Title: Chapter 5: Structure and Function of Macromolecules


1
Chapter 5Structure and Functionof
Macromolecules
2
Polymers Most macromolecules are polymers
  • Definition Large molecule consisting of many
    identical or similar subunits connected together
  • Monomer Subunit or building block molecule of a
    polymer
  • Macromolecule Large organic polymer 4
    classes carbohydrates, lipids, proteins, nucleic
    acid

3
D. Making and breaking polymers
4
1. Polymerization reactions
  • Chemical reactions that link two or more small
    molecules to form larger molecules with repeating
    structural units

5
2. Condensation reactions (dehydration synthesis)
  • polymerization reactions during which monomers
    are covalently linked, producing a net removal of
    a water molecule for each covalent linkage
  • One monomer losses OH, the other one loses H
  • Requires energy and enzymes

6
3. Hydrolysis
  • A reaction that breaks covalent bonds between
    monomers by the addition of water molecules
  • One monomer gains OH, the other gains H
  • Digestive enzymes catalyze hydrolytic reactions

7
Linking Molecules Together
8
Carbohydrates
  • Organic molecules made of sugars and their
    polymers

9
A. Monosaccharide - Simple sugar in which C, H, O
occur in ratios of CH2O, carbons 3-7
  • Major nutrient for cells, especially glucose
  • Produced through photosynthesis store energy
    from the sun
  • Aldehyde terminal carbon forms a double bond
    with oxygen
  • Ketone carbonyl group within the carbon
    skeleton
  • Ring and linear forms in aqueous solutions,
    many monosaccharides form rings. Chemical
    equilibrium favors ring structure

10
(No Transcript)
11
(No Transcript)
12
B. Disaccharides - Double sugar that consists of
two monosaccharides joined by a glycosidic linkage
  • Glycosidic linkage Covalent bond formed by a
    condensation reaction btwn 2 sugar monomers
  • Maltose (glucose glucose)
  • Lactose (glucose galactose)
  • Sucrose (glucose fructose)

13
(No Transcript)
14
C. Polysaccharides- Polymers of a few hundred or
thousand monosaccharides
  • Storage Polysaccharides cells hydrolyze storage
    polysaccharides into sugars as needed, alpha 1,4
    linkages
  • Starch Glucose polymer, plant storage
  • Stored in granules in plastids
  • Amylase, unbranched
  • Amylopectin, branched
  • Glycogen glucose polymer, animal storage
  • Large polymer, highly branched
  • Stored in muscle and liver vertebrates

15
(No Transcript)
16
Polysaccharides cont.
  • Structural polysaccharides
  • Cellulose linear unbranched polymer of
    D-glucose in beta 1,4 linkages (-OH of C1 in up
    position)
  • Major structural component of plant cell walls
  • Chitin amino sugar polymer
  • Exoskeleton in arthropods
  • Found in cell walls of some fungi

17
Lipids Nonpolar
18
A. Fats - Macromolecules constructed from
  • Glycerol 3 carbon alcohol
  • Fatty Acid (carboxylic acid)
  • Carboxyl group (head) at one end functions as
    an acid
  • Hydrocarbon carbon (tail) at other end,
    nonpolar, usually 16-18 Cs long
  • Ester linkage Bond formed between the hydroxyl
    of glycerol and the carboxyl of fatty acid by
    condensation
  • Triacylglycerol A fat composed of three fatty
    acids bonded to one glycerol by ester linkages
    (triglyceride)

19
(No Transcript)
20
5. Characteristics of fat
  • Insoluble in water due to hydrophobic fatty acid
    chains
  • Variation among fat molecules due to fatty acid
    composition
  • Fatty acids may all be the same or different
  • Fatty acids vary in length

21
Characteristics of fat cont.
  • Saturated fat
  • No double bonds between Cs in the tail
  • Cs bonded to maximum number of Hs (saturated)
  • Usually solid at room temperature
  • Most animal fats
  • Unsaturated fat
  • One or more double bonds between Cs in tail
  • Tail kinks at each CC. So molecules do not pack
    closely enough to solidify at room temperature
  • Usually liquid at room temperature
  • Most plant fats (oils)

22
(No Transcript)
23
Characteristics of fat cont.
  • Functions
  • Energy storage (9 Cal/g)
  • Cushions vital organs in mammals (kidneys)
  • Insulates against heat loss

24
6. Phospholipids - glycerol, 2 fatty acids,
phosphate group
  • Hydrophilic head (phosphate group)
  • Hydrophobic tail (fatty acids)
  • Major constituents of cell membranes

25
(No Transcript)
26
Phospholipid bilayer separates the inside of
the cell from the outside of the cell, only water
and small ions can pass through
27
7. Steroids - four fused carbon rings with
various functional groups attached
  • Cholesterol
  • Precursor to many other steroids including
    vertebrate sex hormones and bile acids
  • Component of animal cell membranes
    stabilization and rigidity
  • Can contribute to atherosclerosis

28
Proteins
  • Molecular tools for most cellular function
    Consists of one or more polypeptide chains folded
    and coiled into specific conformations

29
Polypeptide Chains polymers of amino acids
that are arranged in a specific linear sequence
and are linked by peptide bonds
30
B. Function
  • Structural Support
  • Storage (of amino acids)
  • Transport (e.g. hemoglobin)
  • Signaling (chemical messengers)
  • Cellular response to chemical stimuli (receptor
    proteins)
  • Movement (contractile proteins)
  • Defense against foreign substances and disease
    causing organisms (antibodies)
  • Catalysis of biochemical reactions (enzymes)

31
C. Properties
  • Abundant 50 or more of cellular dry weight
  • Vary extensively in structure unique 3D shape
    (conformation)
  • Made up of 20 amino acid monomers in different
    amounts and combinations

32
D. Amino Acids - building block molecules of a
protein
  • Structure Asymmetric carbon, alpha carbon,
    bonded to
  • Hydrogen atom
  • Amino group
  • Carboxyl group
  • Variable R group (side chain) specific to each aa

33
  • Grouped by properties of side chains
  • Nonpolar side groups hydrophobic
  • Polar side groups hydrophilic
  • Uncharged polar
  • Charged polar
  • Acidic side groups dissociated carboxyl group
    negative charge
  • Basic side groups amino group w/extra proton
    positive charge

34
(No Transcript)
35
(No Transcript)
36
E. Polypeptide Chains - polymers formed when
amino acids polymerize
  • Peptide bond Covalent bond formed by a
    condensation reaction that links the carboxyl
    group of one amino acid to the amino acid group
    of another
  • Backbone - N C C N C C N -

37
F. Protein Conformation 3D shape of a protein
function is dependent on structure
  • Protein Structure
  • Primary
  • Secondary
  • Tertiary
  • Quarterary

38
Primary structure - Unique sequence of amino
acids
  • Determined by genes
  • Slight change can significantly affect
    conformation

39
b. Secondary structure - Regular, repeated
coiling and folding of a proteins polypeptide
backbone
  • Contributes to overall structure
  • Stabilized by H bonds between peptide linkages in
    the protein backbone
  • Alpha Helix helical coil stabilized by
    H-bonding between every 4th peptide bond
  • Found in fibrous proteins (keratin, collagen) for
    most of their length and some portions of
    globular proteins
  • Beta Pleated Sheets sheets of antiparallel
    chains folded into accordion pleats
  • Make up dense core of globular protein and major
    portion of some fibrous proteins

40
Hydrogen bonds
41
c. Tertiary structure - Irregular contortions of
a protein due to bonding between side chains (R
groups) third level of protein structure
superimposed upon primary and secondary structure
  • Weak interactions
  • H-bonding between polar side chains
  • Ionic bonds between charged side chains
  • Hydrophobic interactions between nonpolar side
    chains in proteins interior
  • Covalent linkages Disulfide bridges form
    between two cysteine monomers strong bond

42
(No Transcript)
43
d. Quaternary structure - Structure that results
from the interaction among polypeptides in a
single protein
44
Folding due to hydrophilic and hydrophobic amino
acids
45
G. Denaturation - A process that alters a
proteins native conformation and biological
activity caused by
  • Transfer to an organic solvent (nonpolar)
  • Chemical agents can disrupt H bonds, ionic bonds,
    and disulfide bridges
  • Excessive heat
  • Inappropriate pH

46
(No Transcript)
47
V. Nucleic Acids - Protein conformation is
determined by primary structure. Primary
structure is determined by genes (DNA sequences)
48
A. DNA Deoxyribonucleic Acid
  • Contains coded info that programs all cell
    activity
  • Contains directions for its own replication
  • Is copied and passed from 1 generation of cells
    to another
  • In eukaryotic cells, found primarily in the
    nucleus
  • Genes direct the synthesis of RNA

49
B. RNA Ribonucleic Acid
  • Functions in the actual synthesis of proteins
    coded for by DNA
  • Sites of protein synthesis are on ribosomes in
    the cytoplasm
  • mRNA carries genetic message from nucleus to
    cytoplasm

50
C. Nucleotides building blocks of a nucleic
acid
  • Pentose 5-carbon sugar (RNA/ribose
    DNA/deoxyribose)
  • Phosphate group attached to a number 5 carbon of
    the sugar
  • Nitrogenous base
  • Pyrimidine six-membered ring made up of carbon
    and nitrogen atoms
  • Cytosine (C)
  • Thymine (T) found only in DNA
  • Uracil (U) found only in RNA
  • Purine 5 membered ring fused to a 6 membered
    ring
  • Adenine (A)
  • Guanine (G)

51
(No Transcript)
52
Nucleotides cont.
  • Function
  • Monomers for nucleic acids
  • Transfer chemical energy from one molecules to
    another (ATP)
  • Are electron acceptors in enzyme controlled redox
    reactions (NAD)
  • Phosphodiester linkages between phosphate of one
    nucleotide and sugar of the next

53
DNA Structure
  • Two nucleotide chains wound in a double helix
  • Sugar-phosphate backbones are on the outside of
    the helix
  • Nitrogenous bases are paired in the interior of
    the helix and held together by H bonds
  • A-T and C-G pairing

54
What You Need to Know About Ch.5
55
The Principles of Polymers
  • List the four major classes of macromolecules.
  • Distinguish between monomers and polymers.
  • Draw diagrams to illustrate condensation and
    hydrolysis reactions.

56
Carbohydrates Serve as Fuel and Building Material
  • Distinguish between monosaccharides,
    disaccharides, and polysaccharides.
  • Describe the formation of a glycosidic linkage.
  • Distinguish between the glycosidic linkages found
    in starch and cellulose. Explain why the
    difference is biologically important.
  • Describe the role of symbiosis in cellulose
    digestion.

57
Lipids are a Diverse Group of Hydrophobic
Molecules
  • Describe the building-block molecules, structure,
    and biological importance of fats, phospholipids,
    and steroids.
  • Identify an ester linkage and describe how it is
    formed.
  • Distinguish between saturated and unsaturated
    fats.
  • Name the principal energy storage molecules of
    plants and animals.

58
Proteins have Many Structures and Many Functions
  • Distinguish between a protein and a polypeptide.
  • Explain how a peptide bond forms between two
    amino acids.
  • List and describe the four major components of an
    amino acid. Explain how amino acids may be
    grouped according to the physical and chemical
    properties of the R group.
  • Explain what determines protein conformation and
    why it is important.
  • Explain how the primary structure of a protein is
    determined.
  • Name two types of secondary protein structure.
    Explain the role of hydrogen bonds in maintaining
    secondary structure.
  • Explain how weak interactions and disulfide
    bridges contribute to tertiary protein structure.
  • List four conditions under which proteins may be
    denatured.

59
Nucleic Acids Store and Transmit Hereditary
Information
  • List the major components of a nucleotide, and
    describe how these monomers are linked to form a
    nucleic acid.
  • Distinguish between
  • pyrimidine and purine
  • nucleotide and nucleoside
  • ribose and deoxyribose
  • 5 end and 3 end of a nucleotide
  • Briefly describe the three-dimensional structure
    of DNA.
Write a Comment
User Comments (0)
About PowerShow.com
