Sensor Technologies

1
Sensor Technologies
2
Phase Linearity

• Describe how well a system preserves the phase
  relationship between frequency components of the
  input
• Phase linearity fkf
• Distortion of signal
• Amplitude linearity
• Phase linearity

3
Sensor Technology - Terminology

• Transducer is a device which transforms energy
  from one type to another, even if both energy
  types are in the same domain.
• Typical energy domains are mechanical,
  electrical, chemical, magnetic, optical and
  thermal.
• Transducer can be further divided into Sensors,
  which monitors a system and Actuators, which
  impose an action on the system.
• Sensors are devices which monitor a parameter of
  a system, hopefully without disturbing that
  parameter.

4
Categorization of Sensor

• Classification based on physical phenomena
• Mechanical strain gage, displacement (LVDT),
  velocity (laser vibrometer), accelerometer, tilt
  meter, viscometer, pressure, etc.
• Thermal thermal couple
• Optical camera, infrared sensor
• Others
• Classification based on measuring mechanism
• Resistance sensing, capacitance sensing,
  inductance sensing, piezoelectricity, etc.
• Materials capable of converting of one form of
  energy to another are at the heart of many
  sensors.
• Invention of new materials, e.g., smart
  materials, would permit the design of new types
  of sensors.

5
Paradigm of Sensing System Design
Zhang Aktan, 2005
6
Instrumentation Considerations

• Sensor technology
• Sensor data collection topologies
• Data communication
• Power supply
• Data synchronization
• Environmental parameters and influence
• Remote data analysis.

7
Measurement

• Measurement output
• interaction between a sensor and the environment
  surrounding the sensor
• compound response of multiple inputs

• Measurement errors
• System errors imperfect design of the
  measurement setup and the approximation, can be
  corrected by calibration
• Random errors variations due to uncontrolled
  variables. Can be reduced by averaging.

8
Sensors

• Definition a device for sensing a physical
  variable of a physical system or an environment
• Classification of Sensors
• Mechanical quantities displacement, Strain,
  rotation velocity, acceleration, pressure,
  force/torque, twisting, weight, flow
• Thermal quantities temperature, heat.
• Electromagnetic/optical quantities voltage,
  current, frequency phase visual/images, light
  magnetism.
• Chemical quantities moisture, pH value

9
Specifications of Sensor

• Accuracy error between the result of a
  measurement and the true value being measured.
• Resolution the smallest increment of measure
  that a device can make.
• Sensitivity the ratio between the change in the
  output signal to a small change in input physical
  signal. Slope of the input-output fit line.
• Repeatability/Precision the ability of the
  sensor to output the same value for the same
  input over a number of trials

10
Accuracy vs. Resolution
11
Accuracy vs. Precision
Precision without accuracy
Accuracy without precision
Precision and accuracy
12
Specifications of Sensor

• Dynamic Range the ratio of maximum recordable
  input amplitude to minimum input amplitude, i.e.
  D.R. 20 log (Max. Input Ampl./Min. Input Ampl.)
  dB
• Linearity the deviation of the output from a
  best-fit straight line for a given range of the
  sensor
• Transfer Function (Frequency Response) The
  relationship between physical input signal and
  electrical output signal, which may constitute a
  complete description of the sensor
  characteristics.
• Bandwidth the frequency range between the lower
  and upper cutoff frequencies, within which the
  sensor transfer function is constant gain or
  linear.
• Noise random fluctuation in the value of input
  that causes random fluctuation in the output value

13
Attributes of Sensors

• Operating Principle Embedded technologies that
  make sensors function, such as electro-optics,
  electromagnetic, piezoelectricity, active and
  passive ultraviolet.
• Dimension of Variables The number of dimensions
  of physical variables.
• Size The physical volume of sensors.
• Data Format The measuring feature of data in
  time continuous or discrete/analog or digital.
• Intelligence Capabilities of on-board data
  processing and decision-making.
• Active versus Passive Sensors Capability of
  generating vs. just receiving signals.
• Physical Contact The way sensors observe the
  disturbance in environment.
• Environmental durability will the sensor robust
  enough for its operation conditions

14
Strain Gauges

• Foil strain gauge
• Least expensive
• Widely used
• Not suitable for long distance
• Electromagnetic Interference
• Sensitive to moisture humidity
• Vibration wire strain gauge
• Determine strain from freq. of AC signal
• Bulky
• Fiber optic gauge
• Immune to EM and electrostatic noise
• Compact size
• High cost
• Fragile

15
Strain Sensing

• Resistive Foil Strain Gage
• Technology well developed Low cost
• High response speed broad frequency bandwidth
• A wide assortment of foil strain gages
  commercially available
• Subject to electromagnetic (EM) noise,
  interference, offset drift in signal.
• Long-term performance of adhesives used for
  bonding strain gages is questionable
• Vibrating wire strain gages can NOT be used for
  dynamic application because of their low response
  speed.
• Optical fiber strain sensor

16
Strain Sensing

• Piezoelectric Strain Sensor
• Piezoelectric ceramic-based or Piezoelectric
  polymer-based (e.g., PVDF)
• Very high resolution (able to measure nanostrain)
• Excellent performance in ultrasonic frequency
  range, very high frequency bandwidth therefore
  very popular in ultrasonic applications, such as
  measuring signals due to surface wave propagation
• When used for measuring plane strain, can not
  distinguish the strain in X, Y direction
• Piezoelectric ceramic is a brittle material (can
  not measure large deformation)

Courtesy of PCB Piezotronics
17
Acceleration Sensing

• Piezoelectric accelerometer
• Nonzero lower cutoff frequency (0.1 1 Hz for
  5)
• Light, compact size (miniature accelerometer
  weighing 0.7 g is available)
• Measurement range up to /- 500 g
• Less expensive than capacitive accelerometer
• Sensitivity typically from 5 100 mv/g
• Broad frequency bandwidth (typically 0.2 5 kHz)
• Operating temperature -70 150 C

18
Acceleration Sensing

• Capacitive accelerometer
• Good performance over low frequency range, can
  measure gravity!
• Heavier ( 100 g) and bigger size than
  piezoelectric accelerometer
• Measurement range up to /- 200 g
• More expensive than piezoelectric accelerometer
• Sensitivity typically from 10 1000 mV/g
• Frequency bandwidth typically from 0 to 800 Hz
• Operating temperature -65 120 C

19
Accelerometer
20
Force Sensing

• Metal foil strain-gage based (load cell)
• Good in low frequency response
• High load rating
• Resolution lower than piezoelectricity-based
• Rugged, typically big size, heavy weight

Courtesy of Davidson Measurement
21
Force Sensing

• Piezoelectricity based (force sensor)
• lower cutoff frequency at 0.01 Hz
• can NOT be used for static load measurement
• Good in high frequency
• High resolution
• Limited operating temperature (can not be used
  for high temperature applications)
• Compact size, light

Courtesy of PCB Piezotronics
22
Displacement Sensing

• LVDT (Linear Variable Differential Transformer)
• Inductance-based ctromechanical sensor
• Infinite resolution
• limited by external electronics
• Limited frequency bandwidth (250 Hz typical for
  DC-LVDT, 500 Hz for AC-LVDT)
• No contact between the moving core and coil
  structure
• no friction, no wear, very long operating
  lifetime
• Accuracy limited mostly by linearity
• 0.1-1 typical
• Models with strokes from mms to 1 m available

Photo courtesy of MSI
23
Displacement Sensing

• Linear Potentiometer
• Resolution (infinite), depends on?
• High frequency bandwidth ( 10 kHz)
• Fast response speed
• Velocity (up to 2.5 m/s)
• Low cost
• Finite operating life (2 million cycles) due to
  contact wear
• Accuracy /- 0.01 - 3 FSO
• Operating temperature -55 125 C

Photo courtesy of Duncan Electronics
24
Displacement Transducer

• Magnetostrictive Linear Displacement Transducer
• Exceptional performance for long stroke position
  measurement up to 3 m
• Operation is based on accurately measuring the
  distance from a predetermined point to a magnetic
  field produced by a movable permanent magnet.
• Repeatability up to 0.002 of the measurement
  range.
• Resolution up to 0.002 of full scale range (FSR)
• Relatively low frequency bandwidth (-3dB at 100
  Hz)
• Very expensive
• Operating temperature 0 70 C

Photo courtesy of Schaevitz
25
Displacement Sensing

• Differential Variable Reluctance Transducers
• Relatively short stroke
• High resolution
• Non-contact between the measured object and
  sensor

Courtesy of Microstrain, Inc.
26
Velocity Sensing

• Scanning Laser Vibrometry
• No physical contact with the test object
  facilitate remote, mass-loading-free vibration
  measurements on targets
• measuring velocity (translational or angular)
• automated scanning measurements with fast
  scanning speed
• However, very expensive ( 120K)

27
Laser Vibrometry

• References
• Structural health monitoring using scanning laser
  vibrometry, by L. Mallet, Smart Materials
  Structures, vol. 13, 2004, pg. 261
• the technical note entitled Principle of
  Vibrometry from Polytec

28
Shock (high-G) Sensing

• Shock Pressure Sensor
• Measurement range up to 69 MPa (10 ksi)
• High response speed (rise time
• High frequency bandwidth (resonant frequency up
  to 500 kHz)
• Operating temperature -70 to 130 C
• Light (typically weighs 10 g)
• Shock Accelerometer
• Measurement range up to /- 70,000 g
• Frequency bandwidth typically from 0.5 30 kHz
  at -3 dB
• Operating temperature -40 to 80 C
• Light (weighs 5 g)

Photo courtesy of PCB Piezotronics
29
Angular Motion Sensing (Tilt Meter)

• Inertial Gyroscope (e.g., http//www.xbow.com)
• used to measure angular rates and X, Y, and Z
  acceleration.
• Tilt Sensor/Inclinometer (e.g.,
  http//www.microstrain.com)
• Tilt sensors and inclinometers generate an
  artificial horizon and measure angular tilt with
  respect to this horizon.
• Rotary Position Sensor (e.g., http//www.msiusa.co
  m)
• includes potentiometers and a variety of magnetic
  and capacitive technologies. Sensors are designed
  for angular displacement less than one turn or
  for multi-turn displacement.

Photo courtesy of MSI and Crossbow
30
MEMS Technology

• What is MEMS?
• Acronym for Microelectromechanical Systems
• MEMS is the name given to the practice of making
  and combining miniaturized mechanical and
  electrical components. K. Gabriel, SciAm,
  Sept 1995.
• Synonym to
• Micromachines (in Japan)
• Microsystems technology (in Europe)
• Leverage on existing IC-based fabrication
  techniques (but now extend to other non IC
  techniques)
• Potential for low cost through batch fabrication
• Thousands of MEMS devices (scale from 0.2 ?m
  to 1 mm) could be made simultaneously on a single
  silicon wafer

31
MEMS Technology

• Co-location of sensing, computing, actuating,
  control, communication power on a small
  chip-size device
• High spatial functionality and fast response
  speed
• Very high precision in manufacture
• miniaturized components improve response speed
  and reduce power consumption

32
MEMS Fabrication Technique
Courtesy of A.P. Pisano, DARPA
33
Distinctive Features of MEMS Devices

• Miniaturization
• micromachines (sensors and actuators) can handle
  microobjects and move freely in small spaces
• Multiplicity
• cooperative work from many small micromachines
  may be best way to perform a large task
• inexpensive to make many machines in parallel
• Microelectronics
• integrate microelectronic control devices with
  sensors and actuators

Fujita, Proc. IEEE, Vol. 86, No 8
34
MEMS Accelerometer

• Capacitive MEMS accelerometer
• High precision dual axis accelerometer with
  signal conditioned voltage outputs, all on a
  single monolithic IC
• Sensitivity from 20 to 1000 mV/g
• High accuracy
• High temperature stability
• Low power (less than 700 uA typical)
• 5 mm x 5 mm x 2 mm LCC package
• Low cost (5 14/pc. in Yr. 2004)

Courtesy of Analog Devices, Inc.
35
MEMS Accelerometer

• Piezoresistive MEMS accelerometer
• Operating Principle a proof mass attached to a
  silicon housing through a short flexural element.
  The implantation of a piezoresistive material on
  the upper surface of the flexural element. The
  strain experienced by a piezoresistive material
  causes a position change of its internal atoms,
  resulting in the change of its electrical
  resistance
• low-noise property at high frequencies

Courtesy of JP Lynch, U Mich.
36
MEMS Dust

• MEMS dust here has the same scale as a single
  dandelion seed - something so small and light
  that it literally floats in the air.

Source Distributed MEMS New Challenges for
Computation, by A.A. BERLIN and K.J. GABRIEL,
IEEE Comp. Sci. Eng., 1997
37
Sensing System

• Reference
• Zhang, R. and Aktan, E., Design consideration
  for sensing systems to ensure data quality,
  Sensing issues in Civil Structural Health
  Monitoring, Eded by Ansari, F., Springer, 2005,
  P281-290
