Application Development (Current toolkits and
approaches for grid-enabling applications)

• Hartmut Kaiser hkaiser_at_cct.lsu.edu
• Center of Computation and Technology
• Louisiana State University

2
Basic Grid Model
Grid Applications
New devices Sensors Wireless
Common policies Grid Economy Global networks
Application Grid Middleware
Common Infrastructure
Global Resources
3
Why another Grid-API?

• The situation today
• Grids everywhere
• Supposedly. At least many projects ?
• Grid applications nowhere
• Almost. At least our experience shows that this
  is difficult, GGF APPS group
• Why is this?
• Application programmers accept the Grid as a
  computing paradigm only very slowly.
• Problems (multifold and often cited - amongst
  others)
• Interfaces are NOT simple (see next slides. . .)
• Typical Globus code... ahem... ?
• Different and evolving interfaces to the Grid
• Versions, new services, new implementations, WSDL
  does not solve all problems at all
• Environment changes in many ways
• Globus, grid members, services, network,
  applications, ...

4
Dynamic Middleware

• Globus, Unicore, my_service, your_service, . . .
• The same functionality has different interfaces
  all over the place.
• But you don't want to recompile your app every
  time, not to speak of recoding...
• WSDL does not mean end of all problems (see CoG
  code), but begin of new ones... - on application
  level, WSDL is not trivial enough
• Restricting yourself to Globus does not help
  either version changes every couple of months
• (2.4.x, 3.2.y, 4.a.b)
• and gets bug fixes. Changes often are MAJOR - we
  have seen a number of them over the last couple
  of years...
• The application that runs today will fail
  tomorrow!
• Right now, it is basically impossible for a
  programmer to focus on the science, not on IT
  (i.e. Grid) problems.

5
Dynamic Grids

• Services (and interfaces) get exchanged
  (upgraded) on regular basis
• That is related to the point above, but also a
  social problem!
• Institutions (resources, services, applications)
  join/leave YOUR grid without (much) notice.
• The grid is designed to ease and simplify that
  kind of fluctuation - its not a bug, its a
  feature!
• But the applications are not able to make use of
  that feature right now
• The Grid changes AT RUNTIME services go down,
  resources get busy/free, disks and storage nodes
  are empty/full, . . . THINGS CONSTANTLY CHANGE.
• Today Grid middleware allows to cope with that,
  but utilizing that in an intelligent way is a
  major programming effort, and blows the
  application with code that needs constancy
  maintenance...
• Applications need LOTS of code for handling
  transient problems.
• Most applications share most of these problems,
  but code reuse is difficult/impossible.
• We can reuse the Globus libraries, right, but
  isn't every project re-inventing its own
  abstraction layer for these? In our
  experience/projects they do!
• Arent we all re-inventing abstraction layers for
  this all the time?

6
Existing frameworks

• Specialized client side libraries
• Globus pre-WS C client bindings
• Webservice (WS) and Webservice resource Framework
  (WSRF) interfaces
• Globus
• Many other Grid Services out there...

7
Existing frameworks

• Commodity Grids (Java CoG) Kits
• Has over the years provided successfully access
  to grid services through the Java framework.
• Provides client and limited server side
  capabilities
• Significantly enhances the capabilities of the
  Globus Toolkit by introducing grid workflows,
  control flows, and a task based programming model
• More information at http//www.cogkits.org

8
Existing frameworks

• RealityGrid
• A UK e-Science pilot project that has used
  grid-based computational steering for a wide
  range of scientific applications
• is defined as any mechanism that enables the
  control of the evolution of a computation, based
  upon the real time analysis and visualization of
  the status of a simulation
• Oriented towards scientific computation, not a
  generic solution
• More information http//www.realitygrid.org/

9
Existing frameworks

• gLite (Lightweight Grid Interface)
• Provides own middleware stack and related stable
  application interfaces
• Job management
• Data management
• Information services
• Deployment modules
• Oriented towards EEGE project needs and
  middleware
• Very similar to the GAT
• More Information at http//www.glite.org

10
Copy a File Globus GASS
11
Copy a File CoG/RFT
12
Copy a File Wishful thinking

• include ltGAT.hppgt
• GATResult RemoteFileGetFile (GATContext
  context,
• stdstring source_url, stdstring
  target_url)
• try
• GATFile file (context, source_url)
• file.Copy (target_url)
• catch (GATException const e)
• stdcerr ltlt "Some error " ltlt e.what() ltlt
  stdendl
• return e.Result()
• return GAT_SUCCESS

13
Copy a File GAT/C

• include ltGAT.hppgt
• GATResult RemoteFileGetFile (GATContext
  context,
• stdstring source_url, stdstring
  target_url)
• try
• GATFile file (context, source_url)
• file.Copy (target_url)
• catch (GATException const e)
• stdcerr ltlt e.what() ltlt stdendl
• return e.Result()
• return GAT_SUCCESS

14
Code Statistics
15
Simplicity!

• The key objective for application programmers
• Remember an applications programmer is a
  physicist, chemist, linguist, medical
• Simple APIs should
• be easy to use
• Simple, finite, consistent API which allows error
  tracing
• be invariant make upgrades really, really simple
• Well defined API which rarely changes.
• Implementation which allows dynamic exchange of
  key elements and provides runtime abstractions.
• avoid refactoring/recoding/recompilation
• Same applications runs today and tomorrow here
  and there on Globus and Unicore on Globus 2.2.4
  and Globus 2.4 on Linux and on Mac local and on
  grid
• focus on well-known programming paradigms
• (e.g., for a file provide a file API without
  services to services to files. . .)
• Files are best example expect open, close, read,
  write, seek. Do not introduce fancy things like
  the need to ask a service discovery service to
  tell me the location of an service which is able
  to tell me the location of my file...

16
What Applications want

• ...and what they GAT
• Enough of 'we want this' and 'we dont want that'
  - you got the picture, right? So, here is what
  we do
• An API that allows to implement basic Grid use
  cases
• Stay simple! As simple as possible! But not
  simpler!
• Focus on applications, and scientists, rather
  than Grid nerds
• As you and me
• Next slides will give an overview of what we
  think is essential, and how we envision usage of
  that. Remind this is version 1 - our first shot
  - we know its not perfect, but we are converging
  to something we can work with already.

17
GAT API Scope

• Files
• Monitoring and Events
• Resources, Jobs
• Information Exchange
• Utility classes (error handling, security,
  preferences...)
• NOTHING ELSE

18
API Sub Systems

• The pipe stuff in the file subsystem is
  'historical, pipe is VERY simple - we don't do
  real communication and data exchange a la MPI!
• The actual API is somewhat larger (especially
  the resource part) 34 objects as opposed to 27
  shown here. BUT THATS IT!!!

19
Examples in GAT

• Read remote physical file
• Read a logical file
• Spawn a Subtask
• Migrate a Subtask

20
Read a remote File

• try
• char data25
• GATFileStream file (context, source_url)
• file.seek (100, SEEK_SET)
• file.read (data, sizeof(data))
• catch (GATException const e)
• stdcerr ltlt "Some error " ltlt e.what() ltlt
  stdendl
• return e.Result()
• Well known paradigm.
• Whatever service/lib/... implements that, the
  programmer does not know (no reference to
  Globus... ?)
• Whatever the URL/protocol (ftp//, gsiftp//,
  http// file//) no code changes! No service
  specific parameter settings (can be drawback BUT
  SIMPLIFIES)

21
Read a logical file

• try
• GATLogicalFile logical_file (context,
  name)
• stdlistltGATFilegt files
• logical_file.get_files()
• files.front().Copy(dest_url)
• catch (GATException const e)
• stdcerr ltlt "Some error " ltlt e.what()
• ltlt stdendl
• return e.Result()
• SAME paradigm 'private name space
• URL Unknown! Service unknown! complete
  abstraction gt Virtualization!
• Still simple

22
Spawn a Subtask

• GATTable sdt sdt.add ("location",
  "/bin/date")
• GATTable hdt hdt.add ("machine.type",
  "i686")
• GATSoftwareDescription sd (sdt)
• GATHardwareResourceDescription hrd (hdt)
• GATJobDescription jd (context, sd, hrd)
• GATResourceBroker rb (context, prefs)
• GATJob j rb.submit (jd)

23
Migrate a Job

• GATTable sdt sdt.add ("location",
  "/bin/sleep")
• sdt.add ("arguments",
  "36000")
• GATTable hdt hdt.add ("machine.type",
  "i386")
• GATSoftwareDescription sd (sdt)
• GATHardwareResourceDescription hrd (hdt)
• GATJobDescription jd (context, sd, hrd)
• GATResourceBroker rb (context, prefs)
• GATJob job rb.submit (jd)
• hdt.set ("machine.name", "fs0.das2.cs.vu.nl")

• stdlistltGATResourcegt resources
  rb.find_resources (hrd)
• job.Migrate (resources0)
• if (GATJobState_Running job.GetState ())

24
How does it work?

• Architecture
• Timing diagrams

25
Architecture
26
Architecture

• API is a very thin layer, provides no
  capabilities by itself
• (bind to the Grid-Environment)
• Adaptors implement capabilities mirroring the API
• Engine mediates between API and adaptors
• switch adaptors at runtime (shared libraries)
• error tracing and fallback mechanisms
• (default local adaptor set)
• CPI is also well defined - adaptors are
  interchangeable

27
GAT Engine Initialisation
28
Making an API Call
29
An API Call
30
State of Affairs

• API Status
• Implementation
• Demo

31
API Status

• Version 1.6
• Is object oriented, but language neutral
• Defines syntax and semantics of GRID access
• Specification is open process
• Hopefully gets input from many communities
• Will evolve along with the findings of GGFs new
  SAGA-WG (Simple APIs for Grid Applications)

32
Implementation (Engine)

• C Version fully implemented
• C Wrapper to C fully implemented
• Python wrapper to C (90 completed)
• Java Version fully implemented
• Even adaptor writing is possible in all of the
  languages, (mixed language programming possible
  at least for C/C and Python)
• Fortran, Perl (wrappers to C) to follow (SWIG?)
• Focus portability, lightness, flexibility,
  adaptivity

33
Implementation (Adaptors)

• Full set of local adaptors implemented (contained
  in the download)
• Couple of external adaptors implemented as well
  (GridLab services, Globus)
• Lots of adaptors currently under development
  (DRMAA, GRAM, Curl/wget etc.)
• http//www.gridlab.org/WorkPackages/wp-1/adaptorre
  leases.html

34
Demo

• Copying a file
• Locally
• Remotely

35
Open problems

• Memory management is very tedious in the C
  version
• User has to do a lot by himself
• Track all GAT object instance copies
• Free all GAT object instances
• Call constructor and destructor
• Error handling is complicated (even with macros)
• Always check for error codes, cluttered code.
• All of these problems are solved by the C and
  Python wrappers use these if possible!
• Current implementation of the GAT is not thread
  safe
• Asynchronicity is (almost) completely missing

36
SAGA Simple API for Grid Applications

• A GGF standardization effort that provides a
  simple, stable, and uniform programming interface
  that integrates the most common grid programming
  abstractions.
• Think of it as GAT V2, incorporating the lesson
  weve learned
• Asynchronous by design, synchonous API on top
• Modular architecture allows
• Later extensions
• Smooth migration from GAT
• Minimal library footprint for concrete needs
• Integrates well with other standards developed by
  the GGF (GridRPC, DRMAA etc.)

37
Conclusions

• The GAT provides a simple and stable API to
  various Grid environments
• It is used as a prototype implementation for the
  ongoing standardization process at the SAGA WG of
  the GGF
• Downloads
• http//www.gridlab.org/wp-1/
• Currently, snapshots available for GAT V1.6
• Platforms Linux, Windows, Mac OS X, SGI Irix,
  True64 UNIX
• Support via mailing list gat_at_gridlab.org
