Title: Chapter 6 Introduction to Design Patterns


1
Chapter 6 Introduction to Design Patterns
2
Process Phase Discussed in This Chapter
Requirements Analysis
Design
Architecture
Framework
Detailed Design
Implementation
Key
secondary emphasis
main emphasis
x
x
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
3
Sample Design Goals and Ways to Accomplish Them
  • Reusability, Flexibility, and Maintainability
  • Reuse flexible designs
  • Keep code at a general level
  • Minimize dependency on other classes
  • Robustness
  • Reuse reliable designs
  • Reuse robust parts
  • Sufficiency / Correctness
  • Modularize design
  • Reuse trusted parts

Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
4
KitchenViewer Interface
Wall cabinet
menu
?
Counter
display area
styles
Floor cabinet
Modern
Classic
Antique
Arts Crafts
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
5
KitchenViewer Example
Wall cabinets
Floor cabinets
Countertop











Modern
Classic
Antique
Arts Crafts
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
6
Selecting Antique Style











Modern
Classic
Antique
Arts Crafts
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
7
KitchenViewer Without Design Patterns
Client renderKitchen()
Kitchen
FloorCabinet
WallCabinet
ModernWallCabinet
AntiqueWallCabinet
ModernFloorCabinet
AntiqueFloorCabinet
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
8
Design Goal At Work ? Flexibility ?
Our design should be flexible enough to produce
any of several kitchen styles.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
9
The Abstract Factory Idea
KitchenStyle getWallCabinet() getFloorCabinet()
WallCabinet
FloorCabinet
AntiqueWallCabinet
AntiqueFloorCabinet
…
…
ModernKStyle getWallCabinet() getFloorCabinet()
AntiqueKStyle getWallCabinet() getFloorCabinet()
FloorCabinet getFloorCabinet() return new
AntiqueFloorCabinet()
FloorCabinet getFloorCabinet() return new
ModernFloorCabinet()
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
10
Abstract Factory Design Pattern Applied to
KitchenViewer
Client renderKitchen( KitchenStyle )
KitchenStyle getWallCabinet() getFloorCabinet()
Kitchen getWallCabinet() getFloorcabinet()
WallCabinet
FloorCabinet
ModernWallCabinet
ModernKStyle getWallCabinet() getFloorCabinet()
AntiqueWallCabinet
ModernFloorCabinet
AntiqueKStyle getWallCabinet() getFloorCabinet()
AntiqueFloorCabinet
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
11
Abstract Factory Design Pattern
Client doOperation( Style myStyle )
Style getComponentA() getComponentB()
Collection
ComponentA
ComponentB
Style1ComponentA
Style1 getComponentA() getComponentB()
Style2ComponentA
Style1ComponentB
Style2 getComponentA() getComponentB()
Style2ComponentB
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
12
Abstract Factory Design Pattern Alternative
Client doOperation()
Collection getComponentA() getComponentB()
Style getComponentA() getComponentB()
ComponentA
ComponentB
Style1ComponentA
Style1 getComponentA() getComponentB()
Style2ComponentA
Style1ComponentB
Style2 getComponentA() getComponentB()
Style2ComponentB
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
13
Key Concept ? Design Pattern ?
-- class combination and algorithm fulfilling a
common design purpose.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
14
Key Concept ? Creational Design Patterns ?
-- used to create objects in flexible or
constrained ways.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
15
Key Concept ? Structural Design Patterns ?
-- used to represent data structures such as
trees, with uniform processing interfaces.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
16
Example of Behavioral Design Goal Port Traffic
obstacles
to drydock ?
berth
berth
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
17
Design Goal At Work ? Flexibility ?
Our design should be flexible enough to produce
any of several kitchen styles.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
18
Avoiding Dependencies
?
Harbor application
1..n
1
Ship
Tugboat
Customs application reuse Ship alone
Ship
Longshoreman
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
19
Core Mediator Concept Applied to The Harbor
Problem
Ship
LeavingPort estimateTime()
Tugboat
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
20
Applying the Mediator Design Pattern to The
Harbor Problem
PortMission estimateTime()
Vessel
Mediator base class
Ship
Tugboat
EnteringPort estimateTime()
LeavingPort estimateTime()
BeingMaintained estimateTime()
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
21
A Design Problem Solvable by Chain of
Responsibility
Choose an automobile to view.
This part is fixed
Model
Basic
Midsize
SUV
Luxury
Display depends on model selected
Body Style
Luxury
Extra
Basic
Display depends on body style selected
Body color
Black
Brown
Red
White
Assume that each of these will eventually be a
small, expensive animation.
You have requested to view a luxury model with
luxury body style, and black body color.
OK
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
22
Key Concept ? Behavioral Design Patterns ?
-- to capture behavior among objects.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
23
Characteristics of Design Patterns 1
  • Viewpoints ways to describe patterns
  • Static class model (building blocks)
  • Dynamic sequence or state diagram (operation)
  • Levels decomposition of patterns
  • Abstract level describes the core of the pattern
  • Concrete ( non abstract) level describes the
    particulars of this case
  • Roles the players in pattern usage
  • Application of the design pattern itself
  • Clients of the design pattern application
  • Setup code initializes and controls

Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
24
Characteristics of Design Patterns 2
(class or classes)
1. Client role
3. Role Application of the design pattern
A. Static viewpoint
B. Dynamic viewpoint
A
B
(i) Abstract level
(ii) Concrete level
C
D
(sequence or state diagram)
(class model)
2. Setup role
Reference direction
(class or classes)
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
25
Abstract Factory Application Sequence Diagram
myStyleKitchenStyle
Client
myStyle. getWallCabinet()
-- IF myStyle BELONGS TO ModernKStyle --
myStyle ModernKStyle
wallCabinet1 ModernWallCabinet
renderKitchen ( myStyle )
getWallCabinet()
ModernWallCabinet()
-- IF myStyle BELONGS TO AntiqueKStyle --
myStyle AntiqueKStyle
wallCabinet1 AntiqueWallCabinet
getWallCabinet()
AntiqueWallCabinet()
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
26
Key Concept ? Two Viewpoints ?
We consider design patterns from the static
viewpoint (what they are made from) and the
dynamic viewpoint (how they function).
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
27
Concrete and Abstract Layers
Client
WallCabinet
KitchenStyle
FloorCabinet
Abstract level
Concrete level
Kitchen
ModernWallCabinet
AntiqueWallCabinet
ModernKStyle
ModernFloorCabinet
AntiqueKStyle
AntiqueFloorCabinet
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
28
Design Goal At Work ? Correctness ?
We want to provide an interface to a design
pattern so that its functionality is clear and
separate.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
29
Key Concept ? Two Levels ?
Design patterns usually have an abstract level
and a non-abstract (concrete) level.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
30
Design Goal At Work ? Correctness ?
To use design patterns effectively, we
distinguish the roles involved.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
31
The Three Roles Involved in Design Pattern Usage
2. Client Role
1. Design Pattern Application
Interacts with the design pattern only through
its interface
Interface to the pattern (frequently abstract
possibly several classes)
DPClient
DPInterface
3. Setup Role

No limitations
Rest of the design pattern application
Rest of the Application





Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
32
Key Concept ? Three Roles ?
A part of a design either 1) applies a design
pattern, 2) is a client of the pattern
application, or 3) re/initializes these.
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
33
Basic Idea of Delegation
… intermediaryFunction( … ) …
requiredFunction() …
… clientFunction( … ) … intermediaryFunction( …
) …
Client clientFunction()
intermediaryFunction()
?
replace
requiredFunction()
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
34
Basic Design Pattern Form 1 Delegation
… interfaceMethod( … ) … doerObject.doIt() …
Client
doerObject
DoerBase doIt()
DPInterface interfaceMethod()
ConcreteDoer1 doIt()
ConcreteDoer2 doIt()
. . .
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
35
Basic Design Pattern Form 2 Recursion
RecursionBase doOperation()
Client
aggregate
NonrecursiveClass doOperation()
RecursiveClass doOperation()
void doOperation( … ) … aggregate …
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
36
The Recursion Form Applied to an Organization
Chart
Employee printOrganization()
Client
supervisees
IndividualContributor printOrganization()
Supervisor printOrganization()
void printOrganization( … ) …
supervisees.printOrganization() …
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
37
Key Concept ? Two Forms ?
A design patterns form is usually a delegation
of responsibility or a class that relates to
itself (recursive).
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
38
Summary of This Chapter
  • Design Patterns are recurring designs satisfying
    recurring design purposes
  • Described by Static and Dynamic Viewpoints
  • Typically class models and sequence diagrams
    respectively
  • Use of a pattern application is a Client Role
  • Client interface carefully controlled
  • Setup, typically initialization, a separate
    role
  • Design patterns Forms usually Delegation or
    Recursion
  • Classified as Creational, Structural, or
    Behavioral

Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
39
Observer Design Pattern
Trigger
1..n
Observer update()
Source notify()
Initialize
ConcreteObserver observerState update()
ConcreteSubject state
Adapted from Software Design From Programming to
Architecture by Eric J. Braude (Wiley 2003), with
permission.
About PowerShow.com
