TCPPeach: A New Congestion Control Scheme for Satellite IP Networks

1
TCP-Peach A New Congestion Control Scheme
forSatellite IP Networks

• ?????
• ???????
• Date09/27

2
Author Source

• Author
• Akyildiz, I.F. Morabito, G. Palazzo, S
• Source
• Networking, IEEE/ACM Transactions onVolume 9,
  Issue 3,  June 2001 Page(s)307 - 321

3
Outline

• Introduction
• TCP-Peach
• Sudden Start
• Rapid Recovery
• Simulation Result
• Conclusion

4
Introduction

• In satellite networks, TCP throughput decreases
  because
• the long propagation delays
• high link error rates
• In this paper, we introduce TCP-Peach, a new
  congestion control scheme for satellite networks
  which is an end-to-end solution to improve the
  throughput performance in satellite networks.

5
The Performance Problem with Long Propagation
Delay

• In the beginning of a new connection, the sender
  enters the Slow Start Phase to probe the
  availability of bandwidth , the time required by
  the Slow Start to reach a bit rate B is

RTT Round Trip Time l average packet length
expressed in bits B Bit Rate
6
Table 1. DURATION OF THE SLOW START
PHASE FOR LEO, MEO, AND GEO
SATELLITES (With average Packet Size
(l)1Kbytes)
7
Proposed solutions for the performance problems
of Slow Start in long propagation delay networks

• Increasing Initial Window (IIW)
• TCP Spoofing
• TCP Splitting
• Fast Start

8
The throughput of IW1 and IW4 with BER0
9
The throughput of IW1 and IW4 with BER10-4
10
TCP Spoofing

• A router near the source sends back ACKs for TCP
  packets in order to give the source the illusion
  of a short delay path.
• TCP Spoofing has some problems
• The router must analyze TCP header. But current
  router just analyze IP header. So it exceed its
  ability.
• TCP Spoofing requires ACKs to flow through the
  same path as data.
• If IP (Data Field) encryption is used, the scheme
  cannot be applied.

11
TCP Splitting

• TCP connection is divided into multiple
  connections.
• This solution has the same problems as TCP
  spoofing with the exception of Problem 2 .

12
Fast Start

• The basic idea of the Fast Start is to reuse the
  values of the transmission rate from the recent
  past.
• The TCP packets transmitted during this Fast
  Start period are carried by low-priority IP
  packets.

13
Fast Start (Cont.)

• Fast Start has some Problems
• The transmitted low-priority packets carry new
  information to the receiver, thus, they are still
  data packets, and if they are lost, then they
  must be recovered.
• Fast Start can be used only if for the same path.
  This requires that within a short time the same
  server (sender) transfers several files to the
  same user (receiver), which may often not be the
  case.

14
The performance problem with Error Rate

• TCP was initially developed for wire-line
  networks where the link error rate is low, such
  that the majority of the packet losses is due to
  network congestions.
• Satellite networks have several orders of
  magnitude higher error rates than the wire-line
  networks.

15
The performance problem with Error Rate (Cont.)

• In other paper, the author suggest to decouple
  error control and congestion control
• TCP would then be responsible only for congestion
  control while the error control is handled by the
  link layer.
• The link layers of all sub-networks composing the
  Internet need to be redesigned.

16
TCP-Peach
TCP-Peach
17
Dummy Packets

• Low priority packets generated by the sender as a
  copy of the last transmitted data packet. (They
  do not carry any new information.)
• The sender uses dummy packets to probe the
  availability of the network resources.

18
Sudden Start

• The sudden start algorithm is executed at the
  beginning of a new connection in order to avoid
  the low throughput performance of slow start.
• For the sender, an ACK for a dummy packet is the
  sign that there are still unused resources in the
  network.
• During the sudden start the sender transmits one
  data packet and (rwnd 1) dummy packets.

19
Sudden Start (Cont.)

• In this phase, the sender will increase its
  congestion window, cwnd, by one packet each time
  it receives an ACK for a dummy packet.
• At the end of the sudden start algorithm, the
  transmission rate for the new connection suddenly
  jumps from (1/RTT) to (nAbsorbed/RTT) .
• The cwnd reaches rwnd within 2RTTs.

The number of dummy packets the network is able
to absorb
20
Comparison of TCP-Peach and TCP-Reno in the
beginning of a new connection (rwnd64 packets)
The cwnd of TCP-Reno reaches rwnd within 7RTT
The cwnd of TCP-Peach reaches rwnd within 2RTT
21
Rapid Recovery

• Objective Solving the throughput degradation
  problem due to link errors.
• When a packet loss is detected through ndup
  duplicate ACKs, the original Fast Retransmit
  scheme is used.
• After completing the Fast Retransmit scheme, we
  apply the Rapid Recovery scheme .

22
Rapid Recovery (Cont.)

• The rapid recovery algorithm first keeps the fast
  recovery conservative assumption that all packet
  losses are due to network congestion.
• Accordingly, the TCP sender halves cwnd.
• If the packet loss is due to link errors, the
  dummy packets will reach the receiver and be
  acknowledged to the sender, which will increase
  cwnd.

23
Rapid Recovery
nDummy is Double of Current cwnd which is at
begin of Rapid Recovery
24
The Behavior of Rapid Recovery with RTT0.26Secs
Packet Loss due to Link Error
½ RTT
Last for 1RTT
25
Simulation Experiments

• N20 , rwnd64 packets
• Earth Station buffer K50 packets, RTT500ms
• tsimulation 500secs

26
Goodput performance comparison of TCP-Peach and
TCP-Reno for different values of Ploss
(c1300packets/sec)
27
Goodput performance comparison of TCP-Peach and
TCP-Reno for different values link capacity C
(Ploss10-2)
28
Transmission of files of S 50 segments average
goodput
TCP-Peach
TCP-Reno
IIW
29
Fairness evaluation in heterogeneous scenario
RTTX500ms(satellite link)
RTTY200ms(terrestrial Link) PLOSS,X0, 10-4,
10-3, 10-2 PLOSS,Y0 NM5 K50packets Rwnd64pack
ets
30
Fairness evaluation in heterogeneous scenario
Homogeneous scenario
31
CONCLUSION

• TCP-Peach is based on the use of dummy packets
  that do not carry any new data to the receiver.
• TCP-Peach requires the routers along the
  connection to implement some priority mechnism at
  the IP layer.
• TCP-Peach contains two new algorithms Sudden
  Start Rapid Recovery
• TCP-Peach improves the goodput performance and
  fairness in satellite networks
