The SnapTV concept

1
(No Transcript)
2
The SnapTV concept

• Snap TV is een nieuw concept voor
  gemeenschappelijke sateliet en CAI antenne
  systemen (CATV/SMATV)
• Concept is optimized for owners of
• small and medium size networks
• clusters of small and medium size networks
• Using IPTV technology to enable cost efficiency

3
The IPTV puzzle
What DVB gateway?
What VOD server?
What CA system?

What monitoring system?
What middleware?
What set-top box?
4
IPTV puzzled by SnapTV
What DVB gateway?
What VOD server?
What CA system?
What monitoring system?

What middleware?
What set-top box )?
What applications )?
No CA is also option for closed networks )
Provided through 3rd parties
Kreatel/Motorola is pre-integrated for nPVR and
VoD.
5
(No Transcript)
6
Versatility
7
Quality monitoring
8
Usage patterns
9
Availability reports
10
Configuration
11
Functions summary
12
Conventional DVB-IPTV head-end
Demodulation Descrambling Service filtering
MPTS to SPTS splitting Multicasting
Bit-rate adaptation Re-multiplexing
DVB-S
TS descrambler
IP streamer
TS descrambler
ASI mux
IP streamer
TS descrambler
Network Gear
IP streamer
DVB-T
IRD
IRD
IP streamer
IRD
Camera
Web server
Encoder
Portal EPG
AV encoding
VoD server
Network Manager
VOD streaming
QoS Monitoring
13
The difference?
14
Content neutral

• Network owner defines the channel offering and
  line-up
• Most conditional access systems supported
• New video formats supported
• MPEG-2, MPEG-4 AVC, Windows Media
• Standard definition and high definition
• Multiple feeds supported
• DVB-S, DVB-S2 (digital satellite)
• DVB-T (digital terrestrial)
• Multistandard RF/PAL (analog radio and TV)
• Baseband video (CVBS and S-video)
• MPEG files and DVD

15
Time-shifting support

• Network recorder with 1000 or 4000 hours of TV
  program storage
• Enables individual playback of any program, eg
  from last day or last week

16
On demand support

• Video on demand
• Video advertising
• Content uploaded from file, DVD or provided as
  baseband video
• Easy publishing of local content such as info
  channel, training videos, ads etc
• Trick play

17
Network requirements

• Independent of physical cabling, can use any of
• Coax
• CAT-5/6
• Fiber
• Unlike conventional SMATV, no requirement to
  install and maintain an RF network
• Reuse of broadband infrastucture
• Cabling
• Switches and other network components
• Maintenance
• Know-how
• Multicast routing protocols should be supported,
  eg PIM-SM
• For multiple services (eg IP telephony, internet
  access and IPTV, QoS should be established)

18
Functionality for users

• Ordinary TV channel zapping
• Digital radio
• TV and PC playback
• Program guide always up to date, no limitation on
  the number of channels or the number of days
• Searchable program guide
• Time-shift (Pause, playback of programs from the
  past etc)
• Wide channel offering
• Upload of own video clips from PC

19
Playback on TV and PC

• Pre-integrated with leading STB manufacturers
• Kreatel/Motorola
• Amino
• WIP on Kaon and on LCD TVs with integrated IPTV
  modules

20
TV with EPG and timeshift
Program guide with both future and past events.
Seamless navigation. Watch yesterdays football
match or Lost episode today
21
Searchable program guide
With thousands of radio and TV channels available
and a historic program guide, Search is a key!
22
Private storage
Storage resources can be reserved for private
use. Upload own content from PC!
23
Functions for network owner

• Simple feeding of own infochannel and own video
  clips
• Built-in web browser in STB enables web and
  portal solutions
• Usage reports and statistics
• Per channel
• Per program
• QoS monitoring in the network
• Packet loss
• Jitter
• SnapTV can deliver fully provisioned service

24
Case study 1

• Pioneers in offering and IPTV to their
  inhabitants
• Owns and runs their own triple play network
• 65 flats, expanding to 350 by inviting neighbours
• First IP-based SMATV network in a city in Norway
• 24 TV channels with recording
• Operational since summer 2006

Welhavens gate 10-14 OBOS apartment block
25
Case study 2

• Triple play provided by Cyberhemsen
• IPTV system by SnapTV
• 36 TV channels
• Locally produced info-channel
• Operational since Jan 2006

Geilo ski resort Apartments and cottages
26
Case study 3

• First off-shore IPTV system in the world
• 350 workiers sharing 175 cabins
• 14 TV channels with 24 hours time-shifting
• Operational since fall 2005

Borgholm Dolphin Accomodation unit in the North
Sea
27
Summary

• Inexpensive and versatile IPTV-system
• Content neutral
• Ideal for new-builds removes the need for RF
  networks and RF know-how
• Supports info-channel
• Supports PC playback
• Supports Pay TV
• Supports Interactive solutions/web

28
Supplier for BeneluxRian BV bergstraat 255581
BG Waalre Nederland040-2213656
29
Enkele door ons gerealiseerde GSO projecten
30
(No Transcript)
31

32
TECHNOCAMPUS INMIDDELS MEER DAN 400 aansl.
dakopstelling
33
Kabelboom naar headend
