Department of Electrical and Computer Engineering

1
Multilevel Solver for Continuous Markov Chains

• Daniel Chen
• Xiaolan Zhang

2
Outline

• Motivation
• Introduction to multilevel solver
• Gauss-Seidel algorithm (GS)
• Horton-Leutenegger Multilevel algorithm (ML)
• Our automatic aggregation algorithm (2AGG)
• Implementation
• Results
• Lecture notes example
• M/M/1/1000 queue example
• Molloys closed queuing network example
• Conclusion

3
Motivation

• Markov system generated by modeling tool
  generally has large number of states
• Steady state solution must be solved numerically
  - Power, Gauss-Seidel, and SOR.
• Many iterations required to reach convergence.
• When modeling complex system
• When high precision is required
• When the transition rate has large variance

4
The idea of iteration
If we define
and put
, we find
5
Gauss-Seidel algorithm
6
GS Example
7
Multi-level algorithm
8
Multi-level Algorithm
Solve Directly
Smoothing by running GS
Construct upper level steady state distribution -
q
Construct upper level rate transition matrix - P
Call MSS with the upper level q and P
Correct the result in the lower level
9
ML Example
Create upper level matrix
10
States aggregation

• Aggregation of states is essential to the success
  of ML algorithm.
• Optimal aggregation makes most out of GS
  smoothing at each level and reduces the number of
  levels (recursion in MSS).
• Searching for the optimal strategy for grouping
  any number of states could be difficult.
• We provide a heuristic aggregation criteria for
  grouping two states.

11
Two-state aggregation (2AGG)

• An automatic aggregation tool analyzing the rate
  transition matrix.
• Group states in a unit of two.
• Start with states of maximum out degree.
• For each state, greedy search a mate in all
  available states. The mate state should present
  the following three properties to the given
  state
• Strong connection
• Similar magnitude in transition rate
• Preferable high transition rate
• Determine unit one by one until exhaust the state
  space.

12
Mutual communication
Similar magnitude
Maximum rate
13
Implementation

• Linked adjacency list to save space. However have
  penalty on ML speed. Matrix search function has
  been accelerated for ML.
• GS algorithm.
• ML algorithm for neighboring state aggregation at
  all levels.
• 2AGG algorithm.
• Pre-process function to permute states with the
  mate state. Better aggregation provided.
• Only preprocess at the first level. Future
  improve expected if applied on all levels.

14
Comparison metrics and results

• Fair comparison between GS and ML.
• Reflects the implementation potential of ML.
• Three metrics
• Number of total GS iterations
• For ML number of MSS iterations x total number
  of GS calls in each iteration x GS iterations at
  each call (v).
• Disadvantage to ML because the size matrix being
  smoothed is reduced at upper level.
• Number of floating point operations (nflop)
• Count multiplication, division and beyond.
• Rough but reflects the computational complexity
  of ML without memory overheads.
• CPU processing time
• Most fair comparison on a particular
  implementation.
• Lack of insight on overhead improvements.

15
Lecture notes example

• Show the advantage of ML on Markov chain with
  obvious bottleneck rate transitions.
• Show the importance of aggregation choices

16
Lecture notes example
17
Lecture notes example
18
Lecture notes example
19
M/M/1/1000 queue

• Birth-death chain with asymmetric rate flows.
• 2AGG tool is not applicable.
• Show how death rate u affects the performance.
• Understand different performance metrics.

20
M/M/1/1000 queue
21
M/M/1/1000 queue
22
M/M/1/1000 queue
23
Molloys closed queuing network

• Show how increment of state space affects the
  performance.
• Change the number of states by number of tokens
  initially put at place P.
• ML-p is the version integrated with 2AGG at the
  first level.

24
Molloys closed queuing network
25
Molloys closed queuing network
26
Conclusion and future work

• Aggregation strategy is very important.
• The result is mostly case-wise.
• Overhead cost of ML impairs the overall
  performance.
• Challenges lies on the demand of intelligent
  tools to improve ML and the control of overhead
  cost.
• Future work
• Determine optimal number of GS smoothing at each
  level.
• Extend aggregation tool to arbitrary state
  grouping at all levels.
• Improve Q matrix data structure to reduce memory
  access overheads.

27
References

• G. Horton, S. Leutenegger, A Multi-Level
  Solution Algorithm for Steady-State Markov
  Chains.
• W. H. Sanders, Lecture Notes for ECE/CS 541 and
  CSE 524 Computer System Analysis.
• PERFORM group, Mobius User Manual.

28
Multilevel Solver for Continuous Markov Chains

• Daniel Chen
• Xiaolan Zhang

29
Lecture notes example
30
Lecture notes example
31
Molloys closed queuing network
