Vessel Stability

1
Vessel Stability

• Dan Hardin
• Commercial Fishing Industry Vessel Safety
  Coordinator
• U. S. Coast Guard
• Marine Safety Office, Seattle WA

2
Vessel Sinking

• Oct 1, 1998 - 36 crabber.
• Working south of Point Roberts.
• Generator stops while 2 crew recover pots.
• Owner stated he saw water in the E/R.
• Before being able to do anything the vessel
  sinks.
• 2 POB were picked up by nearby fishing vessel.

3
Vessel Sinking

• Oct 1, 1998 - 28 crabber.
• Working south of Point Roberts (within 1 hour of
  first vessel).
• Vessel heels to stbd, crab pots on deck shift,
  before vessel can recover, vessels rolls to stbd
  and sinks.
• 2 POB were picked up by nearby fishing vessel.

4
Vessel Sinking

• 30 Oct 97, 58 Seiner coming into Bellingham
  Bay.
• 4 persons on board (2 deceased/2 missing).
• F/O Tanks near empty, vessel to go in to DDX.
• Fish hold partially full of fish/ice slurry.
• Towing a seine skiff, up close on aft deck, tied
  off low on deck and attached to boom up high.
• Oversize drum for vessel/house mods extended.

5
Bellingham Seiner
6
Overview

• Watertight Integrity
• Vessel Subdivision
• Vessel Loading
• Intact Stability
• Damage Control

7
Stability

• The ability of a vessel to return to the upright
  position after being heeled by an external force.

8
Heel
9
Heel
10
Heel
11
Heel
12
Heel
13
Heel
14
Heel
15
Why boats float

• The weight of a boat
• equals
• the weight of water it displaces

16
Why boats float

• The weight of a boat
• equals
• the weight of water it displaces

17
Why boats float

• The weight of a boat
• equals
• the weight of water it displaces

18
Buoyancy
19
Buoyancy
20
Buoyancy
21
Buoyancy
22
Buoyancy
23
Buoyancy
24
Buoyancy
25
Buoyancy
26
Buoyancy
27
Buoyancy
28
Buoyancy
29
Buoyancy
30
Maintaining Watertight Integrity

• Goal To provide the vessel with a proven means
  to minimize the effects of flooding.

Page 5
31
Maintaining Watertight Integrity Vessel Hull
32
Bulkhead deck
The uppermost deck to which watertight bulkheads
extend, commonly the main deck.
Page 5
33
Watertight Hatches Doors

• Watertight closures prevent water from entering
  the watertight enclosure of the hull.
• Water is extra weight reducing vessel freeboard
  and increasing free surface effect dangers.

Page 7
34
Watertight Hatches Doors

• Know the location of all watertight closures.
• Inspect all watertight closures for condition.

Page 7
35
Watertight Hatches Doors

• Inspect the operation of dogs, gaskets and
  sealing surfaces.

Page 7
36
Watertight Hatches Doors

• Closures should be closed and dogged while
  underway unless actually in use, to prevent
  downflooding.

Page 7
37
Watertight Hatches Doors

• Dont allow cargo or deck gear to block
  weathertight closures or any other doorway

Page 7
38
Watertight Hatches Doors

• Dont paint gaskets.
• Inspect to ensure gaskets remain in serviceable
  condition.
• Inspect and grease dogs regularly.

Page 7
39
Watertight Hatches Doors

• Always keep portlights closed and deadlight
  covers secured when at sea.

Page 7
40
Downflooding
41
Downflooding
42
Downflooding
43
Downflooding
44
Downflooding
45
Downflooding
46
Downflooding
47
Downflooding
48
Downflooding
49
Downflooding
50
Downflooding
51
Recommend Practices

• Watertight condition of the deck, house and side
  shell must be maintained.
• Discharge piping penetrating the hull should be
  fitted with check and positively closing valves
• Inlet piping should be fitted with positive
  closing valves located at the shell plating.
• Deckhouse openings should be fitted with
  weathertight doors.

Page 6
52
Recommended Practices

• Doors should be steel or equivalent material
  permanently attached to the bulkhead
• Weathertight doors should open outward and be
  fitted with a minimum or two dogging devices in
  addition to hinges.
• All emergency doors should be quick acting.
• Propulsion machinery spaces above the bulkhead
  deck should be watertight.

Page 6
53
Maintaining Watertight Integrity Vessel
Subdivision
54
Subdivision
Watertight transverse bulkheads up to bulkhead
deck down to the keel
Page 5
55
Subdivision
56
Subdivision
57
Subdivision
58
Subdivision
59
Recommend Practices

• Vessel should be subdivided with collision
  bulkhead and watertight bulkheads.
• Collision bulkhead be stepless and intact up to
  the bulkhead deck. (No doors/scuttles)
• Penetrations shall include valves operable from
  aft of the collision bulkhead and above the
  bulkhead deck.
• All pipe penetrations shall be as far inboard and
  high as practicable
• Minimize the number of pipe penetrations.

Page 8
60
Recommend Practices

• Ensure watertight bulkheads watertight.
• Machinery spaces should be enclosed by W/T
  bulkheads (Engine room, auxiliary equipment).
• W/T bulkheads with openings should be quick
  acting W/T doors and should always be kept
  closed.
• Watertight doors should open outward from the
  machinery space.

Page 5-6
61
Vessel Loading
Freeing ports
Deck
Freeboard
Draft
Page 9
62
Vessel Loading
Adding weight reduces freeboard and
reduces reserve buoyancy
Page 9
63
Vessel Loading
Reserve buoyancy lost
Page 9
64
Vessel Loading
Reserve buoyancy
Page 9
65
Vessel Loading
Reserve buoyancy lost
Page 9
66
Vessel Loading
Reserve buoyancy lost
Page 9
67
Recommended Practices

• Keep weight low in the vessel.
• Avoid adding weight above the main deck.
• Secure gear and catch to prevent loads from
  shifting.
• Limit duration of side lifting operations.
• Minimize number of partially filled tanks.
• Do not overload.
• Keep freeing ports clear.

Page 9
68
Stability
69
Center of Buoyancy
B
Page 10
70
Center of Buoyancy
The point through which the force of buoyancy
acts vertically upwards (B)
B
Page 10
71
Center of Gravity
Center of Gravity (G) is a downward force
G
B
Page 10
72
Center of Gravity
(G) rises and falls when weights are
moved, added, and/or removed.
Fish
G
B
Page 10
73
Center of Gravity
G
B
Fish
Page 10
74
Metacenter
G
B
Page 11
75
Metacenter
Can be considered as being the pivot point when
the vessel is being inclined.
M
G
B
Page 11
76
Metacenter
Page 11
77
Metacenter
Page 11
78
Metacenter
Page 11
79
Metacenter
Page 11
80
Metacenter
Page 11
81
Metacenter
Page 11
82
Roll PeriodShorter Roll Period
Stable
M
G
B
The distance between G and M referred to as GM is
the Metacentric Height
This vessel has positive GM
Page 11
83
Roll PeriodLonger Roll Period
Unstable
G
M
B
This vessel has negative GM
Page 11
84
Uncontrolled Weight Movements
M
G
Page 12
85
Uncontrolled Weight Movements
M
G
Page 12
86
Free Surface Effect
M
G
Page 13
87
Free Surface Effect
M
G
Page 13
88
Free Surface Effect
M
G
89
Unsecured Loads
Live Tank
M
G
B
90
Unsecured Loads
Live Tank
M
G
B
91
Recommended Practices

• Limit free surface effect by minimizing the width
  of tanks and the number of partially filled
  tanks.
• Install bin boards in center of wide fish holds.
• Secure all loads.
• Devise a system to secure each item like crab
  pots while loading or off loading.

92
Maintaining Intact StabilityGoal To maintain
intact stability of your vessel at all times of
operation

• Adequate intact stability
• Established when the vessel is built and
  initially outfitted for operation.
• When the vessel at rest possesses characteristics
  of the stable condition.
• Intact stability is considered to be adequate if
  GM is 2.
• Older vessels designed with GM 1.6 to 2. Check
  with a marine architect.

Page 13
93
Recommended Practices

• Ensure vessel maintains adequate intact stability
  prior to getting underway, will be a tremendous
  benefit when vessel is exposed to forces of
  fishing and the sea.
• Have vessel stability evaluated by a qualified
  individual.

Page 13
94
Important Factors Affecting Vessel Stability
M
G
B
Page 14
95
Important Factors Affecting Vessel Stability
M
G
B
Load Height
Page 14
96
Recommended Practices

• Minimize the height of traps or pots on deck.
• Ice can collect on traps increasing Center of
  Gravity.

Page 14
97
Important Factors Affecting Vessel Stability
Live Tank
M
G
B
Live Tanks on Deck
Page 14
98
Recommended Practices

• Minimize the width and the number of live tanks.

Page 14
99
Important Factors Affecting Vessel Stability
Live Tank
M
G
B
Suspended Weight
Page 15
100
Important Factors Affecting Vessel Stability
Live Tank
M
G
B
Page 15
101
Important Factors Affecting Vessel Stability
Live Tank
M
G
B
Vessel slips out from beneath weight
Page 15
102
Important Factors Affecting Vessel Stability
Live Tank
M
G
B
Restrain load to prevent vessel slip
Page 15
103
Recommended Practices

• Minimize the duration of these operations.
• Exercise extreme caution when lifting over the
  side or quarters as change in center of gravity
  is even more significant.
• Ensure to prevent the suspended weight from
  swinging to mitigate adverse effects.

Page 15
104
Important Factors Affecting Vessel Stability
High Tow Points
Page 16
105
Recommended Practices

• After deploying, shift the towing point to a
  lower location.
• Maintain the tow on the longitudinal center line
  of the vessel (directly behind the vessel).
• Avoid towing off the quarter or beam.

Page 16
106
Damage Control
107
Hull Breaches
Page 18
108
Chafed Hose
Page 19
109
Chafed Hose
Page 19
110
Chafed Hose
Page 19
111
Damaged Through Hull Fitting
Page 20
112
Damage Control Kit
Page 22
113
Summary
114
Vessel Sinking

• Oct 1, 1998 - 36 crabber.
• Working south of Point Roberts.
• Generator stops while 2 crew recover pots.
• Owner stated he saw water in the E/R.
• Before being able to do anything the vessel
  sinks.
• 2 POB were picked up by nearby fishing vessel.

115
Vessel Sinking

• Oct 1, 1998 - 28 crabber.
• Working south of Point Roberts (within 1 hour of
  first vessel).
• Vessel heels to stbd, crab pots on deck shift,
  before vessel can recover, vessels rolls to stbd
  and sinks.
• 2 POB were picked up by nearby fishing vessel.

116
Vessel Sinking

• Oct 97, 58 Seiner coming into Bellingham Bay.
• 4 persons on board (2 deceased/2 missing).
• F/O Tanks near empty, vessel to go in to DDX.
• Fish hold partially full of fish/ice slurry.
• Towing a seiner skiff, up close on aft deck, tied
  off low on deck and attached to boom up high.
• Oversize drum for vessel/house mods extended.

117
Bellingham Seiner
118
THE END
