteer
  • Step 1 Explicit control of window

Congestion window (CWND)
W
Actual Window Min(Cwnd, Wr)
  • Step 2 Control rate of acks (ack-bucket)
    Tradeoff ack queues in reverse path for fewer
    packets in forward path

r
pkts
W
acks
R
Time
43
TCP Modeling Stochastic Approach TCP
Friendliness Concept
44
TCP Modeling
  • Given the congestion behavior of TCP can we
    predict what type of performance we should get?
  • What are the important factors
  • Loss rate
  • Affects how often window is reduced
  • RTT
  • Affects increase rate and relates BW to window
  • RTO
  • Affects performance during loss recovery
  • MSS
  • Affects increase rate

45
Overall TCP Behavior
  • Lets focus on steady state (congestion
    avoidance) with no slow starts, no timeouts and
    perfect loss recovery
  • Some additional assumptions
  • Fixed RTT
  • No delayed ACKs

Window
Time
46
Derivation
window
t
  • Each cycle delivers 2w2/3 packets
  • Assume each cycle delivers 1/p packets 2w2/3
  • Delivers 1/p packets followed by a drop
  • gt Loss probability p/(1p) p if p is small.
  • Hence

47
Law
  • Equilibrium window size
  • Equilibrium rate
  • Empirically constant a 1
  • Verified extensively through simulations and on
    Internet
  • References
  • T.J.Ott, J.H.B. Kemperman and M.Mathis (1996)
  • M.Mathis, J.Semke, J.Mahdavi, T.Ott (1997)
  • T.V.Lakshman and U.Mahdow (1997)
  • J.Padhye, V.Firoiu, D.Towsley, J.Kurose (1998)

48
Implications
  • Applicability
  • Additive increase multiplicative decrease (Reno)
  • Congestion avoidance dominates
  • No timeouts, e.g., SACKRH
  • Small losses
  • Persistent, greedy sources
  • Receiver not bottleneck
  • Implications
  • Reno equalizes window
  • Reno discriminates against long connections
  • Halving throughput gt quadrupling loss rate!

49
Refinement (Padhye, Firoin, Towsley Kurose
1998)
  • Renewal model including
  • FR/FR with Delayed ACKs (b packets per ACK)
  • Timeouts
  • Receiver wnd limitation
  • Source rate
  • When p is small and Wr is large, reduces to

50
TCP Friendliness
  • What does it mean to be TCP friendly?
  • TCP is not going away
  • Any new congestion control must compete with TCP
    flows
  • Should not clobber TCP flows and grab bulk of
    link
  • Should also be able to hold its own, i.e. grab
    its fair share, or it will never become popular

51
Binomial Congestion Control
  • In AIMD
  • Increase Wn1 Wn ?
  • Decrease Wn1 (1- ?) Wn
  • In Binomial
  • Increase Wn1 Wn ?/Wnk
  • Decrease Wn1 Wn - ? Wnl
  • k0 l1 ? AIMD
  • l lt 1 results in less than multiplicative
    decrease
  • Good for multimedia applications

52
Binomial Congestion Control
  • Rate 1/ (loss rate)1/(kl1)
  • If kl1 ? rate 1/p0.5
  • TCP friendly if kl 1
  • AIMD (k0, l1) is the most aggressive of this
    class
  • SQRT (k1/2,l1/2) and IIAD (k1,l0)
  • Good for applications that want to probe quickly
    and can use any available bandwidth

53
Optimization Models for Congestion Control
54
Model
  • Sources s
  • L(s) - links used by source s
  • Us(xs) - utility if source rate xs
  • Network
  • Links l of capacities cl

55
Example
56
Static Optimization Framework
pl(t)
xi(t)
  • Duality theory ? equilibrium
  • Source rates xi(t) are primal variables
  • Congestion measures pl(t) are dual variables
  • Congestion control is optimization process over
    Internet

57
Overview equilibrium
  • Interaction of source rates xs(t) and congestion
    measures pl(t)
  • Duality theory
  • They are primal and dual variables
  • Flow control is optimization process
  • Example congestion measure
  • Loss (Reno)
  • Queueing delay (Vegas)

58
Overview equilibrium
  • Congestion control problem
  • TCP/AQM protocols (F, G)
  • Maximize aggregate source utility
  • With different utility functions Us(xs)

59
Primal problem
  • Assumptions
  • Strictly concave increasing Us
  • Unique optimal rates xs exist
  • Direct solution impractical

60
Duality Approach
61
Gradient algorithm
  • Gradient algorithm

Theorem (Low, Lapsley, 1999) Converges to
optimal rates in an asynchronous environment
62
Active queue management
  • Idea provide congestion information by
    probabilistically marking packets
  • Issues
  • How to measure congestion (p and G)?
  • How to embed congestion measure?
  • How to feed back congestion info?

63
RED (Floyd Jacobson 1993)
  • Congestion measure average queue length
  • pl(t1) pl(t) xl(t) - cl
  • Embedding p-linear probability function

marking
1
Avg queue
64
REM (Athuraliya Low 2000)
  • Congestion measure price
  • pl(t1) pl(t) g(al bl(t) xl (t) - cl
    )
  • Embedding exponential probability function

65
Key features
  • Clear buffer and match rate

Theorem (Paganini 2000) Global asymptotic
stability for general utility function (in the
absence of delay)
66
AQM Summary
67
Reno F
for every ack (ca) W 1/W for every
loss W W/2


Primal-dual algorithm
x(t1) F( p(t), x(t) ) p(t1) G( p(t),
x(t) )
68
Reno Implications
  • Equilibrium characterization
  • Duality
  • Congestion measure p loss
  • Implications
  • Reno equalizes window wi ti xi
  • inversely proportional to delay ti
  • dependence for small p
  • DropTail fills queue, regardless of queue
    capacity

69
Reno gradient algorithm
  • Gradient algorithm
  • TCP approximate version of gradient algorithm

70
Summary
  • Active Queue Management (AQM) RED, REM etc
  • Alternative models
  • Accumulation-based schemes Monaco, Vegas
  • Explicit Rate-based Schemes
  • TCP stochastic modeling
  • Static (Duality) Optimization Framework
About PowerShow.com
