CAG Expansion and Huntingtons Disease

1
CAG Expansion and Huntingtons Disease -

• Could you repeat that, please?
• A research review on Huntingtons disease

Image source http//www.vh.org/Providers/Textbook
s/BrainAnatomy/Ch5Text/Section01.html
2
Heres the Plan

• Introduction
• Clinical symptoms
• Pathology
• Molecular basis
• Current research
• Treatment ideas
• Future plans
• Conclusions

3
Huntingtons Disease
Introduction

• Dr. George Sumner Huntington
• Published paper in 1872
• Patients of East Hampton, Long Island

http//www.uic.edu/depts/mcne/founders/page0048.ht
ml
4
Check Out My Figures
Introduction

• Affects 30,000 people in the U.S.
• Frequency of about 1 in 10,000
• 150,000 may develop the disorder
• Strikes both men and women
• 10 of the cases are children

5
Symptoms A Threefold Attack
Symptoms

• Three stages of progression
• Three areas affected
• Mental Dementia
• Emotional Mood swings
• Physical Chorea, unsteady gait, weight loss

http//www.nlm.nih.gov/medlineplus/ency/article/00
3199.htm
6
Pathology The Wreckage of HD
Pathology

• General loss of brain mass
• Specific neuronal loss in the striatum (caudate
  nucleus and the putamen) and the cerebral cortex

DebBurman, S.K.
7
Damage Report
Pathology

• Inhibitory and excitatory neurons
• Loss of inhibitory control
• Manifested in chorea

8
CULPRIT Huntingtin Gene its Mutation
Molecular Basis

• Normal huntingtin protein - vital, but function
  unknown
• Gene identified as IT15
• Chromosome location 4p16.3
• Dynamic mutation
• Expanded CAG repeat

9
How mutation happens Expanded CAG Repeat
Sequence
Molecular Basis
10
Biological ModelMutant Huntingtin causes disease
Molecular Basis
Huntingtin Gene IT15
11
Longer the repeat, earlier the onset
Molecular Basis
Persichetti et al., 1994
12
Paternal Anticipation
Molecular Basis

• Longer CAG repeats are more unstable
• Expansions occur more when passed through the
  male germ line
• Meiotic transmission may cause the CAG expansion
• Age of onset decreases with the increasing number
  of generations
• Paternal anticipation is not fully understood

Decreasing Age of Onset
13
Conclusions
Molecular Basis

• A dynamic mutation results in the CAG repeat
• The mutation may be caused by DNA polymerase
  slippage
• Inverse relation between length of CAG repeat
  and age at death
• Paternal Anticipation results in longer CAG
  repeat and earlier age of onset

14
Let Us Demonstrate
Demonstration

• An example of a sequence specific amplification

15
Gaps in Knowledge in 1997

• How does mutant huntingtin protein misfold?
• What kind of cell death takes place?
• How does misfolded huntingtin cause cell death?
• Who talks with huntingtin in health?
• How does that change in disease?
• How can we prevent HD?

16
1. How does Huntingtin misfold?Discovery of
Neuronal Intranuclear Inclusions (NIIs)
Current Research

• N-terminus of htt accumulates in neuronal nuclei
• PolyQ repeat leads to the formation of insoluble
  ?-sheets or barrels
• Role of NIIs in HD pathology is presently unclear

DiFiglia, 1997
17
Causal Role Of NIIs?
Current Research

• NIIs are hallmarks of polyQ diseases
• Observed in the striatum and cortex
• Appear before onset of HD
• Ubiquitinated
• Reduction NIIs decreases in vitro cell death

Saudou, 1998
18
The Plot Thickens Are NIIs Helpful or
Deleterious?
Current Research

• htt induces cell death
• Reduction in NII formation shows increased death
  from HD
• NIIs a possible protection mechanism?

Saudou, 1998
19
Presently the role of NIIs in HD is unclear
Current Research
20
2. How Do Neurons Die?
Current Research

• Apoptosis - programed cell death
• Non-apoptotic model - role for NIIs
• Excitotoxicity - death by over-excitement

21
A. Role of Caspases in apoptosis
Current Research

• Degrade apoptotic cells
• Triggers activation of other caspases
• Overactivation of caspases in HD

22
B. A Non-Apoptotic Model
Current Research
23
C. Excitotoxicity
Current Research

• High glutamate levels excite some neurons to
  death
• Expected increased cell death in HD mice
• Surprise! HD mice are resistant to the addition
  of quinolinic acid

Hansson et al, 1999
24
So Which One is It?
Current Research

• No one knows!
• Contradictory evidence from different
  laboratories and many unanswered questions
• Still investigating each mechanism

25
Who does huntingtin talk with?Healthy
pathogenic Protein Interactions
Current Research

• Molecular Chaperones Transcription Factors

26
Chaperones Fold With Me
Current Research

• Yeast model
• Different levels of polyQ
• Ubiquitination?
• Still aggregation

http//www.letterset.com/ufo.htm
27
Keep Foldin, Foldin, Foldin
Current Research

• Overexpression or deletion of HSPs
• Increased HSPs, increased aggregation
• Deletion of HSP104 - NO AGGREGATION

http//www.ccc.nottingham.ac.uk/mbzspd/tutorials/
CSC.htm
28
Additional Folding Models
Current Research

• Mammalian model
• HSPs increase aggregation
• Worm model
• _ NIIs move to cytoplasm with more Hsps
• Fly model
• Hsp70 and Hsp40 together Inhibit fibril
  (aggregate) formation

29
Transcribe thisconnecting with p53
Current Research

• htt and p53
• p53 aggregation
• Repressed transcription
• Leads to Apoptosis?

Perutz, 1994
30
What in the CA150??
Current Research

• Aggregation leads to
• Interfered transcription
• Essential protein synthesis disruption
• Cell death

• CA150
• Transcriptional co-activator
• Rich in Glu-Ala
• Found with ubiquitinated htt in inclusions
• binds preferentially with htt

31
So
Current Research

• HSPs are essential in htt misfolding
• Possibility that the pathology involved htt
  aggregrating with transcription factors, which
  leads to cell death

32
4. Therapeutic Possibilities
Treatment Ideas

• Addition of Minocycline
• Turn off promoter to prevent htt translation
• Fetal striatal tissue transplant

33
A. Minocycline Treatment
Treatment Ideas

• An antibiotic that can cross BBB
• Will inhibit caspases
• Delays disease progression
• No inhibitory effect on the nuclear inclusions

34
B. Inhibiting transcription halts HD in
mice
Treatment Ideas

• Transgenic mice developed with the ability to
  inhibit htt expression with addition of
  doxycycline (DOX)

35
Lose Your Inhibitions
Treatment Ideas

• Inhibition of htt expression allows for neuronal
  recovery
• Gene off mice show caudate regeneration

Yamamoto, 2000
36
C. Transplanting the Seeds of Hope... with fetal
transplants
Treatment Ideas
Freeman, et al., 2000

• Fetal striatal transplants by Freeman et al.
• Used human subject
• Only 18 months of data collected
• Transplanted neurons unaffected

37
The Underlying Theme
Conclusion

• The field of HD has become increasingly
  controversial at the molecular level
• Mechanisms are unknown even though progress has
  been substantial
• HD does not follow suit with the rest of the
  trinucleotide repeat diseases

38
What Next?
Future Plans

• Combine treatments to target the different
  proposed mechanisms
• Continued research to determine a definitive
  mechanism
• Re-evaluate other trinucleotide repeat diseases

39
We Wish We Knew...
Future Plans

• How are the symptoms and pathology interrelated?
• What is the exact mechanism of HD?
• The role of NIIs is it cause or effect?
• What causes paternal genetic anticipation?

40
