NAT requirements for TCP(BEHAVE WG)

• draft-sivakumar-behave-nat-tcp-req-00.txt

S.Sivakumar, K.Biswas, B.Ford
2
Scope

• Recommendations to NAT implementors as pertaining
  to TCP session processing.
• At the time of writing of this draft,
  ltdraft-ford-behave-gen-00.txtgt was not available.
  Recommendations that are not specific to TCP or
  UDP will be moved to ltdraft-ford-behave-gen-00.txt
  gt, pending WG consensus.

3
Req 1 TCP State Machine(SM)

• TCP NAT Sessions MUST be stateful. NAT MUST use
  light-weight TCP State Machine for managing
  timers, seq/ack adjustments etc.
• TCP NAT Sessions can be light-weight and must
  carry three states at a minimum STARTUP,
  ACTIVE, CLOSING.
• A TCP NAT Session enters STARTUP state upon
  seeing the first SYN for a TCP session.
• A TCP NAT Session enters ACTIVE state upon
  completing 3-way handshake.
• A TCP NAT Session enters CLOSING state upon
  seeing FIN or RST for the session.

4
Req 2 - Address/Port Binding

• NAT MUST maintain Address Binding and/or TCP Port
  Binding. Multiple TCP NAT Sessions could reuse
  the same TCP Port Binding.
• The filtering behavior of NAT for TCP sessions is
  as dictated by the NAT type (traditional,
  Bi-directional, Twice NAT types).
• Port parity, Port-contiguity - Some suggestions
  have been made to specifically mention about
  port-parity, port-contiguity not being applicable
  to TCP traffic. Needs discussion?

5
Req 3 TCP SM Timeouts

• NAT MUST maintain timeouts for different states
  of state machine in a TCP NAT Session.The
  timeouts MUST be configurable.
• NAT MUST maintain SYN Timer to protect against
  SYN flood-attacks in STARTUP state. Suggested
  timeout 30 to 60 secs.
• NAT MUST maintain Session Timer to track
  idle-time on active TCP sessions. Suggested
  timeout 60 mins if no KeepAlive implemented and
  120 minutes if KeepAlive implemented.
• NAT MUST maintain Close Timer, to allow for
  proper session termination, and to allow
  re-opening a recently closed or reset TCP session
  if desired. NAT can delete the TCP NAT session
  Upon expiry of Close timer, or enter STARTUP
  state and initiate SYN timer upon receipt of SYN.
  Suggested timeout 2xMSL (Maximum Segment
  Lifetime) to 60 seconds.

6
Req 3 TCP Keep-alive

• Upon Session Timer expiry, NAT SHOULD enter a
  "probe" state and send TCP keep-alive packets to
  internal endpoint.
• Upon receiving ACK or data traffic, NAT should
  reset Session Timer and remain in ACTIVE state.
• Upon receiving RST, NAT should forward the RST to
  External Server, enter CLOSING state and start
  Close Timer.
• Upon not receiving any response after a few
  retries, NAT should send RST to both parties,
  enter CLOSING state and start Close Timer.

7
Req 4 - Port Reservation

• NATs TCP Port space is shared by 2 functions
• (a) Routers local end-host functionality
• (b) Routers NAT functionality
• NAT MUST NOT use a single TCP port for both NATd
  sessions and local application sessions at the
  same time.
• Recommendation NAT implementers SHOULD set
  aside port-blocks for end-host functionality vs.
  NAT functionality.

8
Req 5 - IP Frags,TCP Segments

• IP Fragments Suggest moving this to
  draft-ford-behave-gen-00.txt
• TCP Segment processing - Recommended only when
  ALGs are enabled on the same NAT device. Not
  mandatory requirement.
• NAT SHOULD support TCP Segments received out of
  order. TCP Segment processing SHOULD be as
  described in the draft.
• NAT SHOULD enforce sequencing on the out-of-order
  TCP segments such that NAT reassembles the TCP
  segments prior to handing off to an ALG.
• NAT SHOULD send TCP ACK to the endpoint (when a
  segment is out of order) for obtaining subsequent
  segments from the endpoint.

9
Req 6 - Seq/Ack adjustment

• Recommendation for NAT only when ALGs are enabled
  on the same device. Not mandatory requirement.
• If NAT has ALG enabled, the ALG might cause
  application-payload to increase/decrease in size.
  The ALG will need to change seq/ack number in the
  TCP header save this information along with the
  delta of change in the TCP NAT Session, so as to
  adjust subsequent TCP packets of the session.
• If NAT has ALG enabled, the TCP NAT Sessions
  SHOULD be extended to include seq-delta,
  ack-delta info in the TCP NAT Session.

10
Req 7 - ICMP Err-Msg handling

• NAT SHOULD fix the embedded payload in the ICMP
  Error messages. This is not specific to TCP.
  Suggest moving this to draft-ford-behave-gen-00.tx
  t.

11
New Reqs (Not included yet)

• NAT must generate process PMTU msgs for TCP
  packets
• TCP packets often have DF(Donot Fragment) bit set
  will require devices enroute to not fragment
  TCP segments. If MTUs donot match, NAT MUST send
  a destination unreachable ICMP message with
  suggested MTU to the sender drop the TCP
  packet.
• NAT must also honor the ICMP destination
  unreachable messages it receives from
  intermediate nodes in either realm and forward to
  appr. end-node

12
Wrap-up

• Comments/Suggestions ?
• (We plan to summarize the requirements at the
  end, and move the text common to both TCP UDP
  to draft-ford-behave-gen-00.txt, based on WG
  inputs )
• Accept as WG item ?

13
Differences between 2 TCP submissions

• Both drafts (Sivakumar-draft
  Modadugu-draft) are similar in content. So,
  common Reqs are not listed. Below are the main
  differences
• TCP State Machine requirement
• sivakumar-draft states that NAT MUST maintain
  a light-weight TCP state-machine.
• modadugu-draft doesnot mandate this.

14
Differences between 2 TCP submissions

• Port reservation requirement
• sivakumar-draft recommends that NAT SHOULD
  set aside ports for local TCP applications
  running on the box and avoid port-number
  conflicts.
• modadugu-draft does not provide a
  recommendation.
• TCP Timers requirement
• sivakumar-draft recommends that NAT MUST
  maintain SYN, Session Close timers
• modadugu-draft discusses timers, but does
  not list them as a requirement.

15
Differences between 2 TCP submissions

• TCP KeepAlive requirement
• sivakumar-draft recommends this as a SHOULD,
  without making this a mandatory requirement
• modadugu-draft does not offer a
  recommendation (author believes this is not
  needed).
• TCP Segments handling requirement
• sivakumar-draft recommends this as a SHOULD
  only when ALG enabled on the NAT.
• modadugu-draft does not offer a
  recommendation (Author believes this is not
  needed)

16
Differences between 2 TCP submissions

• Allow Incoming SYN requirement
• sivakumar-draft does not offer an explicit
  recommendation on this.
• modadugu-draft recommends that NAT MUST allow
  incoming SYN while a Nat Session is alive (ex in
  CLOSING state)
• Paired Source-IP address pooling behavior
  requirement
• sivakumar-draft does not offer a
  recommendation on this.
• (draft-ford-behave-gen-00.txt covers this)
• modadugu-draft recommends that a NAT SHOULD
  support IP address pooling behavior of Paired,
  if NAT supports IP address pooling.

17
Differences between 2 TCP submissions

• Finally, some stylistic differences
• Sivakumar-draft lists the requirements as you
  go along. Summary requirements intended to be
  listed at the end.
• Modadugu-draft lists the requirments first
  similar to behave-udp draft, followed by
  discussion on the requirements.
