GLG110 Geologic Disasters and the Environment

1
Unit 6 Mass Wasting, Landslides and Subsidence
2
I. Mass Wasting

• A. What is Mass Wasting?
• 1. Is defined as the down slope movement of
  rock and regolith near the Earth's surface mainly
  due to the force of gravity.
• 2. Includes the following
• a. Landslides, earthflows, mudflows,
• rockfalls, debris and snow avalanches, and
  subsidence
• 3. Can be initiated by heavy rainfall or
  Earthquakes.
• 4. Sculpt the Earths surface and can cause
  stream valleys.

3
Examples of Mass Wasting
4
II. Slope Processes

• Slopes are the most common landforms
• Most appear stable, but material on slopes is
  constantly moving
• Slope form depends on
• Underlying rock type
• Climate
• Regional tectonics
• Regional drainage pattern

5
Cliff Face
Talus Slope (rock fall debris)
Hard Granite
Soil
Convex Slope
Straight Slope
Concave Slope
Weak Rock
6
(No Transcript)
7
Talus Slope at Wheeler Peak, Great Basin
National Park, Nevada
Source Tom Bean/DRK Photos
8

• Slope - how steep the angle of the hillside is
• Slope stability depends on the driving and
  resisting forces that act on the slope
• As angle of slope increases, driving forces
  increase

9
Driving forces move material down the slope (Most
common weight of slope material, vegetation,
and structures on slope)
Resisting forces oppose downward movement (Most
common strength of slope material)

• Driving Forces and Resisting Forces

Friction
Weight of Material
Upward force of supporting materials
Gravity
10
(No Transcript)
11
III. Slope Stability

• Slope stability is evaluated by computing safety
  factor
• Safety Factor - ratio of resisting forces to
  driving forces
• If S.F. gt 1 the resisting forces are stronger and
  the slope is stable
• If S.F. lt 1 the driving forces are stronger and
  the slope is unstable

12

• Slope stability changes over time as conditions
  change causing ratio to change
• Driving and resisting forces are determined by
  interactions between
• Type of earth materials
• Slope angle and topography
• Climate
• Vegetation
• Water
• Time

13
IV. Factors affecting Mass Movement A. Role
of Slope Material

• Affects type of mass movement
• Shale or weak volcanic material slopes tend to
  creep, flow, or slump
• Affects falls when strong, resistant rock is
  underlain by weak, easily erodable rock, can
  result in undercutting and subsequent rock fall

14

• Affects type and frequency of slides
• Patterns of movement
• Rotational- occurs along curved slip surface,
  produces terrace-like structures
• Translational- planar, along slip planes within
  the slope
• Slip planes include fractures, layers, bedding
  planes, foliation, etc.

15
B. Role of Slope Topography

• Angle of Repose - maximum angle at which
  unconsolidated material on slope is stable 30-35

The larger and more uniform the size of fragments
the steeper the angle of repose

• Controlled by
• Coarseness, shape, size and uniformity of size of
  fragments
• Water content

Steep slopes often associated with rockfalls and
debris avalanches
16
C. Role of Climate

• Climate - characteristic weather at specific
  place over time
• Includes
• Average temperature
• Amount and timing of precipitation
• Which then infiltrates slope thus affecting
  stability
• Affects vegetation which influences slope
  stability
• Seasonal weather patterns

Common mass movements in arid and semiarid
regions fall, debris flow, shallow slips
17
D. Role of Vegetation

• Vegetation is a function of climate, soil type,
  topography, and fire history
• Can increase or decrease the chances of mass
  movement
• Shields soil thus mitigates runoff during heavy
  precipitation
• Roots help fix soil in place
• Adds weight to the slope
• Corner on Route 67 added vegetation to stop mass
  movement
• Peru, no vegetation, mudslides occurred.

In subhumid to humid areas vegetation is
abundant, thick soil develops so mass movements
complex landslides, flows, and creep
18
E. Role of Water

• Almost always directly or indirectly involved
  with mass movements
• Water fills pore spaces between sediments,
  reduces internal resistance, adds weight because
  water is heavier than air.

• Affects
• Decreasing stability when slope becomes saturated

• Slumps or slides can occur years after deep water
  infiltration
• Can erode base of slope decreasing stability
• Change angle of repose
• Example building a sand castle

19

• Water Erosion
• Stream or wave erosion may remove material
  creating steeper slope thus reducing safety
  factor
• May reactivate old landslides
• Liquefaction
• Some clays behave as liquid and flow when
  disturbed
• Does not always require earthquake, can occur
  through toe erosion, which is erosion on the base
  of a landform.

20
Water's Role In Mass Movement Before Slide
21
Water's Role In Mass Movement After Slide
22
F. Role of Time

• Forces on slopes often change with time
• Driving and resisting forces can change
  seasonally as water content changes
• Chemical weathering introduces elements into
  soils which change properties

A slope that is becoming less stable with time
may exhibit increasing creep until failure occurs
23
V. Types of Mass Movements

• Important variables in classifying downslope
  movement of Earth materials are
• Types of mass movements
• slide, slump, fall, flow, subsidence, or complex
• Slope material
• Amount of water
• Rate of movement

24

• Slide -downslope movement of Earth material

25
Blackhawk Landslide, California

• Started as slide
• Rode on blanket of air
• Was pulverized when hit the base of slope
• Created debris blanket 10-30 m thick

26
Geology of Sheep Mountain Slide
27
Geology of Sheep Mountain Slide
Source Breck P. Kent
28
Yosemite National Park, California

• Fall -free fall of Earth material
• Rock fall- piece of rock on a steep slope becomes
  dislodge and falls down the slope.
• Debris falls- involves a mixture of soil,
  regolith, vegetation and rocks

29

• Debris Avalanche - very rapid downslope movement
  of soil, rock, organic debris

In lt2 minutes 40 million cubic yards of rock
covered the town of Frank, Alberta, Canada, in
1903
30

• Avalanche
• Rapid downslope movement of snow and ice
  sometimes with rock, soil, and trees
• Often begins with slab weighing millions of tons,
  falling from an overloaded slope
• Can travel as much as 62 mph
• Tend to travel down chutes where previous
  avalanches have flown

31
(No Transcript)
32
Before the Yungay Avalanche
Source Lloyd S. Cluff
33
After the Yungay Avalanche
Source Lloyd S. Cluff
34

• Flow - downslope movement of unconsolidated Earth
  material saturated with water
• particles within also move with respect to each
  other

• Debris Flow - gt50 of particles coarser than sand
• Velocities between 1 meter/yr to 100 meters/hr
• Mudflow - gt50 of particles finer than sand
• Consistency between soup like and wet concrete
• Velocity up to 50 mph

35

• Lahar - mudflow produced when large volume of
  volcanic ash and ejecta becomes saturated with
  water

Armero, Nevado Del Ruiz, 1985
36
Mt. Sopris, Colorado

• Rock Glacier- mass or rock and ice frozen
  together and flowing downslope

37

• Creep Heave - slow, imperceptible downslope
  movement of unconsolidated Earth material
• Often related to seasonal effects and/or
  precipitation rates
• Slow Flow

38
(No Transcript)
39
Source Peter L. Kresan
40
Source John S. Shelton
41
(No Transcript)
42

• Slump - rock or soil moving downslope along
  curved slip plane producing slump blocks

Black Hills, N.D.
43

• Subsidence - sinking of mass of Earth material
  below level of surrounding material
• can occur on slopes or flat ground

San Joaquin Valley, California
44

• Subsidence can occur as a result of
• Withdrawal of groundwater
• Withdrawal of oil and gas
• Dissolution of limestone
• Mining (coal, ore, salt)
• See Lake Peigneur example in book
• Subsidence can cause earth fissures and sinkholes

45
La Conchita, California, 1995

• Landslide - complex combinations of sliding and
  flow

46
La Conchita Complex Landslide
47
Turtle Mountain Landslide
48
Turtle Mountain Landslide
Source Betty Crowell/Faraway Places
