Evolving the PC Platform Chipset Directions for 2005 and Beyond

1
Evolving the PC PlatformChipset Directions for
2005 and Beyond

• Mark Overby
• Platform ArchitectNVIDIA Corporation

2
Caveats

• Client PC Focused
• Some server platform applicability though
• These are ideas and directions to investigate
• Not an NVIDIA roadmap
• Not a Microsoft roadmap
• Not anyone elses roadmap

3
Agenda

• Todays chipset technology
• What is driving change in chipsets
• Addressing the demand for change
• Moving the platform forward

4
The Platform Chipset Today

• Chipset integration often affirms the arrival of
  a technology as an accepted baseline component
  ofthe PC platform
• Chipsets are no longer just a discrete I/O
  interconnect, they have become media and
  communications processors (MCP)
• Continued advances in high-speed bus interconnect
  along with Moore's Law have helped to drive
  consolidation of the PC subsystem into a few
  major silicon components - CPU, GPU, and MCP, all
  sharinga large common heap of memory
• The emergence of "media processing" as a primary
  function of the PC will lead to a new era of
  Media Communications Processors that will replace
  todays Platform Chipsets

5
What Is Driving Change In Chipsets?

• Consumer expectations
• Processor advances
• Networking broadband connectivity
• Increasing storage size, capability, and demand
• High speed interconnects
• Security/content protection

6
Consumer Expectations

• The PC needs to be appliance like (small, quiet)
• Never off Exception (maybe) is a power outage
• Never idle
• Connects to all devices ubiquitously
• Autonomous Self Maintenance interactive
  troubleshooting

7
Processor Advances

• Power / performance improvements
• Dual Core
• Hyper-threading
• Memory technology
• Power State Management
• Virtual processing
• Security improvements

8
Networking Broadband

• Home LAN with Broadband connection
• Mobile devices with internet and network
  connectivity
• PANs - Transient multiple external device
  connections
• More and more demand for Broadband resources
• High bandwidth multimedia (e.g. HD video) creates
  a huge demand for more bandwidth
• The megahertz debate is replaced by theMbps
  debate
• Wireless often replacing wired networksin some
  scenarios

9
Storage

• All that content needs somewhere to go
• Capacities increasing quickly(e.g. 400 500 GB
  disks available today)
• PC capable of Massive Storage
• Needs to be Secure
• Needs to be Safe/Robust
• Needs to be Manageable

10
High Speed Interconnects

• PCI Express
• Ushers in a new era of high performance add in
  boards with advanced processing capabilities
• Serial ATA
• Internal and External hot pluggable storage
• Wireless USB
• New era of wireless plug and play device
  interacting with the PC
• USB 2.0
• For anything that is not wireless (e.g. portable
  storage)

11
Security Content Protection Needs

• Platform and peripheral Security
• Vital data stored on the PC and PCs across the
  network needs to be protected
• Premium content owners demand protection

12
Addressing the Demand for Change

• A new Thermal (Power) Management paradigm
• The PC is never off
• Performance scales to demand
• Enables a 24/7 processing model
• Task specific processing offload
• Safe, reliable, expandable, andmanageable
  storage
• Leveraging Multi-core Processors
• Securing the PC, LAN, Content
• Actively managing the platform

13
Power Management

• Power button puts the PC in reduced capability
  mode but does not shut it down
• Expand on Always Ready demonstratedat WinHEC
  2004
• To appear off, it must run in a state that
  reduces noise to below ambient level
• An efficient solution requires managing the
  entire PC HW suite, not just slowing down the CPU
  and putting devices in D3 state
• Applications must be more aware of power state
• OS management of PC resources is required
• Different activities have different resource
  requirements
• System performance thermal management
  shouldadjust accordingly

14
Adopting a 24/7 Processing Model

• Distributing software work to hardware offload
  devices in system, where it makes sense
• Safe, reliable, expandable, and manageable
  Storage
• No down time
• No back up required
• Simple can be done by user
• Use Multi-core CPUs for efficiency
• Optimizing SW for I/O

15
Take Advantage of Offload Technologies

• GPU massive processing capability
• PCI Express opens access to powerful processing
  capabilities
• Media Encode/Decode/Transcode
• Post-processing of photo and video content
• Networking Offload
• Firewall Offload
• Storage Offload
• Cryptography Offload
• Protect massive amounts of data media content
  moving to/from storage across internal PC bus

16
Safe, Reliable, Expandable Manageable Storage

• RAID 5 should be the standard for at leastone PC
  in the home network
• Redundancy/fault tolerance
• Performance
• Expandable
• Easy expansion of storage
• External SATA, Hot Plug capabilities of SATA
• Network
• Backup needs to take place automatically
• Need to completely isolate the user from the
  complexity of storage

17
Making Storage Easier to Manage
18
NVIDIA nForce MediaShieldDemo
19
Leveraging Multi-Core Processors

• Multi-core processors will be ubiquitous
• Multi-core processor is more power efficient
  compared to 2 single core processors
• Provides opportunity to do more processing at
  a lower power/thermal cost (performance / watt)

20
Securing the Platform Network

• Platform Peripheral Protection
• Cryptography Offload
• Firewall Offload
• TCP Offload

21
Platform Peripheral Protection

• TPM
• Processor Security Extensions
• Cryptography
• Virtualization

22
Cryptography Offload

• Using the distributed resources of the PC while
  in a low power state will necessitate being able
  to offload the cryptography task for I/O to a
  dedicated engine in the chipset
• Example using the GPU to transcode premium
  content on demand for downloading to a portable
  media center
• Not just networking storage, audio, and others

23
Hardware Firewall Offload

• Hardware firewall provides additional layer of
  protection to each PC on the Home LANand/or
  connected to the PC
• As bandwidth increases demand on the firewall
  will strip CPU capacity to keep up

24
Managing the Platform

• Numerous vital tasks running in the background
• Virus, anti-spyware scanning
• Search engine indexing
• SW updates
• System maintenance tasks running inthe
  background
• Disk optimization
• System optimization
• Media secure content consolidation and
  protection
• Diagnostic and troubleshooting support
• Hardware automation for common tasks orcomplex
  tasks
• Failure prediction and analysis

25
MCP Opportunities
MCP Core
Networking
PCI Express
MCP Controller Logic
Storage
Legacy Interfaces
26
MCP Opportunities
Wireless USB Firewall Offload TCP Offload
MCP Core
Networking
PCI Express
MCP Controller Logic
Storage
Legacy Interfaces
27
MCP Opportunities
MCP Core
PCI Express Gen2 PCI Express Hotplug Multiple GPU
Networking
PCI Express
MCP Controller Logic
Storage
Legacy Interfaces
28
MCP Opportunities
MCP Core
Networking
PCI Express
MCP Controller Logic
Storage
Legacy Interfaces
RAID 5 SATA Gen2 SAS Storage Offload
29
MCP Opportunities
MCP Core
Networking
PCI Express
MCP Controller Logic
Storage
Legacy Interfaces
Management Intelligence Cryptography
Offload TPM Processor Security Extensions HW
Virtualization
30
MCP Opportunities
MCP Core
Networking
PCI Express
Power Management
MCP Controller Logic
Storage
Legacy Interfaces
31
Operating System Opportunities

• Support processing and offload capabilities in
  the MCP and attached peripheral devices
• Schedule tasks based on power state and
  availability of resources
• Provide application awareness for reducedpower
  modes
• Incorporate management infrastructure to support
  intelligent device management, diagnostic, and
  troubleshooting capabilities
• Support advanced capabilities of high-speed
  interconnects

32
Call to Action

• Design for thermal (power) management
  flexibility
• Always on, always working
• Implement intelligence to offload user tasks
• Use existing Industry Standards dont reinvent
  the wheel, just improve it
• Write applications to utilize offload capability
  provided by Windows
• Work with Microsoft and industry partners to
  standardize support for advanced scenarios

33
Standards and Specification Bodies

• PCI
• http//pcisig.com
• Serial ATA
• http//www.t13.org
• http//www.sata-io.org
• SCSI
• http//www.t10.org
• Networking
• http//standards.ieee.org/getieee802
• Platform Security
• http//trustedcomputinggroup.org
• ACPI
• http//www.acpi.info
• USB
• http//www.usb.org

34
Community Resources

• Windows Hardware Driver Central (WHDC)
• www.microsoft.com/whdc/default.mspx
• Technical Communities
• www.microsoft.com/communities/products/default.msp
  x
• Non-Microsoft Community Sites
• www.microsoft.com/communities/related/default.mspx

• Microsoft Public Newsgroups
• www.microsoft.com/communities/newsgroups
• Technical Chats and Webcasts
• www.microsoft.com/communities/chats/default.mspx
• www.microsoft.com/webcasts
• Microsoft Blogs
• www.microsoft.com/communities/blogs

35
Additional Resources

• Microsoft Hardware Developer Central
• http//www.microsoft.com/whdc
• AMD
• http//www.amd.com
• Intel
• http//www.intel.com

36
NVIDIA Resources

• NVIDIA nForce MCPs
• http//www.nvidia.com/page/mobo.html (example)
• Related NVIDIA Technologies
• http//www.nvidia.com/page/technologies.html
• NVIDIA Homepage
• http//www.nvidia.com
